New member

[Heron]

Hello fellow autoitters,

I'm a new member because I wanted to show my first AutoIT project and get your feedback. It's a launcher/macro tool like KeyBreeze and Launchy but able to run AutoIT macro's.

But now I've to post 5 messages first...

I have fallen in love with AutoIT a few month ago and like it very much because of the simplicity and fun factor of it. Also I'm enjoying the helpfull and respectfull atmosphere of this forum.

Ok, 4 posts more to go

[CodyBarrett]

WELCOME to the forums...

lol

[Heron]

WELCOME to the forums...

lol

Well, thanks

And a question at the same time: is there a IE for AutoIT that you could recommend? Now I use SciTE, it's ok but I miss a debug facility.

[Jos]

Well, thanks

.. Now I use SciTE, it's ok but I miss a debug facility.

Debugging is something that would have to be supported by AutoIt3 internally. using another IDE will not help much.

I have added some LUA functionality that allow for easy Debugging/Tracing by means of adding Consolewrite statements.

The FULL installer of SciTE4AutoiT3 is required for this.

Jos

[Heron]

Debugging is something that would have to be supported by AutoIt3 internally. using another IDE will not help much.

I have added some LUA functionality that allow for easy Debugging/Tracing by means of adding Consolewrite statements.

The FULL installer of SciTE4AutoiT3 is required for this.

Jos

Thanks Jos for your reply. I saw a IDE in VB some time ago but i think it uses a kind of trick indeed to simulate debugging functionality. I was thinking of making a function myself that would allow for executing manually entered statements in the middle of a program. That way you could watch the value of a variable or even assign a value to an application value. Is there already made such an approach that you know of? (before inventing the wheel again)

[Jos]

Thanks Jos for your reply. I saw a IDE in VB some time ago but i think it uses a kind of trick indeed to simulate debugging functionality. I was thinking of making a function myself that would allow for executing manually entered statements in the middle of a program. That way you could watch the value of a variable or even assign a value to an application value. Is there already made such an approach that you know of? (before inventing the wheel again)

Yeap, there is a debugger made by Stumpii in the Examples forum that does something like that.

http://www.autoitscript.com/forum/index.php?showtopic=21834

[Heron]

Yeap, there is a debugger made by Stumpii in the Examples forum that does something like that.

http://www.autoitscript.com/forum/index.php?showtopic=21834

Thanks, I will give it a try. It looks promising!

[DisabledMonkey]

Hey,

I'm new here to the forum also and am also trying to get 5 posts so I can post my first program and get some feedback. I created an ICMP messenger using Nicolas Ricquemaque's Winpcap udf.

http://www.autoitscript.com/forum/index.ph...st&p=667070

Here's the code if anyone wants to look at it before I am able to post it on the example scripts forum.

CODE

#Include <Array.au3>

#include <GUIConstants.au3>

#Include <GuiEdit.au3>

#Include <EditConstants.au3>

#include <WindowsConstants.au3>

#include <Constants.au3>

#include <GuiIPAddress.au3>

#include <String.au3>

#include <ComboConstants.au3>

#include <GDIPlus.au3>

#include <Winpcap.au3>

; GUI

$GUI = GuiCreate("ICMP Messenger", 410, 290, -1, -1, -1, $WS_EX_TOOLWINDOW+$WS_EX_TOPMOST)

; MENU's

$filemenu = GuiCtrlCreateMenu("File")

$aboutmenu = GuiCtrlCreateMenu("About")

; File Menu

$Broadcastmenu = GuiCtrlCreateMenuItem("Set IP to Broadcast Address", $filemenu)

$Quitmenu = GuiCtrlCreateMenuItem("Quit", $filemenu)

; About Menu

$aboutmenuselect = GuiCtrlCreateMenuItem("About", $aboutmenu)

; CONTEXT MENU

$contextMenu = GuiCtrlCreateContextMenu()

GuiCtrlCreateMenuItem("Context Menu", $contextMenu)

GuiCtrlCreateMenuItem("", $contextMenu)

GuiCtrlCreateMenuItem("&Properties", $contextMenu)

; CTRLS

$IP = _GUICtrlIpAddress_Create($GUI,85,5,135,23)

GUICtrlCreateLabel ( "Send To IP :", 20, 9, 60)

GUICtrlSetFont(-1,8)

GUICtrlSetBkColor(-1, 0x000000)

GUICtrlSetColor(-1, 0xC4C4C4)

$message = GUICtrlCreateEdit("", 20, 75, 370, 140, $ES_MULTILINE + $ES_READONLY + $WS_VSCROLL)

GUICtrlSetBkColor(-1, 0x000000)

GUICtrlSetColor(-1, 0xC4C4C4)

$text = GuiCtrlCreateInput("", 20, 230, 300, 20)

GUICtrlSetBkColor(-1, 0x000000)

GUICtrlSetColor(-1, 0xC4C4C4)

GUISetBkColor(0x000000)

GUISetFont(9, 400, 0, "Tahoma")

WinSetTrans("ICMP Messenger", "", 230)

$start = GUICtrlCreateButton ( "Start", 250, 5, 60)

GUICtrlSetBkColor(-1, 0x000000)

GUICtrlSetColor(-1, 0xC4C4C4)

$stop = GUICtrlCreateButton ( "Stop", 330, 5,60)

GUICtrlSetBkColor(-1, 0x000000)

GUICtrlSetColor(-1, 0xC4C4C4)

$send = GUICtrlCreateButton ( "Send", 330, 227,60)

GUICtrlSetBkColor(-1, 0x000000)

GUICtrlSetColor(-1, 0xC4C4C4)

$winpcap=_PcapSetup()

If ($winpcap=-1) Then

MsgBox(16,"Pcap error !","WinPcap not found !")

exit

EndIf

$pcap_devices=_PcapGetDeviceList()

If ($pcap_devices=-1) Then

MsgBox(16,"Pcap error !",_PcapGetLastError())

exit

EndIf

GUICtrlCreateLabel ( "Interface :", 20, 45, 60)

GUICtrlSetFont(-1,8)

GUICtrlSetBkColor(-1, 0x000000)

GUICtrlSetColor(-1, 0xC4C4C4)

$interface=GUICtrlCreateCombo("", 85, 42, 305,default,$CBS_DROPDOWNLIST)

GUICtrlSetBkColor(-1, 0x000000)

GUICtrlSetColor(-1, 0xC4C4C4)

For $i = 0 to Ubound($pcap_devices)-1

GUICtrlSetData(-1, $pcap_devices[$i][1])

Next

GUISetState()

$i=0

$pcap=0

$packet=0

$pcapfile=0

Global $MACS[500]

Opt("GuiOnEventMode", 1)

GUICtrlSetOnEvent($start,"Start")

GUICtrlSetOnEvent($stop,"Stop")

GUICtrlSetOnEvent($text, "Packetize")

GUICtrlSetOnEvent($send,"Packetize")

HotKeySet("{Enter}","Packetize")

GUICtrlSetOnEvent($aboutmenuselect,"About")

GUISetOnEvent($GUI_EVENT_CLOSE, "Quit")

GUICtrlSetOnEvent($broadcastmenu, "SetBroadcast")

GUICtrlSetOnEvent($Quitmenu,"Quit")

While 1

$ICMPmessage = ""

If IsPtr($pcap) Then ; If $pcap is a Ptr, then the capture is running

$time0=TimerInit()

While (TimerDiff($time0)<500) ; Retrieve packets from queue for maximum 500ms before returning to main loop, not to "hang" the window for user

$packet=_PcapGetPacket($pcap)

If IsInt($packet) Then ExitLoop

If IsArray($packet) = 1 Then

$ICMPmessage = evalPacket($packet[3])

EndIf

If $ICMPmessage <> "" Then

_GUICtrlEdit_AppendText($message, $ICMPmessage & @CRLF)

EndIf

Wend

EndIf

WEnd

Func evalPacket($data) ; Quick example packet dissector....

Local $macdst=StringMid ($data,3,2)&":"&StringMid ($data,5,2)&":"&StringMid ($data,7,2)&":"&StringMid ($data,9,2)&":"&StringMid ($data,11,2)&":"&StringMid ($data,13,2)

Local $macsrc=StringMid ($data,15,2)&":"&StringMid ($data,17,2)&":"&StringMid ($data,19,2)&":"&StringMid ($data,21,2)&":"&StringMid ($data,23,2)&":"&StringMid ($data,25,2)

Local $ethertype=BinaryMid ( $data, 13 ,2 )

If $ethertype="0x0800" Then

Local $src=Number(BinaryMid ($data, 27 ,1))&"."&Number(BinaryMid ($data, 28 ,1))&"."&Number(BinaryMid ($data, 29 ,1))&"."&Number(BinaryMid ($data, 30 ,1))

Local $dst=Number(BinaryMid ($data, 31 ,1))&"."&Number(BinaryMid ($data, 32 ,1))&"."&Number(BinaryMid ($data, 33 ,1))&"."&Number(BinaryMid ($data, 34 ,1))

Switch BinaryMid ($data, 24 ,1)

Case "0x01" ; Match ICMP Packet

$got = StringTrimLeft($data,86)

If StringLeft($got,36) = "3C69636D704D657373656E676572312E303E" Then ; If Matches <icmpMessenger1.0>

$cutcode = _HexToString(StringTrimLeft($got,36))

If $cutcode <> "" Then

return $src & ": " & $cutcode

EndIf

EndIf

EndSwitch

EndIf

return ""

EndFunc

Func Packetize()

If _GUICtrlIpAddress_IsBlank($IP) <> True Then

$sip = StringSplit(@IPAddress1,".")

$dip = _GUICtrlIpAddress_GetArray($IP)

;Ethernet Header

$etherHeader = GetDestinationMac(_GUICtrlIpAddress_Get($IP)) ;Destination Mac

$etherHeader &= GetLocalMac(@IPAddress1) ;Source Mac

$etherHeader &= "0800" ;Protocol

;IP Header

$ipHeader = "45" ;Version / Header Length

$ipHeader &= "00" ;Type of Service

$ipHeader &= "003c" ;Length

$ipHeader &= "00a5" ;Identification

$ipHeader &= "0000" ;Flags / Fragment offset

$ipHeader &= "80" ;Time to Live

$ipHeader &= "01" ;Protocol

$ipHeader &= "0000" ;IP Checksum

$ipHeader &= hex($sip[1],2) & hex($sip[2],2) & hex($sip[3],2) & hex($sip[4],2) ;Source IP Address

$ipHeader &= hex($dip[0],2) & hex($dip[1],2) & hex($dip[2],2) & hex($dip[3],2) ;Destination IP Address

;ICMP Header

$icmpHeader = "08" ;Type

$icmpHeader &= "00" ;Code

$icmpHeader &= "0000" ;ICMP Checksum

$icmpHeader &= "0200" ;ID

$icmpHeader &= "0100" ;Sequence number

;Data

$data = _StringToHex("<icmpMessenger1.0>")

$data &= _StringToHex(GUICtrlRead($text))

;Create Packet

$packet = $etherHeader & $ipHeader & $icmpHeader & $data

;Send Packet

$success = _PcapSendPacket($pcap,_HexToString($packet))

If $pcap = 0 Then

_GUICtrlEdit_AppendText($message, "Error: Please Start Messenger." & @CRLF)

Else

Clear()

EndIf

Else

_GUICtrlEdit_AppendText($message, "Error: Please enter an IP Address to send messages to." & @CRLF)

EndIf

EndFunc

Func Start()

$prom=0

$int=""

If (GUICtrlRead($interface)="Pcap capture file") Then

$file=FileOpenDialog ( "Pcap file to open ?", ".", "Pcap (*.pcap)|All files (*.*)" ,1 )

$int="file://"&$file

Else

For $n = 0 to Ubound($pcap_devices)-1

If $pcap_devices[$n][1]=GUICtrlRead($interface) Then

$int = $pcap_devices[$n][0]

EndIf

Next

EndIf

$pcap=_PcapStartCapture($int,"",$prom)

If ($pcap=-1) Then

_GUICtrlEdit_AppendText($message, "Error: " & _PcapGetLastError() & @CRLF)

Else

$linktype=_PcapGetLinkType($pcap)

If ($linktype[1]<>"EN10MB") Then

_GUICtrlEdit_AppendText($message, "Error: This example only works for Ethernet captures." & @CRLF)

Endif

GUICtrlSetState ($stop, $GUI_ENABLE)

GUICtrlSetState ($start, $GUI_DISABLE)

_GUICtrlEdit_AppendText($message, "----------------------------------------------------------------------------------------------------" & @CRLF)

_GUICtrlEdit_AppendText($message, "Session Started: " & @Hour & ":" & @Min & " - " & @MON & "/" & @MDAY & "/" & @YEAR & @CRLF)

_GUICtrlEdit_AppendText($message, "----------------------------------------------------------------------------------------------------" & @CRLF)

EndIf

EndFunc

Func Stop()

If $pcap <> -1 Then

_PcapStopCapture($pcap)

$pcap=-1

GUICtrlSetState ($stop, $GUI_DISABLE)

GUICtrlSetState ($start, $GUI_ENABLE)

_GUICtrlEdit_AppendText($message, "----------------------------------------------------------------------------------------------------" & @CRLF)

_GUICtrlEdit_AppendText($message, "Session Ended: " & @Hour & ":" & @Min & " - " & @MON & "/" & @MDAY & "/" & @YEAR & @CRLF)

_GUICtrlEdit_AppendText($message, "----------------------------------------------------------------------------------------------------" & @CRLF)

EndIf

EndFunc

Func GetDestinationMac($ip)

$Pos = _ArraySearch($MACS, $ip, 0, 0, 0, True)

If $Pos <> -1 Then

$split = StringSplit($MACS[$Pos],"|")

return $split[2]

Else

Ping($ip)

$foo = Run(@ComSpec & " /c arp -g " & $ip, @SystemDir, @SW_HIDE, $STDOUT_CHILD)

While 1

$line = StdoutRead($foo)

If $line <> "" Then

$split = StringSplit($line,$ip,1)

$strip = StringLeft(StringStripWS($split[2],8),17)

$mac = StringReplace($strip,"-","")

return $mac

EndIf

WEnd

EndIf

EndFunc

Func GetLocalMac($ip)

$Pos = _ArraySearch($MACS, $ip, 0, 0, 0, True)

If $Pos <> -1 Then

$split = StringSplit($MACS[$Pos],"|")

return $split[2]

Else

$foo = Run(@ComSpec & " /c nbtstat -A " & $ip, @SystemDir, @SW_HIDE, $STDOUT_CHILD)

While 1

$line = StdoutRead($foo)

If $line <> "" Then

$mac = StringSplit($line,"MAC Address = ",1)

If $mac[0] <> 1 Then

$mac = StringStripWS(StringReplace($mac[2],"-",""),8)

_ArrayAdd($MACS, $ip & "|" & $mac)

return $mac

EndIf

EndIf

WEnd

EndIf

EndFunc

Func Clear()

GUICtrlSetData($text, "")

EndFunc

Func SetBroadcast()

_GUICtrlIpAddress_Set($IP,_BroadcastIP())

EndFunc

Func Quit()

Exit

EndFunc

Func About()

Opt("GuiOnEventMode", 0)

GUISetState(@SW_DISABLE,$GUI)

$AboutGUI = GUICreate("ABOUT ICMP Messenger", 410, 350,-1,-1,-1,-1,$GUI)

$hWnd = WinGetHandle("ABOUT ICMP Messenger")

WinSetTrans("ABOUT ICMP Messenger", "", 230)

GUISetState(@SW_SHOW)

;Create Monkey

_GDIPlus_Startup ()

$Graphic = _GDIPlus_GraphicsCreateFromHWND ($hWnd)

FileInstall("C:\monkey.gif", @scriptdir&"\monkey.gif",0)

$ParticleBitmap = _GDIPlus_BitmapCreateFromFile(@scriptdir & "\monkey.gif")

_AntiAlias($Graphic, 4)

_GDIPlus_GraphicsDrawImageRect($Graphic, $ParticleBitmap, 0, 0, 410, 350)

_GDIPlus_GraphicsFillEllipse ($Graphic, 206 , 168, 4, 7)

_GDIPlus_GraphicsFillEllipse ($Graphic, 216 , 168, 4, 7)

;End Create Monkey

$lastPos = MouseGetPos()

While 1

$mp = MouseGetPos()

$newx = $mp[0]

$newy = $mp[1]

If $newx <> $lastpos[0] Or $newy <> $lastpos[1] Then

$winPos = WinGetPos("ABOUT ICMP Messenger")

$eyeXlocation = $winPos[0] + 251

$eyeYlocation = $winPos[1] + 233

$percentx = (($newx - $eyeXlocation) / @DesktopWidth)

$percenty = (($newy - $eyeYlocation) / @DesktopHeight)

$positionx = Int(5*$percentx)

$positiony = Int(4*$percenty)

_GDIPlus_GraphicsDrawImageRect($Graphic, $ParticleBitmap, 0, 0, 410, 350)

If $positionx = 0 Then

_GDIPlus_GraphicsFillEllipse ($Graphic, 216+$positionx, 168+$positiony, 4, 7)

$positionx +=1

_GDIPlus_GraphicsFillEllipse ($Graphic, 206+$positionx, 168+$positiony, 4, 7)

Else

_GDIPlus_GraphicsFillEllipse ($Graphic, 216+$positionx, 168+$positiony, 4, 7)

_GDIPlus_GraphicsFillEllipse ($Graphic, 206+$positionx, 168+$positiony, 4, 7)

EndIf

EndIf

$lastPos[0] = $newx

$lastPos[1] = $newy

$msg = GUIGetMsg()

If $msg = $GUI_EVENT_CLOSE Then

ExitLoop

EndIf

sleep(20)

Wend

Opt("GuiOnEventMode", 1)

_GDIPlus_BitmapDispose($ParticleBitmap)

_GDIPlus_GraphicsDispose ($Graphic)

_GDIPlus_Shutdown()

GUIDelete($AboutGUI)

GUISetState(@SW_ENABLE,$GUI)

EndFunc

Func _SubnetMask($strIP = @IPAddress1)

Local $strEnumKey, $nEnum

Local $strKey = "HKLM\SYSTEM\CurrentControlSet\" & _

"Services\Tcpip\Parameters\Interfaces\"

While 1

$nEnum += 1

$strEnumKey = RegEnumKey($strKey, $nEnum)

If @error <> 0 Then ExitLoop

If RegRead($strKey & $strEnumKey, "DhcpIPAddress") = $strIP Then

Return RegRead($strKey & $strEnumKey, "DhcpSubnetMask")

EndIf

WEnd

Return SetError(1, 0, 0)

EndFunc

Func _BroadcastIP()

$submask = _SubnetMask()

$split_sub = stringsplit($submask,".")

$split_ip = stringsplit(@IPAddress1,".")

$Broadcast = ""

If $split_sub[1] <> 0 Then

for $i = 1 to 4

$Broadcast &= "."&bitOR((255-$split_sub[$i]),$split_ip[$i])

next

Else

return -1

EndIf

$Broadcast = stringmid($Broadcast,2)

return $Broadcast

Endfunc

Func _AntiAlias($Graphics, $iMode)

Local $aResult

$aResult = DllCall($ghGDIPDll, "int", "GdipSetSmoothingMode", "hwnd", $Graphics, "int", $iMode)

If @error Then Return SetError(@error, @extended, False)

Return SetError($aResult[0], 0, $aResult[0] = 0)

EndFunc

I've been programming for less than a year so if you have any suggestions at all I would love to hear them.

And if you have any suggestions on a quick way to get these five posts out of the way, I would love to hear those also.

Thanks for your time,

Disabled Monkey

[Heron]

Hey,

I'm new here to the forum also and am also trying to get 5 posts so I can post my first program and get some feedback. I created an ICMP messenger using Nicolas Ricquemaque's Winpcap udf.

http://www.autoitscript.com/forum/index.ph...st&p=667070

Here's the code if anyone wants to look at it before I am able to post it on the example scripts forum.

I've been programming for less than a year so if you have any suggestions at all I would love to hear them.

And if you have any suggestions on a quick way to get these five posts out of the way, I would love to hear those also.

Thanks for your time,

Disabled Monkey

Tried your code but haven't installed winpcap yet so it quited early. What is de GDI+ stuff for? Is it a graphical representation of traffic?

(I reached 5 posts already. It's easy :-)

[DisabledMonkey]

Tried your code but haven't installed winpcap yet so it quited early. What is de GDI+ stuff for? Is it a graphical representation of traffic?

(I reached 5 posts already. It's easy :-)

GDI+ stuff is for the about page, which won't really look any good without the Monkey.gif, which I forgot to upload.

Here's the picture if your going to try it out.

The about page is just a picture of a monkey with it's eye's following the mouse, that's why I needed GDI+.

Five posts does seem fairly simple, I just hate to spam random topics that I am not interested in and have no good comments or thoughts on.
