Detect mouse click anywhere on window

[nullschritt]

Hello I have a custom gui I am making with no actual titlebar, I need to be able to allow users to move the window by clicking anywhere in the window and dragging. To do this I need to detect if they clicked anywhere in the window, and where.

Though I'm not 100% sure how I'm going to calculate where to move the window based on where they clicked.

[orbs]

register the WM_NCHITTEST message like this:

GUIRegisterMsg($WM_NCHITTEST, 'WM_NCHITTEST')

Func WM_NCHITTEST($hWnd, $iMsg, $wParam, $lParam)
    #forceref $hWnd, $iMsg, $wParam, $lParam
    Return $HTCAPTION
EndFunc   ;==>WM_NCHITTEST

credits to guinness (i can't recall the original post though).

[nullschritt]

This doesn't work..... with my script. The message is never sent because an animated control covers the whole window. I need to know how to do it via wm_notify.

Thanks though.

[orbs]

care to post your script (or an extract for replication)?

[nullschritt]

http://ge.tt/api/1/files/8SkjhvM5KK1/0/blob?download

Sorry one of the gifs I use is pretty large.

Edited February 17, 2014 by nullschritt

[orbs]

please check your download link, when i follow it i'm redirected to:

http://w101531.blob3.ge.tt/streams/8SvM5KK1/Animatedgui.zip?sig=-URBRV4hLMvXZs5iqgrL3oxZLlb5Val0u-4&type=download

and i get blank screen and nothing happens.

that snippet i tested with a GUI completely covered by an image (.jpg file) and it works fine. download the attached image and save this script in the same folder:

(EDIT: it is working because i disabled the background image. disable yours.)

expandcollapse popup

#include <StaticConstants.au3>
#include <WindowsConstants.au3>
#include <GuiConstants.au3>

$hGUI=GuiCreate("MyGUI",290,500,Default,Default,$WS_POPUP)
_GuiRoundCorners($hGUI, 0, 0, 40, 40)
GUICtrlCreatePic("background-w-icons(7.7x13.3).jpg", 0, 0, 290, 500)    ; crop : botton 153, right 631
GUICtrlSetState(-1,$GUI_DISABLE)

; button
$gHeadButtonDropdown=GUICtrlCreateLabel('',80,0,15,19,$SS_CENTER)
GUICtrlSetBkColor(-1,$GUI_BKCOLOR_TRANSPARENT)
GUICtrlSetCursor(-1,0)
GUICtrlSetTip(-1,'Menu')
$gHeadButtonPaddingTop=GUICtrlCreateLabel('',95,0,100,2,$SS_CENTER)
GUICtrlSetBkColor(-1,$GUI_BKCOLOR_TRANSPARENT)
GUICtrlSetCursor(-1,0)
$gHeadButtonLabel=GUICtrlCreateLabel('My App Title',95,2,100,17,$SS_CENTER)
GUICtrlSetBkColor(-1,$GUI_BKCOLOR_TRANSPARENT)
GUICtrlSetCursor(-1,0)
GUICtrlSetFont(-1,Default,800);,Default,'Tahoma')
$gHeadButtonMinimize=GUICtrlCreateLabel('',195,0,15,19,$SS_CENTER)
GUICtrlSetBkColor(-1,$GUI_BKCOLOR_TRANSPARENT)
GUICtrlSetCursor(-1,0)
GUICtrlSetTip(-1,'Minimize')

GuiSetState()
GUIRegisterMsg($WM_NCHITTEST, 'WM_NCHITTEST')

While True
    $msg=GuiGetMsg()
    Switch $msg
        Case $GUI_EVENT_CLOSE
            ExitLoop
        Case $gHeadButtonDropdown,$gHeadButtonLabel,$gHeadButtonPaddingTop
            MsgBox(0,'','Head Button pressed for Menu')
        Case $gHeadButtonMinimize
            MsgBox(0,'','Head Button pressed for Minimize')
    EndSwitch
WEnd

Exit

Func _GuiRoundCorners($h_win, $i_x1, $i_y1, $i_x3, $i_y3)
   Dim $pos, $ret, $ret2
   $pos = WinGetPos($h_win)
   $ret = DllCall("gdi32.dll", "long", "CreateRoundRectRgn", "long", $i_x1, "long", $i_y1, "long", $pos[2], "long", $pos[3], "long", $i_x3, "long", $i_y3)
   If $ret[0] Then
      $ret2 = DllCall("user32.dll", "long", "SetWindowRgn", "hwnd", $h_win, "long", $ret[0], "int", 1)
      If $ret2[0] Then
         Return 1
      Else
         Return 0
      EndIf
   Else
      Return 0
   EndIf
EndFunc  ;==>_GuiRoundCorners

Func WM_NCHITTEST($hWnd, $iMsg, $wParam, $lParam)
    #forceref $hWnd, $iMsg, $wParam, $lParam
    Return $HTCAPTION
EndFunc   ;==>WM_NCHITTEST

Edited February 17, 2014 by orbs

[nullschritt]

Perfect! Thanks mate!
