Iterative Detection and LDPC Decoding Algorithms for MIMO Systems in Block-Fading Channels
Abstract
We propose an Iterative Detection and Decoding (IDD) scheme with Low Density Parity Check (LDPC) codes for Multiple Input Multiple Output (MIMO) systems for block-fading and fast fading Rayleigh channels. An IDD receiver with soft information processing that exploits the code structure and the behaviour of the log likelihood ratios (LLR)’s is developed. Minimum Mean Square Error (MMSE) with Successive Interference Cancellation (SIC) and with Parallel Interference Cancellation (PIC) schemes are considered. The soft a posteriori output of the decoder in a block-fading channel with Root-Check LDPC codes has allowed us to create a new strategy to improve the Bit Error Rate (BER) of a MIMO IDD scheme. Our proposed strategy in some scenarios has resulted in up to 3dB of gain in terms of BER for block-fading channels and up to 1dB in fast fading channels.
LDPC, Root-Check, MIMO, IDD, Block-Fading
I Introduction
The most recent IEEE Wireless Local Area Network (WLAN) 802.11ad standard suggests that to achieve high throughput the devices must operate with LDPC codes. Since a WLAN MIMO system is subject to multi-path propagation and mobility, this wireless system is characterized by time-varying channels with fluctuating signal strength. In applications subject to delay constraints and slowly-varying channels, only limited independent fading realizations are experienced. In such conditions also known as non-ergodic scenarios, the channel capacity is zero since there is an irreducible probability, termed outage probability [1], that the transmitted data rate is not supported by the channel. A simple and useful model that captures the essential characteristics of non-ergodic channels is the block-fading channel [2]. It is especially important in wireless communications with slow time-frequency hopping (e.g., cellular networks and wireless local area networks) or multi-carrier modulation using Orthogonal Frequency Division Multiplexing (OFDM) [3]. Codes designed for block-fading channels are expected to achieve the channel diversity and to offer good coding gains.
A family of LDPC codes called Root-Check for block-fading channels was proposed in [3]. Root-check codes are able to achieve the maximum diversity of a block-fading channel and have a performance near the limit of outage when decoded using the Sum Product Algorithm (SPA). Root-check codes are always designed with code rate , since the Singleton bound determines that this is the highest code rate possible to obtain the maximum diversity order [3]. Several works have been proposed to improve the coding gain, and to address problems such as low complexity encoding and even low memory storage. The most recent works in the literature in terms of Root-Check construction are found in [4, 5, 6, 8, 9].
Spatially multiplexed coded modulations that are decoded using Iterative Detection and Decoding (IDD) techniques can offer capacity-approaching performance. One seminal work that introduced the concept of IDD schemes was reported in [10]. In [10], it is proposed a low-complexity iterative multiuser receivers for coded code-division multiple-access (CDMA) systems over multipath channels. It is shown that as the number of outer iteration (the message exchanged between detector and decoder) increase their scheme is capable to get close to the single user capacity. The work done in [11] is essentially an extension of [10] applied for Multiple Input Multiple Output (MIMO) systems even though, it is suggested that scheme in [11] is computationally more efficient than [10] and it can be applied to multi-user detection.
In [14], the authors proposed an MMSE decision feedback (DF) detector that employs a successive parallel arbitrated DF structure based on the generation of parallel arbitrated branches. The motivation for that was to mitigate the effects of error propagation often found in interference cancellation structures. The results in [14] showed for both uncoded and convolutionally encoded systems using Viterbi and turbo decoding that the detection schemes proposed can offer considerable gains as compared to existing DF and linear receivers. In [15] it is proposed a cancellation technique to mitigate Inter Symbol Interference (ISI) and Multiple Access Interference (MAI) for frequency-selective MIMO channels. Moreover, the authors in [15] have shown a scheme for channel estimation which is more realistic in terms of practical systems.
The work done in [20] proposes a SIC strategy for MIMO spatial multiplexing systems based on a structure with multiple interference cancellation branches. This multi-branch SIC (MB-SIC) structure employs multiple SIC schemes in parallel and each branch detects the signal according to its respective ordering pattern. By selecting the branch which yields the estimates with the best performance according to the selection rule, the MB-SIC detector, therefore, achieves higher detection diversity. A low-complexity multiple feedback successive interference cancellation (MF-SIC) is proposed in [21] for the uplink of multiuser MIMO (MU-MIMO) systems. Also, the authors have made an extension of the work in [20] to combine the MF-SIC with MB-SIC to achieve a higher detection diversity order. The results presented in [21] show that their schemes significantly outperform the conventional SIC scheme and approach the optimal detector.
All the works previously mentioned deal with quasi-static Rayleigh fading channels or even fast Rayleigh fading channel. However, there is very little research in the literature related to the case of block-fading channels with MIMO systems. To the best of our knowledge, the only work which discusses the MIMO under block-fading channels is [23]. In [23], the authors claimed that using Root-Check LDPC codes the MIMO system can achieve the desired channel diversity. Furthermore, they presented a relationship between the maximum LDPC code rate and transmitting antennas is . In [23], it is only considered the direct application of Root-Check LDPC codes for MIMO in block-fading channels. In contrast, in our work we discuss how we can improve the system performance based on the log likelihood ratio (LLR) behaviour of a Root-Check LDPC code. We have observed that if we properly manipulate the LLR output of the decoder and exploit the code structure we can obtain gains of up to with respect to non Root-Check LDPC codes in a IDD system. Moreover, we have considered several scenarios of MIMO signalling. The main contribution of our work is to develop a novel IDD scheme that exploits the code structure and provides a new strategy for LLR manipulation that improves the performance of MIMO IDD systems under block-fading channels. Furthermore, the improved performance noticed in block-fading channels instigated us to consider the case of fast-fading channels which also results in a better performance than traditional IDD schemes. The most important aspect to be considered is that the gains provided by our proposed IDD scheme do not require extra computationally effort or even any extra memory storage.
The rest of this paper is organized as follows. In Section II we describe the system model. In section III we discuss our proposed LLR strategy. Section IV it is depicted the simulation results, while Section V concludes the paper.
Ii System Model
Consider a Root-Check LDPC-coded MIMO system with transmitter antennas and receiver antennas, signalling through a block fading channel, where is the number of independent fading blocks per codeword of length . The transmitter and receiver structure are illustrated in Fig. 1. The data is first encoded by a Root-Check LDPC code with rate , modulated by a complex constellation with possible signal points and average energy equal to , and then distributed among the antennas. Let be an vector of transmitted symbols and an vector of received signals related by:
(1) |
where , , and are related by , where returns the smallest integer not smaller than , is the real complex channel matrix with Rayleigh fading coefficient of the -th block and is a vector of independent zero-mean, complex Gaussian noise entries with variance per real component. In the case of fast fading we assume that each received symbol will be under a distinct fading coefficient, which means . Also we consider that the average signal-to-noise ratio (SNR) at each receiver antenna is independent of the number of transmitter antennas . So, the SNR can be defined as . In this paper, we assume that the transmitted symbols are taken from a modulation constellation . The information transmission rate is , where is the number of information bits per codeword of length . For the case of a block-fading channel, we consider 4]. , since then it is possible to design a practical diversity achieving code [
An IDD scheme is used to approach the maximum-likelihood (ML) performance of joint MIMO detection and LDPC decoding. Fig. 1 gives a block diagram of the turbo iterative receiver structure. In this structure, the soft MIMO detector incorporates extrinsic information provided by the LDPC decoder, and the LDPC decoder incorporates soft information provided by the MIMO detector. Extrinsic information between the detector and decoder is then exchanged in an iterative fashion until an LDPC codeword is found or a maximum number of iterations is performed. We will call inner iterations the iterations done by the log Sum Product (SP) LDPC decoder, and outer iterations the iterations between the decoder and the detector.
Ii-a MAP Detector
In the soft maximum a posteriori (MAP) detector, the received vector is demapped by LLR calculation for each bit of the coded bits included in the transmit vector . The extrinsic information provided by the MAP detector is the difference of the soft-input and soft-output LLR values on the coded bits. For the t code bit () of the transmit vector , the extrinsic LLR value of the estimated bit is computed as
(2) | |||||
where is the extrinsic information of the bit computed by the LDPC decoder in the previous turbo iteration ( at the first iteration) and is the set of vector hypotheses having , ( is similarly defined). Assuming the bits within are statistically independent of one another, the a priori probability can be written as
(3) |
where corresponds to the value (+1,-1) of the j bit in the vector . In the above LLR value calculation, the likelihood function is especified by a multivariate Gaussian density function.
Ii-B Detection Techniques for Spatial Multiplexing
The optimal detection algorithm is the maximum likelihood (ML) detection algorithm given by
(4) |
where denotes a set of -dimensional candidate vectors. The computational complexity, which increases exponentially with the number of transmit antennas, prevents the practical application of the ML detector. The MMSE linear detector is a relatively simple strategy to separate the transmitted signals at the receiver. It corresponds to designing an parameter matrix according to the MMSE criterion. The design of the MMSE filter matrix is based on the minimization of the following cost function
(5) |
where stands for the expected value and is the Hermitian transpose operation. By computing the gradient of (5) with respect to and then equating it to a null matrix, we obtain the MMSE filter matrix
(6) |
where is the noise variance, is the signal power and is the identity matrix. The MMSE linear detector expression (6) requires the channel matrix (in practice an estimate of it) and the noise variance at the receiver. There are a number of other strategies to achieve the capacity gain of MIMO systems in which the V-BLAST [26] is the most competitive one because of its lower complexity and good performance. Nevertheless, there is still a large performance gap between linear algorithms and ML-type detectors.
The SIC algorithm is usually combined with MMSE filtering, resulting in V-BLAST [26] receivers. This provides improved performance at the cost of increased computational complexity. Rather than jointly decoding the transmitted signals, this nonlinear detection scheme first detects the first row of the signal and then cancels its effect from the overall received signal vector. It then proceeds to the next row. The reduced channel matrix now has dimension and the signal vector has dimension . It then does the same operation on the next row. The channel matrix now reduces to and the signal vector reduces to and so on. If we assume that all the decisions at each layer are correct, then there is no error propagation. Otherwise, the error rate performance is dominated by the weakest stream, which is the first stream decoded by the receiver. Hence, the improved diversity performance of the succeeding layers does not help. To get around this problem the ordered SIC receiver was introduced [27]. In this case, the signal with the strongest signal-to-interference-noise (SINR) ratio is selected for processing. This improves the quality of the decision and reduces the chances of error propagation. This is like an inherent form of selection diversity wherein the signal with the strongest SNR is selected [27].
Iii Proposed IDD Scheme and LLR Strategy
We started by investigating the performance of the Root-Check LDPC codes under MIMO systems with IDD schemes. Several simulations were conducted under different scenarios which lead to similar results, where Root-Check LDPC codes lose in terms of bit error rate (BER) to the standard LDPC codes at high SNR. In addition, Fig. 2 will provide a set of sub-plots which are important to understand how our proposed IDD scheme of LLR strategy are devised.
Let us consider a simple scenario where the Root-Check LDPC codes are expected to obtain full diversity in a single input single output (SISO) system. An arbitrary modulation was used, fadings per codeword, code rate and , all null code word will be sent through the ”channel”. For practical purposes, let us consider and . Furthermore, we assume that there is no noise contribution from the receiver side for this particular experiment. As a result, we will be analysing only the influence of the fading under the soft decision at the decoder. The received code word will be, , channel fading coefficients
(7) |
where , leads to something like,
(8) |
Moreover, applying eq. (8) through a real system with a block length , the output of the decoder is depicted in Fig. 2. From the results shown in Fig. 2 we can see clearly that the LLR contribution of the second half of the systematic bits is marginal compared to the first half. Each systematic half is under fadings and respectively. Nevertheless, it was assumed that the Root-Check codes would be able to recover all the systematic bits under the same scenario discussed in this document.
Furthermore, we have investigated if we were properly generating a block-fading channel using a complex channel. What instigated us to conduct this analysis, it was based on the fact that from the decoder point of view the received symbols must be in a binary phase shift keying (BPSK) style. Consequently, we have obtained the message LLR output shown in Fig. 2.
The results presented in Fig. 2, suggest that it is not a block-fading behaviour. However, if we just multiply the channel matrix ( or ) to its complex conjugate to obtain the envelope of that channel realization, we obtain a proper block-fading channel as it can be seen on Fig. 2. We have noticed that the parity check nodes of a general Root-Check LDPC codes tend to not converge, which means in an IDD process the extrinsic information exchanged between the decoder and the detector might not be fruitful in terms of improving the overall performance. One interesting approach is the controlled doping via high-order Root-Checks in graph codes presented in [28]. The codes designed in [28] are able to guarantee the parity check nodes converge.
Following the analysis done for a SISO case we have now considered a MIMO signalling system. The channel can be interpreted as a block-fading channel with , the LDPC code word has a block length of , maximum inner iterations and code rate 28]. The LLR output of the decoder can be represented as: . The Root-Check LDPC code used is the one presented in [
(9) |
where is the t bit and is the a priori probability of the the t bit. At the first outer iteration . Furthermore, we will be looking at the a posteriori LLR output of the decoder. For the case of SIC we have the symbols versus LLR output as shown in Fig. 2. From the figure, we can see that the LLR of the parity bits (600 up to 1200) half of then are about while the rest are even below . Therefore, we have an average gap of in terms of LLR.
We have adopted an LLR processing scheme for IDD with block-fading channels (LLR-PS-BF). We have observed that before calculating the extrinsic information for the next outer iteration, we calculate
(10) |
The reason why we have chosen the absolute maximum value of is whether we choose an arbitrary upper bound this leads to a degradation in the overall performance.
Accordingly, the final LLR with respect to the parity check becomes:
(11) |
It must be noted that in (11) every time the decoder generate an a posteriori LLR a new value for must be obtained. The main purpose of performing (11) is to enable a convergence for the detector in the next outer iteration. Therefore, the extrinsic message exchanged between the decoder and the detector will benefit from this operation. Consequently, a better performance in terms of BER will be noticed. Applying our proposed scheme LLR-PS-BF to LLR output obtained in Fig. 2 prior to the extrinsic information calculation, the final output is presented in Fig. 2.
One can claim that it is not fair to only apply our method LLR-SP-BF to the Root-Check LDPC codes and not to apply for their counterpart, for instance, irregular repeat accumulate (IRA) LDPC codes. Correspondingly, we can show in Fig. 2 that in the case of IRA LDPC code rate , with block length there is no gap on the parity bits LLR. Moreover, we have applied our technique to see if this would bring some improvements. However, it has caused a degradation on overall performance. For the sake of clarity, all results that will be presented in Section IV based on IRA LDPC codes, we will not apply our method LLR-SP-BF to avoid a degradation on overall performance.
The structure of our proposed LLR-PS-BF with soft cancellation detector is described in terms of iterations. In the first iteration, the a priori information provided by the decoder is zero which heavily degrades the performance of PIC based detection. Therefore, we considered using PIC and SIC to see the overall performance. In the case of SIC approach, the soft estimates of is used to calculate the LLRs of their constituent bits. We assume is Gaussian, and, the soft output of the SISO detector for the -th user is written as [14]
(12) |
where is a scalar variable which is equal to the -th users amplitude and is a Gaussian random variable with variance , with
(13) |
and
(14) |
The estimates of and can be obtained by time averages of the corresponding samples over the transmitted packet.
After the first iteration, the soft cancellation MMSE performs PIC and SIC by subtracting the soft replica of MAI components from the received vector as
(15) |
where and a filter is developed to further reduce the residual interference as
(16) |
where the soft output of the filter is also assumed Gaussian. The first and the second-order statistics of the symbols are also estimated via time averages of (13) and (14). The pseudo code of our proposed LLR-SP-BF IDD scheme is presented in Algorithm 1.
Iv Simulations
The bit error rate (BER) performance of the proposed LLR-PS-BF with PIC and SIC IDD scheme is compared with Root-Check LDPC codes and LDPC codes using a different number of antennas. Both LDPC codes used in the simulation are with block length for rate . For rate the block length is . The maximum number of inner iterations was set to and a maximum of outer iterations were used. We considered the proposed algorithms and all their counterparts in the independent and identically-distributed (i.i.d) random fast and block fading channels models. The coefficients are taken from complex Gaussian random variables with zero mean and unit variance. The modulation used is QPSK. The final SNR seen by the receiver is calculated as which is based on equation (14).
Iv-a Single User Multiple Antennas
In Fig. 3 the results for a MIMO system with , single user, block-fading channel with fadings and LDPC codes rate are presented. We can see clearly for both SIC and PIC that our proposed scheme LLR-PS-BF with Root-Check LDPC codes outperforms the LDPC code by about in terms of SNR.
Fig. 4 presents the results for a MIMO system with , single user, block-fading channel with fadings and LDPC codes rate . We can see clearly for both SIC and PIC that our proposed scheme LLR-PS-BF with Root-Check LDPC codes again outperforms the LDPC by about in terms of SNR. It can be noted that the SNR range presented in Fig. 4 is much lower than the range in Fig. 3, this happens because in a MIMO system the diversity order is as stated in [23]. Therefore, the upper bounded maximal code rate is .
Fig. 5 shows the outcomes for a MIMO system with , single user, fast fading Rayleigh channel and LDPC codes rate . In this channel the combination of Root-Check LDPC codes with our scheme LLR-PS-BF has provided a gain of with respect to the LDPC codes. In a fast fading channel the convergence for a lower BER is much earlier than in a block fading channel. Furthermore, in fast fading channel the coherence channel time is much less than symbol period .
V Conclusion
In this paper, we have presented a strategy based on the observation of the LLR output of the decoder for IDD systems. The proposed LLR-SP-BF algorithm has provided up to for a MIMO and up to for a MIMO systems both over a block-fading channel with . For the case of a MIMO system over fast-fading the proposed LLR-SP-BF IDD scheme has obtained a gain of up to . All the gains obtained in this paper are with respect to a MIMO IDD system using LDPC codes. There are some ongoing works to be done: first, to extend the proposed LLR-SP-BF strategy for Multi-User MIMO systems; second, to use scheduling techniques as proposed in [29]; third, we are considering improved decoding strategies [30] for the above mentioned strategies.
Acknowledgment
This work was partially supported by CNPq (Brazil), under grant 237676/2012-5.
