BBs19

MetroGUI UDF v5.1 - Windows 10 style buttons, toggles, radios, menu etc.

Recommended Posts

On 5/7/2014 at 1:36 AM, BBs19 said:

Features:

  • Create modern looking borderless and resizable GUIs with control buttons (Close,Maximize/Restore,Minimize, Fullscreen, Menu)
  • True borderless, resizeable GUI with full support for aerosnap etc.
  • Many color schemes/themes included. See MetroThemes.au3 for more details.
  • 3 type of Windows 8/10 style buttons.
  • Modern checkboxes, radios, toggles and progressbar.
  • All buttons, checkboxes etc. have hover effects!
  • Windows 10 style modern MsgBox.
  • Windows 10/Android style menu that slides in from left.
  • Windows 10 style right click menu



Credits: @UEZ, for the function to create buttons with text using GDIPlus. @binhnx for his SSCtrlHover UDF

please add support RTL

Share this post


Link to post
Share on other sites

Thanks for this udf.

Could you add an indeterminate state for checkbox ?

I tried, but my gdi experience isn't very good.



I played a little to see if i could make undeterminate checkbox state, and change size of some components :






Thanks again for this udf.

Edited by kaz

Share this post


Link to post
Share on other sites
27 minutes ago, Miliardsto said:

gonna be any update ?

Is there something wrong with it as it is now?


If I posted any code, assume that code was written using the latest release version unless stated otherwise. Also, if it doesn't work on XP I can't help with that because I don't have access to XP, and I'm not going to.
Give a programmer the correct code and he can do his work for a day. Teach a programmer to debug and he can do his work for a lifetime - by Chirag Gude
How to ask questions the smart way!

I hereby grant any person the right to use any code I post, that I am the original author of, on the autoitscript.com forums, unless I've specifically stated otherwise in the code or the thread post. If you do use my code all I ask, as a courtesy, is to make note of where you got it from.

Back up and restore Windows user files _Array.au3 - Modified array functions that include support for 2D arrays.  -  ColorChooser - An add-on for SciTE that pops up a color dialog so you can select and paste a color code into a script.  -  Customizable Splashscreen GUI w/Progress Bar - Create a custom "splash screen" GUI with a progress bar and custom label.  -  _FileGetProperty - Retrieve the properties of a file  -  SciTE Toolbar - A toolbar demo for use with the SciTE editor  -  GUIRegisterMsg demo - Demo script to show how to use the Windows messages to interact with controls and your GUI.  -   Latin Square password generator

Share this post


Link to post
Share on other sites
On 6/28/2019 at 3:24 PM, Miliardsto said:

you answer your piece of reality

I don't use this UDF and never have, so I asked because the answer would be more informative as to what you need an update for rather than attacking the question.


If I posted any code, assume that code was written using the latest release version unless stated otherwise. Also, if it doesn't work on XP I can't help with that because I don't have access to XP, and I'm not going to.
Give a programmer the correct code and he can do his work for a day. Teach a programmer to debug and he can do his work for a lifetime - by Chirag Gude
How to ask questions the smart way!

I hereby grant any person the right to use any code I post, that I am the original author of, on the autoitscript.com forums, unless I've specifically stated otherwise in the code or the thread post. If you do use my code all I ask, as a courtesy, is to make note of where you got it from.

Back up and restore Windows user files _Array.au3 - Modified array functions that include support for 2D arrays.  -  ColorChooser - An add-on for SciTE that pops up a color dialog so you can select and paste a color code into a script.  -  Customizable Splashscreen GUI w/Progress Bar - Create a custom "splash screen" GUI with a progress bar and custom label.  -  _FileGetProperty - Retrieve the properties of a file  -  SciTE Toolbar - A toolbar demo for use with the SciTE editor  -  GUIRegisterMsg demo - Demo script to show how to use the Windows messages to interact with controls and your GUI.  -   Latin Square password generator

Share this post


Link to post
Share on other sites

@rcn3t0 you have already opened your own topic for this, and that's fine. Let's not spam other people's threads to promote your script please.


"Profanity is the last vestige of the feeble mind. For the man who cannot express himself forcibly through intellect must do so through shock and awe" - Spencer W. Kimball

How to get your question answered on this forum!

Share this post


Link to post
Share on other sites
22 hours ago, JLogan3o13 said:

@rcn3t0 you have already opened your own topic for this, and that's fine. Let's not spam other people's threads to promote your script please.

You're right, I'm sorry

Share this post


Link to post
Share on other sites
#AutoIt3Wrapper_Run_Au3Stripper=y
#Au3Stripper_Parameters=/so /rm /pe

#Au3Stripper_Ignore_Funcs=_iHoverOn,_iHoverOff,_iFullscreenToggleBtn,_cHvr_CSCP_X64,_cHvr_CSCP_X86,_iControlDelete
#AutoIt3Wrapper_Res_HiDpi=y

#NoTrayIcon
#include "libs\MetroGUI-UDF\MetroGUI_UDF.au3"
#include "libs\MetroGUI-UDF\_GUIDisable.au3"
#include <GUIConstants.au3>
#include <AutoItConstants.au3>

_Metro_EnableHighDPIScaling()

_SetTheme("DarkTeal")

$Form1 = _Metro_CreateGUI("ffff", 300, 200)

$Control_Buttons = _Metro_AddControlButtons(True, False, True, False, False)

$GUI_CLOSE_BUTTON = $Control_Buttons[0]
$GUI_MAXIMIZE_BUTTON = $Control_Buttons[1]
$GUI_RESTORE_BUTTON = $Control_Buttons[2]
$GUI_MINIMIZE_BUTTON = $Control_Buttons[3]
$GUI_FULLSCREEN_BUTTON = $Control_Buttons[4]
$GUI_FSRestore_BUTTON = $Control_Buttons[5]
$GUI_MENU_BUTTON = $Control_Buttons[6]

$Button1 = _Metro_CreateButtonEx2("Download !", 180, 80, 100, 40)

$Radio1 = _Metro_CreateRadio("1", "Offf", 16, 50, 150, 25)
$Radio2 = _Metro_CreateRadio("1", "Afff", 16, 80, 150, 25)
$Radio3 = _Metro_CreateRadio("1", "fffod", 16, 110, 150, 25)
_Metro_RadioCheck("1", $Radio1)
GUISetState(@SW_SHOW)



I tried to create a no resizable gui but still resizable :(

Share this post


Link to post
Share on other sites
10 minutes ago, Blitzkid said:

First of all great UDF!



Is there a way, to use the $WS_EX_MDICHILD style on a childgui?

Something like this:

$Form1 = _Metro_CreateGUI("Destiny Raidbuddy", 1010, 710, -1, -1, True)
GUISetState(@SW_SHOW)

$form1_child = _Metro_CreateGUI("", 750, 600, -1, -1, True, $Form1)
GUISetStyle($WS_CHILD, $WS_EX_MDICHILD, $form1_child)
GUISetState(@SW_SHOW)



I have solved my problem by putting _GUIDisable under the childgui. now it moves together with the maingui

;Create resizable Metro GUI
$Form1 = _Metro_CreateGUI("Raidbuddy", 1010, 710, -1, -1, True)
GUISetState(@SW_SHOW)

FullscreenBtn = True, MenuBtn = True
$form1_child = _Metro_CreateGUI("", 750, 600, -1, -1, False, $Form1)
GUISetStyle($WS_CHILD, $WS_EX_MDICHILD, $form1_child)
GUISetState(@SW_SHOW)
_GUIDisable($Form1, 0, 30)
_GUIDisable($Form1)



Share this post


Link to post
Share on other sites
On 11/9/2018 at 9:44 AM, islandspapand said:

I will give it a try and re download the udf and create a new WinPE10 x64(1803) from scratch and se if it help.

the udf works fine in windows  it only in WinPE this ocurres.

Will give feedback when I have tried it later tonight

Hello,

First off great UDF @BBs19 !! I only wish I found it years ago.

I know it has been about 1 year since the quoted post, but I was wondering if anyone was able to resolve the issue with the MetroUDF controls in WinPE. I have tried different versions of the Windows 10 (1703, 1803, and 1903) and 8.1 ADK's , tried downloading the UDF again (as someone else suggested), used a clean install of AutoIT, compiled the example app and it too has the issue.

For the _Metro_CreateOnOffToggle control it doesn't seem to like passing font parameters.

Working - $USB_ISO_Toggle = _Metro_CreateOnOffToggle("ISO", "USB Flash", 335, 115, 155, 30)
Not working - $USB_ISO_Toggle = _Metro_CreateOnOffToggle("ISO", "USB Flash", 335, 115, 155, 30, 0xD7D7D7, 0x000000, "Arial", 12)

Any insight to why this is happening would be greatly appreciated. Thanks in advance!!

In Windows

In WinPE



****UPDATE******
So of course after posting my issue I found the solution

WinPE has very few fonts installed by default (Segoe UI, Sylfaen, Tahoma) so if you use any of these 3 fonts you will be good  :thumbsup:

Edited by cgmiapapi

Share this post
