GAM

Selecting Syslistview32

10 posts in this topic

#1 ·  Posted (edited)

Hi All,

I have trying to select an object in the 'systlistview32' but not sucessful Can somebody tell on how to select the objects in 'Syslistview32'? Am attaching my UI on which am working, please somebody pitch in here? The window info gives like his...

Thanks

GAM

--------------- WINDOW INFO --------------------------

>>>> Window <<<<
Title:  On-Access Scan Properties
Class:  #32770
Position:   136, 129
Size:   586, 601
Style:  0x94C800CC
ExStyle:    0x00050101
Handle: 0x00030300

>>>> Control <<<<
Class:  SysListView32
Instance:   5
ClassnameNN:    SysListView325
Name:
Advanced (Class):   [CLASS:SysListView32; INSTANCE:5]
ID: 102
Text:   List1
Position:   8, 8
Size:   108, 520
ControlClick Coords:    43, 100
Style:  0x5001E80C
ExStyle:    0x00000204
Handle: 0x000602D8

>>>> Mouse <<<<
Position:   190, 266
Cursor ID:  2
Color:  0xFFFFFF

>>>> StatusBar <<<<

>>>> ToolsBar <<<<

>>>> Visible Text <<<<
These tabs affect all applications.
Scan
&Boot sectors
&Floppy during shutdown
General
E&nable on-access scanning at system startup
Scan time
Ma&ximum archive scan time (seconds):
15
Spin1
&Enforce a maximum scanning time for all files
&Maximum scan time (seconds):
45
Spin1
&Processes on enable
Heuristic network check for suspicious files
&Sensitivity level:
Very low
List1
Tab1
OK
Cancel
&Apply
&Help


>>>> Hidden Text <<<<
Specify how to respond when a threat is detected.
When a threat is found:
&Perform this action first:
Clean files automatically
I&f the first action fails, then perform this action:
Delete files automatically
Prevents access to files that have been detected.
The location of the quarantine folder is configured on the 'General' tab under 'General Settings'.
When an unwanted program is found:
P&erform this action first:
Clean files automatically
If &the first action fails, then perform this action:
Delete files automatically
The location of the quarantine folder is configured on the 'General' tab under 'General Settings'.
Specify what items to exclude from scanning.
What not to scan
Exclude disks, files, and folders (0)
&Exclusions...
Specify what items will be scanned.
Scan Files
&When writing to disk
Whe&n reading from disk
&On network drives
O&pened for backup
What to scan
All fil&es
Defa&ult + additional file types (0)
Specified file t&ypes only (0)
Also s&can for macros in all files
Addi&tions...
&Specified...
Heuristics
Find un&known unwanted programs and trojans
&Find unknown macro threats
Compressed files
Scan inside archives (e.g. .&ZIP)
&Decode MIME encoded files
Unwanted programs detection
Detect unwanted p&rograms
These tabs affect the Low-Risk Processes listed below.  Use these settings for processes that have a low risk of introducing or spreading a potential threat.
&Static
List1
A&dd...
&Remove
Specify how to respond when a threat is detected.
When a threat is found:
&Perform this action first:
Clean files automatically
I&f the first action fails, then perform this action:
Delete files automatically
Prevents access to files that have been detected.
The location of the quarantine folder is configured on the 'General' tab under 'General Settings'.
When an unwanted program is found:
P&erform this action first:
Clean files automatically
If &the first action fails, then perform this action:
Delete files automatically
The location of the quarantine folder is configured on the 'General' tab under 'General Settings'.
Specify what items to exclude from scanning.
What not to scan
Exclude disks, files, and folders (0)
&Exclusions...
Specify what items will be scanned.
Scan Files
&When writing to disk
Whe&n reading from disk
&On network drives
O&pened for backup
What to scan
All fil&es
Defa&ult + additional file types (0)
Specified file t&ypes only (0)
Also s&can for macros in all files
Addi&tions...
&Specified...
Heuristics
Find un&known unwanted programs and trojans
&Find unknown macro threats
Compressed files
Scan inside archives (e.g. .&ZIP)
&Decode MIME encoded files
Unwanted programs detection
Detect unwanted p&rograms
These tabs affect either all processes or those processes not listed as High-Risk or Low-Risk Processes.
&Configure one scanning policy for all processes.
C&onfigure different scanning policies for high-risk, low-risk, and default processes
All on-access scanning is performed using the same policy options.
List1
Specify how to respond when a threat is detected.
When a threat is found:
&Perform this action first:
Clean files automatically
I&f the first action fails, then perform this action:
Delete files automatically
Prevents access to files that have been detected.
The location of the quarantine folder is configured on the 'General' tab under 'General Settings'.
When an unwanted program is found:
P&erform this action first:
Clean files automatically
If &the first action fails, then perform this action:
Delete files automatically
The location of the quarantine folder is configured on the 'General' tab under 'General Settings'.
Specify what items to exclude from scanning.
What not to scan
Exclude disks, files, and folders (0)
&Exclusions...
Specify what items will be scanned.
Scan Files
&When writing to disk
Whe&n reading from disk
&On network drives
O&pened for backup
What to scan
All fil&es
Defa&ult + additional file types (0)
Specified file t&ypes only (0)
Also s&can for macros in all files
Addi&tions...
&Specified...
Heuristics
Find un&known unwanted programs and trojans
&Find unknown macro threats
Compressed files
Scan inside archives (e.g. .&ZIP)
&Decode MIME encoded files
Unwanted programs detection
Detect unwanted p&rograms
These tabs affect the High-Risk Processes listed below.  Use these settings for processes that have a high risk of introducing or spreading a potential threat.
&Static
List1
A&dd...
&Remove
Configure the logging of scanning activity. Specify the information to be captured for each log entry.
Log file
&Enable activity logging and accept the default location for the log file or specify a new location.
&View Log
%DEFLOGDIR%\OnAccessScanLog.txt
&Browse...
Limit the si&ze of log file
&Maximum log file size (MB):
1
Spin1
&Log file format:
Unicode (UTF8)
What to log in addition to scanning activity
&Session settings
Sessi&on summary
&Failure to scan encrypted files
&User name
Notify local users when detections occur and specify what actions can be taken.
Messages for local users
&Show the messages dialog box when a threat is detected and display the specified text in the message.
Acc&ept the default message or type a new message.
VirusScan Alert!
Actions available to user
&Remove messages from the list
&Clean files
&Delete files
Block connections from remote computers that have files with potential threats or unwanted programs in a shared folder.
Message
&Send the specified message to the network user when a threat is detected.
&Type a custom message
Block
&Block the connection when a threat is detected in a shared folder.
&Unblock connections after (minutes)
10
Bl&ock the connection when a file with a potentially unwanted program is detected in a shared folder.
Scan JavaScript and VBScript scripts that are executed by the Windows Scripting Host. WSH is used by Internet Explorer and Outlook. If an unwanted script is detected it is not allowed to execute.
ScriptScan
E&nable scanning of scripts
&ScriptScan exclusions:
A&dd...
&Edit...
&Remove
Cookies
S&can cookie files
Tab1


----------------------------

post-27284-0-98915000-1311503659_thumb.j

Edited by Jos
added code tags

Neil

Share this post


Link to post
Share on other sites



My objective here is to select "GENERAL SETTINGS" and "ALL PROCESSES" objects that are shown on the left side of the image.


Neil

Share this post


Link to post
Share on other sites

GAM,

Please edit your first post to put [code] before and [/code] after the "WINDOW INFO" stuff - then you get a nice scrolling window and people might begin to look at your problem. :)

M23


Any of my own code posted anywhere on the forum is available for use by others without any restriction of any kind._______My UDFs:

Spoiler

ArrayMultiColSort ---- Sort arrays on multiple columns
ChooseFileFolder ---- Single and multiple selections from specified path treeview listing
Date_Time_Convert -- Easily convert date/time formats, including the language used
ExtMsgBox --------- A highly customisable replacement for MsgBox
GUIExtender -------- Extend and retract multiple sections within a GUI
GUIFrame ---------- Subdivide GUIs into many adjustable frames
GUIListViewEx ------- Insert, delete, move, drag, sort, edit and colour ListView items
GUITreeViewEx ------ Check/clear parent and child checkboxes in a TreeView
Marquee ----------- Scrolling tickertape GUIs
NoFocusLines ------- Remove the dotted focus lines from buttons, sliders, radios and checkboxes
Notify ------------- Small notifications on the edge of the display
Scrollbars ----------Automatically sized scrollbars with a single command
StringSize ---------- Automatically size controls to fit text
Toast -------------- Small GUIs which pop out of the notification area



Share this post


Link to post
Share on other sites

#4 ·  Posted (edited)

is this working?

#include <GUIListView.au3>
$hWnd = ControlGetHandle("On-Access Scan Properties","","SysListView325")
_GUICtrlListView_SetItemSelected($hWnd, 0)
MsgBox(0, 'pause', '1st item in your list should be selected now')
_GUICtrlListView_SetItemSelected($hWnd, 1)
MsgBox(0, 'pause', '2nd item in your list should be selected now')
Edited by dragan

Share this post


Link to post
Share on other sites

Nope, i tried and its not working.


Neil

Share this post


Link to post
Share on other sites

I have tried this - "_GUICtrlListBox_ClickItem($hWnd, 1, "left", True)', this helped in getting the focus on the control but not specifically on the object inside the controls. I thought posting this would help.


Neil

Share this post


Link to post
Share on other sites

#7 ·  Posted (edited)

ok, try this just to see if you can get all items from the list (just to make sure that you can get list's handle):

#include <GUIListView.au3>
#include <Array.au3>

$hWnd = ControlGetHandle("On-Access Scan Properties","","SysListView325")
$arr = _GUICtrlListView_GetContents($hWnd)
_ArrayDisplay($arr)

;===============================================================================
;
; Function Name:   _GUICtrlListView_GetContents
; Description::    Captures Contents of a SysListView32 Contrl Into an Array
; Parameter(s):    $hWnd - Handle to the control
; Requirement(s):  #include <GUIListView.au3>
; Return Value(s): Success - Array with ListView Contents
;                  Failure - 0
; Author(s):       Paul Wilson (spudw2k)
;
;===============================================================================
Func _GUICtrlListView_GetContents($hWnd)
    $iCol = _GUICtrlListView_GetColumnCount($hWnd)
    If $iCol = 0 Then Return 0
    Dim $arrListView[1][$iCol]
    For $i = 0 to $iCol-1
        Local $Col=_GUICtrlListView_GetColumn($hWnd,$i)
        $arrListView[0][$i]=$Col[5]
    Next
    $Col = 0
    $iRows = _GUICtrlListView_GetItemCount($hWnd)
    For $i = 0 to $iRows-1
        Redim $arrListView[UBound($arrListView)+1][$iCol]
        $arrListView[UBound($arrListView)-1][0]=_GUICtrlListView_GetItemText($hWnd,$i)
        For $j = 1 To $iCol-1
            $arrListView[UBound($arrListView)-1][$j]=_GUICtrlListView_GetItemText($hWnd,$i,$j)
        Next
    Next
    $arrListView[0][0] = UBound($arrListView)-1
    Return $arrListView
EndFunc   ;==>_GUICtrlListView_GetContents

edit: p.s. you can also try:

#include <GUIListView.au3>
$hWnd = ControlGetHandle("On-Access Scan Properties","","SysListView325")
_GUICtrlListView_ClickItem($hWnd, 1)
Edited by dragan

Share this post


Link to post
Share on other sites

Thanks dragan, I will have a look into it and update this thread. Thank for the help!!!!


Neil

Share this post


Link to post
Share on other sites

#9 ·  Posted (edited)

ok, try this just to see if you can get all items from the list (just to make sure that you can get list's handle):

...

If that work with the windows start menu then it should work with you SysListView32 Class control.

EDIT: Also works with the desktop.

Edited by monoscout999

Share this post


Link to post
Share on other sites

This works even when the workstation is locked

AutoItSetOption ( "SendKeyDelay", 1000 )
$strComputer = "."
$objWMIService = ObjGet("winmgmts:" & $strComputer & "rootdefault")
$colEvents = $objWMIService.ExecNotificationQuery _
    ("SELECT * FROM RegistryValueChangeEvent WHERE Hive='HKEY_LOCAL_MACHINE' AND " & _
        "KeyPath='SOFTWAREMcAfeeVSCoreOn Access ScannerMcShieldConfigurationDefault'" & _
"AND ValueName='bScanOutgoing'")
while 1

$var = RegRead("HKEY_LOCAL_MACHINESoftwareMcAfeeVSCoreOn Access ScannerMcShieldConfigurationDefault", "bScanOutgoing")

if $var = 1 THEN
  Run('C:Program FilesMcAfeeVirusScan Enterpriseshcfg32.exe')
  WinWait("On-Access Scan Properties")
  ControlSend("On-Access Scan Properties", "", 103,"!e")
  sleep(500)
  ControlSend("On-Access Scan Properties", "", 137,"!x")
  sleep(500)
  ControlSend("On-Access Scan Properties", "", 139,"999")
  sleep(500)
  ControlClick("On-Access Scan Properties", "", 102,"left",1,52,129)
  sleep(500)
  ControlClick("On-Access Scan Properties", "", 163,"left",1,89,13)
  sleep(500)
  ControlSend("On-Access Scan Properties", "", 127,"!n")
  sleep(500)
  ControlSend("On-Access Scan Properties", "", 1093,"!p")
  sleep(500)
  ControlSend("On-Access Scan Properties", "", 1097,"!z")
  sleep(500)
  ControlSend("On-Access Scan Properties", "", 1098,"!d")
  sleep(500)
  ControlSend("On-Access Scan Properties", "", "","{ENTER}")

EndIf

$objEvent = $colEvents.NextEvent
sleep (1000)

WEnd

Share this post


Link to post
Share on other sites

Create an account or sign in to comment

You need to be a member in order to leave a comment

Create an account

Sign up for a new account in our community. It's easy!


Register a new account

Sign in

Already have an account? Sign in here.


Sign In Now
Sign in to follow this
Followers 0
