Malkey

Text to pixels, image file, encrypted, & back to text.

6 posts in this topic

The CreateASCIIBitmap script sequentially divides up the ASCII equivalent value of each character of a text file into groups of three. The three ASCII numeric values make up the three colour channels of a pixel (RGB).

The resulting string of pixels are made into a bitmap.

A colour matrix is applied to the bitmap. The purpose of this is mainly for enciphering (encoding) the plain pixels to encipher pixels. This also adds or changes the overall colour of the image. The colour depends on the values used in the colour matrix.

The image can be saved as a BMP or PNG image file. A resultant BMP image file is the same size as the TXT file used. A PNG file is not the same size.

The BitmapToASCII script loads the previously created image file.

An inverse matrix of the colour matrix used to create image, is applied to loaded bitmap. This deciphers (decodes) back to the original plain pixels.

The pixel colour channels values are converted back to ASCII text and pasted to NotePad.

Enjoy.

This PNG is an example encrypted text file.


CreateASCIIBitmap
;
#include <GuiConstantsEx.au3>
#include <GDIPlus.au3>
#include <Misc.au3>
#include <string.au3>
#include <WindowsConstants.au3>

Opt('MustDeclareVars', 1)

Global $hGui, $hImage, $hImage2, $hGraphic1, $hGraphicGUI, $hBMPBuff, $iW, $iH, $sString, $Path
Global $aM[5][5] = [[1, 0, 0, 0, 0],[0, 1, 0, 0, 0],[0, 0, 1, 0, 0],[0, 0, 0, 1, 0],[0.3, 0.2, 0.4, 0, 1]]

$sString = FileRead("C:\Program Files\Autoio\Examples\matrixCalc\MatrixUDF_Examples\Matrix.txt")
$Path = FileOpenDialog("Choose Image File", @DesktopDir & "", _
            "Images (*.txt;*.au3;*.ini;*.log)| All (*.*)", 1, "Test.txt")
    If Not @error Then
        $sString = FileRead($Path)
        _CreateASCIIBitmap($sString)
    Else
        Exit
    EndIf

Func _CreateASCIIBitmap($sString)
    Local $Num, $SqrNum, $Extrachars, $sDat, $hBitmap1, $Reslt, $iSize, $hGraphic, $width, $height
    Local $stride, $format, $Scan0, $v_BufferA, $AllPixels, $strLen, $sString1, $sDat, $tMP
    Local $strLen = StringLen($sString)
    $sString &= _StringRepeat(" ", (3 - Mod($strLen, 3)) * (Mod($strLen, 3) <> 0))

    $strLen = StringLen($sString)
    $Num = $strLen / 3;Num of Pixels
    $SqrNum = Int(Sqrt($Num))
    $iW = $SqrNum
    $iH = $SqrNum

    Do
        If $iW <= $iH Then
            $iW += 1
        Else
            $iH += 1
        EndIf
        If (Mod($iW * $iH, 12) = 0 And $iW * $iH >= $Num) Then $Extrachars = (($iW * $iH) - $Num) * 3
    Until (Mod($iW * $iH, 12) = 0 And $iW * $iH >= $Num)

    $sString &= _StringRepeat(" ", $Extrachars)
    ConsoleWrite($iW & "x" & $iH & "   " & Mod(StringLen($sString), 3) & "   srtLen = " & StringLen($sString) & @CRLF)
    $sString1 = StringToBinary($sString)
; Create a GUI for the original image
    $hGui = GUICreate("Text as ACSII Image", $iW, $iH, -1, -1);, $WS_CAPTION)
    GUISetState()

    GUIRegisterMsg(0xF, "MY_PAINT"); Register PAINT-Event 0x000F = $WM_PAINT (WindowsConstants.au3)
; Initialize GDI+ library and load image
    _GDIPlus_Startup()

; Draw original image
    $hGraphicGUI = _GDIPlus_GraphicsCreateFromHWND($hGui)
    $hBMPBuff = _GDIPlus_BitmapCreateFromGraphics($iW, $iH, $hGraphicGUI)
    $hGraphic = _GDIPlus_ImageGetGraphicsContext($hBMPBuff)
    $hBitmap1 = _GDIPlus_BitmapCloneArea($hBMPBuff, 0, 0, $iW, $iH, $GDIP_PXF24RGB)

; Locks a portion of a bitmap for reading or writing
    $Reslt = _GDIPlus_BitmapLockBits($hBitmap1, 0, 0, $iW, $iH, BitOR($GDIP_ILMREAD, $GDIP_ILMWRITE), $GDIP_PXF24RGB);$GDIP_PXF32RGB )

;Get the returned values of _GDIPlus_BitmapLockBits ()
    $width = DllStructGetData($Reslt, "width")
    $height = DllStructGetData($Reslt, "height")
    $stride = DllStructGetData($Reslt, "stride")
    $format = DllStructGetData($Reslt, "format")
    $Scan0 = DllStructGetData($Reslt, "Scan0")
    ConsoleWrite("$width " & $width & @CRLF & _
            "$height " & $height & @CRLF & _
            "$stride " & $stride & @CRLF & _
            "$format " & $format & @CRLF)

    $v_BufferA = DllStructCreate("byte[" & $width * $height * 3 & "]", $Scan0); Create DLL structure for all pixels
    $AllPixels = DllStructSetData($v_BufferA, 1, $sString1)

    _GDIPlus_BitmapUnlockBits($hBitmap1, $Reslt); releases the locked region
;_GDIPlus_GraphicsDrawImage($hGraphic, $hBitmap1, 0, 0)
    _GDIPlus_GraphicsDrawImageRectRectTrans($hGraphic, $hBitmap1, 0, 0)
    _GDIPlus_GraphicsDrawImage($hGraphicGUI, $hBMPBuff, 0, 0)


    Do
        $tMP = _WinAPI_GetMousePos()
        If _WinAPI_WindowFromPoint($tMP) = WinGetHandle($hGui) Then
            ToolTip("Press Ctrl + Left mouse click to save image", DllStructGetData($tMP, "X") + 5, DllStructGetData($tMP, "Y") - 20)
        Else
            ToolTip("")
        EndIf
        If _IsPressed("01") And _IsPressed("11") Then;Left click + Ctrl key to save image
            Do
            Until Not _IsPressed("01")
            Local $PathFile = FileSaveDialog("Choose Image File Name", @DesktopDir & "", _
                    "Images (*.png;*.bmp)| All (*.*)", 1, "AsciiBitmap.png")
            If Not @error Then
                _GDIPlus_ImageSaveToFile($hBMPBuff, $PathFile)
                ShellExecute($PathFile)
            EndIf
        EndIf
        Sleep(10)
    Until GUIGetMsg() = $GUI_EVENT_CLOSE

; Release resources
    _WinAPI_DeleteObject($hBitmap1)
    _GDIPlus_GraphicsDispose($hGraphic)
    _GDIPlus_GraphicsDispose($hGraphicGUI)
    _WinAPI_DeleteObject($hBMPBuff)
    _GDIPlus_ImageDispose($hImage)
    _GDIPlus_ImageDispose($hImage2)
    _GDIPlus_Shutdown()
EndFunc  ;==>_CreateASCIIBitmap

Func _GDIPlus_GraphicsDrawImageRectRectTrans($hGraphics, $hImage, $iSrcX, $iSrcY, $iSrcWidth = "", $iSrcHeight = "", _
        $iDstX = "", $iDstY = "", $iDstWidth = "", $iDstHeight = "", $iUnit = 2)
    Local $tColorMatrix, $x, $hImgAttrib, $iW = _GDIPlus_ImageGetWidth($hImage), $iH = _GDIPlus_ImageGetHeight($hImage)
    If $iSrcWidth = 0 Or $iSrcWidth = "" Then $iSrcWidth = $iW
    If $iSrcHeight = 0 Or $iSrcHeight = "" Then $iSrcHeight = $iH
    If $iDstX = "" Then $iDstX = $iSrcX
    If $iDstY = "" Then $iDstY = $iSrcY
    If $iDstWidth = "" Then $iDstWidth = $iSrcWidth
    If $iDstHeight = "" Then $iDstHeight = $iSrcHeight
    If $iUnit = "" Then $iUnit = 2
;;create color matrix data
    $tColorMatrix = DllStructCreate("float[5];float[5];float[5];float[5];float[5]")

    $x = DllStructSetData($tColorMatrix, 1, $aM[0][0], 1) * DllStructSetData($tColorMatrix, 1, $aM[0][1], 2) * DllStructSetData($tColorMatrix, 1, $aM[0][2], 3) * _
            DllStructSetData($tColorMatrix, 2, $aM[1][0], 1) * DllStructSetData($tColorMatrix, 2, $aM[1][1], 2) * DllStructSetData($tColorMatrix, 2, $aM[1][2], 3) * _
            DllStructSetData($tColorMatrix, 3, $aM[2][0], 1) * DllStructSetData($tColorMatrix, 3, $aM[2][1], 2) * DllStructSetData($tColorMatrix, 3, $aM[2][2], 3) * _
            DllStructSetData($tColorMatrix, 4, $aM[3][3], 4) * DllStructSetData($tColorMatrix, 5, $aM[4][0], 1) * DllStructSetData($tColorMatrix, 5, $aM[4][1], 2) * _
            DllStructSetData($tColorMatrix, 5, $aM[4][2], 3) * DllStructSetData($tColorMatrix, 5, $aM[4][3], 4) * DllStructSetData($tColorMatrix, 5, $aM[4][4], 5)
    $hImgAttrib = DllCall($ghGDIPDll, "int", "GdipCreateImageAttributes", "ptr*", 0)
    $hImgAttrib = $hImgAttrib[1]

    DllCall($ghGDIPDll, "int", "GdipSetImageAttributesColorMatrix", "ptr", $hImgAttrib, "int", 1, _
            "int", 1, "ptr", DllStructGetPtr($tColorMatrix), "ptr", 0, "int", 0)
;;draw image into graphic object with alpha blend
    DllCall($ghGDIPDll, "int", "GdipDrawImageRectRectI", "hwnd", $hGraphics, "hwnd", $hImage, "int", $iDstX, "int", _
            $iDstY, "int", $iDstWidth, "int", $iDstHeight, "int", $iSrcX, "int", $iSrcY, "int", $iSrcWidth, "int", _
            $iSrcHeight, "int", $iUnit, "ptr", $hImgAttrib, "int", 0, "int", 0)
;;clean up
    DllCall($ghGDIPDll, "int", "GdipDisposeImageAttributes", "ptr", $hImgAttrib)
    Return
EndFunc  ;==>_GDIPlus_GraphicsDrawImageRectRectTrans

Func MY_PAINT($hWnd, $msg, $wParam, $lParam)
    If $hWnd = $hGui Then _GDIPlus_GraphicsDrawImageRectRectTrans($hGraphicGUI, $hBMPBuff, 0, 0);_GDIPlus_GraphicsDrawImage($hGraphicGUI, $hBMPBuff, 0, 0)
    Return $GUI_RUNDEFMSG
EndFunc  ;==>MY_PAINT
;

BitmapToASCII

;
#include <GuiConstantsEx.au3>
#include <GDIPlus.au3>
#include <Misc.au3>
#include <string.au3>
#include <WindowsConstants.au3>
#include <Array.au3>

Opt('MustDeclareVars', 1)

Global $hGui, $hImage, $hImage2, $hGraphic1, $hGraphicGUI, $hBMPBuff, $iW, $iH
;Global $aM[5][5] = [[1, 0, 0, 0, 0],[0, 1, 0, 0, 0],[0, 0, 1, 0, 0],[0, 0, 0, 1, 0],[0.3, 0.2, 0.4, 0, 1]]
Global $aInv[5][5] = [[1, 0, 0, 0, 0],[0, 1, 0, 0, 0],[0, 0, 1, 0, 0],[0, 0, 0, 1 , 0],[-0.3, -0.2, -0.4, 0, 1]]
Global $aInv

_BitmapToASCII()

Func _BitmapToASCII()
    Local $Num, $SqrNum, $Extrachars, $sDat, $hBitmap1, $Reslt, $iSize, $hGraphic, $width, $height
    Local $stride, $format, $Scan0, $v_BufferA, $AllPixels, $hbmp
    Local $Path = FileOpenDialog("Choose Image File", @DesktopDir & "", _
            "Images (*.png;*.bmp)| All (*.*)", 1, "AsciiBitmap.png")
    If Not @error Then
        _GDIPlus_Startup()
        Local $hImage = _GDIPlus_ImageLoadFromFile($Path)
    Else
        Exit
    EndIf

    $iW = _GDIPlus_ImageGetWidth($hImage)
    $iH = _GDIPlus_ImageGetHeight($hImage)

; Create a GUI for the original image
    $hGui = GUICreate("Text as ACSII Image", $iW, $iH, -1, -1);, $WS_CAPTION)
    GUISetState()
    GUIRegisterMsg(0xF, "MY_PAINT"); Register PAINT-Event 0x000F = $WM_PAINT (WindowsConstants.au3)

; Initialize GDI+ library and load image
    _GDIPlus_Startup()
;$hImage = _GDIPlus_ImageLoadFromFile(@MyDocumentsDir & "\GDIPlus_Image.png")

; Draw original image
    $hGraphicGUI = _GDIPlus_GraphicsCreateFromHWND($hGui)
    $hBMPBuff = _GDIPlus_BitmapCreateFromGraphics($iW, $iH, $hGraphicGUI)
    $hGraphic = _GDIPlus_ImageGetGraphicsContext($hBMPBuff)
;_GDIPlus_GraphicsDrawImage($hGraphic, $hImage, 0, 0)
    _GDIPlus_GraphicsDrawImageRectRectTrans($hGraphic, $hImage, 0, 0)
    _GDIPlus_GraphicsDrawImage($hGraphicGUI, $hBMPBuff, 0, 0)

    $hBitmap1 = _GDIPlus_BitmapCloneArea($hBMPBuff, 0, 0, $iW, $iH, $GDIP_PXF24RGB)

; Locks a portion of a bitmap for reading or writing
    $Reslt = _GDIPlus_BitmapLockBits($hBitmap1, 0, 0, $iW, $iH, BitOR($GDIP_ILMREAD, $GDIP_ILMWRITE), $GDIP_PXF24RGB)

;Get the returned values of _GDIPlus_BitmapLockBits ()
    $width = DllStructGetData($Reslt, "width")
    $height = DllStructGetData($Reslt, "height")
    $stride = DllStructGetData($Reslt, "stride")
    $format = DllStructGetData($Reslt, "format")
    $Scan0 = DllStructGetData($Reslt, "Scan0")
;ConsoleWrite("$width " & $width & @CRLF & _
;"$height " & $height & @CRLF & _
;"$stride " & $stride & @CRLF & _
;"$format " & $format & @CRLF)

    $v_BufferA = DllStructCreate("byte[" & $width * $height * 3 & "]", $Scan0); Create DLL structure for all pixels
    Local $sDat = DllStructGetData($v_BufferA, 1)
;ConsoleWrite( $sDat & @CRLF)
    $sDat = StringRegExpReplace($sDat, "(.{2})", '\1 ')
    $sDat = StringRegExpReplace($sDat, "(00)", '')
    $sDat = StringRegExpReplace($sDat, "(20 )*$", '')
;ConsoleWrite( $sDat & @CRLF)
    $sDat = StringStripWS($sDat, 8)
;ConsoleWrite( $sDat & @CRLF)
    Local $str1 = BinaryToString($sDat)
;ConsoleWrite("  StrLen = " & StringLen($str1)  &  @CRLF & $str1 &  @CRLF)
    _GDIPlus_BitmapUnlockBits($hBitmap1, $Reslt); releases the locked region
    ClipPut($str1)

    Run("notepad.exe")
    WinActivate("[Class:Notepad]")
    WinWaitActive("[Class:Notepad]", "", 3)
    ControlSend("[Class:Notepad]", "", "Edit1", "^v")

; Loop until user exits
    Do
        If _IsPressed("01") And _IsPressed("11") Then;Left click + Ctrl key to save image
            Do
            Until Not _IsPressed("01")
            Local $PathFile = FileSaveDialog("Choose Image File Name", @DesktopDir & "", _
                    "Images (*.png;*.bmp)| All (*.*)", 1, "AsciiBitmap.png")
            If Not @error Then
                _GDIPlus_ImageSaveToFile($hBitmap1, $PathFile)
                ShellExecute($PathFile)
            EndIf
        EndIf
        Sleep(10)
    Until GUIGetMsg() = $GUI_EVENT_CLOSE

; Release resources
    _WinAPI_DeleteObject($hBitmap1)
    _GDIPlus_GraphicsDispose($hGraphic)
    _GDIPlus_GraphicsDispose($hGraphicGUI)
    _WinAPI_DeleteObject($hBMPBuff)
    _GDIPlus_ImageDispose($hImage)
    _GDIPlus_ImageDispose($hImage2)
    _GDIPlus_Shutdown()
EndFunc  ;==>_BitmapToASCII

Func _GDIPlus_GraphicsDrawImageRectRectTrans($hGraphics, $hImage, $iSrcX, $iSrcY, $iSrcWidth = "", $iSrcHeight = "", _
        $iDstX = "", $iDstY = "", $iDstWidth = "", $iDstHeight = "", $iUnit = 2)
    Local $tColorMatrix, $x, $hImgAttrib, $iW = _GDIPlus_ImageGetWidth($hImage), $iH = _GDIPlus_ImageGetHeight($hImage)
    If $iSrcWidth = 0 Or $iSrcWidth = "" Then $iSrcWidth = $iW
    If $iSrcHeight = 0 Or $iSrcHeight = "" Then $iSrcHeight = $iH
    If $iDstX = "" Then $iDstX = $iSrcX
    If $iDstY = "" Then $iDstY = $iSrcY
    If $iDstWidth = "" Then $iDstWidth = $iSrcWidth
    If $iDstHeight = "" Then $iDstHeight = $iSrcHeight
    If $iUnit = "" Then $iUnit = 2
;;create color matrix data
    $tColorMatrix = DllStructCreate("float[5];float[5];float[5];float[5];float[5]")

    $x = DllStructSetData($tColorMatrix, 1, $aInv[0][0], 1) * DllStructSetData($tColorMatrix, 1, $aInv[0][1], 2) * DllStructSetData($tColorMatrix, 1, $aInv[0][2], 3) * _
            DllStructSetData($tColorMatrix, 2, $aInv[1][0], 1) * DllStructSetData($tColorMatrix, 2, $aInv[1][1], 2) * DllStructSetData($tColorMatrix, 2, $aInv[1][2], 3) * _
            DllStructSetData($tColorMatrix, 3, $aInv[2][0], 1) * DllStructSetData($tColorMatrix, 3, $aInv[2][1], 2) * DllStructSetData($tColorMatrix, 3, $aInv[2][2], 3) * _
            DllStructSetData($tColorMatrix, 4, $aInv[3][3], 4) * DllStructSetData($tColorMatrix, 5, $aInv[4][0], 1) * DllStructSetData($tColorMatrix, 5, $aInv[4][1], 2) * _
            DllStructSetData($tColorMatrix, 5, $aInv[4][2], 3) * DllStructSetData($tColorMatrix, 5, $aInv[4][3], 4) * DllStructSetData($tColorMatrix, 5, $aInv[4][4], 5)
    $hImgAttrib = DllCall($ghGDIPDll, "int", "GdipCreateImageAttributes", "ptr*", 0)
    $hImgAttrib = $hImgAttrib[1]

    DllCall($ghGDIPDll, "int", "GdipSetImageAttributesColorMatrix", "ptr", $hImgAttrib, "int", 1, _
            "int", 1, "ptr", DllStructGetPtr($tColorMatrix), "ptr", 0, "int", 0)
;;draw image into graphic object with alpha blend
    DllCall($ghGDIPDll, "int", "GdipDrawImageRectRectI", "hwnd", $hGraphics, "hwnd", $hImage, "int", $iDstX, "int", _
            $iDstY, "int", $iDstWidth, "int", $iDstHeight, "int", $iSrcX, "int", $iSrcY, "int", $iSrcWidth, "int", _
            $iSrcHeight, "int", $iUnit, "ptr", $hImgAttrib, "int", 0, "int", 0)
;;clean up
    DllCall($ghGDIPDll, "int", "GdipDisposeImageAttributes", "ptr", $hImgAttrib)
    Return
EndFunc  ;==>_GDIPlus_GraphicsDrawImageRectRectTrans

Func MY_PAINT($hWnd, $msg, $wParam, $lParam)
    If $hWnd = $hGui Then _GDIPlus_GraphicsDrawImage($hGraphicGUI, $hBMPBuff, 0, 0)
    Return $GUI_RUNDEFMSG
EndFunc  ;==>MY_PAINT
;

Share this post


Link to post
Share on other sites



Very clever Malkey. I love these kind of stuff :D


Broken link? PM me and I'll send you the file!

Share this post


Link to post
Share on other sites

Brilliant stuff. Swell idea.

Share this post


Link to post
Share on other sites

Very clever Malkey. I love these kind of stuff :D

Indeed.

@OP

You did a way better job of this than I did lol...

I created something that did the same exact thing (Bah deleted attachment here...). I was just starting to code and didn't no squat about GDI or dll calling to get some of the pixel data. Was really slow and sluggish, but it worked :D

Share this post


Link to post
Share on other sites

Ha ha. That is very smart. Nice work Malkey.


When the words fail... music speaks

Share this post


Link to post
Share on other sites

#6 ·  Posted (edited)

It doesn't work for me, when I convert it back I get something else then what the input was.

first I use the "CreateASCIIBitmap" then it creates a png, and then I convert it back with "BitmapToASCII" and then I get the wrong string back.

I might do it wrong?

Nevermind I fixed it, it really looks nice :D

Edited by timgames

Share this post


Link to post
Share on other sites

Create an account or sign in to comment

You need to be a member in order to leave a comment

Create an account

Sign up for a new account in our community. It's easy!


Register a new account

Sign in

Already have an account? Sign in here.


Sign In Now
Sign in to follow this
Followers 0
