GUISetIcon DPI Bug

[WildByDesign]

GUISetIcon seems to have a bug with regard to DPI. When a windows application utilizes an icon, it is supposed to choose the icon size which is closest to the size needed by the system from the .ICO file. TraySetIcon does not seem to have this bug.

I have created an example which shows the problem. The example creates a GUI with system DPI awareness and sets the same icon file with GUISetIcon and TraySetIcon.

You will notice that the icon in the GUI is blurry and stretched, while the same icon in the system tray is sharp as expected.

Example: (app.ico is attached to this message)

#include <GUIConstantsEx.au3>

; System DPI awareness
DllCall("user32.dll", "bool", "SetProcessDpiAwarenessContext", @AutoItX64 ? "int64" : "int", -2)

Example()

Func Example()
    ; Create a GUI with various controls.
    Local $hGUI = GUICreate("Example", 400, 400)

    ; Display the GUI.
    GUISetState(@SW_SHOW, $hGUI)

    ; set GUI icon
    GUISetIcon(@ScriptDir & "\app.ico")

    ; set tray icon
    TraySetIcon(@ScriptDir & '\app.ico')

    ; Loop until the user exits.
    While 1
        Switch GUIGetMsg()
            Case $GUI_EVENT_CLOSE
                ExitLoop

        EndSwitch
    WEnd

    ; Delete the previous GUI and all controls.
    GUIDelete($hGUI)
EndFunc   ;==>Example



On a side note, does anyone know of any WinAPI or DLL calls that we can use to load a GUI icon so that I can avoid this bug?

app.ico

[argumentum]

Yes, the tray icon looks better than the GUI caption's icon.

Edited 5 hours ago by argumentum
I broke something. Fixed.

[argumentum]

 tray looks better with just 64x64, let the OS / AutoIt do the resizing.     au3.213458-guiseticon-dpi-bug.app_v2.ico

And yes, @jpm should look at this.
( I don't know of a work around but there should be one on the _WinAPI_* side of things )

[WildByDesign]

Thanks for confirming and for tagging the right person to escalate the issue.

I will have a look at the WinAPI functions and see if I can get something going there.

[argumentum]

1 hour ago, argumentum said:

there should be one on the _WinAPI_* side of things

expandcollapse popup

#Region ;**** Directives created by AutoIt3Wrapper_GUI ****
#AutoIt3Wrapper_UseX64=y
#EndRegion ;**** Directives created by AutoIt3Wrapper_GUI ****
#include <GUIConstantsEx.au3>
#include <WinAPIIcons.au3> ; _WinAPI_ExtractIcon
#include <SendMessage.au3> ; _SendMessage


; System DPI awareness
DllCall("user32.dll", "bool", "SetProcessDpiAwarenessContext", @AutoItX64 ? "int64" : "int", -2)

Example() ; https://www.autoitscript.com/forum/topic/213458-guiseticon-dpi-bug/#comment-1549810

Func Example()
    ; Create a GUI with various controls.
    Local $hGUI = GUICreate("Example", 400, 400)

    ; Display the GUI.
    GUISetState(@SW_SHOW, $hGUI)

    ; set GUI icon
;~     GUISetIcon(@ScriptDir & "\app.ico")
    _WinSetIcon($hGUI, @ScriptDir & "\app.ico")

    ; set tray icon
    TraySetIcon(@ScriptDir & '\app.ico')

    ; Loop until the user exits.
    While 1
        Switch GUIGetMsg()
            Case $GUI_EVENT_CLOSE
                ExitLoop

        EndSwitch
    WEnd

    ; Delete the previous GUI and all controls.
    GUIDelete($hGUI)
EndFunc   ;==>Example

Func _WinSetIcon($hWnd, $sFile, $iIndex = 0, $bSmall = False) ; https://www.autoitscript.com/forum/topic/168698-changing-a-windows-icon/#findComment-1461109
  Local $WM_SETICON = 128, $ICON_SMALL = 0, $ICON_BIG = 1, $hIcon = _WinAPI_ExtractIcon($sFile, $iIndex, $bSmall)
  If Not $hIcon Then Return SetError(1, 0, 1) ; https://learn.microsoft.com/en-us/windows/win32/winmsg/wm-seticon
  _SendMessage($hWnd, $WM_SETICON, Int(Not $bSmall), $hIcon)
  _WinAPI_DestroyIcon($hIcon)
EndFunc   ;==>_WinSetIcon

Google is your friend. Actually @Nine is

   vs this:

Edit:

#include <windows.h>

// ... inside your code, e.g., after CreateWindow or in WM_CREATE handler ...

HICON hIcon = LoadIcon(hInstance, MAKEINTRESOURCE(IDI_MYICON)); // Load your icon resource
if (hIcon)
{
    // Set the large icon (appears in Alt+Tab, etc.)
    SendMessage(hWnd, WM_SETICON, ICON_BIG, (LPARAM)hIcon);

    // Set the small icon (appears in the title bar)
    SendMessage(hWnd, WM_SETICON, ICON_SMALL, (LPARAM)hIcon);
}



Edited 4 hours ago by argumentum
better ?

[WildByDesign]

That is so much better. I’m just going by your screenshots right now because I won’t be able to test it until maybe an hour from now.

I am always amazed at the versatility of AutoIt. So many ways to do just about anything. Or as I believe @Nine had wrote before , “different ways to skin a cat”.



[WildByDesign]

This ended up being a perfect solution. Excellent. Thanks again, @argumentum
