Round Corner GUI and Controls UDF

[WildByDesign]

Yes, of course. Sorry about that. In the following example, if you do the rounded input or the rounded group separately, they both end up rounded as expected. Initially, try the script with just the input enabled. It's rounded. Then remove the comment from the rounded group and run script again. You'll notice that the group is rounded but the input on the inside of the group is squared.

Spoiler

#include "RoundGUI.au3"

Opt("GUIOnEventMode", 1)

$hGUI = GUICreate("test", 500, 500)
GUISetOnEvent($GUI_EVENT_CLOSE, "SpecialEvents")

GUISetBkColor(0x202020)


_RGUI_RoundInput("test input", 0xFFFFFF, 100, 100, 200, 200, 0x404040, 0X404040, 15, 6)

;_RGUI_RoundGroup("Advanced", 0xffffff, 75, 75, 300, 300, 0x404040, 0x202020, 8, 6)

GUISetState()

While 1
    Sleep(1000)
WEnd

Func SpecialEvents()
    Select
        Case @GUI_CtrlId = $GUI_EVENT_CLOSE
Exit
    EndSelect
EndFunc





[argumentum]

15 minutes ago, WildByDesign said:

but the input on the inside of the group is squared.

#include "RoundGUI.au3"

Opt("GUIOnEventMode", 1) ;;; https://www.autoitscript.com/forum/topic/212767-round-corner-gui-and-controls-udf/page/2/#comment-1544167

$hGUI = GUICreate("test", 500, 500)
GUISetOnEvent($GUI_EVENT_CLOSE, "SpecialEvents")

GUISetBkColor(0x202020)

_RGUI_RoundGroup($hGUI, "Advanced", 0xffffff, 75, 75, 300, 300, 0x404040, 0x202020, 8, 6)
_RGUI_RoundInput("test input", 0xFFFFFF, 100, 100, 200, 200, 0x404040, 0X404040, 15, 6)
GUICtrlCreateGroup("", -99, -99, 1, 1) ;close group

GUISetState()

While Sleep(1000)
WEnd

Func SpecialEvents()
    Select
        Case @GUI_CtrlId = $GUI_EVENT_CLOSE
            GUIDelete()
            Exit
    EndSelect
EndFunc   ;==>SpecialEvents

You may need to read about GUICtrlCreateGroup().

[WildByDesign]

15 minutes ago, argumentum said:

You may need to read about GUICtrlCreateGroup().

Thank you so much. I forgot to close the group. That solved the issue for me.
