Olish

Copyright-free Wake on LAN script !

Recommended Posts

I found this thread and the starting script.

The script worked not (but not of the main WOL feature, but because it uses only @IpAdress1)

By writing something around the script finally I came to a little bigger script.....

What could the extended script do?

1) You can enter a IP START and and IP STOP address. The script enumerate the last ip segment (sorry but enumerate in all possible addresses does not fit to my need....)

The script will then write a file(MACLIST.DAT) in the format:

[MACLISTE]
192.168.0.1=08000e42faa7
192.168.0.2=0090fb181c18

2) Of course you can edit the file manually and read via button MACLIST.DAT

3) The file will be read on startup and will display the content in a listview

4) Now you can select a single entry and push the button WAKE UP SELECTED

or

5) Send magic packet to all in the listview

6) it will send the magic packet via @IPAddress1 to @IPAddress4, in my PC there are 4 adapters and the mac was on @IPAddress3.....

7) The button SET TIMER to now will set the time controls(combo) (three) to the current time

8) If you activate the timer with the button ACTIVATE TIMER the script will wait until the EXACT (yes, yes, that's not so nice and a possible gap) and will wake up all in the list

9) The status is just for displaying what is going on

So, as parts of this script are from the community, I want to give something back.

I tested this stuff on XP32/SP3 German. Maybe you can tell if this works for you as well.

This is my first contribution to the forum, so please do not punish me for writing wrong coding rules...

In case of errors please correct my script (but at least here it worked fine :-) )

...

Tankbuster, that is an awesome script, thank you for sharing!! =)

I just had to make a modification to the get_mac() function because the script would crash if it attempted to process the IP/MAC of the PC it was running on: in that case, I observed that the $aOutputLine array did not contain enough elements.

So here is the modified get_mac() function that worked for me...

func get_mac($remote_ip,$filemaclist="MACLIST.DAT")


                    Ping($remote_ip,200)
                    if @error =0 Then
                        $arpinfo = Run(@ComSpec & " /c ARP -a "&$remote_ip, @SystemDir, @SW_HIDE, 2)
                        sleep(200)
                        $output = StdoutRead($arpinfo, -1)
                            $aOutputLine=StringSplit($output,@CRLF)
                            If UBound($aOutputLine) > 5 Then ; <=== added so script doesn't choke when processing the IP for the computer it's running on
                                $macadress=Stringmid($aOutputLine[7],25,17)
                                $macadress=StringReplace($macadress,"-","")
                                IniWrite(@ScriptDir&"\"&$filemaclist,"MACLISTE",$remote_ip,$macadress)
                                setStatusMsg("Found maclist "&$macadress)
                            EndIf ; <=== and this one...

                        Else
                            setStatusMsg("Host "&$remote_ip&" not reachable")
                            Return
                        endif
                    EndFunc
Edited by TheSovereign

[font="Courier New"]__________________________________________________There is always another way, usually a better one.[/font]

Share this post


Link to post
Share on other sites

Tankbuster, that is an awesome script, thank you for sharing!! =)

Thx :)

So here is the modified get_mac() function that worked for me...

....

I added this to my post, as it makes the script better ...

@gcue

1. i shut down pc

2. wake it up - and it works!

3. shut down pc again << -- I think this overwrites in some ways the S3 state, in otherwords the networkcard does not care about the magic packets

4. wake it up - fails

5. turn on pc manually

6. wake it up - and it works!

..

I did the same thing with XP pcs. As long as I use the "shutdown" command of xp WOL was working, but if I pressed the Powerbutton (and the OS was shutting down the os), WOL was not able to start the PC. I guess I need to change the network card energy settings, but this is just a suggestion.

Edited by Tankbuster

Share this post


Link to post
Share on other sites

Thx to all for this code.

works fine, i made a script to switch on my PCs in my LAN with a small GUI and i used an external exe before to make the WOL call, but now i implemented it into the script.

And now i am working on a script that shut downs the PCs remotely, but i have some trouble with the remote access to the other PCs...

Edited by CrazyThom

Share this post


Link to post
Share on other sites

And now i am working on a script that shut downs the PCs remotely, but i have some trouble with the remote access to the other PCs...

I'm just guessing, but you got user right problems , correct?

You need a user that is able to shutdown (eg. Administrator).

On comandline you need to connect as a user to IPC$ and than execute the shutdown command.

C:\>net use \\yourpc SuperPass /u:yourpc\Superadmin

C:\>shutdown -i -s -m \\yourpc -t 10 -c "AdminsLastWill"

I'm not aware of one, but I think Autoit (or UDF) will already offer such ways "inside" Autoit.

But I think it's about user rights.

I will have a look too, as the feature would be nice to have .... If I find something I will post it here again...

Share this post


Link to post
Share on other sites

Tankbuster, thanks for this script, it's been very useful! The MAC scanner is a great time-saver. I've used this to replace the broken WOL feature in the Smartlaunch control software that I have to deal with at client locations.

/beer

Share this post


Link to post
Share on other sites

there is an easier way to get the mac address instead of using the arp command, you can use the "getmac" command via dos, it has a less convoluted output.

Edited by l15ard

RichE

[font="'Arial Narrow';"]Current projects[/font]

[font="'Arial Narrow';"]are on my site [/font]Sellostring

Share this post


Link to post
Share on other sites

Correct getmac is nicer to look at and gives better formatted results (CSV,FILE,TABLE) but you need a user and a password.

GETMAC [/S system [/U username [/P [password]]]] [/FO format] [/NH] [/V]

Also I think it will work only with Windows Clients, but I will remember it in case of a certain use case.

Thank you for the hint.

Edited by Tankbuster

Share this post


Link to post
Share on other sites

As time goes by, I returned to this script, as I found out that my old script now does not work anymore....

Why?

As I installed VMWare player (some time ago) I got now 6 Networkadapters some virtual ones and some real ones.

So the @IpAdress thing does not work anymore (1 to 4).

I added a function by 99ojo WMI NETWORKADAPTER LLIST

And during the implementation of this function I found some other stuff that would be nice to have (like the mentioned Commandline).

If you got a MACLIST you could start the WOLLE (it's for Wake-On-Lan-Light-Edition or translated from German to English : Wool )

WOLLE /?

WOLLE HH:MM:SS RESTART|EXIT

The first argument is the time of course and the second one is what should the WOLLE do after triggering, just Exit or Restart (and wait for the same time again on the next day)

If you got some other ideas (like the getmac command see previous post), would be nice if you extend my version (and post it of course)

If you find errors, do not punish me, help me to solve it.

So here is the script (attached is the .AU3 file with a screen shot):

Tested and compiled here with 3.3.4.0

#include <Array.au3>
#include <WindowsConstants.au3>
#include <GUIConstantsEx.au3>
#include <GuiListView.au3>
#Include <Date.au3>

AutoItSetOption ( "GUICoordMode",1)
Global $aNetWorkAdapters [1] [2] ; Global array for network adapter and ip
global $NextHH,$NextMM,$NextSS,$NextRun
_getnetworkadapter ()

$filemaclist="MACLIST.DAT"

Dim $MACAddressList[1]


; ===================================================================
; Gui
;
; ===================================================================
$mainwindow=GUICreate("WOLLE",500,600)
$mwbtnExit=GUICtrlCreateButton("Exit",350,150,100)
$mwbtnGetMac=GUICtrlCreateButton("Get Mac adresses",10,150,100)
$mwbtnWakeupall=GUICtrlCreateButton("Wake up all in list",130,150,100)
$mwbtnWakeupSelected=GUICtrlCreateButton("Wake up selected",240,150,100)
$mwlblIpRange=GUICtrlCreateLabel("Enter Start and End IP for search, will only search for last segment, sorry....",10,115,200,30)

$mvinpIpStart=GUICtrlCreateInput("192.168.0.1",250,120,100,15)
$mvinpIpStop=GUICtrlCreateInput("192.168.0.10",350,120,100,15)
$mvinpWakeupTimeHH=GUICtrlCreateCombo("00",10,220,40)
$mvinpWakeupTimeMM=GUICtrlCreateCombo("00",50,220,40)
$mvinpWakeupTimeSS=GUICtrlCreateCombo("00",90,220,40)
FillTimeCombos()
$mwbtnActivateTimer=GUICtrlCreateButton("Activate Timer",290,220,120)
$mwbtnSetTimertoNow=GUICtrlCreateButton("Set Timer to now",160,220,120)
$mwbtnReadMacListFile=GUICtrlCreateButton("read MACLIST.DAT",260,20,120)
$mwbtnMarkAllMacList=GUICtrlCreateButton("Mark All",260,50,80)
$mwbtnUNMarkAllMacList=GUICtrlCreateButton("Un-Mark All",260,80,80)
$mwlvMacadresses=GUICtrlCreateListView("MacAdresses   |IP                ",10,10,250,100,-1,bitor($LVS_EX_FULLROWSELECT,$LVS_EX_GRIDLINES,$LVS_EX_CHECKBOXES))
$mwlblStatus=GUICtrlCreateLabel("Status:",10,180,400)
GUICtrlSetColor(-1,0xff0000)
$mwlblStatusNext=GUICtrlCreateLabel("Next:",10,200,400)
GUICtrlSetColor(-1,0x0099aa)

$mwlblWOLDelay1=GUICtrlCreateLabel("WOL DelayTimer (between two WOL msg)",10,500,100,15)
$mwinpWOLDelay=GUICtrlCreateInput("1000",110,500,100,15)
$mwlblWOLDelay2=GUICtrlCreateLabel("ms (Keep an eye on  the power usage on startup of a PC)",150,500,400,15)



$mwlvNetWorkAdapters=GUICtrlCreateListView("Name           |IP                ",10,270,405,200,-1,bitor($LVS_EX_FULLROWSELECT,$LVS_EX_GRIDLINES,$LVS_EX_CHECKBOXES))
$mwbtnMarkAllAdapters=GUICtrlCreateButton("Mark All",415,220,80)
$mwbtnUNMarkAllAdapters=GUICtrlCreateButton("Un-Mark All",415,250,80)






readmacfile()
setTimertoNow()


addNetworkAdapters2ListView()

global $RunType="GUI"
if $CmdLine[0]=2 then
    GUISetState(@SW_SHOW)
    $RunType="COMMANDLINE"
    $CommandlineWakeUpTime=$CmdLine[1]
    $CommandlineCompleteCommand=$CmdLine[2]

    local $aCommandLineTime=StringSplit($CommandlineWakeUpTime,":")
    guictrlsetdata($mvinpWakeupTimeHH,$aCommandLineTime[1])
    guictrlsetdata($mvinpWakeupTimeMM,$aCommandLineTime[2])
    guictrlsetdata($mvinpWakeupTimeSS,$aCommandLineTime[3])
    $boolTimerActive=1
    DisableControls(1)
elseif $CmdLine[0]=1  then
    msgbox(0,"WOLLE","Commandline Parameter"&@CRLF&"PARA1 = Wakeuptime"&@CRLF&"PARA2 = COMMAND after WAKUP (EXIT - RESTART)"&@CRLF&"WOLLE HH:MM:SS EXIT")
    exit
Else

    GUISetState(@SW_SHOW)
    $boolTimerActive=0
EndIf





    While 1
        $msg = GUIGetMsg()
        select
            case $msg = $GUI_EVENT_CLOSE
                ExitLoop
            case $msg = $mwbtnExit
                ExitLoop
            case $msg = $mwbtnWakeupall
                wol_all()
            case $msg = $mwbtnGetMac
                getmacinrange()
            case $msg = $mwbtnGetMac
                getmacinrange()
            case $msg = $mwbtnWakeupSelected
                wol_selected()
            case $msg = $mwbtnReadMacListFile
                readmacfile()
            case $msg = $mwbtnMarkAllMacList
                togglelistviewcheckboxes($mwlvMacadresses,true)
            case $msg = $mwbtnUNMarkAllMacList
                togglelistviewcheckboxes($mwlvMacadresses,false)
            case $msg = $mwbtnMarkAllAdapters
                togglelistviewcheckboxes($mwlvNetWorkAdapters,true)
            case $msg = $mwbtnUNMarkAllAdapters
                togglelistviewcheckboxes($mwlvNetWorkAdapters,false)
            case $msg = $mwbtnActivateTimer
                if $boolTimerActive=1 Then
                    DisableControls(0)
                Else
                    DisableControls(1)
                endif
            case $msg = $mwbtnSetTimertoNow
                setTimertoNow()



            EndSelect
            if $boolTimerActive=1 Then
                CheckWakeup()
                sleep(100)
            endif
    WEnd
    GUIDelete()
    exit

; ===================================================================
; Function: setTimertoNow
;   sets the thre time controls to the current time
; ===================================================================
func setTimertoNow()
    guictrlsetdata($mvinpWakeupTimeHH,@HOUR)
    guictrlsetdata($mvinpWakeupTimeMM,@MIN)
    guictrlsetdata($mvinpWakeupTimeSS,@SEC)
EndFunc

; ===================================================================
; Function: DisableControls($TimerState)
;~          $TimerState = 0 = Enable
;~          $TimerState = 1 = Disable
;   Toggle for the Timer button
; ===================================================================
func DisableControls($TimerState)
    $boolTimerActive=$TimerState
    if $TimerState = "0" Then
        GUICtrlSetState($mwbtnExit,$GUI_ENABLE)
        GUICtrlSetState($mwbtnGetMac,$GUI_ENABLE)
        GUICtrlSetState($mwbtnWakeupall,$GUI_ENABLE)
        GUICtrlSetState($mwbtnWakeupSelected,$GUI_ENABLE)
        GUICtrlSetState($mvinpIpStart,$GUI_ENABLE)
        GUICtrlSetState($mvinpIpStop,$GUI_ENABLE)
        GUICtrlSetState($mvinpWakeupTimeHH,$GUI_ENABLE)
        GUICtrlSetState($mvinpWakeupTimeMM,$GUI_ENABLE)
        GUICtrlSetState($mvinpWakeupTimeSS,$GUI_ENABLE)
        GUICtrlSetState($mwbtnReadMacListFile,$GUI_ENABLE)
        GUICtrlSetState($mwbtnSetTimertoNow,$GUI_ENABLE)
GUICtrlSetState($mwlvMacadresses,$GUI_ENABLE)
GUICtrlSetState($mwlvNetWorkAdapters,$GUI_ENABLE)
        GUICtrlSetState($mwbtnMarkAllMacList,$GUI_ENABLE)
        GUICtrlSetState($mwbtnUNMarkAllMacList,$GUI_ENABLE)
        GUICtrlSetState($mwbtnMarkAllAdapters,$GUI_ENABLE)
        GUICtrlSetState($mwbtnUNMarkAllAdapters,$GUI_ENABLE)



        GUICtrlSetData($mwbtnActivateTimer," Activate Timer")
        setStatusMsg("Timer deactivated")
        setStatusMsgNext("")

    Else
        GUICtrlSetState($mwbtnExit,$GUI_DISABLE)
        GUICtrlSetState($mwbtnGetMac,$GUI_DISABLE)
        GUICtrlSetState($mwbtnWakeupall,$GUI_DISABLE)
        GUICtrlSetState($mwbtnWakeupSelected,$GUI_DISABLE)
        GUICtrlSetState($mvinpIpStart,$GUI_DISABLE)
        GUICtrlSetState($mvinpIpStop,$GUI_DISABLE)
        GUICtrlSetState($mvinpWakeupTimeHH,$GUI_DISABLE)
        GUICtrlSetState($mvinpWakeupTimeMM,$GUI_DISABLE)
        GUICtrlSetState($mvinpWakeupTimeSS,$GUI_DISABLE)
        GUICtrlSetState($mwbtnReadMacListFile,$GUI_DISABLE)
        GUICtrlSetState($mwbtnSetTimertoNow,$GUI_DISABLE)
GUICtrlSetState($mwlvMacadresses,$GUI_DISABLE)
GUICtrlSetState($mwlvNetWorkAdapters,$GUI_DISABLE)

        GUICtrlSetState($mwbtnMarkAllMacList,$GUI_DISABLE)
        GUICtrlSetState($mwbtnUNMarkAllMacList,$GUI_DISABLE)
        GUICtrlSetState($mwbtnMarkAllAdapters,$GUI_DISABLE)
        GUICtrlSetState($mwbtnUNMarkAllAdapters,$GUI_DISABLE)

        GUICtrlSetData($mwbtnActivateTimer," De-Activate Timer")

        EndIf
EndFunc


; ===================================================================
; Function: CheckWakeup
; critical only equal time will trigger (needs something better like a small range)
; ===================================================================
func CheckWakeup()

    local $intWakeupTime=(GUICtrlRead($mvinpWakeupTimeHH)*60*60)+(GUICtrlRead($mvinpWakeupTimeMM)*60)+GUICtrlRead($mvinpWakeupTimess)
    local $intNow=(@HOUR*60*60)+(@MIN*60)+@SEC

    setStatusMsg("Current time:"&@HOUR&":"&@MIN&":"&@SEC)
    $NextRun=$intWakeupTime-$intNow
    if $NextRun<0 then
        $NextRun=($NextRun+(24*60*60))*1000
    EndIf
    _TicksToTime($NextRun,$NextHH,$NextMM,$NextSS)

    setStatusMsgNext(""&$NextHH&":"&$NextMM&":"&$NextSS)

    _DebugConsole("WAKESECS:"&$intWakeupTime&":NOWSECS:"&$intNow&":TICKSNEXT:"&$NextRun)
    if $intNow = $intWakeupTime Then
        SoundPlay(@WindowsDir & "\media\tada.wav",0)
        if $RunType = "GUI"  Then
            wol_selected()
        Else
            wol_all()
        EndIf


    select
        case $RunType = "COMMANDLINE"
        Select
            case $CommandlineCompleteCommand="EXIT"
                Exit
            case Else
;~              RESTART
                $boolTimerActive=1
                DisableControls(1)
                sleep(500)
        EndSelect

        case else
;~      GUI
    EndSelect
    EndIf
EndFunc
; ===================================================================
; Function: FillTimeCombos
;          filling the controls with data
; ===================================================================
func FillTimeCombos()
    for $i=1 to 9
            GUICtrlSetData($mvinpWakeupTimeHH,"0"&$i)
            GUICtrlSetData($mvinpWakeupTimeMM,"0"&$i)
            GUICtrlSetData($mvinpWakeupTimeSS,"0"&$i)

        Next
    for $i=10 to 23
            GUICtrlSetData($mvinpWakeupTimeHH,$i)
        Next

    for $i=10 to 59
            GUICtrlSetData($mvinpWakeupTimeMM,$i)
            GUICtrlSetData($mvinpWakeupTimeSS,$i)
    Next

EndFunc


; ===================================================================
; Function: readmacfile
;           reads mac list in ini format
; ===================================================================
func readmacfile($filemaclist="MACLIST.DAT")
    if FileExists($filemaclist) Then
        $aMaclist=IniReadSection(@scriptdir&"\"&$filemaclist,"MACLIST")
        _GUICtrlListView_DeleteAllItems($mwlvMacadresses)
        for $i  = 1 to $aMaclist[0][0]
                GUICtrlCreateListViewItem(""&$aMaclist[$i][1]&"|"&$aMaclist[$i][0]&"", $mwlvMacadresses)
            Next
    EndIf


    EndFunc
; ===================================================================
; Function: getmacinrange
;           simple try to get all mac adresses from a given range (only last segment)
; ===================================================================
func getmacinrange()
    FileDelete(@ScriptDir&"\"&$filemaclist)
    $aIpStart=StringSplit(GUICtrlRead($mvinpIpStart),".")
    $aIpStop=StringSplit(GUICtrlRead($mvinpIpStop),".")


                for $IpSegD = $aIpStart[4] to $aIpStop[4]
                    get_mac($aIpStart[1]&"."&$aIpStart[2]&"."&$aIpStart[3]&"."&$IpSegD)
                Next
                readmacfile()

EndFunc

; ===================================================================
; Function: togglelistviewcheckboxes($listviewcontrol,$state)
;           $listviewcontrol      --- Handle of control
;           unmark all entries in a list
; ===================================================================
func togglelistviewcheckboxes($listviewcontrol,$state)
    for $i = 0 to _GUICtrlListView_GetItemCount($listviewcontrol)
        _GUICtrlListView_SetItemChecked($listviewcontrol,-1,$state)
    next
EndFunc


; ===================================================================
; Function: wol_selected
;   sents magic paket to the macadress selected in listview
; ===================================================================
func wol_selected()
    local $SelectedMacEntries=0
    local $SelectedNetworkAdapters=0
    local $WOLSendCounter=0
    for $i = 0 to _GUICtrlListView_GetItemCount($mwlvMacadresses)
        if _GUICtrlListView_GetItemChecked($mwlvMacadresses, $i) Then
            $SelectedMacEntries=$SelectedMacEntries+1

                _DebugConsole("Adresses:"&$SelectedMacEntries)
                local $SelectedNetworkAdapters=0
                for $j = 0 to _GUICtrlListView_GetItemCount($mwlvNetWorkAdapters)
                    if _GUICtrlListView_GetItemChecked($mwlvNetWorkAdapters, $j) Then
                        $SelectedNetworkAdapters=$SelectedNetworkAdapters+1
                        _DebugConsole("Adapters:"&$SelectedNetworkAdapters)

                            local $macadress=_GUICtrlListView_GetItemText($mwlvMacadresses,$i)
                            local $adapter =_GUICtrlListView_GetItemText($mwlvNetWorkAdapters,$j,1)
                            wol_adapter($adapter,$macadress)
                            _DebugConsole("WOL for MAC:"&$macadress&" on ADAP:"&$adapter)
                            setStatusMsg("Check "&$macadress&" awake?")
                            $WOLSendCounter=$WOLSendCounter+1
                    EndIf

                Next


        EndIf
    Next
    if $WOLSendCounter<>0 then
        msgbox(64,"WOLLE","Done",60)
    EndIf
    if $SelectedMacEntries=0 then
        msgbox(64,"WOLLE","Sorry, no MAC/Ip selected for WakeUp")
    EndIf
    if $SelectedNetworkAdapters=0 then
        msgbox(64,"WOLLE","Sorry, no Adapter for Broadcast selected")
    EndIf

endfunc

; ===================================================================
; Function: wol_all
;
; ===================================================================
func wol_all()
    togglelistviewcheckboxes($mwlvMacadresses,true)
    togglelistviewcheckboxes($mwlvNetWorkAdapters,true)
    wol_selected()
endfunc
; ===================================================================
; Function: setStatusMsg($msgtext)
;           $msg    --- Message for status text
; ===================================================================
func setStatusMsg($msgtext)
    GUICtrlSetData($mwlblStatus,"Status:"&$msgtext)
endfunc
; ===================================================================
; Function: setStatusMsgNext($msgtext)
;           $msg    --- Message for status text
; ===================================================================
func setStatusMsgNext($msgtext)
    GUICtrlSetData($mwlblStatusNext,"Next trigger in:"&$msgtext)
endfunc
; ===================================================================
; Function: wol_adapter($adapter,$$macadress)
;           $adapter        --- is the ipadress of the adapter
;          $macadress       --- is the macadress
; ===================================================================

func wol_adapter($adapter,$macadress)
    if $adapter <> "0.0.0.0" Then
        $IPADRESS = StringSplit($adapter,".")
        $Broadcast = $IPADRESS[1] & "." & $IPADRESS[2] & "." & $IPADRESS[3] & "." & "255"

        $String=""
                setStatusMsg("Sent WOL via "&$Broadcast&" for:"&$macadress)
                _DebugConsole("Sent WOL via "&$Broadcast&" for:"&$macadress)
                WOL($Broadcast,$macadress)
    EndIf

    EndFunc

; ===================================================================
; Function: WOL($Broadcast,$element)
;          $Broadcast       --- is ipadress of adapter with 255 at the End
;           $MACAddress     --- is the macadress
; ===================================================================

; Wake up on Lan Function (Open connection and broadcast to Lan)
Func WOL($Broadcast,$MACAddress)
UDPStartUp()
$connexion = UDPOpen($Broadcast,7)
UDPSend($connexion, GenerateMagicPacket($MACAddress))
UDPCloseSocket($connexion)
UDPShutdown()
EndFunc


; This function convert a MAC Address Byte (e.g. "1f") to a char
Func HexToChar($strHex)

    Return Chr(Dec($strHex))

EndFunc

; This function generate the "Magic Packet"
Func GenerateMagicPacket($strMACAddress)

    $MagicPacket = ""
    $MACData = ""

    For $p = 1 To 11 Step 2
        $MACData = $MACData & HexToChar(StringMid($strMACAddress, $p, 2))
    Next

    For $p = 1 To 6
        $MagicPacket = HexToChar("ff") & $MagicPacket
    Next

    For $p = 1 To 16
        $MagicPacket = $MagicPacket & $MACData
    Next

    Return $MagicPacket

EndFunc

; ===================================================================
; Function: get_mac($remote_ip,$filemaclist)
;           $remote_ip      --- remote ip
;           $filemaclist    --- file in ini format
; enhanced by TheSovereign - skip local mac adress
; ===================================================================
func get_mac($remote_ip,$filemaclist="MACLIST.DAT")
                    Ping($remote_ip,200)
                    if @error =0 Then
                        $arpinfo = Run(@ComSpec & " /c ARP -a "&$remote_ip, @SystemDir, @SW_HIDE, 2)
                        sleep(200)
                        $output = StdoutRead($arpinfo, -1)
                            $aOutputLine=StringSplit($output,@CRLF)
                            If UBound($aOutputLine) > 5 Then ; <=== added so script doesn't choke when processing the IP for the computer it's running on
                                $macadress=Stringmid($aOutputLine[7],25,17)
                                $macadress=StringReplace($macadress,"-","")
                                IniWrite(@ScriptDir&"\"&$filemaclist,"MACLIST",$remote_ip,$macadress)
                                setStatusMsg("Found maclist "&$macadress)
                            EndIf ; <=== and this one...

                        Else
                            setStatusMsg("Host "&$remote_ip&" not reachable")
                            Return
                        endif
                    EndFunc




; ===================================================================
; Function: addNetworkAdapters2ListView()
;           Adds all networkadapters to the listviw
; ===================================================================
Func addNetworkAdapters2ListView()
        _GUICtrlListView_DeleteAllItems($mwlvNetWorkAdapters)
        for $i = 0 to Ubound($aNetWorkAdapters)-1
                GUICtrlCreateListViewItem(""&$aNetWorkAdapters[$i][0]&"|"&$aNetWorkAdapters[$i][1], $mwlvNetWorkAdapters)
        Next
    _GUICtrlListView_SetColumnWidth($mwlvNetWorkAdapters,0,$LVSCW_AUTOSIZE)

EndFunc
; ===================================================================
; Function: _getnetworkadapter()
;           Get All Network adapters with WMI
;           @IPAddressx does only support 4
; Original : 99ojo http://www.autoitscript.com/forum/index.php?showtopic=107247&view=findpost&p=756774
; ===================================================================

; WMI get only Adapter with ip settings
; If WMI fail or no adapter with ip settings Return 0
Func _getnetworkadapter ()
    $wbemFlagReturnImmediately = 0x10
    $wbemFlagForwardOnly = 0x20
    $colItems = ""
    $found = False
    $strComputer = "localhost"
    $count = 0
    $objWMIService = ObjGet("winmgmts:\\" & $strComputer & "\root\CIMV2")
    $colItems = $objWMIService.ExecQuery("SELECT * FROM Win32_NetworkAdapterConfiguration", "WQL", _
                                              $wbemFlagReturnImmediately + $wbemFlagForwardOnly)

    If IsObj($colItems) then
        For $objItem In $colItems
            If StringInStr ($objItem.IPAddress(0), ".") <> 0 Then
                ReDim $aNetWorkAdapters [$count + 1] [2]
                $aNetWorkAdapters [$count] [0] = $objItem.Caption ;corrected to $count
                $aNetWorkAdapters [$count] [1] = $objItem.IPAddress(0) ;corrected to $count
                $count += 1
                $found = True
            EndIf
        Next
    Else
        Return 0
    EndIf
    If Not $found Then Return 0
EndFunc
; ===================================================================
; Function: _DebugConsole()
;           Simple Console Output
; ===================================================================
Func  _DebugConsole($strString)
    consolewrite(@HOUR&@MIN&@SEC&" :"&$strString&@LF)
    EndFunc


WOLLE.AU3

Edited by Tankbuster

Share this post


Link to post
Share on other sites

@meomeo192, this thread is 9 years old, with code that was last updated in version 3.3.4.0, and an author that has not been active in 7 years. Do not hold your breath waiting for a response, or hoping the code is still 100% compatible with the latest version of AutoIt.

As AutoIt is a constantly evolving and growing language, you are going to be much better off creating a new thread and explaining in detail what you are attempting to accomplish, as well as what issues you are running into. If you began your script based on code in this thread, you can even include a link to here for reference, but post the code you are currently using, so people aren't trying to guess at what you're doing.


"Profanity is the last vestige of the feeble mind. For the man who cannot express himself forcibly through intellect must do so through shock and awe" - Spencer W. Kimball

How to get your question answered on this forum!

Share this post


Link to post
Share on other sites

Create an account or sign in to comment

You need to be a member in order to leave a comment

Create an account

Sign up for a new account in our community. It's easy!

Register a new account

Sign in

Already have an account? Sign in here.

Sign In Now
Sign in to follow this

  • Recently Browsing   0 members

    No registered users viewing this page.

×
×
  • Create New...
