lesther

Hi, I´m trying to use the _CommAPI_GetCommTimeouts command from CommAPI.au3, but I have no luck... Does any one have already used this command before, or have an example using it? and also the _CommAPI_SetCommTimeouts? Why use this command? Because I have to open a com port using the file_create and file_read, but when using it (file_read) sometimes I get hanged when I don´t receive a character on the com port.. so the script get hanged waiting for some data to move on... I believe that setting a timeout on the com port I can move on when no character is received... (please correct me if I´m wrong...) Thanks in advance!

Hi, here it is: On Panel 2 (link 2) there are 3 input boxes, but pressing tab on inputbox one, instead going to inputbox2 it get lost somewhere... #include <GuiConstants.au3> #include <EditConstants.au3> #include <WindowsConstants.au3> #include <StaticConstants.au3> #region GLOBAL VARIABLES Global $iW = 600, $iH = 400, $iT = 52, $iB = 52, $iLeftWidth = 150, $iGap = 10, $hMainGUI #endregion GLOBAL VARIABLES _MainGui() Func _MainGui() Local $hFooter, $nMsg, $aPos Local $iLinks = 5 Local $sMainGuiTitle = "Sample Title" Local $sHeader = "Sample GUI" Local $sFooter = "2012 © AutoIt" Local $aLink[$iLinks], $aPanel[$iLinks] $aLink[0] = $iLinks - 1 $aPanel[0] = $iLinks - 1 $hMainGUI = GUICreate($sMainGuiTitle, $iW, $iH, -1, -1, BitOR($GUI_SS_DEFAULT_GUI, $WS_MAXIMIZEBOX, $WS_TABSTOP)) GUISetIcon("shell32.dll", -58, $hMainGUI) GUICtrlCreateLabel($sHeader, 48, 8, $iW - 56, 32, $SS_CENTERIMAGE) GUICtrlSetFont(-1, 14, 800, 0, "Arial", 5) GUICtrlSetResizing(-1, $GUI_DOCKLEFT + $GUI_DOCKTOP + $GUI_DOCKWIDTH + $GUI_DOCKHEIGHT) GUICtrlCreateIcon("shell32.dll", -131, 8, 8, 32, 32) GUICtrlSetResizing(-1, $GUI_DOCKLEFT + $GUI_DOCKTOP + $GUI_DOCKWIDTH + $GUI_DOCKHEIGHT) GUICtrlCreateLabel("", 0, $iT, $iW, 2, $SS_SUNKEN);separator GUICtrlSetResizing(-1, $GUI_DOCKTOP + $GUI_DOCKLEFT + $GUI_DOCKRIGHT + $GUI_DOCKHEIGHT) GUICtrlCreateLabel("", $iLeftWidth, $iT + 2, 2, $iH - $iT - $iB - 2, $SS_SUNKEN);separator GUICtrlSetResizing(-1, $GUI_DOCKTOP + $GUI_DOCKLEFT + $GUI_DOCKBOTTOM + $GUI_DOCKWIDTH) GUICtrlCreateLabel("", 0, $iH - $iB, $iW, 2, $SS_SUNKEN);separator GUICtrlSetResizing(-1, $GUI_DOCKBOTTOM + $GUI_DOCKLEFT + $GUI_DOCKRIGHT + $GUI_DOCKHEIGHT) $hFooter = GUICtrlCreateLabel($sFooter, 10, $iH - 34, $iW - 20, 17, BitOR($SS_LEFT, $SS_CENTERIMAGE)) GUICtrlSetTip(-1, "AutoIt Forum", "Click to open...") GUICtrlSetCursor(-1, 0) GUICtrlSetResizing(-1, $GUI_DOCKLEFT + $GUI_DOCKRIGHT + $GUI_DOCKBOTTOM + $GUI_DOCKHEIGHT) ;add links to the left side $aLink[1] = _AddNewLink("Link 1") $aLink[2] = _AddNewLink("Link 2", -167) $aLink[3] = _AddNewLink("Link 3", -222) $aLink[4] = _AddNewLink("Link 4", -22) ;and the corresponding GUI's $aPanel[1] = _AddNewPanel("Title for the panel 1") $aPanel[2] = _AddNewPanel("Title for the panel 2") $aPanel[3] = _AddNewPanel("Title for the panel 3") $aPanel[4] = _AddNewPanel("Title for the panel 4") ;add some controls to the panels _AddControlsToPanel($aPanel[1]) GUICtrlCreateEdit("", 10, 37, $iW - $iLeftWidth + 2 - 20 - 5, $iH - $iT - $iB - 40, BitOR($ES_AUTOVSCROLL, $ES_NOHIDESEL, $ES_WANTRETURN, $WS_VSCROLL), $WS_EX_STATICEDGE) Local $sTestTxt = "" For $i = 1 To 10 $sTestTxt &= @TAB & "Lorem ipsum dolor sit amet, consectetur adipiscing elit. Vestibulum felis lectus, pharetra vel laoreet nec, pulvinar nec justo. Donec malesuada, nunc eu faucibus sodales, diam sem tempor neque, id condimentum turpis nunc vel lacus. Nulla a nulla libero, eget eleifend dolor. Vivamus volutpat tincidunt ultricies. Vestibulum eu libero nisi, quis tincidunt nisi. Proin tincidunt, ipsum ullamcorper posuere venenatis, libero nulla venenatis enim, ultrices tincidunt ipsum arcu nec turpis. In at erat sed ipsum gravida mattis in at felis. Vivamus diam purus, dictum ut luctus vitae, sollicitudin ut velit. Maecenas velit mauris, fringilla ut condimentum bibendum, aliquam a neque. Nulla metus eros, commodo id dictum in, interdum sed ipsum. Vivamus feugiat, mi at auctor fringilla, libero lectus vulputate tortor, eu sollicitudin nulla lacus at neque." & @CRLF $sTestTxt &= @TAB & "Aenean eleifend risus vitae lorem laoreet facilisis. Suspendisse ac urna quam, vel rutrum sem. Sed bibendum porta tellus malesuada scelerisque. Vestibulum at ligula sed nulla sollicitudin tincidunt. Pellentesque mi magna, vulputate et aliquam a, auctor et nunc. Phasellus feugiat fringilla accumsan. Donec ultrices, elit id dapibus auctor, nunc odio viverra lorem, non commodo mi libero a libero. Cras vitae felis venenatis augue laoreet tincidunt scelerisque id odio. Proin lorem purus, molestie feugiat pretium nec, ornare aliquam turpis. " Next GUICtrlSetData(-1, $sTestTxt) GUICtrlSetResizing(-1, $GUI_DOCKTOP + $GUI_DOCKLEFT + $GUI_DOCKRIGHT + $GUI_DOCKBOTTOM) _AddControlsToPanel($aPanel[2]) GUICtrlCreateLabel("Label1", 8, 38, 36, 17) GUICtrlSetResizing(-1, $GUI_DOCKTOP + $GUI_DOCKLEFT + $GUI_DOCKWIDTH + $GUI_DOCKHEIGHT) Local $hInput1 = GUICtrlCreateInput("Input1", 56, 35, 121, 21) GUICtrlSetResizing(-1, $GUI_DOCKTOP + $GUI_DOCKLEFT + $GUI_DOCKWIDTH + $GUI_DOCKHEIGHT) GUICtrlCreateLabel("Label2", 8, 58, 36, 17) GUICtrlSetResizing(-1, $GUI_DOCKTOP + $GUI_DOCKLEFT + $GUI_DOCKWIDTH + $GUI_DOCKHEIGHT) Local $hInput2 = GUICtrlCreateInput("Input2", 56, 55, 121, 21) GUICtrlSetResizing(-1, $GUI_DOCKTOP + $GUI_DOCKLEFT + $GUI_DOCKWIDTH + $GUI_DOCKHEIGHT) GUICtrlCreateLabel("Label3", 8, 78, 36, 17) GUICtrlSetResizing(-1, $GUI_DOCKTOP + $GUI_DOCKLEFT + $GUI_DOCKWIDTH + $GUI_DOCKHEIGHT) Local $hInput3 = GUICtrlCreateInput("Input3", 56, 75, 121, 21) GUICtrlSetResizing(-1, $GUI_DOCKTOP + $GUI_DOCKLEFT + $GUI_DOCKWIDTH + $GUI_DOCKHEIGHT) Local $hButton1 = GUICtrlCreateButton("Button1", 200, 33, 75, 25) GUICtrlSetResizing(-1, $GUI_DOCKTOP + $GUI_DOCKLEFT + $GUI_DOCKWIDTH + $GUI_DOCKHEIGHT) _AddControlsToPanel($aPanel[3]) GUICtrlCreateList("", 8, 37, 121, 93, -1, 0) GUICtrlSetData(-1, "dfgdfg|ertert|kljlkj|poipoi|qweqwe") GUICtrlSetResizing(-1, $GUI_DOCKTOP + $GUI_DOCKLEFT + $GUI_DOCKWIDTH + $GUI_DOCKHEIGHT) _AddControlsToPanel($aPanel[4]) GUICtrlCreateGroup("Group1", 8, 35, 129, 90) GUICtrlSetResizing(-1, $GUI_DOCKTOP + $GUI_DOCKLEFT + $GUI_DOCKWIDTH + $GUI_DOCKHEIGHT) Local $aChkBox[4] For $i = 1 To 3 $aChkBox[$i] = GUICtrlCreateRadio("Some radio " & $i, 16, 56 + ($i - 1) * 20, 113, 17) GUICtrlSetResizing(-1, $GUI_DOCKTOP + $GUI_DOCKLEFT + $GUI_DOCKWIDTH + $GUI_DOCKHEIGHT) Next GUICtrlSetState(-1, $GUI_CHECKED) GUICtrlCreateGroup("", -99, -99, 1, 1) ;set default to Panel1 GUISwitch($aPanel[1]) ;show the main GUI GUISetState(@SW_SHOW, $hMainGUI) While 1 Sleep(10) $nMsg = GUIGetMsg(1) Switch $nMsg[1] Case $hMainGUI Switch $nMsg[0] Case $GUI_EVENT_CLOSE Exit Case $GUI_EVENT_MINIMIZE, $GUI_EVENT_MAXIMIZE, $GUI_EVENT_RESTORE $aPos = WinGetPos($hMainGUI) $iW = $aPos[2] $iH = $aPos[3] For $i = 0 To $aPanel[0] WinMove($aPanel[$i], "", $iLeftWidth + 2, $iT, $iW - $iLeftWidth + 2, $iH - $iT - $iB - 20) Next Case $aLink[1], $aLink[2], $aLink[3], $aLink[4] For $i = 1 To $aLink[0] If $nMsg[0] = $aLink[$i] Then GUISetState(@SW_SHOW, $aPanel[$i]) Else GUISetState(@SW_HIDE, $aPanel[$i]) EndIf Next Case $hFooter ShellExecute("http://www.autoitscript.com/forum/topic/146952-gui-design-concepts/") EndSwitch Case $aPanel[2] Switch $nMsg[0] Case $hButton1 MsgBox(32, "Test", "You have " & GUICtrlRead($hInput1) & "?") EndSwitch Case $aPanel[4] Switch $nMsg[0] Case $aChkBox[1], $aChkBox[2], $aChkBox[3] For $i = 1 To 3 If GUICtrlRead($aChkBox[$i]) = $GUI_CHECKED Then MsgBox(64, "Test", "You checked nr. " & $i & "!") Next EndSwitch EndSwitch WEnd EndFunc ;==>_MainGui Func _AddNewLink($sTxt, $iIcon = -44) Local $hLink = GUICtrlCreateLabel($sTxt, 36, $iT + $iGap, $iLeftWidth - 46, 17) GUICtrlSetCursor(-1, 0) GUICtrlSetResizing(-1, $GUI_DOCKLEFT + $GUI_DOCKTOP + $GUI_DOCKWIDTH + $GUI_DOCKHEIGHT) GUICtrlCreateIcon("shell32.dll", $iIcon, 10, $iT + $iGap, 16, 16) GUICtrlSetResizing(-1, $GUI_DOCKLEFT + $GUI_DOCKTOP + $GUI_DOCKWIDTH + $GUI_DOCKHEIGHT) $iGap += 22 Return $hLink EndFunc ;==>_AddNewLink Func _AddNewPanel($sTxt) Local $gui = GUICreate("", $iW - $iLeftWidth + 2, $iH - $iT - $iB, $iLeftWidth + 2, $iT, $WS_CHILD + $WS_VISIBLE, -1, $hMainGUI) GUICtrlCreateLabel($sTxt, 10, 10, $iW - $iLeftWidth - 20, 17, $SS_CENTERIMAGE) GUICtrlSetFont(-1, 9, 800, 4, "Arial", 5) GUICtrlSetResizing(-1, $GUI_DOCKTOP + $GUI_DOCKLEFT + $GUI_DOCKWIDTH + $GUI_DOCKHEIGHT) Return $gui EndFunc ;==>_AddNewPanel Func _AddControlsToPanel($hPanel) GUISwitch($hPanel) EndFunc ;==>_AddControlsToPanel

Hi, I´m making a script to send and receive data to/from Bluetooth serial, but I´m having a problem to connect to the com port. The problem is that I´ve two ports, one is the COM4 and the other is COM6 (not using at the same time) COM4 is a standard com port thought USB port that I can connect using CommMG, it´s working fine. _CommSetPort($port, $sportSetError, 9600, 8, 0 ,1,0)COM6 is a Bluetooth serial, that only works (I mean I can connect, send and receive data) with _WinAPI_CreateFile. $openport = _WinAPI_CreateFile("COM6", 2, 6) . . . _WinAPI_ReadFile($openport, DllStructGetPtr($tBuffer), 1, $nRead) $sText = BinaryToString(DllStructGetData($tBuffer, 1)) If I try to connect the COM4 with _WinAPI_CreateFile it´s not working... and when I try to connect with CommMG to COM6 it´s give a -16 (Port not found) error.. The problem is: How can I open/connect to the bluetooth (COM6) port using CommMG ( to write one single script instead of two - one using CommMG and another using _WinAPI_CreateFile)... Thanks in advance!

Hi everyone! I´m trying to use the interface that was posted by taietel on https://www.autoitscript.com/forum/topic/146952-gui-design-concepts/?do=findComment&comment=1041208 ( I believe that is the #9 post) but I´m having a little problem, that maybe someone can help me... I created another input box on the panel[2] but when I press TAB (on keyboard or send {TAB} command) to move between the two (or more) input box it´s not working... and I don´t know why... Can someone help me on this one? Thanks in advance!
