OldCodger

I have created a snapshot of the issue. Should you want to view it... Save the attached files to a folder Rename the .doc file to .swf Rename the .docx file to .js run the .htm for the snapshot I can't attach swf or js files, I understand why.. but if you know what you are doing as far as protection is concerned you can see what happens sometimes. ListviewDrag.htm ListviewDrag.doc ListviewDrag.docx

No, it's the sample code you delivered, I haven't changed anything yet and wouldn't modify my application until the code was ratified. Yeah I know, it's a nice to have, not imperative. Cheers.. Glenn.

I've only tried single drag so far.. it's random.. no patterns to the error at all. Also, the drop is sometimes above, sometimes below the cursor item. I have to go now, so I'll let your genius flow. See you tomorrow.

Thanks M23.. It works(mostly).. Intermittently, it removes all target items and puts a numeric in row1-column1 eg '13'

Ok.. this is the cut down version. #include <GUIConstantsEx.au3> #include <WindowsConstants.au3> #include <EditConstants.au3> #include <StaticConstants.au3> #include <StringConstants.au3> #include <GUIListView.au3> #include <GUIImageList.au3> ;Dim Globals Global $blDragging = False, $hDragImage = 0, $hLwDragFrom = 0, $sInputSeason = "", $sInput17WS = "" #region GUI Global $hGUI = GUICreate("Test Listview drag", 900, 535) ;Input the target season code GUICtrlCreateLabel("Season", 40, 430, 80, 20, $SS_CENTER) GUICtrlSetFont(-1, 10, 800) Global $iInputSeason = GUICtrlCreateInput("", 40, 450, 80, 20) ;Input Target item description GUICtrlCreateLabel("Desc.", 130, 430, 80, 20, $SS_CENTER) GUICtrlSetFont(-1, 10, 800) Global $iInput17WS = GUICtrlCreateInput("", 130, 450, 80, 20) ;Define Source listview to recieve search results - 3 columns GUICtrlCreateLabel("Source", 10, 105, 250, 20, $SS_CENTER) GUICtrlSetFont(-1, 10, 800) Global $iLwSource = GUICtrlCreateListView("Director|Manager|Buyer", 10, 125, 250, 300, BitOR($LVS_REPORT, $LVS_SHOWSELALWAYS)) Global $hLwSource = GUICtrlGetHandle($iLwSource) For $i = 0 To 2 _GUICtrlListView_SetColumnWidth($hLwSource, $i, 75) Next For $i = 0 To 16 $item = _GUICtrlListView_AddItem($iLwSource, _makeJunkName()) _GUICtrlListView_AddSubItem($iLwSource, $item, _makeJunkName(), 1) _GUICtrlListView_AddSubItem($iLwSource, $item, _makeJunkName(), 2) Next ;Define Target listview to recieve segment selections - 5 columns GUICtrlCreateLabel("Target", 400, 10, 300, 20, $SS_CENTER) GUICtrlSetFont(-1, 10, 800) Global $iLwTarget = GUICtrlCreateListView("Season|Director|Manager|Buyer|Description", 330, 30, 480, 395) Global $hLwTarget = GUICtrlGetHandle($iLwTarget) _GUICtrlListView_SetExtendedListViewStyle($hLwTarget, $LVS_EX_GRIDLINES) For $i = 0 To 4 _GUICtrlListView_SetColumnWidth($hLwTarget, $i, 92) Next For $i = 0 To 16 $item = _GUICtrlListView_AddItem($iLwTarget, _makeJunkName()) _GUICtrlListView_AddSubItem($iLwTarget, $item, _makeJunkName(), 1) _GUICtrlListView_AddSubItem($iLwTarget, $item, _makeJunkName(), 2) _GUICtrlListView_AddSubItem($iLwTarget, $item, _makeJunkName(), 3) _GUICtrlListView_AddSubItem($iLwTarget, $item, _makeJunkName(), 4) Next GUIRegisterMsg($WM_NOTIFY, "WM_NOTIFY") GUIRegisterMsg($WM_LBUTTONUP, "WM_LBUTTONUP") GUISetState(@SW_SHOW, $hGUI) #endregion GUI ;Main control loop While 1 Sleep(10) Switch GUIGetMsg() Case $GUI_EVENT_CLOSE ExitLoop EndSwitch WEnd GUIDelete($hGUI) ; Create a junk name for testing Func _makeJunkName() Local $labelout = '' For $i = 1 To 10 $labelout &= Chr(Random(65, 90, 1)) Next Return $labelout EndFunc ;==>_makeJunkName Func WM_NOTIFY($hWnd, $iMsg, $iwParam, $ilParam) #forceref $hWnd, $iMsg, $iwParam, $ilParam Local $tNMHDR = 0, $hWndFrom = 0, $iIDFrom = 0, $iCode = 0 $tNMHDR = DllStructCreate($tagNMHDR, $ilParam) $hWndFrom = HWnd(DllStructGetData($tNMHDR, "hWndFrom")) $iIDFrom = DllStructGetData($tNMHDR, "IDFrom") $iCode = DllStructGetData($tNMHDR, "Code") Switch $iIDFrom Case $iLwSource Switch $iCode Case $LVN_BEGINDRAG Local $tInfo = DllStructCreate($tagNMLISTVIEW, $ilParam) Local $iItem = DllStructGetData($tInfo, "Item") Local $aImageData = _GUICtrlListView_CreateDragImage($hWndFrom, $iItem) $hDragImage = $aImageData[0] _GUIImageList_BeginDrag($hDragImage, 0, -7, 3) $hLwDragFrom = $hWndFrom $blDragging = True EndSwitch EndSwitch Return $GUI_RUNDEFMSG EndFunc ;==>WM_NOTIFY Func WM_LBUTTONUP($hWnd, $iMsg, $iwParam, $ilParam) #forceref $hWnd, $iMsg, $iwParam, $ilParam If Not $blDragging Then Return $GUI_RUNDEFMSG _GUIImageList_DragLeave($hLwDragFrom) _GUIImageList_EndDrag() _GUIImageList_Destroy($hDragImage) Local $sInputSeason = GUICtrlRead($iInputSeason) Local $sInput17WS = GUICtrlRead($iInput17WS) Local $aNewCInfo = GUIGetCursorInfo($hGUI) ConsoleWrite("season = " & $sInputSeason & @CRLF) ConsoleWrite("desc = " & $sInput17WS & @CRLF) ConsoleWrite("dragging from " & $hLwDragFrom & @CRLF) ConsoleWrite("hwnd = " & $hLwSource & @CRLF) ConsoleWrite("CInfo = " & $aNewCInfo[4] & @CRLF) ConsoleWrite("Target = " & $hLwTarget & @CRLF) ; If we are moving from source to target and we ARE in target box If $hLwDragFrom = $hLwSource And $aNewCInfo[4] = $iLwTarget AND($sInputSeason <> "" AND $sInput17WS <> "") Then ;################################################################# ;#Add season to the start and Description to end and then drag to cursor row on the target... ;################################################################ _GUICtrlListView_CopyItems($hLwSource, $hLwTarget, 1) EndIf $blDragging = False Return $GUI_RUNDEFMSG EndFunc ;==>WM_LBUTTONUP Thanks.. Edit: Corrected error in code.

I have had a play with that udf and although it's a peach, Melba(he he).. I can't suss how to use it for my issues. I am learning AutoIT(slowly) but some things do me tree in.

Morning.. I have searched the forums high and low and can't find an answer to my issue. I have two list views: The source has 3 columns and the target has 5 columns. I would like the capability to drag an item from source to target(which is easy) but modify the source item by adding a value to the start of the item and a value to the end of the item so it marries with the target listview columns... ..also the dropped modified item should be inserted at a row where the cursor is released in the target. Any ideas? Thanks.

Someone could have told me though.. would have saved me days. Thanks for your help FF.

After days of f'ing about with arrays I finally solved it with a simple function. Func _Dupes() Local $iSeg, $iPvw ;Get the segment 'buyer' value For $k = 0 To _GUICtrlListView_GetItemCount($hLwSegments) - 1 $iSeg = _GUICtrlListView_GetItemText($hLwSegments, $k, 2) ;Get the preview 'buyer' value For $m = 0 To _GUICtrlListView_GetItemCount($hLwPreview) - 1 $iPvw = _GUICtrlListView_GetItemText($hLwPreview, $m, 3) If $iPvw == $iSeg Then ConsoleWrite("Duplicate found = " & $iPvw & @CRLF) $cRetval = 1 EndIf Next Next Return $cRetval EndFunc ;==>_Dupes

Yeah, I looked at that before but it's different to the requirement as I need to inform the user before the row is added to preview so they can amend segment. Don't worry, I understand that you can't keep on coding for me.. I'll just keep trying. Take care.

No problem.. thanks.

Ok.. Thanks again FF for the code. I have made some enhancements(whether they are coded correctly or optimally is another thing). Created addition preview/output columns Added output file name input requirement Allowed multiple search criteria Annotated the controls One of the requirements I'm having difficulty with is preventing duplicate rows from being input to the preview. I've tried all sorts of listview to array examples from the forums to achieve this but am getting nowhere. Basically, when the commit button is clicked there should be a check to see if a row in the Segments list view already exists in the Preview list view and if there is the commit is stopped and the user informed of the offending row so they can do something. Current code: #include <GUIConstantsEx.au3> #include <WindowsConstants.au3> #include <EditConstants.au3> #include <StaticConstants.au3> #include <StringConstants.au3> #include <GUIListView.au3> #include <GUIImageList.au3> ;Dim Globals Global $blDragging = False, $hDragImage = 0, $hLwDragFrom = 0, $sInputSeason = "", $sInput17WS = "" Global $aKalRecs = 0, $sPreviewData = "" #region GUI Global $hGUI = GUICreate("Kaleidoscope Segment Builder", 1020, 535) GUICtrlSetDefColor(0x0043737) GUICtrlCreateGroup("File Search... (Multiple search items must be seperated by comma)", 10, 10, 510, 80) GUICtrlSetFont(-1, 10, 800) GUICtrlCreateLabel("Director Code", 20, 37, Default, 15) Global $iInputDirectorCode = GUICtrlCreateInput("", 100, 33, 40, 20, $ES_AUTOHSCROLL) GUICtrlCreateLabel("Manager Code", 180, 37, Default, 15) Global $iInputManagerCode = GUICtrlCreateInput("", 265, 33, 40, 20, $ES_AUTOHSCROLL) GUICtrlCreateLabel("Buyer Code", 345, 37, Default, 15) Global $iInputBuyerCode = GUICtrlCreateInput("", 415, 33, 40, 20, $ES_AUTOHSCROLL) GUICtrlCreateLabel('* in Director Code = List all Items', 20, 65, 280, 20) GUICtrlSetFont(-1, 8, 600, 0, "Verdana", 2) ;Define Source listview to recieve search results - 3 columns GUICtrlCreateLabel("Source Items", 10, 105, 250, 20, $SS_CENTER) GUICtrlSetFont(-1, 10, 800) Global $iLwSource = GUICtrlCreateListView("Director|Manager|Buyer", 10, 125, 250, 300, BitOR($LVS_REPORT, $LVS_SHOWSELALWAYS)) Global $hLwSource = GUICtrlGetHandle($iLwSource) For $i = 0 To 2 _GUICtrlListView_SetColumnWidth($hLwSource, $i, 75) Next ;Define Segment listview to recieve segment selections - 3 columns GUICtrlCreateLabel("Segment Items", 270, 105, 250, 20, $SS_CENTER) GUICtrlSetFont(-1, 10, 800) Global $iLwSegments = GUICtrlCreateListView("Director|Manager|Buyer", 270, 125, 250, 300, BitOR($LVS_REPORT, $LVS_SHOWSELALWAYS)) Global $hLwSegments = GUICtrlGetHandle($iLwSegments) For $i = 0 To 2 _GUICtrlListView_SetColumnWidth($hLwSegments, $i, 75) Next ;Input the season code GUICtrlCreateLabel("Season", 270, 430, 80, 20, $SS_CENTER) GUICtrlSetFont(-1, 10, 800) Global $iInputSeason = GUICtrlCreateInput("", 270, 450, 80, 20) ;Input segment description GUICtrlCreateLabel("Desc.", 360, 430, 80, 20, $SS_CENTER) GUICtrlSetFont(-1, 10, 800) Global $iInput17WS = GUICtrlCreateInput("", 360, 450, 80, 20) ;Output File name GUICtrlCreateLabel("Output File", 600, 430, 80, 20, $SS_CENTER) GUICtrlSetFont(-1, 10, 800) Global $iOutputFname = GUICtrlCreateInput("", 600, 450, 130, 20) ;Define the commit button - disable until season and segment description is entered. Global $iBtnCommit = GUICtrlCreateButton("Commit...", 451, 448, 70, 25) GUICtrlSetState($iBtnCommit, $GUI_DISABLE) GUICtrlCreateLabel("Use the left/right arrows to add or remove items from the lists.", 10, 490, 510, 20) GUICtrlSetFont(-1, 10, 800) GUICtrlCreateLabel("Preview", 600, 10, 300, 20, $SS_CENTER) GUICtrlSetFont(-1, 10, 800) ;Define Preview listview to recieve segment selections - 5 columns Global $iLwPreview = GUICtrlCreateListView("Season|Director|Manager|Buyer|Description", 530, 30, 480, 395) Global $hLwPreview = GUICtrlGetHandle($iLwPreview) For $i = 0 To 4 _GUICtrlListView_SetColumnWidth($hLwPreview, $i, 92) Next ;Define the submit to csv button. Local $iBtnSubmit = GUICtrlCreateButton("Submit...", 751, 448, 80, 25) GUICtrlSetState($iBtnSubmit, $GUI_DISABLE) GUIRegisterMsg($WM_COMMAND, "WM_COMMAND") GUIRegisterMsg($WM_NOTIFY, "WM_NOTIFY") GUIRegisterMsg($WM_LBUTTONUP, "WM_LBUTTONUP") ;Call array load _LoadDb() ;Create dummy controls to enable hotkey detection $iDyLeft = GUICtrlCreateDummy() $iDyRight = GUICtrlCreateDummy() ;Hotkey definition enabling left/right arrow use for moving items between listviews Local $aHotkey[2][2] = [["{LEFT}", $iDyLeft],["{RIGHT}", $iDyRight]] GUISetAccelerators($aHotkey) GUISetState(@SW_SHOW, $hGUI) #endregion GUI ;Main control loop While 1 Sleep(10) Switch GUIGetMsg() Case $GUI_EVENT_CLOSE ExitLoop Case $iBtnCommit _Commit() Case $iBtnSubmit _Submit() Case $iDyLeft _MoveFromSegmentsToSource() Case $iDyRight _MoveFromSourceToSegments() EndSwitch WEnd GUIDelete($hGUI) ;The commit function takes all entries in the segment listview and the ;annotations in the input boxes and populates(appends) to the preview listview Func _Commit() _GUICtrlListView_BeginUpdate($hLwPreview) Local $aData = 0, $sData = "" For $i = 0 To _GUICtrlListView_GetItemCount($hLwSegments) - 1 $aData = _GUICtrlListView_GetItemTextArray($hLwSegments, $i) ;_ArrayDisplay($aData) $sPreviewData &= $sInputSeason & "," & $aData[1] & "," & $aData[2] & "," & $aData[3] & "," & $sInput17WS & @CRLF GUICtrlCreateListViewItem($sInputSeason & "|" & _ArrayToString($aData, "|", 1) & "|" & $sInput17WS, $iLwPreview) Next GUICtrlCreateListViewItem("----------------|----------------|----------------|----------------|---------------- ", $iLwPreview) ;MsgBox(4096,"wibble",$sPreviewData) _GUICtrlListView_EndUpdate($hLwPreview) _GUICtrlListView_DeleteAllItems($hLwSegments) ;Clear description for next segment GUICtrlSetData($iInput17WS, "") ;Initialise output description var $sInput17WS = "" EndFunc ;==>_Commit ;The submit function takes all entries in the preview listview and creates a save dialog to create the output file. Func _Submit() Local $cColtitle = GUICtrlRead($iOutputFname) $cColtitle = "" & $cColtitle & "" Local $sPath = FileSaveDialog("save", "", "CSV file (*.csv)", BitOR($FD_PATHMUSTEXIST, $FD_PROMPTOVERWRITE), $cColtitle) If @error Then Return 0 If StringRight($sPath, 4) <> ".csv" Then $sPath &= ".csv" Local $hFile = FileOpen($sPath, $FO_OVERWRITE) FileWrite($hFile, "SEASON,DIRECTOR_CODE,MERCH_MANAGER_CODE,BUYER_CODE," & $cColtitle & @CRLF & $sPreviewData) FileClose($hFile) $sPreviewData = "" _GUICtrlListView_DeleteAllItems($hLwPreview) GUICtrlSetData($iInputSeason, "") GUICtrlSetData($iOutputFname, "") EndFunc ;==>_Submit ;Array load function from current csv version Func _LoadDb() Local $sData = FileRead(@ScriptDir & "\Dir_man_Buyer.csv") If @error Then Exit 1 Local $aBase = StringSplit($sData, @CRLF, BitOR($STR_ENTIRESPLIT, $STR_NOCOUNT)) ;-2/-3 for the UBound because the first line is a header and the last line is empty Global $aKalRecs[UBound($aBase) - 2][3] Local $aTmp = 0 For $i = 0 To UBound($aBase) - 3 $aTmp = StringSplit($aBase[$i + 1], ",", BitOR($STR_ENTIRESPLIT, $STR_NOCOUNT)) $aKalRecs[$i][0] = $aTmp[0] $aKalRecs[$i][1] = $aTmp[1] $aKalRecs[$i][2] = $aTmp[2] Next EndFunc ;==>_LoadDb ;Move the selected items from source to segment Func _MoveFromSourceToSegments() Local $sSelectedItem = _GUICtrlListView_GetSelectedIndices($hLwSource) If $sSelectedItem = "" Then Return 0 Local $aSelectedItem = StringSplit($sSelectedItem, "|") _GUICtrlListView_BeginUpdate($hLwSource) _GUICtrlListView_BeginUpdate($hLwSegments) For $i = 1 To $aSelectedItem[0] GUICtrlCreateListViewItem(_GUICtrlListView_GetItemTextString($hLwSource, Number($aSelectedItem[$i]) - ($i - 1)), $iLwSegments) _GUICtrlListView_DeleteItem($hLwSource, Number($aSelectedItem[$i]) - ($i - 1)) Next _GUICtrlListView_EndUpdate($hLwSegments) _GUICtrlListView_EndUpdate($hLwSource) EndFunc ;==>_MoveFromSourceToSegments Func _Dupes($aSels) EndFunc ;==>_Dupes ;Move the selected items from segment to source Func _MoveFromSegmentsToSource() Local $sSelectedItem = _GUICtrlListView_GetSelectedIndices($hLwSegments) If $sSelectedItem = "" Then Return 0 Local $aSelectedItem = StringSplit($sSelectedItem, "|") _GUICtrlListView_BeginUpdate($hLwSegments) _GUICtrlListView_BeginUpdate($hLwSource) For $i = 1 To $aSelectedItem[0] GUICtrlCreateListViewItem(_GUICtrlListView_GetItemTextString($hLwSegments, Number($aSelectedItem[$i]) - ($i - 1)), $iLwSource) _GUICtrlListView_DeleteItem($hLwSegments, Number($aSelectedItem[$i]) - ($i - 1)) Next _GUICtrlListView_EndUpdate($hLwSource) _GUICtrlListView_EndUpdate($hLwSegments) EndFunc ;==>_MoveFromSegmentsToSource ;Receive a message from an input and populate source listview with search results Func WM_COMMAND($hWnd, $iMsg, $iwParam, $ilParam) Local $iIDFrom = 0, $iCode = 0 $iIDFrom = BitAND($iwParam, 0xFFFF) $iCode = BitShift($iwParam, 16) Switch $iIDFrom Case $iInputDirectorCode Switch $iCode Case $EN_UPDATE GUICtrlSetData($iInputManagerCode, "") GUICtrlSetData($iInputBuyerCode, "") _GUICtrlListView_BeginUpdate($hLwSource) _GUICtrlListView_DeleteAllItems($hLwSource) Local $sInput = GUICtrlRead($iInputDirectorCode) Local $aInput = StringSplit($sInput, ",", 0) For $j = 1 to $aInput[0] If StringRegExp($aInput[$j], "^([A-Za-z]|\*)$") = 1 Then _ArraySort($aKalRecs, 0, 0, 0, 0) If $sInput = "*" Then For $i = 0 To UBound($aKalRecs) - 1 GUICtrlCreateListViewItem($aKalRecs[$i][0] & "|" & $aKalRecs[$i][1] & "|" & $aKalRecs[$i][2], $iLwSource) Next Else For $i = 0 To UBound($aKalRecs) - 1 If $aInput[$j] <> StringStripWS($aKalRecs[$i][0], $STR_STRIPTRAILING) Then ContinueLoop GUICtrlCreateListViewItem($aKalRecs[$i][0] & "|" & $aKalRecs[$i][1] & "|" & $aKalRecs[$i][2], $iLwSource) Next EndIf EndIf Next _GUICtrlListView_EndUpdate($hLwSource) EndSwitch Case $iInputManagerCode Switch $iCode Case $EN_UPDATE GUICtrlSetData($iInputDirectorCode, "") GUICtrlSetData($iInputBuyerCode, "") _GUICtrlListView_BeginUpdate($hLwSource) _GUICtrlListView_DeleteAllItems($hLwSource) Local $sInput = GUICtrlRead($iInputManagerCode) Local $aInput = StringSplit($sInput, ",", 0) For $j = 1 to $aInput[0] If StringRegExp($aInput[$j], "^\d+$") = 1 Then _ArraySort($aKalRecs, 0, 0, 0, 1) For $i = 0 To UBound($aKalRecs) - 1 If $aInput[$j] <> $aKalRecs[$i][1] Then ContinueLoop GUICtrlCreateListViewItem($aKalRecs[$i][0] & "|" & $aKalRecs[$i][1] & "|" & $aKalRecs[$i][2], $iLwSource) Next EndIf Next _GUICtrlListView_EndUpdate($hLwSource) EndSwitch Case $iInputBuyerCode Switch $iCode Case $EN_UPDATE GUICtrlSetData($iInputDirectorCode, "") GUICtrlSetData($iInputManagerCode, "") _GUICtrlListView_BeginUpdate($hLwSource) _GUICtrlListView_DeleteAllItems($hLwSource) Local $sInput = GUICtrlRead($iInputBuyerCode) Local $aInput = StringSplit($sInput, ",", 0) For $j = 1 to $aInput[0] If StringRegExp($aInput[$j], "^[\dA-Za-z]+$") = 1 Then _ArraySort($aKalRecs, 0, 0, 0, 2) For $i = 0 To UBound($aKalRecs) - 1 If $aInput[$j] <> $aKalRecs[$i][2] Then ContinueLoop GUICtrlCreateListViewItem($aKalRecs[$i][0] & "|" & $aKalRecs[$i][1] & "|" & $aKalRecs[$i][2], $iLwSource) Next _GUICtrlListView_EndUpdate($hLwSource) EndIf Next EndSwitch Case $iInput17WS, $iInputSeason Switch $iCode Case $EN_UPDATE $sInputSeason = GUICtrlRead($iInputSeason) $sInput17WS = GUICtrlRead($iInput17WS) If $sInputSeason = "" Or $sInput17WS = "" Then GUICtrlSetState($iBtnCommit, $GUI_DISABLE) Else GUICtrlSetState($iBtnCommit, $GUI_ENABLE) EndIf EndSwitch Case $iOutputFname Switch $iCode Case $EN_UPDATE $sOutputFname = GUICtrlRead($iOutputFname) If $sOutputFname = "" Then GUICtrlSetState($iBtnSubmit, $GUI_DISABLE) Else GUICtrlSetState($iBtnSubmit, $GUI_ENABLE) EndIf EndSwitch EndSwitch Return $GUI_RUNDEFMSG EndFunc ;==>WM_COMMAND Func WM_NOTIFY($hWnd, $iMsg, $iwParam, $ilParam) #forceref $hWnd, $iMsg, $iwParam, $ilParam Local $tNMHDR = 0, $hWndFrom = 0, $iIDFrom = 0, $iCode = 0 $tNMHDR = DllStructCreate($tagNMHDR, $ilParam) $hWndFrom = HWnd(DllStructGetData($tNMHDR, "hWndFrom")) $iIDFrom = DllStructGetData($tNMHDR, "IDFrom") $iCode = DllStructGetData($tNMHDR, "Code") Switch $iIDFrom Case $iLwSource, $iLwPreview Switch $iCode Case $LVN_BEGINDRAG Local $tInfo = DllStructCreate($tagNMLISTVIEW, $ilParam) Local $iItem = DllStructGetData($tInfo, "Item") Local $aImageData = _GUICtrlListView_CreateDragImage($hWndFrom, $iItem) $hDragImage = $aImageData[0] _GUIImageList_BeginDrag($hDragImage, 0, -7, 3) $hLwDragFrom = $hWndFrom $blDragging = True EndSwitch EndSwitch Return $GUI_RUNDEFMSG EndFunc ;==>WM_NOTIFY Func WM_LBUTTONUP($hWnd, $iMsg, $iwParam, $ilParam) #forceref $hWnd, $iMsg, $iwParam, $ilParam If Not $blDragging Then Return $GUI_RUNDEFMSG _GUIImageList_DragLeave($hLwDragFrom) _GUIImageList_EndDrag() _GUIImageList_Destroy($hDragImage) ; Get new position Local $aNewCInfo = GUIGetCursorInfo($hGUI) ; If we were moving from source to destination and we ARE in the destination box If $hLwDragFrom = $hLwSource And $aNewCInfo[4] = $iLwSegments Then _GUICtrlListView_CopyItems($hLwSource, $hLwSegments, 1) EndIf ; If we are moving from destination to source and we ARE in source box If $hLwDragFrom = $hLwSegments And $aNewCInfo[4] = $iLwSource Then _GUICtrlListView_CopyItems($hLwSegments, $hLwSource, 1) EndIf $blDragging = False Return $GUI_RUNDEFMSG EndFunc ;==>WM_LBUTTONUP Regards

It's really good now FF.. There are some issues like the preview columns are not displaying in the correct order and there are some enhancements that I could do with but I'm gonna try them all myself. Don't worry, I'll be back to pester the community if when I bollax it up!

Thanks FF.. I'll have a play and see if I can break it

Morning FF Thanks for your time and knowledge on this. I downloaded the Beta but got and error saying the stringconstants couldn't be found (I did run in Scite using alt-f5.. honest ) I just copied the stringconstants to my user includes and ran under autoit. It's taking shape and looking good but I don't know what all the WM_ function stuff is about? A few things I note: The search works fine although it only accepts uppercase for the alpha inputs so I changed the code for that and I have aslo changed the array variable name for local requirement(see code 1). I need multi-select in the listviews else it could be a laborious process.(see code 2) The ability to drag selections between listviews would be of benefit.(see code 2) The segment build is good and works fine but when 'commited' I get spurious results in the preview.. eg. numerics in the director column, repeated values, sometimes no values. The preview should be appended to and only cleared on submit as it is the representation of x number of segments. Prior to a commit of a segment the user should annotate the segment using two input boxes somewhere near the segment listview and the text in box 1 added as an additional column at the beginning of the preview record and the text in box 2 added as an additional column at the end of the preview record eg. W13 | W | 38 | 0S7 | 17.Ladieswear (see sample output '17 way split.txt' attached). I need the ability to delete records from preview if the user has made an error. Sorry to cause you pain. Code 1 (Your code slightly ammended:) #include <GUIConstantsEx.au3> #include <WindowsConstants.au3> #include <EditConstants.au3> #include <StaticConstants.au3> #include "StringConstants.au3" #include <GUIListView.au3> Global $blGUIMinimized = False Global $aKalRecs = 0, $sPreviewData = "" #region GUI Global $hGUI = GUICreate("MyGUI", 840, 485) GUICtrlCreateGroup("Specify Director Code, Manager Code or Buyer Code", 10, 10, 510, 80) GUICtrlSetFont(-1, 10, 800) GUICtrlCreateLabel("Director Code", 20, 37, Default, 15) Global $iInputDirectorCode = GUICtrlCreateInput("", 100, 33, 40, 20, $ES_AUTOHSCROLL) GUICtrlCreateLabel("Manager Code", 180, 37, Default, 15) Global $iInputManagerCode = GUICtrlCreateInput("", 265, 33, 40, 20, $ES_AUTOHSCROLL) GUICtrlCreateLabel("Buyer Code", 345, 37, Default, 15) Global $iInputBuyerCode = GUICtrlCreateInput("", 415, 33, 40, 20, $ES_AUTOHSCROLL) GUICtrlCreateLabel('"*" in Director Code = List all entries', 20, 65, 240, 20) GUICtrlSetFont(-1, 10, 800) GUICtrlCreateLabel("Source Items", 10, 105, 250, 20, $SS_CENTER) GUICtrlSetFont(-1, 10, 800) Global $iLwSource = GUICtrlCreateListView("Director|Manager|Buyer", 10, 125, 250, 300) Global $hLwSource = GUICtrlGetHandle($iLwSource) For $i = 0 To 2 _GUICtrlListView_SetColumnWidth($hLwSource, $i, 75) Next GUICtrlCreateLabel("Segment Items", 270, 105, 250, 20, $SS_CENTER) GUICtrlSetFont(-1, 10, 800) Global $iLwSegments = GUICtrlCreateListView("Director|Manager|Buyer", 270, 125, 250, 300) Global $hLwSegments = GUICtrlGetHandle($iLwSegments) For $i = 0 To 2 _GUICtrlListView_SetColumnWidth($hLwSegments, $i, 75) Next Local $iBtnCommit = GUICtrlCreateButton("Commit", 441, 430, 80, 25) GUICtrlCreateLabel("Use the left/right arrows to add or remove items from the lists.", 10, 460, 510, 20) GUICtrlSetFont(-1, 10, 800) GUICtrlCreateLabel("Preview", 530, 10, 300, 20, $SS_CENTER) GUICtrlSetFont(-1, 10, 800) Global $iLwPreview = GUICtrlCreateListView("Director|Manager|Buyer", 530, 30, 300, 395) Global $hLwPreview = GUICtrlGetHandle($iLwPreview) For $i = 0 To 2 _GUICtrlListView_SetColumnWidth($hLwPreview, $i, 92) Next Local $iBtnSubmit = GUICtrlCreateButton("Submit...", 751, 430, 80, 25) GUIRegisterMsg($WM_COMMAND, "WM_COMMAND") GUIRegisterMsg($WM_ACTIVATE, "WM_ACTIVATE") GUIRegisterMsg($WM_SYSCOMMAND, "WM_SYSCOMMAND") _LoadDb() _HotKey_Enable() GUISetState(@SW_SHOW, $hGUI) #endregion GUI While 1 Sleep(10) Switch GUIGetMsg() Case $GUI_EVENT_CLOSE ExitLoop Case $iBtnCommit _Commit() Case $iBtnSubmit _Submit() EndSwitch WEnd GUIDelete($hGUI) Func _Commit() _GUICtrlListView_BeginUpdate($hLwPreview) _GUICtrlListView_DeleteAllItems($hLwPreview) Local $aData = _GUICtrlListView_GetItemTextArray($hLwSegments, $i), $sData = "" $sPreviewData = "" For $i = 0 To _GUICtrlListView_GetItemCount($hLwSegments) - 1 $sPreviewData &= $aData[0] & ";" & $aData[1] & ";" & $aData[2] & @CRLF GUICtrlCreateListViewItem(_ArrayToString($aData, "|"), $iLwPreview) Next _GUICtrlListView_EndUpdate($hLwPreview) _GUICtrlListView_DeleteAllItems($hLwSegments) EndFunc ;==>_Commit Func _Submit() Local $sPath = FileSaveDialog("save", "", "CSV file (*.csv)", BitOR($FD_PATHMUSTEXIST, $FD_PROMPTOVERWRITE)) If @error Then Return 0 If StringRight($sPath, 4) <> ".csv" Then $sPath &= ".csv" Local $hFile = FileOpen($sPath, $FO_OVERWRITE) FileWrite($hFile, $sPreviewData) FileClose($hFile) EndFunc ;==>_Submit Func _LoadDb() Local $sData = FileRead(@ScriptDir & "\Dir_man_Buyer.csv") Local $aBase = StringSplit($sData, @CRLF, BitOR($STR_ENTIRESPLIT, $STR_NOCOUNT)) ;-2/-3 for the UBound because the first line is a header and the last line is empty Global $aKalRecs[UBound($aBase) - 2][3] Local $aTmp = 0 For $i = 0 To UBound($aBase) - 3 $aTmp = StringSplit($aBase[$i + 1], ",", BitOR($STR_ENTIRESPLIT, $STR_NOCOUNT)) $aKalRecs[$i][0] = $aTmp[0] $aKalRecs[$i][1] = $aTmp[1] $aKalRecs[$i][2] = $aTmp[2] Next EndFunc ;==>_LoadDb Func _MoveFromSourceToSegments() Local $sSelectedItem = _GUICtrlListView_GetSelectedIndices($hLwSource) If $sSelectedItem = "" Then Return 0 Local $iSelItem = Number($sSelectedItem) GUICtrlCreateListViewItem(_GUICtrlListView_GetItemTextString($hLwSource, $iSelItem), $iLwSegments) _GUICtrlListView_DeleteItem($hLwSource, $iSelItem) EndFunc ;==>_MoveFromSourceToSegments Func _MoveFromSegmentsToSource() Local $sSelectedItem = _GUICtrlListView_GetSelectedIndices($hLwSegments) If $sSelectedItem = "" Then Return 0 Local $iSelItem = Number($sSelectedItem) GUICtrlCreateListViewItem(_GUICtrlListView_GetItemTextString($hLwSegments, $iSelItem), $iLwSource) _GUICtrlListView_DeleteItem($hLwSegments, $iSelItem) EndFunc ;==>_MoveFromSegmentsToSource Func WM_COMMAND($hWnd, $iMsg, $iwParam, $ilParam) Local $hWndFrom, $iIDFrom, $iCode, $tNMHDR, $hWndListView, $tInfo, $item_txt $iIDFrom = BitAND($iwParam, 0xFFFF) $iCode = BitShift($iwParam, 16) Switch $iIDFrom Case $iInputDirectorCode $iInputDirectorCode = StringUpper($iInputDirectorCode) Switch $iCode Case $EN_UPDATE GUICtrlSetData($iInputManagerCode, "") GUICtrlSetData($iInputBuyerCode, "") Local $sInput = StringUpper(GUICtrlRead($iInputDirectorCode)) If StringRegExp($sInput, "^([A-Z]|\*)$") = 1 Then _ArraySort($aKalRecs, 0, 0, 0, 0) $iSourceSelItem = -1 _GUICtrlListView_BeginUpdate($hLwSource) _GUICtrlListView_DeleteAllItems($hLwSource) If $sInput = "*" Then For $i = 0 To UBound($aKalRecs) - 1 GUICtrlCreateListViewItem($aKalRecs[$i][0] & "|" & $aKalRecs[$i][1] & "|" & $aKalRecs[$i][2], $iLwSource) Next Else For $i = 0 To UBound($aKalRecs) - 1 If $sInput <> StringStripWS($aKalRecs[$i][0], $STR_STRIPTRAILING) Then ContinueLoop GUICtrlCreateListViewItem($aKalRecs[$i][0] & "|" & $aKalRecs[$i][1] & "|" & $aKalRecs[$i][2], $iLwSource) Next EndIf _GUICtrlListView_EndUpdate($hLwSource) EndIf EndSwitch Case $iInputManagerCode Switch $iCode Case $EN_UPDATE GUICtrlSetData($iInputDirectorCode, "") GUICtrlSetData($iInputBuyerCode, "") Local $sInput = GUICtrlRead($iInputManagerCode) If StringRegExp($sInput, "^\d+$") = 1 Then _ArraySort($aKalRecs, 0, 0, 0, 1) $iSourceSelItem = -1 _GUICtrlListView_BeginUpdate($hLwSource) _GUICtrlListView_DeleteAllItems($hLwSource) For $i = 0 To UBound($aKalRecs) - 1 If $sInput <> $aKalRecs[$i][1] Then ContinueLoop GUICtrlCreateListViewItem($aKalRecs[$i][0] & "|" & $aKalRecs[$i][1] & "|" & $aKalRecs[$i][2], $iLwSource) Next _GUICtrlListView_EndUpdate($hLwSource) EndIf EndSwitch Case $iInputBuyerCode StringUpper($iInputBuyerCode) Switch $iCode Case $EN_UPDATE GUICtrlSetData($iInputDirectorCode, "") GUICtrlSetData($iInputManagerCode, "") Local $sInput = StringUpper(GUICtrlRead($iInputBuyerCode)) If StringRegExp($sInput, "^[\dA-Z]+$") = 1 Then _ArraySort($aKalRecs, 0, 0, 0, 2) $iSourceSelItem = -1 _GUICtrlListView_BeginUpdate($hLwSource) _GUICtrlListView_DeleteAllItems($hLwSource) For $i = 0 To UBound($aKalRecs) - 1 If $sInput <> $aKalRecs[$i][2] Then ContinueLoop GUICtrlCreateListViewItem($aKalRecs[$i][0] & "|" & $aKalRecs[$i][1] & "|" & $aKalRecs[$i][2], $iLwSource) Next _GUICtrlListView_EndUpdate($hLwSource) EndIf EndSwitch EndSwitch Return $GUI_RUNDEFMSG EndFunc ;==>WM_COMMAND Func WM_ACTIVATE($hWnd, $iMsg, $iwParam, $ilParam) If $iwParam And Not $blGUIMinimized Then _HotKey_Enable() Else _Hotkey_Disable() EndIf Return $GUI_RUNDEFMSG EndFunc ;==>WM_ACTIVATE Func WM_SYSCOMMAND($hWnd, $iMsg, $wParam, $lParam) Local Const $SC_MINIMIZE = 0xF020, $SC_RESTORE = 0xF120 Switch BitAND($wParam, 0xFFF0) Case $SC_MINIMIZE _Hotkey_Disable() $blGUIMinimized = True Case $SC_RESTORE $blGUIMinimized = False EndSwitch Return $GUI_RUNDEFMSG EndFunc ;==>WM_SYSCOMMAND Func _HotKey_Enable() HotKeySet("{RIGHT}", "_MoveFromSourceToSegments") HotKeySet("{LEFT}", "_MoveFromSegmentsToSource") EndFunc ;==>_HotKey_Enable Func _Hotkey_Disable() HotKeySet("{RIGHT}") HotKeySet("{LEFT}") EndFunc ;==>_Hotkey_Disable Code 2 (Multi Select and drag) ; Includes first! Must must must! #include <GUIConstantsEx.au3> #include <ListViewConstants.au3> #include <GuiListView.au3> #include <StaticConstants.au3> #include <WindowsConstants.au3> #include <Array.au3> #include <Misc.au3> #include <SendMessage.au3> ; Switch on the 'onEvent' notifications Opt("GUIOnEventMode", 1) Opt("PixelCoordMode", 2) ; Generate the GUI. Global $gw = 16 Global $gh = 16 Global $Startx, $Starty, $Endx, $Endy, $aM_Mask, $aMask, $nc Global $MainForm, $list_source, $list_target, $drag_gui, $hSplash $MainForm = GUICreate(" Segment Builder ", 517, 500) ;Headers.. $hSource = GUICtrlCreateLabel("Source Items", 85, 8, 100, 30) GUICtrlSetFont($hSource, 10, 700) $hSegment = GUICtrlCreateLabel("Segment Items", 330, 8, 100, 30) GUICtrlSetFont($hSegment, 10, 700) ; Source list box $list_source = _GUICtrlListView_Create($MainForm, "Director|Manager|Buyer", 13, 25, 240, 300, BitOR($LVS_REPORT, $LVS_SHOWSELALWAYS, $LVS_SORTASCENDING)) ; Target list box $list_target = _GUICtrlListView_Create($MainForm, "Director|Manager|Buyer", 261, 25, 240, 300, BitOR($LVS_REPORT, $LVS_SHOWSELALWAYS, $LVS_SORTASCENDING)) $Pic1 = GUICtrlCreatePic(@ScriptDir & "\left_right_arrow_keys.jpg", 186, 400, 124, 84) ; Populate box with some instructions $text1 = GUICtrlCreateLabel("Select items and drag from source to segment and vice-versa.... OR...", 45, 340, 450, 30) GUICtrlSetBkColor($text1, $GUI_BKCOLOR_TRANSPARENT) GUICtrlSetFont($text1, 9, 800, -1, 'courier new') GUICtrlSetColor($text1, 0x0000ff) $text2 = GUICtrlCreateLabel("Use the left/right arrows to add or remove items from the lists.", 45, 380, 450, 30) GUICtrlSetBkColor($text2, $GUI_BKCOLOR_TRANSPARENT) GUICtrlSetFont($text2, 9, 800, -1, 'courier new') GUICtrlSetColor($text2, 0x0000ff) $left = GUICtrlCreateDummy() GUICtrlSetOnEvent($left, "leftpressed") $right = GUICtrlCreateDummy() GUICtrlSetOnEvent($right, "rightpressed") Dim $aHotkey[2][2] = [["{LEFT}", $left],["{RIGHT}", $right]] GUISetAccelerators($aHotkey) Func leftpressed() _GUICtrlListView_CopyItems($list_target, $list_source, 1) EndFunc ;==>leftpressed Func rightpressed() _GUICtrlListView_CopyItems($list_source, $list_target, 1) EndFunc ;==>rightpressed For $i = 0 To 29 $item = _GUICtrlListView_AddItem($list_source, _makeJunkName()) _GUICtrlListView_AddSubItem($list_source, $item, _makeJunkName(), 1) Next ; Handle GUI events GUIRegisterMsg($WM_NOTIFY, "WM_NOTIFY") GUISetOnEvent($GUI_EVENT_CLOSE, "_formEvents") $drag_gui = GUICreate("Drag", $gw, $gh, 300, 300, BitOR($WS_CLIPCHILDREN, $WS_CLIPSIBLINGS, $WS_POPUP), BitOR($WS_EX_TOOLWINDOW, $WS_EX_TOPMOST), $MainForm) $cursor_icon = GUICtrlCreateIcon("Shell32.dll", -147, 0, 0, 16, 16) GUISetState(@SW_SHOW, $drag_gui) setTrans() GUISetState(@SW_HIDE, $drag_gui) GUISetState(@SW_SHOW, $MainForm) ; Main program loop While 1 Sleep(10) WEnd ; Function to handle other form events Func chase() $mp = MouseGetPos() _WinAPI_UpdateWindow($MainForm) _WinAPI_UpdateWindow($drag_gui) WinMove($drag_gui, "", $mp[0] + 0, $mp[1] + 0) ;ToolTip($moving_txt, $mp[0] + 18, $mp[1]) WinMove($hSplash, "", $mp[0] + 28, $mp[1] + 0) EndFunc ;==>chase Func _formEvents() Exit EndFunc ;==>_formEvents Func setTrans() $aM_Mask = DllCall("gdi32.dll", "long", "CreateRectRgn", "long", 0, "long", 0, "long", 460, "long", 460) $rct = DllStructCreate("int;int;int;inr", $aM_Mask[0]) $TestCol = PixelGetColor(0, 0) $Startx = -1 $Starty = -1 $Endx = 0 $Endy = 0 For $i = 0 To $gw For $j = 0 To $gh If PixelGetColor($i, $j) = $TestCol And $j < $gh Then If $Startx = -1 Then $Startx = $i $Starty = $j $Endx = $i $Endy = $j Else $Endx = $i $Endy = $j EndIf Else If $Startx <> -1 Then addRegion() $Startx = -1 $Starty = -1 EndIf Next Next DllCall("user32.dll", "long", "SetWindowRgn", "hwnd", $drag_gui, "long", $aM_Mask[0], "int", 1) EndFunc ;==>setTrans Func addRegion() $aMask = DllCall("gdi32.dll", "long", "CreateRectRgn", "long", $Startx, "long", $Starty, "long", $Endx + 1, "long", $Endy + 1) $nc += 1 DllCall("gdi32.dll", "long", "CombineRgn", "long", $aM_Mask[0], "long", $aMask[0], "long", $aM_Mask[0], "int", 3) EndFunc ;==>addRegion ; Create a junk name for testing Func _makeJunkName() Local $labelout = '' For $i = 1 To 20 $labelout &= Chr(Random(65, 90, 1)) Next Return $labelout EndFunc ;==>_makeJunkName Func WM_NOTIFY($hWnd, $iMsg, $iwParam, $ilParam) #forceref $hWnd, $iMsg, $iwParam Local $hWndFrom, $iIDFrom, $iCode, $tNMHDR, $hWndListView, $tInfo, $item_txt $tNMHDR = DllStructCreate($tagNMHDR, $ilParam) $hWndFrom = HWnd(DllStructGetData($tNMHDR, "hWndFrom")) $iIDFrom = DllStructGetData($tNMHDR, "IDFrom") $iCode = DllStructGetData($tNMHDR, "Code") $hWndListView = $hWndFrom If Not IsHWnd($hWndFrom) Then $hWndListView = GUICtrlGetHandle($hWndFrom) Switch $hWndFrom Case $hWndListView Switch $iCode Case $LVN_BEGINDRAG ; A drag-and-drop operation involving the left mouse button is being initiated $tInfo = DllStructCreate($tagNMLISTVIEW, $ilParam) If $hWndFrom = $list_source Then $direction = 1 ElseIf $hWndFrom = $list_target Then ; Or are we moving from destination to source $direction = 2 Else MsgBox(0, "", "bad") EndIf $aidx = _GUICtrlListView_GetSelectedIndices($hWndFrom, True) $iselecteditems = $aidx[0] ;retrieve all item text, not just first item For $i = 1 To $aidx[0] $item_txt &= _GUICtrlListView_GetItemText($hWndFrom, $aidx[$i]) & @CRLF Next $item_txt = StringStripWS($item_txt, 1 + 2) _WinAPI_ShowCursor(False) ;$atemp = _GUICtrlListBox_GetItemRect($cinfo[4], Int($idx)) $atemp = _GUICtrlListView_ApproximateViewRect($hWndFrom, $iselecteditems) $hSplash = SplashTextOn("", $item_txt, $atemp[0] - 10, $atemp[1] - 5, -1, -1, 1 + 32, "", 12) Sleep(5) ;MsgBox(0, "", $item_txt) GUISetState(@SW_SHOW, $drag_gui) While _IsPressed(1) chase() WEnd GUISetState(@SW_HIDE, $drag_gui) _WinAPI_ShowCursor(True) SplashOff() ; Get new position Local $newcinfo = GUIGetCursorInfo(WinGetHandle($MainForm)) ; If we were moving from source to destination and we ARE in the destination box If $direction = 1 And $newcinfo[4] = GUICtrlGetHandle($list_target) Then ;ConsoleWrite("Moved " & $iselecteditems & " items from source to destination" & @CRLF) _GUICtrlListView_CopyItems($list_source, $list_target, 1) EndIf ; If we are moving from destination to source and we ARE in source box If $direction = 2 And $newcinfo[4] = GUICtrlGetHandle($list_source) Then ;ConsoleWrite("Moved " & $iselecteditems & " items from destination to source" & @CRLF) _GUICtrlListView_CopyItems($list_target, $list_source, 1) EndIf EndSwitch EndSwitch Return $GUI_RUNDEFMSG EndFunc ;==>WM_NOTIFY Func _DebugPrint($s_text, $line = @ScriptLineNumber) ConsoleWrite( _ "!===========================================================" & @LF & _ "+======================================================" & @LF & _ "-->Line(" & StringFormat("%04d", $line) & "):" & @TAB & $s_text & @LF & _ "+======================================================" & @LF) EndFunc ;==>_DebugPrint 17 way split.txt
