GUIDarkTheme UDF

[WildByDesign]

This UDF was created within the DarkMode UDF for AutoIt's Win32GUIs thread which was originally created by @NoNameCode. I ended up extending the features quite significantly and therefore decided to branch off into a new thread because I do not want to take anything away from the original DarkMode UDF.

Goal:

My goal was to make everything as automated and as simple as possible. I wanted it so that whoever is using it can just add one line of code _GUIDarkTheme_ApplyDark($hGUI, True) just before their already existing GUISetState() function. This would initiate the dark mode and automatically detect all controls, convert to dark mode and use the necessary subclassing whenever needed.

Community:

This UDF contains a lot of code from throughout the amazing AutoIt community and therefore belongs to every single one of us. I am always welcome to any suggestions and collaboration.



Changelog:

Spoiler

GUIDarkTheme 1.2.0:

• GUIDarkTheme and GUIDarkMenu have been combined
• Added new function _GUIDarkTheme_ApplyMaterial() for applying Windows 11 materials (Mica, Acrylic, etc.)
  • SampleControls-ModernDark example has been updated to show material effect
  • Requires Windows 11 build 22621 or higher

GUIDarkTheme 1.2.1:

• Add TVS_EX_DOUBLEBUFFER extended style to TreeView controls



GUIDarkTheme-1.2.0.7z

GUIDarkTheme-1.2.1.7z

Edited 4 hours ago by WildByDesign

[Andreik]

I like the idea of calling a single function and turn everything dark. It seems to work fine in most cases but for tree views some visual artifacts appear. Anyone else experiencing this?

[WildByDesign]

I haven’t seen it before, but I’m thinking maybe adding doublebuffer to the TreeView control should fix it. I can have that applied through the UDF.

I will post an update later with doublebuffer applied to see if it helps.

[argumentum]



Edited 5 hours ago by argumentum

[argumentum]



..yes, after a repaint.
Minimize it and restore it and there it is.

[WildByDesign]

I cannot reproduce the artifact issue on my main system. I just uploaded version 1.2.1 which automatically adds TVS_EX_DOUBLEBUFFER to any TreeView controls.

Can you both please test it and see if it helps with this issue?

[argumentum]



..same "washing"

[argumentum]

1 hour ago, argumentum said:



That was because I wasn't using a standard Windows setup while testing

[Andreik]

56 minutes ago, WildByDesign said:

Can you both please test it and see if it helps with this issue?

Looks good to me.

[UEZ]

You can overpaint the size grips in edit, listvew and treeview.

I used in my example $WM_PAINT in _SubclassProc function:

expandcollapse popup

...
        Case $WM_PAINT
            Local $sClass = StringLower(_WinAPI_GetClassName($hWnd))
            If $sClass = "syslistview32" Or $sClass = "systreeview32" Or $sClass = "edit" Then ; hide Sizegrip boxes
                Local $iRet = _WinAPI_DefSubclassProc($hWnd, $iMsg, $wParam, $lParam)

                ; Overpaint sizegrip boxes if visible
                Local $iWinStyle = _WinAPI_GetWindowLong($hWnd, $GWL_STYLE)
                If BitAND($iWinStyle, $WS_HSCROLL) And BitAND($iWinStyle, $WS_VSCROLL) Then
                    Local $hDC = _WinAPI_GetWindowDC($hWnd) ; GetWindowDC statt GetDC!
                    Local $tWnd = _WinAPI_GetWindowRect($hWnd)
                    Local $tClient = _WinAPI_GetClientRect($hWnd)
                    Local $iScrollW = _WinAPI_GetSystemMetrics($SM_CXVSCROLL)
                    Local $iScrollH = _WinAPI_GetSystemMetrics($SM_CYHSCROLL)

                    ; convert client-area to Window coordinates
                    Local $tPt = DllStructCreate($tagPOINT)
                    $tPt.X = $tClient.right
                    $tPt.Y = $tClient.bottom
                    DllCall("user32.dll", "bool", "ClientToScreen", "hwnd", $hWnd, "struct*", $tPt)

                    ; direct relativ coordinates
                    Local $tCorner = DllStructCreate($tagRECT), $delta = (_WinAPI_GetWindowLong($hWnd, $GWL_EXSTYLE) And $WS_EX_CLIENTEDGE ? 4 : 1)
                    $tCorner.left   = $tClient.right  + $delta
                    $tCorner.top    = $tClient.bottom + $delta
                    $tCorner.right  = $tCorner.left + $iScrollW
                    $tCorner.bottom = $tCorner.top  + $iScrollH

                    Local $hBrush = _WinAPI_CreateSolidBrush(_ColorToCOLORREF($COLOR_TITLE_DARK))
                    _WinAPI_FillRect($hDC, $tCorner, $hBrush)
                    _WinAPI_DeleteObject($hBrush)
                    _WinAPI_ReleaseDC($hWnd, $hDC)
                EndIf
                Return $iRet
            Else
                Return _WinAPI_DefSubclassProc($hWnd, $iMsg, $wParam, $lParam)
            EndIf
...

I didn't test it for DPI <> 1 aka 96 if $tCorner is properly calculated.
