dcat127

Tesseract Top Indent not Working

2 posts in this topic

I am using the Tesseract UDF :

#include <Tesseract.au3>
$cord_r = 1800
$cord_t = 1080
$cord_l = 0
$cord_b = 0
_TesseractScreenCapture(0, "", 1, 1, $cord_l, $cord_t, $cord_r, $cord_b, 1)

My current desktop screen size is

1920x1080

The attached image shows the output. Even though I have my top indent set at 1080 it is cropping only about 1/2 of the screen. Funny part is the left, right and bottom seem to work like expected. Also the graphic looks like it is stretched.

Am I missing something?

post-7325-0-88518000-1319835006_thumb.jp

Share this post


Link to post
Share on other sites



I found 2 problems with the sdk...they only show up when you are cropping to a small area one a large screen.

Line 968: I changed to:

$hBMP = _WinAPI_CreateCompatibleBitmap($hDC, (($pos[2]-$right_indent)* $scale), (($pos[3] -$bottom_indent)* $scale))

Line 973: I changed to:

_GDIPlus_GraphicsDrawImageRect($hGraphic, $hImage2, 0 - ($left_indent * $scale), 0 - ($top_indent * $scale), $pos[2]* $scale, $pos[3] * $scale)

Not sure if this will cause other problems, but it solves my problem.
