climberman

MTGO BOT FINAL

4 posts in this topic

This script is full, but not necessarily working. I won't be around to answer questions but I wish everyone goodluck who wants to use this.

I reccomend just changing this to greet a person by name and do the x cards for x tix if you want. Trying to build a smartbot is very difficult. This comes close, but still has problems, also it's got some references to specific locations on my computer so you'll have to modify those.

things needed are attached. FYI i made one of the tiles black in the mtgo directory so the OCR would have better results.

If you can read the code, I think you can get through with the comments and names, if not the help file will be your friend.

Anyways the flow probly doesn't work with the checksums any more but the bot will wait around, then when the dialog pops up, its supposed to enter the trade. then it'll quote card prices as they're selected, and finally take tickets. also the gui looks for a picture that i attached (just for fun).

; http://msdn2.microsoft.com/en-us/library/a...office.11).aspx
;#include <GUIConstants.au3>


#CS TradeBot Ultra by Brian Oliver
   This program is not for resale without express permission from Brian Oliver
   Please send questions and requests to c08oliverbrian@hotmail.com

   ***In order for this program to run, you must have a folder on the desktop called mtgobot.

   ***With MTGO launched, run the script.  When you are ready to test, click run.  To terminate, click close.
   Do not close, minimize or switch MTGO program while the bot is running.

   Revision History (Date, Initials, Description)
   09/04/08 BCO waitfortrade circular refs cleared, checksum changed to infinite loop
                resetfromwithdraw circular refs cleared
                aborttradecircular refs cleared

    Desired Revisions
        If mtgo becomes inactive, pause the bot
        Add smart buying capability
        Add sales reports
        Use specific checksums in place of other methods such as wait for changve checksums
        Add clean interface
        Add help File
        Add automatic, intellignet, dynamic price adjustment to maximize sales
        Create smarter advertising
        Add function to deal with a chat window opening in the middle of a trade
        Check for inactive trade after 1 minute of inactivity, abort after 2
#CE

#include <GUIConstantsEx.au3>
#include <Array.au3>
#include <WindowsConstants.au3>
#include <ScreenCapture.au3>
#include <File.au3>
#include <WinAPI.au3>
#include <GDIPlus.au3>
#include <Misc.au3>

$dll = DllOpen("user32.dll")

Dim $CardName [99]
Dim $CardSet [99]
Dim $CardQty [99]
Dim $CardPrice [99]
Dim $Update
Dim $run
Dim $stop
Dim $fCursor
Dim $guimsg
Dim $QtyVal [10]
Dim $Price
Dim $Player
Dim $PlayerArray [9999]
Dim $checksum
Const $miLANG_ENGLISH = 9
Dim $i
Dim $j
Dim $miDoc, $Doc
Dim $str
Dim $oWord
Dim $sArray[99]
Dim $count
Dim $miLayout
Dim $sFile
Dim $simage
Dim $greetMessage
Dim $TixQty
Dim $PlayerLocation
Dim $count
Dim $ticketTaken
Dim $bg
Dim $goto
Dim $temp
Dim $Credit

$maxtime = 600000

$gui = GUICreate ( "TradeBot Ultra - by Brian Oliver", 200, 300, @DesktopWidth-200, @DesktopHeight-300)
GUISetBkColor (0x000000)
;$bg = GUICtrlCreatePic(@DesktopDir & "\mtgobot\bg.bmp",0,0)
$run = GUICtrlCreateButton ( "Run Bot", 10, 70)
$stop = GUICtrlCreateButton ( "Stop Bot", 10, 110)
$update = GUICtrlCreateButton ( "Update Prices", 10, 150)
GUISetState ()
GuiWait()
Func Close();close gui and terminate script
Exit
EndFunc

Func GuiWait();Wait for user to select to trade or update prices or...
While 1
    $guimsg = GUIGetMsg()
    Select
    Case $guimsg = $run
;Ad()
        waitForTrade()
    Case $guimsg = $stop
        GuiWait()
    Case $guimsg = $update
        Update()
    Case $guimsg = -3
        Close()
    EndSelect
sleep(100)
  WEnd
EndFunc
Func Ad();Type an ad into the trading channel
        MouseClick("left", 100,728, 1, 10)
        sleep(100)
        MouseClick("left", 100,635, 1, 10)
        sleep(100)
        MouseClick("left", 275,683, 1, 10)
        sleep(100)
        MouseClick("left",867, 490, 5)
        $str = "/join trading"
    Send($str)
    Send("{ENTER}")
    sleep(100)
        MouseClick("left", 770,45, 1, 10)
        sleep(100)
        MouseClick("left",867, 490, 5)
        $str = "Selling Cards at the Best Prices! Don't trade for more, Trade4Less"
    Send($str)
    Send("{ENTER}")
EndFunc

  $maxtime = 600000;end trade after 10 minutes

Func GetQty($j);returns the quantity of an item being sold where j is the line number
$QtyVal[1] =  2123377744
$QtyVal[2] =  3139319573
$QtyVal[3] =  3416667955
$QtyVal[4] =  1109538188
$QtyVal[0] = PixelChecksum(20, 595+$j, 35, 610+$j)

Select
Case $QtyVal[0] = $QtyVal [1]
    return 1
Case $QtyVal[0] = $QtyVal [2]
    return 2
Case $QtyVal[0] = $QtyVal [3]
    return 3
Case $QtyVal[0] = $QtyVal [4]
    return 4
EndSelect
EndFunc
Func GetPrice($CardName);Pass card name to pull prioce from list
    Dim $Arrayline[999]
    Dim $row
    Dim $i

    $count = 1
    _FileReadToArray(@DesktopDir & "\mtgobot\Price.txt", $Arrayline)
    ;_ArrayDisplay($Arrayline)
            $row = _ArraySearch($Arrayline, StringTrimLeft(StringTrimRight($CardName,2),2), 0, 0, 0, 1)+1
            While $row = 0
                $str = StringTrimLeft(StringTrimRight($sArray[1],$count),$count)
                $row = _ArraySearch($Arrayline, $str, 0, 0, 0, 1)+1
                If $str = "" Then
                    return "Unrecognized Card"
                    EndIf
                $count += 1
            WEnd
    return $Arrayline[$row]
EndFunc
Func CheckTix();OCR result for available tix
$left = 16
$right = 104
$top = 108
$bottom = 122
    $sTargetImage = @DesktopDir & "\mtgobot\OCR_tgt.jpg"
    _ScreenCapture_Capture($sTargetImage, $left, $top, $right, $bottom, $fCursor = False)
    $miDoc = ObjCreate("MODI.Document")
$miDocView = ObjCreate("MiDocViewer.MiDocView")

$Viewer = GUICreate ( "Embedded MODI Viewer", 640, 580,(@DesktopWidth-640)/2, (@DesktopHeight-580)/2)
GUICtrlCreatePic ( $sTargetImage, 320, 290, 0, 0)
GUICtrlSetResizing ($Viewer, $GUI_DOCKAUTO)
GUISetBkColor(0x000000)
GUISetState ()
$MiDocView.Document = $miDoc
$MiDocView.SetScale (1, 1)
;_ScreenCapture_Capture($sTargetImage, 350, 250, 750, 600, $fCursor = False)
_ScreenCapture_Capture($sTargetImage, 450, 350, 650, 500, $fCursor = False)
GUISetState (@SW_HIDE)
$miDoc.Create($sTargetImage)
;$miDoc.Ocr($miLANG_ENGLISH, True, False)
$miDoc.Ocr

$i = 0
$str = ""
For $oWord in $miDoc.Images(0).Layout.Words

    $str = $str & " " & $oWord.text
    $sArray [$i] = $oWord.text
    $i += 1
Next

ConsoleWrite("FROM GETNAME: " & $str & @CrLf)
$miDoc.Close

_WinAPI_DeleteObject($miDoc)
_WinAPI_DeleteObject($miDocView)


return $str
EndFunc
Func GetName($j);OCR result for the player's name
$left = 52
$right = 209
$top = 595+$j
$bottom = 610+$j
    $sTargetImage = @DesktopDir & "\mtgobot\OCR_tgt"&$j&".jpg"
    _ScreenCapture_Capture($sTargetImage, $left, $top, $right, $bottom, $fCursor = False)
    $miDoc = ObjCreate("MODI.Document")
$miDocView = ObjCreate("MiDocViewer.MiDocView")

$Viewer = GUICreate ( "Embedded MODI Viewer", 640, 580,(@DesktopWidth-640)/2, (@DesktopHeight-580)/2)
GUICtrlCreatePic ( $sTargetImage, 320, 290, 0, 0)
GUICtrlSetResizing ($Viewer, $GUI_DOCKAUTO)
GUISetBkColor(0x000000)
GUISetState ()
$MiDocView.Document = $miDoc
$MiDocView.SetScale (1, 1)
;_ScreenCapture_Capture($sTargetImage, 350, 250, 750, 600, $fCursor = False)
_ScreenCapture_Capture($sTargetImage, 450, 350, 650, 500, $fCursor = False)
GUISetState (@SW_HIDE)
$miDoc.Create($sTargetImage)
;$miDoc.Ocr($miLANG_ENGLISH, True, False)
$miDoc.Ocr

$i = 0
$str = ""
For $oWord in $miDoc.Images(0).Layout.Words

    $str = $str & " " & $oWord.text
    $sArray [$i] = $oWord.text
    $i += 1
Next

ConsoleWrite("FROM GETNAME: " & $str & @CrLf)
$miDoc.Close

_WinAPI_DeleteObject($miDoc)
_WinAPI_DeleteObject($miDocView)


return $str
EndFunc
Func waitForTrade();Wait until do you want to trade dialog pops up and then commence trading
;Variables for checksum location for looking for beginning of trade
$top = 415
$left = 500
$bottom = 420
$right = 505
While 1
$startTime = TimerInit()
    while 1
        if TimerDiff($startTime) > 300000 then; run an ad if it's been idle more than 5 minutes
            Ad()
            $startTime = TimerInit(); reset the timer
            endif
        If _IsPressed("1B", $dll) Then
            return
        EndIf
            $guimsg = GUIGetMsg()
    Select
    Case $guimsg = $stop
        return
    Case $guimsg = -3
        Close()
    EndSelect
        Sleep(100)
    If PixelChecksum(482,344,566,353) = 939919727 Then;Go if trade pops up
        $goto = enterTrade()
        If $goto = "GuiWait" Then
            Return
        ElseIf $goto = "waitForTrade" Then
            ExitLoop
        EndIf
    EndIf
WEnd
WEnd
    EndFunc
Func enterTrade();Final clicks to get into the trade

        $checksum = PixelGetColor(522,258);click to enter the trade until it goes
        While PixelGetColor(522,258) = $checksum
        $x = 455
        $y = 448
    MouseClick("left",$x,$y, 1, 0)
    Sleep(100)
    WEnd
        $x = 783
        $y = 45
        sleep(1000)
    $checksum = PixelChecksum(8,200,50,500);click to float the chat window in a flat box until it changes
    while $checksum = PixelChecksum(8,200,50,500)
    MouseClick("left",$x,$y, 1, 0)
        Sleep(100)
    Wend
    sleep(200)
    $temp = 1; the trade is proceeding from the beginning with no errors known

    $goto = SellCards()
    Select
        Case $goto = "waitForTrade"
            Return
        Case $goto = "GuiWait"
            Return "GuiWait"
    EndSelect

EndFunc
Func GetPlayer();Get the player's Name
Dim $miDoc, $Doc
Dim $str
Dim $oWord
Dim $sArray[500]
Dim $count
Dim $miLayout

;take screenshot
    $sTargetImage = @DesktopDir & "\mtgobot\Player_tgt.jpg"
    _ScreenCapture_Capture($sTargetImage, 37, 260, 291, 289, $fCursor = False);233

$miDoc = ObjCreate("MODI.Document")
$miDocView = ObjCreate("MiDocViewer.MiDocView")

$Viewer = GUICreate ( "Embedded MODI Viewer", 640, 580,(@DesktopWidth-640)/2, (@DesktopHeight-580)/2)
GUICtrlCreatePic ( $sTargetImage, 320, 290, 0, 0)
GUICtrlSetResizing ($Viewer, $GUI_DOCKAUTO)
GUISetBkColor(0xFFFFFF)
GUISetState ()
$MiDocView.Document = $miDoc
$MiDocView.SetScale (1, 1)
_ScreenCapture_Capture($sTargetImage, 250, 250, 750, 600, $fCursor = False)
GUISetState (@SW_HIDE)
$miDoc.Create(@DesktopDir & "\mtgobot\Player_tgt.jpg")
$miDoc.Ocr($miLANG_ENGLISH, True, False)

$i = 0

For $oWord in $miDoc.Images(0).Layout.Words
    $str = $str & $oWord.text & @CrLf
        ConsoleWrite("FROM GETPLAYER: " & $oWord.text & @CrLf)
    $sArray [$i] = $oWord.text
    $i += 1
Next

return $sArray [0]
EndFunc
Func SellCards();Check for changes and manage sub commands to give player info
    If $temp = 1 Then;initalize the trade and clear credit, tickets taken
    $Credit = 0
    $Player = GetPlayer()
    _FileReadToArray(@DesktopDir & "\mtgobot\Player_Credit.txt", $PlayerArray)
    $PlayerLocation = _ArraySearch($PlayerArray,$Player)
    If $PlayerLocation > 0 Then;This loads the credit from the credit log if there is any for the player
        $Credit = $PlayerArray [$PlayerLocation+1]
        EndIf

    sendMessage("I will send card prices you select. " & $Player & " you have " & $Credit & " Credits -- TradeBot Ultra")
    $startTime = TimerInit()
    $ticketTaken = 0
;This might be unnecessary $confirmed = 0
EndIf

    $checksum = PixelGetColor(810,65); here we click confirm trade to avoid the hassle of asking "are you done"
                                    ;If they choose more cards, the button must be reclicked
    While PixelGetColor(810,65) = $checksum
    MouseClick("left",765,72, 1, 0)
    sleep(100)
    $count += 1
    If $count > 20 Then GuiWait()
    WEnd

        $checksum = PixelChecksum(67, 557, 77, 564)
                if PixelChecksum(470,320,500, 330) = 3185144375 then;the player has withdrawn from the trade
            ResetFromWithdraw()
            return "waitForTrade"
        endif
        While $checksum = PixelChecksum(67, 557, 77, 564)
            Sleep(100)
        If _IsPressed("1B", $dll) Then;Check for the escape key being presseed
            return "GuiWait"
        EndIf
            $guimsg = GUIGetMsg()
        Select
            Case $guimsg = $stop
                return "GuiWait"
            Case $guimsg = -3
                Close()
        EndSelect

        If PixelGetColor(721,80) = 0x000000 Then
            performThisTrade()
        EndIf
        WEnd

            While 1; Making sure that the confirm trade button has been clicked
            PixelSearch(362,59,372,75,0xBAC8CD,5)
            If Not @error Then
                ExitLoop
            EndIf
            MouseClick("left",339,71, 1, 0)
            sleep(100)
            WEnd

        $j = 0
        $Price = 0
        Sleep(100)
        While 1
        PixelSearch(60,598+$j,100,612+$j,0xEBE2AF);slightly lower to not check final line
        If @error Then
            ExitLoop
        EndIf
        $CardName [$j] = GetName($j)
        $CardQty [$j] = GetQty($j)
        $CardPrice [$j] = GetPrice($CardName[$j])
        If $CardPrice [$j] = "Unrecognized Card" Then
            sendMessage($CardName[$j] & " is an" & $CardPrice[$j] & ".  This error has been added to my log.  If you wish to continue trading, return this card.")
            FileOpen(@DesktopDir & "\mtgobot\priceerror.txt", 1)
            $str = @MON & "/" & @WDAY & "/" & @YEAR & @TAB & $CardName[$j] & @TAB & $Player
            FileWrite(@DesktopDir & "\mtgobot\priceerror.txt", $str)
            FileClose(@DesktopDir & "\mtgobot\priceerror.txt")
            $temp = 0
            SellCards()
            EndIf
        sendMessage($CardName[$j] & " (" & $CardPrice[$j] & ")")
        $Price = $Price + $CardQty[$j]*$CardPrice[$j]
        $j = $j + 17
        WEnd
        sendMessage("total is " & $Price & " When you are finished click confirm.")

        $TixQty = Ceiling($Price)
        If $TixQty > $ticketTaken + $Credit Then
        If TakeTickets($TixQty-$ticketTaken) = "waitForTrade" Then
            return "waitForTrade"
        EndIf
        EndIf

        MouseClick("left",339,76, 1, 10)

        if TimerDiff($startTime) > $maxtime then
            abortTrade()
            return "waitForTrade"
        endif

EndFunc
Func sendMessage($messageString);sends a message to the undocked, large chat
    MouseClick("left",67, 218, 5)
    Send($messageString)
    Send("{ENTER}")
EndFunc
Func resetFromWithdraw()
    $checksum = PixelGetColor(512,240)
    While $checksum = PixelGetColor(512,240)
    MouseClick("left",513,450)
    sleep(100)
    WEnd
    sleep(1000)
EndFunc
Func TakeTickets($TixQty);take tickets and store info in a log
    For $i = 1 to $TixQty

            MouseClickDrag("left",158, 36, 158, 180)
        IF Not CheckTix() = "Event Ticket" Then
            sendMessage("Make Tickets Tradeable")
            sleep(300)
            abortTrade()
            return "waitForTrade"
        EndIF
            MouseClickDrag("left",158, 180, 158, 36)
        $checksum = PixelChecksum(451, 555, 476, 564)
        While PixelChecksum(451, 555, 476, 564) = $checksum
                MouseClick("left",19 , 118,2,10)
                Sleep(500)
            WEnd

    Next
    $ticketTaken = $ticketTaken + $TixQty
EndFunc
Func performThisTrade();finalize trade

    $checksum = PixelChecksum(350,50,360,60)
    while $checksum = PixelChecksum(350,50,360,60)
        sleep(100)
        MouseClick("left",363,52)
    wend
    Sleep(1000)
        $checksum = PixelChecksum(350,350,450,450)
    while $checksum = PixelChecksum(350,350,450,450)
        sleep(100)
        $checksum = PixelChecksum(67, 557, 77, 564)
        if PixelChecksum(470,320,500, 330) = 3185144375 then
        ResetFromWithdraw()
        endif
        MouseClick("left",513,529)
    wend

    $sFile = FileOpen(@DesktopDir & "\mtgobot\Player_credit.txt",2)
    $Credit = $Credit + $ticketTaken - $Price
                FileOpen(@DesktopDir & "\mtgobot\tradelog.txt", 1)
            FileWrite(@DesktopDir & "\mtgobot\tradelog.txt", @MON & "/" & @WDAY & "/" & @YEAR & @TAB & $Player & @Tab & "Paid " & $Price & @Tab & "used " & $ticketTaken & " tickets, recieved " & $Credit & " credit")
            FileClose(@DesktopDir & "\mtgobot\tradelog.txt")
$row = _ArraySearch($PlayerArray,$Player)
If @error Then

_ArrayAdd($PlayerArray,$Player)
_ArrayAdd($PlayerArray,$Credit)
Else
$PlayerArray[$PlayerLocation+1] = $Credit
EndIf
_FileWriteFromArray(@DesktopDir & "\mtgobot\Player_credit.txt", $PlayerArray)
    $checksum = PixelGetColor(281,140)
        while $checksum = PixelGetColor(281,140)
        sleep(100)
        MouseClick("left",292,44)
    wend
        sleep(1000)
        MouseClick("left",514,527)
        sleep(1000)
    waitForTrade()
    FileClose($sFile)
EndFunc
Func abortTrade()
    MouseClick("left",437 ,76)
    sleep(200)
    MouseClick("left",454 ,452)
    sleep(2000)
    MouseClick("left",509 ,452)
    sleep(5000)
EndFunc

Func Update();grab newest prices off the internet
$Update = 1
If $Update = 1 Then;update pricelists
    FileDelete(@DesktopDir & "\mtgobot\Price.txt")

    ListUpdate("SHM");shadowmoor
    ListUpdate("MOR");morningtide
    ListUpdate("LRW");lorwyn
    ListUpdate("FUT");futuresight
    ListUpdate("PLC");planar chaos
    ListUpdate("TSP");time spiral
    ListUpdate("CSP");coldsnap
    ListUpdate("10TH");tenth edition


Else
    msgbox(0, "Error", "You have disabled this feature")
EndIf
EndFunc

Func ListUpdate($CardSet);get price results for specified set
Dim $Arrayline[999]
Dim $PriceList[999][10]
Dim $col
Dim $row
Dim $oHTTP
Dim $HTMLSource
Dim $i

        $oHTTP = ObjCreate("winhttp.winhttprequest.5.1")
    $oHTTP.Open("GET","http://www.magictraders.com/cgi-bin/set_query.cgi?set="&$CardSet&"&excel=true")
    $oHTTP.Send()
    $HTMLSource = $oHTTP.Responsetext
    $HTMLSource = StringTrimLeft($HTMLSource, StringInStr($HTMLSource, "Card")-1)
    $HTMLSource = StringReplace($HTMLSource,@LF,"|");couldn't get it without this intermediate step, unsure why
    $Arrayline = StringSplit($HTMLSource, "|")
$col = 1
$row = 0
$i = 1
                for $col = 1 to 8
                    $PriceList[$row][$col] = $Arrayline[$i]
                    $i = $i + 1
                Next
                $row = 1
      While $i <= $Arrayline[0]-8
                for $col = 1 to 8
                    $PriceList[$row][$col] = $Arrayline[$i]
                    $i = $i + 1
                Next
                $row = $row + 1
            WEnd
            $sFile = FileOpen(@DesktopDir & "\mtgobot\Price.txt", 1)
            _FileWriteFromArray($sFile, $Arrayline, 1)
            FileClose($sFile)
        ;Run("Notepad.exe " & @DesktopDir & "\mtgobot\Price.txt")
            FileClose($sFile)

EndFunc

bot.au3


Share this post


Link to post
Share on other sites



I don't play this game but this script is helpful in learning.

Thanks for the share!

Share this post


Link to post
Share on other sites

#3 ·  Posted (edited)

u need a few more PixelChecksum to make it more stable

as in func ad u open windows from the dock i take it but u dont have a checksum or a other way to check if the window is open so if u are laging or mtgo is like it does then u will just send a message in no room but the bot thinks it has

Edited by thenewkid

some of my scripts check them out and give feedback so i can learn from them :)autoclicker a autoclickernote taker a script to take notes with

Share this post


Link to post
Share on other sites

Hi there Newkid,

I left you a message! :)

Share this post


Link to post
Share on other sites
Guest
This topic is now closed to further replies.
Sign in to follow this
Followers 0
