joshiieeii

Vista Deployment Tool Wrapper (Imagex)

12 posts in this topic

#1 ·  Posted (edited)

Imagex GUI

Intended for use within WinPE 2.0

Note: you have to have imagex.exe in the same folder.

Update 4-9-07:

  • Added Poll image function to display what images are available within a wim file.
  • Added Automatic Reboot functionality.
gimagex.ini

[CAPTURE]
Source=C:
Destination=MyWim.wim
Compression=Fast
Flags=Enterprise
Config=
Boot=0
Check=1
Name=My Vista Build Name
Description=My Vista Build Description
[APPLY]
Source=M:\Vista.wim
Destination=C:
Verify=0
Name=1
[MAP]
Letter=M:
Share=\\networkshare\folder
User=domain.com\TestUser

gimagex.exe

#include <Constants.au3>
#include <GUIConstants.au3>
#include <Array.au3>
#include <Process.au3>
#include <String.au3>
#include <GuiTreeView.au3>


Dim $avDriveMapAdd[7]
$avDriveMapAdd[0]   = "Unknown Error"
$avDriveMapAdd[1]   = "Undefined / Other error"
$avDriveMapAdd[2]   = "Access to the remote share was denied"
$avDriveMapAdd[3]   = "The device is already assigned"
$avDriveMapAdd[4]   = "Invalid device name"
$avDriveMapAdd[5]   = "Invalid remote share"
$avDriveMapAdd[6]   = "Invalid password"

Dim $avPing [5]
$avPing[0] = "Unknown Error"
$avPing[1] = "Host is offline"
$avPing[2] = "Host is unreachable"
$avPing[3] = "Bad destination"
$avPing[4] = "Other errors"

; Global Settings
;
Dim $gCaptureSource
Dim $gCaptureDestination
Dim $gCaptureCompression
Dim $gCaptureFlags
Dim $gCaptureConfig
Dim $gCaptureBoot
Dim $gCaptureCheck
Dim $gCaptureName
Dim $gCaptureDescription

Dim $gApplySource
Dim $gApplyDestination
Dim $gApplyVerify
Dim $gApplyName
Dim $imageinfo
Dim $gMapLetter
Dim $gMapUser
Dim $gMapPassword
Dim $gMapShare
Dim $sIni = @ScriptDir & "\gimagex.ini"
Dim $res
;
; Create the main GUI
;
GUICreate("GImageX - ImageX GUI Wrapper", 640, 380, -1, -1 )
$hTab = GUICtrlCreateTab(10, 10, 620, 355)
$BaseX = 20
$BaseY = 35


; Drive Map Tab

$hTab_0 = GUICtrlCreateTabItem(" Drive Map ")

$CurX = $BaseX
$CurY = $BaseY

$CurY = $CurY + 10
GuiCtrlCreateGroup("Drive Mapping", $CurX+10, $CurY, 580, 135)
$CurY = $CurY + 18

GUICtrlCreateLabel("Letter", $CurX+20, $CurY+3)
$hMapLetter = GUICtrlCreateCombo("F:", $CurX+85, $CurY, 100, 500, $CBS_DROPDOWNLIST)
GUICtrlSetData(-1, "G:|H:|I:|J:|K:|L:|M:|N:|O:|P:|Q:|R:|S:|T:|U:|V:|W:|X:|Y:|Z:")

$CurY = $CurY + 27
GUICtrlCreateLabel("UNC Path", $CurX+20, $CurY+3)
$hMapShareEdit = GUICtrlCreateInput("\\Server\Sharename", $CurX+85, $CurY, 300)

$CurY = $CurY + 27
GUICtrlCreateLabel("Username", $CurX+20, $CurY+3)
$hMapUserEdit = GUICtrlCreateInput("Domain.com\%Username%", $CurX+85, $CurY, 300)

$CurY = $CurY + 27
GUICtrlCreateLabel("Password", $CurX+20, $CurY+3)
$hMapPasswordEdit = GUICtrlCreateInput("Password", $CurX+85, $CurY, 300, -1, $ES_PASSWORD)



$hMapButtonGo = GUICtrlCreateButton("&Map!", $BaseX+500, $BaseY+290, 100)

; Capture Tab
;
$hTab_1 = GUICtrlCreateTabItem("  Capture  ")

$CurX = $BaseX
$CurY = $BaseY

; File Group
$CurY = $CurY + 10
GuiCtrlCreateGroup("WIM Image", $CurX+10, $CurY, 580, 155)
$CurY = $CurY + 18
GUICtrlCreateLabel("Source", $CurX+20, $CurY+3)
$hCaptureSourceEdit = GUICtrlCreateInput("C:", $CurX+85, $CurY, 300)
$hCaptureSourceBrowse = GUICtrlCreateButton("Browse", $CurX+395, $CurY-2)

$CurY = $CurY + 27
GUICtrlCreateLabel("Destination", $CurX+20, $CurY+3)
$hCaptureDestEdit = GUICtrlCreateInput("MyWim.wim", $CurX+85, $CurY, 300)
$hCaptureDestBrowse = GUICtrlCreateButton("Browse", $CurX+395, $CurY-2)

$CurY = $CurY + 27
GUICtrlCreateLabel("Compression", $CurX+20, $CurY+3)
$hCaptureCompression = GUICtrlCreateCombo("Maximum", $CurX+85, $CurY, 100, 500, $CBS_DROPDOWNLIST)
GUICtrlSetData(-1, "Fast")

$CurY = $CurY + 27
GUICtrlCreateLabel("Name", $CurX+20, $CurY+3)
$hCaptureNameEdit = GUICtrlCreateInput("My Vista Image", $CurX+85, $CurY, 300)

$CurY = $CurY + 27
GUICtrlCreateLabel("Description", $CurX+20, $CurY+3)
$hCaptureDescEdit = GUICtrlCreateInput("My Vista Image Description", $CurX+85, $CurY, 300)

; Options Group
$CurY = $CurY + 40
GuiCtrlCreateGroup("Options", $CurX+10, $CurY, 580, 100)
$CurY = $CurY + 18

GUICtrlCreateLabel("/config", $CurX+20, $CurY+3)
$hCaptureConfigEdit = GUICtrlCreateInput("", $CurX+85, $CurY, 300)
$hCaptureConfigBrowse = GUICtrlCreateButton("Browse", $CurX+395, $CurY-2)

$CurY = $CurY + 27
GUICtrlCreateLabel("/flags", $CurX+20, $CurY+3)
$hCaptureFlagsEdit = GUICtrlCreateInput("Ultimate", $CurX+85, $CurY, 300)

$CurY = $CurY + 27
$hCaptureBootCheck = GUICtrlCreateCheckbox("/boot (WinPE Images Only) ", $CurX+20, $CurY)
$hCaptureCheckCheck = GUICtrlCreateCheckbox("/check", $CurX+190, $CurY)

$hCaptureButtonGo = GUICtrlCreateButton("&Capture!", $BaseX+500, $BaseY+290, 100)


;
; Apply Tab
;
$hTab_2 = GUICtrlCreateTabItem("  Apply  ")

$CurX = $BaseX
$CurY = $BaseY

; File Group
$CurY = $CurY + 10
GuiCtrlCreateGroup("WIM Image", $CurX+10, $CurY, 580, 205)
$CurY = $CurY + 18
GUICtrlCreateLabel("1. Source", $CurX+20, $CurY+3)
$hApplySourceEdit = GUICtrlCreateInput("MyWim.wim", $CurX+85, $CurY, 300)
$hApplySourceBrowse = GUICtrlCreateButton("Browse", $CurX+395, $CurY-2)

$CurY = $CurY + 27
GUICtrlCreateLabel ("Input Image Number", $CurX+15, $CurY+30, 70, 30)
$hApplyName = GUICtrlCreateInput("1", $CurX+85, $CurY+30, 40, 20)
$hApplyNameBrowse= GUICtrlCreateButton("2. Poll Image Number", $CurX+15, $CurY+1)
$treeview = GUICtrlCreateTreeView ( 150, 90, 450, 120, BitOr($TVS_HASBUTTONS, $TVS_HASLINES, $TVS_LINESATROOT, $TVS_DISABLEDRAGDROP, $TVS_SHOWSELALWAYS), $WS_EX_CLIENTEDGE)
$CurY = $CurY + 27
GUICtrlCreateLabel("Destination", $CurX+20, $CurY+103)
$hApplyDestEdit = GUICtrlCreateInput("C:", $CurX+85, $CurY+100, 300)
$hApplyDestBrowse = GUICtrlCreateButton("Browse", $CurX+395, $CurY+98)

; Options Group
$CurY = $CurY + 40
GuiCtrlCreateGroup("Options", $CurX+10, $CurY+100, 580, 50)
$CurY = $CurY + 18
Dim $hReboot = GUICtrlCreateCheckbox ( "Automatically Reboot", $CurX+20, $CurY+100, 130,15)
$hApplyVerifyCheck = GUICtrlCreateCheckbox("/verify", $CurX+150, $CurY+100, 100, 15 )
GUICtrlSetState ($hReboot, $GUI_CHECKED)
$hApplyButtonGo = GUICtrlCreateButton("&Apply!", $BaseX+500, $BaseY+290, 100)

;
; Set Default Options
;
LoadSettings()
SettingsToGUI()
;
; The GUI message loop
;
GuiSetState()
While 1
    $msg = GuiGetMsg()
    Select
        ; General Messages
        Case $msg = $GUI_EVENT_CLOSE
            ExitLoop

            ; Capture Messages
        Case $msg = $hCaptureButtonGo
            DoCapture()
        Case $msg = $hCaptureSourceBrowse
            $sDir = BrowseForDirectory()
            if $sDir Then GUICtrlSetData($hCaptureSourceEdit, $sDir)
        Case $msg = $hCaptureDestBrowse
            $sFile = BrowseForWimToSave()
            if $sFile Then GUICtrlSetData($hCaptureDestEdit, $sFile)
        Case $msg = $hCaptureConfigBrowse
            $sFile = BrowseForConfig()
            If $sFile Then GUICtrlSetData($hCaptureConfigEdit, $sFile)

            ; Apply Messages
        Case $msg = $hApplyNameBrowse
            PollImage()
        Case $msg = $hApplyButtonGo
            DoApply()
        Case $msg = $hApplyDestBrowse
            $sDir = BrowseForDirectory()
            if $sDir Then GUICtrlSetData($hApplyDestEdit, $sDir)
        Case $msg = $hApplySourceBrowse
            $sFile = BrowseForWimToLoad()
            if $sFile Then GUICtrlSetData($hApplySourceEdit, $sFile)

            ; Drive Map Messages
        Case $msg = $hMapButtonGo
            DoMapping()

        Case Else
            ;;;
    EndSelect
WEnd

Exit


;
; FUNCTIONS
;

Func BrowseForDirectory()
    $sDir = FileSelectFolder("Select source folder", "C:")
    If StringRight($sDir, 1) = "\" Then $sDir = StringTrimRight($sDir, 1)
    Return $sDir
EndFunc


Func BrowseForWimToSave()
    $sFile = FileSaveDialog( "Select destination file", "C:\", "WIM Files (*.wim)", 3)
    If @error Then Return ""

    If StringRight($sFile, 4) <> ".wIM" Then $sFile = $sFile & ".wim"

    Return $sFile
EndFunc


Func BrowseForWimToLoad()
    $sFile = FileOpenDialog( "Select source file", "C:\", "WIM Files (*.wim)", 3)
    If @error Then Return ""

    Return $sFile
EndFunc


Func BrowseForConfig()
    $sFile = FileOpenDialog("Select config file", @ScriptDir, "INI files (*.ini)", 1)
    If @error Or StringRight($sFile, 4) <> ".ini" Then Return ""

    Return $sFile
EndFunc


Func DoCapture()
    $sCmd = '"' & @ScriptDir & '\imagex.exe"'

    If $gCaptureConfig <> "" Then $sCmd = $sCmd & ' /config "' & $gCaptureConfig & '"'

    If $gCaptureCompression = "fast" Then
        $sCmd = $sCmd & " /compress fast"
    Else
        $sCmd = $sCmd & " /compress maximum"
    EndIf

    If $gCaptureCheck = 1 Then $sCmd = $sCmd & " /check"
    If $gCaptureBoot = 1 Then $sCmd = $sCmd & " /boot"
    If $gCaptureFlags <> "" Then $sCmd = $sCmd & ' /flags "' & $gCaptureFlags & '"'

    $sCmd = $sCmd & ' /capture "' & $gCaptureSource & '" "' & $gCaptureDestination & '"'
    $sCmd = $sCmd & ' "' & $gCaptureName & '" "' & $gCaptureDescription & '"'

    $ret = RunWait($sCmd, @WorkingDir, @SW_SHOW)
    SplashTextOn ( "Return Code", "Imagex.exe returned with code = " & $ret, 400, 200, -1, -1, 32, "Tahoma", 16, 500)
    sleep (3000)
    SplashOff ()

EndFunc

Func PollImage ()
    Dim $nitem, $nitem
    Dim $imageinfo = " "
    $read = GUICtrlRead ($hApplySourceEdit)
    $sCmd = "imagex.exe"
    If $read = "" Then
        MsgBox (48, "Input required", "Please select the source")
    Else
        $sCmd = $sCmd & ' /info "' & $read & '"'
    EndIf
    ;MsgBox(0, "scmd", $sCmd)
    Dim $ret = Run(@ComSpec & " /c " & $sCmd & '"', @ScriptDir, @SW_HIDE, $STDERR_CHILD + $STDOUT_CHILD )
    While 1
    $line = StdoutRead($ret)
    If $line = "" Then  ExitLoop
    $imageinfo = $imageinfo & $line
    ;MsgBox(0, "RunDOS", $line)
    If @error Then ExitLoop
    WEnd
     _GUICtrlTreeViewDeleteAllItems ($treeview)
    $aImageInfo = _StringBetween ( $imageinfo, "<name>", "</name>" )
    $aImageDesc = _StringBetween ( $imageinfo, "<Description>", "</Description>" )
    $aImageFileCount = _StringBetween ( $imageinfo, "<Filecount>", "</Filecount>" )
    $aImageBuild = _StringBetween ( $imageinfo, "<Build>", "</Build>" )
    $imagenumber = UBound ($aImageInfo, 1)
    $x = 0
    Dim $nitem[$imagenumber]
    Do
    $nitem[$x] = GUICtrlCreateTreeViewItem ( "Image " & $x +1 & ": " & $aImageInfo[$x], $treeview )
    GUICtrlCreateTreeViewItem ( "Description: " & $aImageDesc [$x], $nitem[$x] )
    GUICtrlCreateTreeViewItem ( "File Count: " & $aImageFileCount [$x], $nitem[$x] )
    GUICtrlCreateTreeViewItem ( "Build Version: " & $aImageBuild [$x], $nitem[$x] )
    GUICtrlSetState($nitem[$x], $GUI_DEFBUTTON)
    $x = $x + 1
    Until $x = $imagenumber
EndFunc

Func DoApply()
    $sCmd = '"' & @ScriptDir & '\imagex.exe"'

    If $gApplyVerify = 1 Then $sCmd = $sCmd & " /verify"

    $sCmd = $sCmd & ' /apply "' & $gApplySource & '" "' & $gApplyName & '" "' & $gApplyDestination & '"'
    $ret = RunWait($sCmd, @WorkingDir, @SW_SHOW)
    SplashTextOn ( "Return Code", "Imagex.exe returned with code = " & $ret, 400, 200, -1, -1, 32, "Tahoma", 16, 500)
    sleep (3000)
    SplashOff ()
    $Rebootstate = GUICtrlRead ($hReboot)
    If $Rebootstate = 1 Then
    _RunDOS("Start wpeutil reboot")
    EndIf
EndFunc


Func DoMapping()
    $gMapLetter = IniRead($sIni, "MAP", "Letter", "V:")
    DriveMapDel($gMapLetter)
    $gMapShare = IniRead($sIni, "Map", "Share", "")
    $VistaAccount = GUICtrlRead ( $hMapUserEdit )
    $VistaPwd = GUICtrlRead ( $hMapPasswordEdit )
    $res = DriveMapAdd($gMapLetter, $gMapShare, 0, $VistaAccount, $VistaPwd)

    If $res Then
        ControlSetText("Mapping Drive", "", "Static1", "Drive successfully mapped!" )
        sleep (2000)
        ;MsgBox(64, "Drive Mapping", "Drive successfully mapped!")
    Else
        SplashOff()
        MsgBox(16, "Drive Mapping", "Error mapping drive! Code: " & $avDriveMapAdd[@error])

    EndIf
EndFunc

Func LoadSettings()
    $sIni = @ScriptDir & "\gimagex.ini"

    $gCaptureSource = IniRead($sIni, "CAPTURE", "Source", "C:")
    $gCaptureDestination = IniRead($sIni, "CAPTURE", "Destination", "MyWim.wim")
    $gCaptureCompression = IniRead($sIni, "CAPTURE", "Compression", "Maximum")
    $gCaptureFlags = IniRead($sIni, "CAPTURE", "Flags", "Ultimate")
    $gCaptureConfig = IniRead($sIni, "CAPTURE", "Config", "")
    $gCaptureBoot = IniRead($sIni, "CAPTURE", "Boot", "0")
    $gCaptureCheck = IniRead($sIni, "CAPTURE", "Check", "1")
    $gCaptureName = IniRead($sIni, "CAPTURE", "Name", "My Vista Build Name")
    $gCaptureDescription = IniRead($sIni, "CAPTURE", "Description", "My Vista Build Description")

    $gApplySource = IniRead($sIni, "APPLY", "Source", "C:")
    $gApplyDestination = IniRead($sIni, "APPLY", "Destination", "MyWim.wim")
    $gApplyVerify = IniRead($sIni, "APPLY", "Verify", "0")
    $gApplyName = IniRead($sIni, "APPLY", "Name", "My Vista Build Name")

    $gMapLetter = IniRead($sIni, "MAP", "Letter", "M:")
    $gMapShare = IniRead($sIni, "MAP", "Share", "\\Server\Share")
    $gMapUser = IniRead($sIni, "MAP", "User", "User")

EndFunc


Func SettingsToGUI()

    ; CAPTURE
    GUICtrlSetData($hCaptureSourceEdit, $gCaptureSource)
    GUICtrlSetData($hCaptureDestEdit, $gCaptureDestination)
    GUICtrlSetData($hCaptureCompression, $gCaptureCompression)
    GUICtrlSetData($hCaptureFlagsEdit, $gCaptureFlags)
    GUICtrlSetData($hCaptureConfigEdit, $gCaptureConfig)
    If $gCaptureBoot = 1 Then
        GUICtrlSetState($hCaptureBootCheck, $GUI_CHECKED)
    Else
        GUICtrlSetState($hCaptureBootCheck, $GUI_UNCHECKED)
    EndIf
    If $gCaptureCheck = 1 Then
        GUICtrlSetState($hCaptureCheckCheck, $GUI_CHECKED)
    Else
        GUICtrlSetState($hCaptureCheckCheck, $GUI_UNCHECKED)
    EndIf
    GUICtrlSetData($hCaptureNameEdit, $gCaptureName)
    GUICtrlSetData($hCaptureDescEdit, $gCaptureDescription)

    ; APPLY
    GUICtrlSetData($hApplySourceEdit, $gApplySource)
    GUICtrlSetData($hApplyDestEdit, $gApplyDestination)
    If $gApplyVerify = 1 Then
        GUICtrlSetState($hApplyVerifyCheck, $GUI_CHECKED)
    Else
        GUICtrlSetState($hApplyVerifyCheck, $GUI_UNCHECKED)
    EndIf
    GUICtrlSetData($hApplyName, $gApplyName)

    ; MAP
    GUICtrlSetData($hMapLetter, $gMapLetter)
    GUICtrlSetData($hMapShareEdit, $gMapShare)
    GUICtrlSetData($hMapUserEdit, $gMapUser)
    GUICtrlSetData($hMapPasswordEdit, $gMapPassword)

EndFunc
Edited by joshiieeii

Share this post


Link to post
Share on other sites



Hi guys,

Jon had posted some script HERE. I thought I would add on to it a little.

Goals:

  • Make the Image Selection process a little neater (under Apply tab)
  • Clear password and username after successfully mapping drive (under Drive map tab)
Note: you have to have imagex.exe in the same folder.

I am hoping to get some suggestions on how to improve the PollImage function, it's a bit sloppy, but I wanted to share what I have thus far with everyone.

This is what I have thus far (it's not as neat as Jon's code):

;
; Constants from GuiConstant.au3 (or just include GuiConstants.au3 instead)
#include <Constants.au3>
#Include<Array.au3>
Global Const $CBS_DROPDOWNLIST      = 0x0003
Global Const $ES_PASSWORD           = 32
Global Const $GUI_EVENT_CLOSE       = -3
Global Const $GUI_CHECKED           = 1
Global Const $GUI_INDETERMINATE     = 2
Global Const $GUI_UNCHECKED         = 4
Dim $sArrayString, $imageSelection
;
; Global Settings
;
Dim $gCaptureSource
Dim $gCaptureDestination
Dim $gCaptureCompression
Dim $gCaptureFlags
Dim $gCaptureConfig
Dim $gCaptureBoot
Dim $gCaptureCheck
Dim $gCaptureName
Dim $gCaptureDescription

Dim $gApplySource
Dim $gApplyDestination
Dim $gApplyVerify
Dim $gApplyName

Dim $gMapLetter
Dim $gMapUser
Dim $gMapPassword
Dim $gMapShare
;
; Create the main GUI
;
GUICreate("GImageX - ImageX GUI Wrapper", 640, 380, -1, -1 )
$hTab = GUICtrlCreateTab(10, 10, 620, 355)
$BaseX = 20
$BaseY = 35
$Domain = @LogonDomain

;
; Drive Map Tab
;
$hTab_0 = GUICtrlCreateTabItem(" Drive Map ")

$CurX = $BaseX
$CurY = $BaseY

$CurY = $CurY + 10
GuiCtrlCreateGroup("Drive Mapping", $CurX+10, $CurY, 580, 135)
$CurY = $CurY + 18

GUICtrlCreateLabel("Letter", $CurX+20, $CurY+3)
$hMapLetter = GUICtrlCreateCombo("F:", $CurX+85, $CurY, 100, 500, $CBS_DROPDOWNLIST)
GUICtrlSetData(-1, "G:|H:|I:|J:|K:|L:|M:|N:|O:|P:|Q:|R:|S:|T:|U:|V:|W:|X:|Y:|Z:")

$CurY = $CurY + 27
GUICtrlCreateLabel("UNC Path", $CurX+20, $CurY+3)
$hMapShareEdit = GUICtrlCreateInput("\\Server\Sharename", $CurX+85, $CurY, 300)

$CurY = $CurY + 27
GUICtrlCreateLabel($domain, $CurX+20, $CurY+3)
$hMapUserEdit = GUICtrlCreateInput("%Username%", $CurX+85, $CurY, 300)

$CurY = $CurY + 27
GUICtrlCreateLabel("Password", $CurX+20, $CurY+3)
$hMapPasswordEdit = GUICtrlCreateInput("Password", $CurX+85, $CurY, 300, -1, $ES_PASSWORD)

$hMapButtonGo = GUICtrlCreateButton("&Map!", $BaseX+500, $BaseY+290, 100)
;
; Capture Tab
;
$hTab_1 = GUICtrlCreateTabItem("  Capture  ")

$CurX = $BaseX
$CurY = $BaseY

; File Group
$CurY = $CurY + 10
GuiCtrlCreateGroup("WIM Image", $CurX+10, $CurY, 580, 155)
$CurY = $CurY + 18
GUICtrlCreateLabel("Source", $CurX+20, $CurY+3)
$hCaptureSourceEdit = GUICtrlCreateInput("C:", $CurX+85, $CurY, 300)
$hCaptureSourceBrowse = GUICtrlCreateButton("Browse", $CurX+395, $CurY-2)

$CurY = $CurY + 27
GUICtrlCreateLabel("Destination", $CurX+20, $CurY+3)
$hCaptureDestEdit = GUICtrlCreateInput("MyWim.wim", $CurX+85, $CurY, 300)
$hCaptureDestBrowse = GUICtrlCreateButton("Browse", $CurX+395, $CurY-2)

$CurY = $CurY + 27
GUICtrlCreateLabel("Compression", $CurX+20, $CurY+3)
$hCaptureCompression = GUICtrlCreateCombo("Maximum", $CurX+85, $CurY, 100, 500, $CBS_DROPDOWNLIST)
GUICtrlSetData(-1, "Fast")

$CurY = $CurY + 27
GUICtrlCreateLabel("Name", $CurX+20, $CurY+3)
$hCaptureNameEdit = GUICtrlCreateInput("My Vista Image", $CurX+85, $CurY, 300)

$CurY = $CurY + 27
GUICtrlCreateLabel("Description", $CurX+20, $CurY+3)
$hCaptureDescEdit = GUICtrlCreateInput("My Vista Image Description", $CurX+85, $CurY, 300)

; Options Group
$CurY = $CurY + 40
GuiCtrlCreateGroup("Options", $CurX+10, $CurY, 580, 100)
$CurY = $CurY + 18

GUICtrlCreateLabel("/config", $CurX+20, $CurY+3)
$hCaptureConfigEdit = GUICtrlCreateInput("", $CurX+85, $CurY, 300)
$hCaptureConfigBrowse = GUICtrlCreateButton("Browse", $CurX+395, $CurY-2)

$CurY = $CurY + 27
GUICtrlCreateLabel("/flags", $CurX+20, $CurY+3)
$hCaptureFlagsEdit = GUICtrlCreateInput("Ultimate", $CurX+85, $CurY, 300)

$CurY = $CurY + 27
$hCaptureBootCheck = GUICtrlCreateCheckbox("/boot (WinPE Images Only) ", $CurX+20, $CurY)
$hCaptureCheckCheck = GUICtrlCreateCheckbox("/check", $CurX+190, $CurY)

$hCaptureButtonGo = GUICtrlCreateButton("&Capture!", $BaseX+500, $BaseY+290, 100)
;
; Apply Tab
;
$hTab_2 = GUICtrlCreateTabItem("  Apply  ")

$CurX = $BaseX
$CurY = $BaseY

; File Group
$CurY = $CurY + 10
GuiCtrlCreateGroup("WIM Image", $CurX+10, $CurY, 580, 205)
$CurY = $CurY + 18
GUICtrlCreateLabel("1. Source", $CurX+20, $CurY+3)
$hApplySourceEdit = GUICtrlCreateInput("MyWim.wim", $CurX+85, $CurY, 300)
$hApplySourceBrowse = GUICtrlCreateButton("Browse", $CurX+395, $CurY-2)

$CurY = $CurY + 27

;~ $hApplyName = GUICtrlCreateInput("1", $CurX+85, $CurY, 300)
$hApplyNameBrowse= GUICtrlCreateButton("2. Select Image", $CurX+15, $CurY+3)
$CurY = $CurY + 27
GUICtrlCreateLabel("Destination", $CurX+20, $CurY+103)
$hApplyDestEdit = GUICtrlCreateInput("C:", $CurX+85, $CurY+100, 300)
$hApplyDestBrowse = GUICtrlCreateButton("Browse", $CurX+395, $CurY+98)

; Options Group
$CurY = $CurY + 40
GuiCtrlCreateGroup("Options", $CurX+10, $CurY+100, 580, 50)
$CurY = $CurY + 18

$hApplyVerifyCheck = GUICtrlCreateCheckbox("/verify", $CurX+20, $CurY+100)

$hApplyButtonGo = GUICtrlCreateButton("&Apply!", $BaseX+500, $BaseY+290, 100)
;
; Set Default Options
;
LoadSettings()
SettingsToGUI();

;
; The GUI message loop
;
GuiSetState()
While 1
    $msg = GuiGetMsg()
    Select
        ; General Messages
        Case $msg = $GUI_EVENT_CLOSE
            GUIToSettings()
            SaveSettings()
            ExitLoop

        ; Capture Messages
        Case $msg = $hCaptureButtonGo
            DoCapture()
        Case $msg = $hCaptureSourceBrowse
            $sDir = BrowseForDirectory()
            if $sDir Then GUICtrlSetData($hCaptureSourceEdit, $sDir)
        Case $msg = $hCaptureDestBrowse
            $sFile = BrowseForWimToSave()
            if $sFile Then GUICtrlSetData($hCaptureDestEdit, $sFile)
        Case $msg = $hCaptureConfigBrowse
            $sFile = BrowseForConfig()
            If $sFile Then GUICtrlSetData($hCaptureConfigEdit, $sFile)

        ; Apply Messages
        Case $msg = $hApplyNameBrowse
            PollImage()
        Case $msg = $hApplyButtonGo
            DoApply()
        Case $msg = $hApplyDestBrowse
            $sDir = BrowseForDirectory()
            if $sDir Then GUICtrlSetData($hApplyDestEdit, $sDir)
        Case $msg = $hApplySourceBrowse
            $sFile = BrowseForWimToLoad()
            if $sFile Then GUICtrlSetData($hApplySourceEdit, $sFile)

        ; Drive Map Messages
        Case $msg = $hMapButtonGo
            DoMapping()

        Case Else
        ;;;
    EndSelect
WEnd

Exit
;
; FUNCTIONS
;

Func BrowseForDirectory()
    $sDir = FileSelectFolder("Select source folder", "C:")
    If StringRight($sDir, 1) = "\" Then $sDir = StringTrimRight($sDir, 1)
    Return $sDir
EndFunc
Func BrowseForWimToSave()
    $sFile = FileSaveDialog( "Select destination file", "C:\", "WIM Files (*.wim)", 3)
    If @error Then Return ""

    If StringRight($sFile, 4) <> ".wIM" Then $sFile = $sFile & ".wim"

    Return $sFile
EndFunc
Func BrowseForWimToLoad()
    $sFile = FileOpenDialog( "Select source file", "C:\", "WIM Files (*.wim)", 3)
    If @error Then Return ""

    Return $sFile
EndFunc
Func BrowseForConfig()
    $sFile = FileOpenDialog("Select config file", @ScriptDir, "INI files (*.ini)", 1)
    If @error Or StringRight($sFile, 4) <> ".ini" Then Return ""

    Return $sFile
EndFunc
Func DoCapture()
    GUIToSettings()
    SaveSettings()

    $sCmd = '"' & @ScriptDir & '\imagex.exe"'

    If $gCaptureConfig <> "" Then $sCmd = $sCmd & ' /config "' & $gCaptureConfig & '"'

    If $gCaptureCompression = "fast" Then
        $sCmd = $sCmd & " /compress fast"
    Else
        $sCmd = $sCmd & " /compress maximum"
    EndIf

    If $gCaptureCheck = 1 Then $sCmd = $sCmd & " /check"
    If $gCaptureBoot = 1 Then $sCmd = $sCmd & " /boot"
    If $gCaptureFlags <> "" Then $sCmd = $sCmd & ' /flags "' & $gCaptureFlags & '"'

    $sCmd = $sCmd & ' /capture "' & $gCaptureSource & '" "' & $gCaptureDestination & '"'
    $sCmd = $sCmd & ' "' & $gCaptureName & '" "' & $gCaptureDescription & '"'

    ;MsgBox(0, "Debug", $sCmd)
    ;$ret = RunWait('imagex.exe /compress fast /capture "c:\drv\nvid" test.wim "test"', @WorkingDir, @SW_SHOW)
    ;$foo = RunWait('imagex.exe /compress fast /scroll /capture "c:\drv\nvid" test.wim "test"', @WorkingDir, @SW_SHOW, $STDOUT_CHILD)
    $ret = RunWait($sCmd, @WorkingDir, @SW_SHOW)
    MsgBox(0, "ImageX.exe", "Imagex.exe returned with code = " & $ret)

EndFunc

Func PollImage ()
    $file = @ScriptDir & '\imagex.ini'
    $sCmd = '"' & @ScriptDir & '\imagex.exe"'
    $edit = GUICtrlRead ($hApplySourceEdit)
    $sCmd = $sCmd & ' /info ' & $edit

    $foo = Run(@ComSpec & " /c " & $sCmd, @WorkingDir, @SW_HIDE, $STDERR_CHILD + $STDOUT_CHILD)

    $avArray = _ArrayCreate ("test")
    While 1
    $line = StdoutRead($foo)
    If @error Then ExitLoop
    _ArrayAdd ( $avArray, $line)
    Wend

    While 1
    $line = StderrRead($foo)
    If @error Then ExitLoop
    MsgBox(0, "STDERR read:", $line)
    Wend
    _ArrayDisplay ($avArray, "array results")

    Dim $sArrayString = _ArrayToString ($avArray, ";")
    $image_count = StringInStr ( $sArrayString, "Image Count:", 0)
    $image_namein = StringInStr ( $sArrayString, "<NAME>", 0)
    $image_nameout = StringInStr ( $sArrayString, "</NAME>", 0)
    $image_nameCount = $image_nameout - $image_namein
    $test = StringMid ( $sArrayString, $image_count, 15)
    $imagename1 = StringMid ( $sArrayString, $image_namein+6, $image_nameCount-6)
    ;MsgBox (0, "Results:", $imagename1)
    Dim $imageSelection = GUICtrlCreateCheckbox ( $imagename1, $CurX+15, $CurY-50)

    ;pulls description from wim image
    $image_descin = StringInStr ( $sArrayString, "<DESCRIPTION>", 0)
    $image_descout = StringInStr ( $sArrayString, "</DESCRIPTION>", 0)
    $image_descCount = $image_descout - $image_descin
    $imageDescription = StringMid ( $sArrayString, $image_descin+13, $image_descCount-13)
    GUICtrlCreateLabel ( "Description: " & $imageDescription, $CurX+15, $CurY-30, 200, 15)


EndFunc

Func DoApply()
    GUIToSettings()
    SaveSettings()

    $sCmd = '"' & @ScriptDir & '\imagex.exe"'
    If $imageSelection = 1 then $gApplySource = 1

    If $gApplyVerify = 1 Then $sCmd = $sCmd & " /verify"

    $sCmd = $sCmd & ' /apply "' & $gApplySource & '" "' & $gApplyName & '" "' & $gApplyDestination & '"'

    ;MsgBox(0, "Debug", $sCmd)
    ;$ret = RunWait('imagex.exe /compress fast /capture "c:\drv\nvid" test.wim "test"', @WorkingDir, @SW_SHOW)
    ;$foo = RunWait('imagex.exe /compress fast /scroll /capture "c:\drv\nvid" test.wim "test"', @WorkingDir, @SW_SHOW, $STDOUT_CHILD)
    $ret = RunWait($sCmd, @WorkingDir, @SW_SHOW)
    MsgBox(0, "ImageX.exe", "Imagex.exe returned with code = " & $ret)

EndFunc
Func DoMapping()
    GUIToSettings()
    SaveSettings()

    DriveMapDel($gMapLetter)

    If $gMapUser Then
        $res = DriveMapAdd($gMapLetter, $gMapShare, 0, $domain & $gMapUser, $gMapPassword)
    Else
        $res = DriveMapAdd($gMapLetter, $gMapShare, 0)
    EndIf

    If $res Then
        MsgBox(64, "Drive Mapping", "Drive successfully mapped!")
    Else
        MsgBox(16, "Drive Mapping", "Error mapping drive!")
    EndIf

EndFunc
Func LoadSettings()
    $sIni = @ScriptDir & "\gimagex.ini"

    $gCaptureSource = IniRead($sIni, "CAPTURE", "Source", "C:")
    $gCaptureDestination = IniRead($sIni, "CAPTURE", "Destination", "MyWim.wim")
    $gCaptureCompression = IniRead($sIni, "CAPTURE", "Compression", "Maximum")
    $gCaptureFlags = IniRead($sIni, "CAPTURE", "Flags", "Ultimate")
    $gCaptureConfig = IniRead($sIni, "CAPTURE", "Config", "")
    $gCaptureBoot = IniRead($sIni, "CAPTURE", "Boot", "0")
    $gCaptureCheck = IniRead($sIni, "CAPTURE", "Check", "1")
    $gCaptureName = IniRead($sIni, "CAPTURE", "Name", "My Vista Build Name")
    $gCaptureDescription = IniRead($sIni, "CAPTURE", "Description", "My Vista Build Description")

    $gApplySource = IniRead($sIni, "APPLY", "Source", "C:")
    $gApplyDestination = IniRead($sIni, "APPLY", "Destination", "MyWim.wim")
    $gApplyVerify = IniRead($sIni, "APPLY", "Verify", "0")
    $gApplyName = IniRead($sIni, "APPLY", "Name", "My Vista Build Name")

    $gMapLetter = IniRead($sIni, "MAP", "Letter", "M:")
    $gMapShare = IniRead($sIni, "MAP", "Share", "\\Server\Share")
    $gMapUser = IniRead($sIni, "MAP", "User", "User")

EndFunc
Func SaveSettings()
    $sIni = @ScriptDir & "\gimagex.ini"

    IniWrite($sIni, "CAPTURE", "Source", $gCaptureSource)
    IniWrite($sIni, "CAPTURE", "Destination", $gCaptureDestination)
    IniWrite($sIni, "CAPTURE", "Compression", $gCaptureCompression)
    IniWrite($sIni, "CAPTURE", "Flags", $gCaptureFlags)
    IniWrite($sIni, "CAPTURE", "Config", $gCaptureConfig)
    IniWrite($sIni, "CAPTURE", "Boot", $gCaptureBoot)
    IniWrite($sIni, "CAPTURE", "Check", $gCaptureCheck)
    IniWrite($sIni, "CAPTURE", "Name", $gCaptureName)
    IniWrite($sIni, "CAPTURE", "Description", $gCaptureDescription)

    IniWrite($sIni, "APPLY", "Source", $gApplySource)
    IniWrite($sIni, "APPLY", "Destination", $gApplyDestination)
    IniWrite($sIni, "APPLY", "Verify", $gApplyVerify)
    IniWrite($sIni, "APPLY", "Name", $gApplyName)

    IniWrite($sIni, "MAP", "Letter", $gMapLetter)
    IniWrite($sIni, "MAP", "Share", $gMapShare)
    IniWrite($sIni, "MAP", "User", $gMapUser)

EndFunc
Func SettingsToGUI()

    ; CAPTURE
    GUICtrlSetData($hCaptureSourceEdit, $gCaptureSource)
    GUICtrlSetData($hCaptureDestEdit, $gCaptureDestination)
    GUICtrlSetData($hCaptureCompression, $gCaptureCompression)
    GUICtrlSetData($hCaptureFlagsEdit, $gCaptureFlags)
    GUICtrlSetData($hCaptureConfigEdit, $gCaptureConfig)
    If $gCaptureBoot = 1 Then
        GUICtrlSetState($hCaptureBootCheck, $GUI_CHECKED)
    Else
        GUICtrlSetState($hCaptureBootCheck, $GUI_UNCHECKED)
    EndIf
    If $gCaptureCheck = 1 Then
        GUICtrlSetState($hCaptureCheckCheck, $GUI_CHECKED)
    Else
        GUICtrlSetState($hCaptureCheckCheck, $GUI_UNCHECKED)
    EndIf
    GUICtrlSetData($hCaptureNameEdit, $gCaptureName)
    GUICtrlSetData($hCaptureDescEdit, $gCaptureDescription)

    ; APPLY
    GUICtrlSetData($hApplySourceEdit, $gApplySource)
    GUICtrlSetData($hApplyDestEdit, $gApplyDestination)
    If $gApplyVerify = 1 Then
        GUICtrlSetState($hApplyVerifyCheck, $GUI_CHECKED)
    Else
        GUICtrlSetState($hApplyVerifyCheck, $GUI_UNCHECKED)
    EndIf
;~  GUICtrlSetData($hApplyName, $gApplyName)

    ; MAP
    GUICtrlSetData($hMapLetter, $gMapLetter)
    GUICtrlSetData($hMapShareEdit, $gMapShare)
    GUICtrlSetData($domain & $hMapUserEdit, $gMapUser)
    GUICtrlSetData($hMapPasswordEdit, $gMapPassword)

EndFunc
Func GUIToSettings()

    ; CAPTURE
    $gCaptureSource = GUICtrlRead($hCaptureSourceEdit)
    $gCaptureDestination = GUICtrlRead($hCaptureDestEdit)
    $gCaptureCompression = GUICtrlRead($hCaptureCompression)
    $gCaptureFlags = GUICtrlRead($hCaptureFlagsEdit)
    $gCaptureConfig = GUICtrlRead($hCaptureConfigEdit)
    If GUICtrlRead($hCaptureBootCheck) = $GUI_CHECKED Then
        $gCaptureBoot = 1
    Else
        $gCaptureBoot = 0
    EndIf
    If GUICtrlRead($hCaptureCheckCheck) = $GUI_CHECKED Then
        $gCaptureCheck = 1
    Else
        $gCaptureCheck = 0
    EndIf
    $gCaptureName = GUICtrlRead($hCaptureNameEdit)
    $gCaptureDescription = GUICtrlRead($hCaptureDescEdit)

    ; APPLY
    $gApplySource = GUICtrlRead($hApplySourceEdit)
    $gApplyDestination = GUICtrlRead($hApplyDestEdit)
    If GUICtrlRead($hApplyVerifyCheck) = $GUI_CHECKED Then
        $gApplyVerify = 1
    Else
        $gApplyVerify = 0
    EndIf
;~  $gApplyName = GUICtrlRead($hApplyName)

    ; MAP
    $gMapLetter = GUICtrlRead($hMapLetter)
    $gMapShare = GUICtrlRead($hMapShareEdit)
    $gMapUser= GUICtrlRead($domain & $hMapUserEdit)
    $gMapPassword= GUICtrlRead($hMapPasswordEdit)

EndFunc

joshiieeii, excellent script would it be possible to edit the script so it can mount and unmount WIM images on local partitions or folders

Thanks

Share this post


Link to post
Share on other sites

@joshiieeii

I really like the changes you've made to Jons code looking forward to seeing it progress.

It's probably something I'm doing wrong, but when I try and map a drive, I get the following error.

"Error mapping drive! Code: Unknown Error"

With Jon's orginal code, I do not get this error.

Thanks and keep up the effort!

-Mike

Share this post


Link to post
Share on other sites

Since I'm a newbie and can't seem to figure out how to edit my own post :"> ...

Maybe my problem is I'm trying to map in WinXP Pro and PE 1.2 - do I need PE 2.0 to use this version or is it just a suggestion?

Thanks again,

-Mike

Share this post


Link to post
Share on other sites

i really like your program but im having problems with it. i can capture an image fine but i cannot deploy (error 2). i have both gimagex.exe and gimagex.ini in the windows folder where imagex.exe is. i think whatever info is in gimagex.ini is what the program uses even if you change options in the gui. if im doing something wrong please let me know. also would it be possible to edit the script so it can mount and unmount WIM images on local partitions or folders. again great program.

Share this post


Link to post
Share on other sites

#6 ·  Posted (edited)

Very nice StdoutRead & _StringBetween & GUICtrlCreateTreeViewItem example code.

Func PollImage ()
    Dim $nitem, $nitem
    Dim $imageinfo = " "
    $read = GUICtrlRead ($hApplySourceEdit)
    $sCmd = "imagex.exe"
    If $read = "" Then
        MsgBox (48, "Input required", "Please select the source")
    Else
        $sCmd = $sCmd & ' /info "' & $read & '"'
    EndIf
    ;MsgBox(0, "scmd", $sCmd)
    Dim $ret = Run(@ComSpec & " /c " & $sCmd & '"', @ScriptDir, @SW_HIDE, $STDERR_CHILD + $STDOUT_CHILD )
    While 1
    $line = StdoutRead($ret)
    If $line = "" Then  ExitLoop
    $imageinfo = $imageinfo & $line
    ;MsgBox(0, "RunDOS", $line)
    If @error Then ExitLoop
    WEnd
     _GUICtrlTreeViewDeleteAllItems ($treeview)
    $aImageInfo = _StringBetween ( $imageinfo, "<name>", "</name>" )
    $aImageDesc = _StringBetween ( $imageinfo, "<Description>", "</Description>" )
    $aImageFileCount = _StringBetween ( $imageinfo, "<Filecount>", "</Filecount>" )
    $aImageBuild = _StringBetween ( $imageinfo, "<Build>", "</Build>" )
    $imagenumber = UBound ($aImageInfo, 1)
    $x = 0
    Dim $nitem[$imagenumber]
    Do
    $nitem[$x] = GUICtrlCreateTreeViewItem ( "Image " & $x +1 & ": " & $aImageInfo[$x], $treeview )
    GUICtrlCreateTreeViewItem ( "Description: " & $aImageDesc [$x], $nitem[$x] )
    GUICtrlCreateTreeViewItem ( "File Count: " & $aImageFileCount [$x], $nitem[$x] )
    GUICtrlCreateTreeViewItem ( "Build Version: " & $aImageBuild [$x], $nitem[$x] )
    GUICtrlSetState($nitem[$x], $GUI_DEFBUTTON)
    $x = $x + 1
    Until $x = $imagenumber
EndFunc
Edited by Zedna

Share this post


Link to post
Share on other sites

i just tried the original code by Jon and all works without problem.

Share this post


Link to post
Share on other sites

Has any of you been able to use ImageX to apply a spanned image. It's a rather ridiculous problem if you ask me because imageX allows you to split the files but not apply them while they are split. Any feedback or experience is much appreciated.

Share this post


Link to post
Share on other sites

Hello.

I am trying to apply a image using this tool but is not working.

I can map a network drive and capture a image, but when i am trying to apply a image from the network location to the C: is not working. returns error=2.

Any ideas why this happens?

Thanks


Please allow me to introduce myself I'm a man of wealth and taste I've been around for a long, long year Stole many a man's soul and faith

Share this post


Link to post
Share on other sites

Hello people, i'm really impressed with this tool i've extended it to include Mount- Unmount, Append, Export, Delete, Info and Split building it up the original script by joshiieeii and the progress bar, DiskPartioner and rtlconsol by ImageXGUI .... i also put a function to save the settings automatically and i'm planning to include a way to make exclusion list ...

here is the script :

#include <Constants.au3>
#include <GUIConstants.au3>
#include <Array.au3>
#include <Process.au3>
#include <String.au3>
#include <GuiTreeView.au3>
#include <Date.au3>

Dim $avDriveMapAdd[7]
$avDriveMapAdd[0] = "Unknown Error"
$avDriveMapAdd[1] = "Undefined / Other error"
$avDriveMapAdd[2] = "Access to the remote share was denied"
$avDriveMapAdd[3] = "The device is already assigned"
$avDriveMapAdd[4] = "Invalid device name"
$avDriveMapAdd[5] = "Invalid remote share"
$avDriveMapAdd[6] = "Invalid password"

Dim $avPing [5]
$avPing[0] = "Unknown Error"
$avPing[1] = "Host is offline"
$avPing[2] = "Host is unreachable"
$avPing[3] = "Bad destination"
$avPing[4] = "Other errors"

; Global Settings
Global $line1
Global $line3
;Capture
Dim $gCaptureSource
Dim $gCaptureDestination
Dim $gCaptureCompression
Dim $gCaptureFlags
Dim $gCaptureConfig
Dim $gCaptureBoot
Dim $gCaptureCheck
Dim $gCaptureName
Dim $gCaptureDescription
Dim $gCaptureDiag
;Export
Dim $gExportSource
Dim $gExportDestination
Dim $gExportCompression
Dim $gExportFlags
Dim $gExportConfig
Dim $gExportBoot
Dim $gExportCheck
Dim $gExportName
Dim $gExportDescription
Dim $gExportNumber
;Info
Dim $gInfoSource
Dim $gInfoFlags
Dim $gInfoBoot
Dim $gInfoCheck
Dim $gInfoName
Dim $gInfoDescription
Dim $gInfoNumber
;Split
Dim $gSplitSource
Dim $gSplitFlags
Dim $gSplitBoot
Dim $gSplitCheck
Dim $gSplitName
Dim $gSplitDescription
Dim $gSplitNumber
;Append
Dim $gAppendSource
Dim $gAppendDestination
Dim $gAppendCompression
Dim $gAppendFlags
Dim $gAppendConfig
Dim $gAppendBoot
Dim $gAppendCheck
Dim $gAppendName
Dim $gAppendDescription
;Delete
Dim $gDeleteSource
Dim $gDeleteDestination
Dim $gDeleteName
Dim $gDelCheck
;Mount
Dim $gMountSource
Dim $gMountDestination
Dim $gMountName
Dim $gRWCheck
;Apply
Dim $gApplySource
Dim $gApplyDestination
Dim $gApplyVerify
Dim $gApplyName
Dim $imageinfo
Dim $gMapLetter
Dim $gMapUser
Dim $gMapPassword
Dim $gMapShare
Dim $sIni = @ScriptDir & "\gimagex.ini"
Dim $res
Dim $foo
Dim $gCaptureDiag
Dim $gApplyDiag

;
;Check for ImageX required files
;
If FileExists(@ScriptDir & "\imagex.exe") Then;File Found
ElseIf FileExists(@ScriptDir & "\wimfltr.dll") Then;File Found
ElseIf FileExists(@ScriptDir & "\wimfltr.sys") Then;File Found
ElseIf FileExists(@ScriptDir & "\wimgapi.dll") Then;File Found
Else
    MsgBox(4096, "ImageXGUI", "You are missing one of the required files in the current folder: " & @ScriptDir & @CRLF & "ImageX will not function without these files!" & _
            @CRLF & @CRLF & "imagex.exe" & @CRLF & "wimfltr.dll" & @CRLF & "wimfltr.sys" & @CRLF & "wimgapi.dll")
EndIf

;
; Create the main GUI
;
GUICreate("GImageX - ImageX GUI Wrapper", 679, 380, -1, -1)
$hTab = GUICtrlCreateTab(10, 10, 660, 355)
$BaseX = 20
$BaseY = 35


; Drive Map Tab

$hTab_0 = GUICtrlCreateTabItem(" Drive Map ")

$CurX = $BaseX
$CurY = $BaseY

$CurY = $CurY + 10
GUICtrlCreateGroup("Drive Mapping", $CurX + 10, $CurY, 580, 135)
$CurY = $CurY + 18

GUICtrlCreateLabel("Letter", $CurX + 20, $CurY + 3)
$hMapLetter = GUICtrlCreateCombo("F:", $CurX + 85, $CurY, 100, 500, $CBS_DROPDOWNLIST)
GUICtrlSetData(-1, "G:|H:|I:|J:|K:|L:|M:|N:|O:|P:|Q:|R:|S:|T:|U:|V:|W:|X:|Y:|Z:")

$CurY = $CurY + 27
GUICtrlCreateLabel("UNC Path", $CurX + 20, $CurY + 3)
$hMapShareEdit = GUICtrlCreateInput("\\Server\Sharename", $CurX + 85, $CurY, 300)

$CurY = $CurY + 27
GUICtrlCreateLabel("Username", $CurX + 20, $CurY + 3)
$hMapUserEdit = GUICtrlCreateInput("Domain.com\%Username%", $CurX + 85, $CurY, 300)

$CurY = $CurY + 27
GUICtrlCreateLabel("Password", $CurX + 20, $CurY + 3)
$hMapPasswordEdit = GUICtrlCreateInput("Password", $CurX + 85, $CurY, 300, -1, $ES_PASSWORD)

$hMapButtonGo = GUICtrlCreateButton("&Map!", $BaseX + 500, $BaseY + 290, 100)

; Mount Tab
;
$hTab_2 = GUICtrlCreateTabItem("  Mount - Unmount  ")

$CurX = $BaseX
$CurY = $BaseY

; File Group
$CurY = $CurY + 10
GUICtrlCreateGroup("WIM Image", $CurX + 10, $CurY, 580, 205)
$CurY = $CurY + 18
GUICtrlCreateLabel("1. Mount image", $CurX + 20, $CurY + 3)
$hMountSourceEdit = GUICtrlCreateInput("MyWim.wim", $CurX + 100, $CurY, 300)
$hMountSourceBrowse = GUICtrlCreateButton("Browse", $CurX + 410, $CurY - 2)

$CurY = $CurY + 27
GUICtrlCreateLabel("Input Image Number", $CurX + 15, $CurY + 30, 70, 30)
$hMountName = GUICtrlCreateInput("1", $CurX + 85, $CurY + 30, 40, 20)
$hMountNameBrowse = GUICtrlCreateButton("2. Poll Image Number", $CurX + 15, $CurY + 1)
$treeviewm = GUICtrlCreateTreeView(150, 90, 450, 120, BitOR($TVS_HASBUTTONS, $TVS_HASLINES, $TVS_LINESATROOT, $TVS_DISABLEDRAGDROP, $TVS_SHOWSELALWAYS), $WS_EX_CLIENTEDGE)
$CurY = $CurY + 27
GUICtrlCreateLabel("Select folder", $CurX + 20, $CurY + 103)
$hMountDestEdit = GUICtrlCreateInput("C:", $CurX + 100, $CurY + 100, 300)
$hMountDestBrowse = GUICtrlCreateButton("Browse", $CurX + 410, $CurY + 98)

; Options Group
$CurY = $CurY + 40
GUICtrlCreateGroup("Options", $CurX + 10, $CurY + 100, 580, 50)
$CurY = $CurY + 18
$hRWCheck = GUICtrlCreateCheckbox("Read Write Access", $CurX + 20, $CurY + 100, 130, 15)
$hMountButtonGo = GUICtrlCreateButton("&Mount!", $BaseX + 390, $BaseY + 290, 100)
$hUnmountButtonGo = GUICtrlCreateButton("&Unmount!", $BaseX + 500, $BaseY + 290, 100)

; Capture Tab
;
$hTab_1 = GUICtrlCreateTabItem("  Capture  ")

$CurX = $BaseX
$CurY = $BaseY

; File Group
$CurY = $CurY + 10
GUICtrlCreateGroup("WIM Image", $CurX + 10, $CurY, 580, 155)
$CurY = $CurY + 18
GUICtrlCreateLabel("Source", $CurX + 20, $CurY + 3)
$hCaptureSourceEdit = GUICtrlCreateInput("", $CurX + 85, $CurY, 300)
$hCaptureSourceBrowse = GUICtrlCreateButton("Browse", $CurX + 395, $CurY - 2)

$CurY = $CurY + 27
GUICtrlCreateLabel("Destination", $CurX + 20, $CurY + 3)
$hCaptureDestEdit = GUICtrlCreateInput("MyWim.wim", $CurX + 85, $CurY, 300)
$hCaptureDestBrowse = GUICtrlCreateButton("Browse", $CurX + 395, $CurY - 2)

$CurY = $CurY + 27
GUICtrlCreateLabel("Compression", $CurX + 20, $CurY + 3)
$hCaptureCompression = GUICtrlCreateCombo("Maximum", $CurX + 85, $CurY, 100, 500, $CBS_DROPDOWNLIST)
GUICtrlSetData(-1, "Fast")

$CurY = $CurY + 27
GUICtrlCreateLabel("Name", $CurX + 20, $CurY + 3)
$hCaptureNameEdit = GUICtrlCreateInput("My Image Name", $CurX + 85, $CurY, 300)

$CurY = $CurY + 27
GUICtrlCreateLabel("Description", $CurX + 20, $CurY + 3)
$hCaptureDescEdit = GUICtrlCreateInput("My Image Description", $CurX + 85, $CurY, 300)

; Options Group
$CurY = $CurY + 40
GUICtrlCreateGroup("Options", $CurX + 10, $CurY, 580, 100)
$CurY = $CurY + 18

GUICtrlCreateLabel("/config", $CurX + 20, $CurY + 3)
$hCaptureConfigEdit = GUICtrlCreateInput("", $CurX + 85, $CurY, 300)
$hCaptureConfigBrowse = GUICtrlCreateButton("Browse", $CurX + 395, $CurY - 2)

$CurY = $CurY + 27
GUICtrlCreateLabel("Switches", $CurX + 20, $CurY + 3)
$hCaptureFlagsEdit = GUICtrlCreateInput("", $CurX + 85, $CurY, 300)

$CurY = $CurY + 27
$hCaptureBootCheck = GUICtrlCreateCheckbox("/boot (WinPE Images Only) ", $CurX + 20, $CurY)
$hCaptureCheckCheck = GUICtrlCreateCheckbox("/check", $CurX + 190, $CurY)
$hCaptureDiagCheck = GUICtrlCreateCheckbox("Display ImageX Console Window", $CurX + 260, $CurY)

$hCaptureButtonGo = GUICtrlCreateButton("&Capture!", $BaseX + 500, $BaseY + 290, 100)

; Append Tab
;
$hTab_1 = GUICtrlCreateTabItem("  Append  ")

$CurX = $BaseX
$CurY = $BaseY

; File Group
$CurY = $CurY + 10
GUICtrlCreateGroup("WIM Image", $CurX + 10, $CurY, 580, 155)
$CurY = $CurY + 18
GUICtrlCreateLabel("Destination Image", $CurX + 20, $CurY + 3)
$hAppendSourceEdit = GUICtrlCreateInput("MyWim.wim", $CurX + 140, $CurY, 300)
$hAppendSourceBrowse = GUICtrlCreateButton("Browse", $CurX + 450, $CurY - 2)

$CurY = $CurY + 27
GUICtrlCreateLabel("Select volume to image", $CurX + 20, $CurY + 3)
$hAppendDestEdit = GUICtrlCreateInput("my computer", $CurX + 140, $CurY, 300)
$hAppendDestBrowse = GUICtrlCreateButton("Browse", $CurX + 450, $CurY - 2)

$CurY = $CurY + 27
GUICtrlCreateLabel("Image name", $CurX + 20, $CurY + 3)
$hAppendNameEdit = GUICtrlCreateInput("My Vista Image", $CurX + 140, $CurY, 300)

$CurY = $CurY + 27
GUICtrlCreateLabel("Description", $CurX + 20, $CurY + 3)
$hAppendDescEdit = GUICtrlCreateInput("My Vista Image Description", $CurX + 140, $CurY, 300)

; Options Group
$CurY = $CurY + 65
GUICtrlCreateGroup("Options", $CurX + 10, $CurY, 580, 100)
$CurY = $CurY + 18

GUICtrlCreateLabel("/config", $CurX + 20, $CurY + 3)
$hAppendConfigEdit = GUICtrlCreateInput("", $CurX + 140, $CurY, 300)
$hAppendConfigBrowse = GUICtrlCreateButton("Browse", $CurX + 450, $CurY - 2)

$CurY = $CurY + 27
GUICtrlCreateLabel("/flags", $CurX + 20, $CurY + 3)
$hAppendFlagsEdit = GUICtrlCreateInput("", $CurX + 140, $CurY, 300)

$CurY = $CurY + 27
$hAppendBootCheck = GUICtrlCreateCheckbox("/boot (WinPE Images Only) ", $CurX + 20, $CurY)
$hAppendCheckCheck = GUICtrlCreateCheckbox("/check", $CurX + 190, $CurY)

$hAppendButtonGo = GUICtrlCreateButton("&Append!", $BaseX + 500, $BaseY + 290, 100)

; Apply Tab
;
$hTab_2 = GUICtrlCreateTabItem("  Apply  ")

$CurX = $BaseX
$CurY = $BaseY

; File Group
$CurY = $CurY + 10
GUICtrlCreateGroup("WIM Image", $CurX + 10, $CurY, 580, 205)
$CurY = $CurY + 18
GUICtrlCreateLabel("1. Source", $CurX + 20, $CurY + 3)
$hApplySourceEdit = GUICtrlCreateInput("MyWim.wim", $CurX + 85, $CurY, 300)
$hApplySourceBrowse = GUICtrlCreateButton("Browse", $CurX + 395, $CurY - 2)

$CurY = $CurY + 27
GUICtrlCreateLabel("Input Image Number", $CurX + 15, $CurY + 30, 70, 30)
$hApplyName = GUICtrlCreateInput("1", $CurX + 85, $CurY + 30, 40, 20)
$hApplyNameBrowse = GUICtrlCreateButton("2. Poll Image Number", $CurX + 15, $CurY + 1)
$treeview = GUICtrlCreateTreeView(150, 90, 450, 120, BitOR($TVS_HASBUTTONS, $TVS_HASLINES, $TVS_LINESATROOT, $TVS_DISABLEDRAGDROP, $TVS_SHOWSELALWAYS), $WS_EX_CLIENTEDGE)
$CurY = $CurY + 27
GUICtrlCreateLabel("Destination", $CurX + 20, $CurY + 103)
$hApplyDestEdit = GUICtrlCreateInput("", $CurX + 85, $CurY + 100, 300)
$hApplyDestBrowse = GUICtrlCreateButton("Browse", $CurX + 395, $CurY + 98)

; Options Group
$CurY = $CurY + 40
GUICtrlCreateGroup("Options", $CurX + 10, $CurY + 100, 580, 50)
$CurY = $CurY + 18
Dim $hReboot = GUICtrlCreateCheckbox("Automatically Reboot", $CurX + 20, $CurY + 105, 125, 15)
$hApplyVerifyCheck = GUICtrlCreateCheckbox("/verify", $CurX + 150, $CurY + 105, 50, 15)
$hApplyDiagCheck = GUICtrlCreateCheckbox("Display ImageX Console Window", $CurX + 210, $CurY + 105, 200, 15)

Dim $hDPart = GUICtrlCreateButton("Partition/Format", $BaseX + 390, $BaseY + 290, 100)
$hApplyButtonGo = GUICtrlCreateButton("&Apply!", $BaseX + 500, $BaseY + 290, 100)

; Export Tab
;
$hTab_1 = GUICtrlCreateTabItem("  Export  ")

$CurX = $BaseX
$CurY = $BaseY

; File Group
$CurY = $CurY + 10
GUICtrlCreateGroup("WIM Image", $CurX + 10, $CurY, 580, 155)
$CurY = $CurY + 18
GUICtrlCreateLabel("Source image", $CurX + 20, $CurY + 3)
$hExportSourceEdit = GUICtrlCreateInput("MyWim.wim", $CurX + 140, $CurY, 300)
$hExportSourceBrowse = GUICtrlCreateButton("Browse", $CurX + 450, $CurY - 2)

$CurY = $CurY + 27
GUICtrlCreateLabel("Source image number", $CurX + 20, $CurY + 3)
$hExportNumber = GUICtrlCreateInput("1", $CurX + 140, $CurY, 40, 20)

$CurY = $CurY + 27
GUICtrlCreateLabel("Exported image", $CurX + 20, $CurY + 3)
$hExportDestEdit = GUICtrlCreateInput("MyWim.wim", $CurX + 140, $CurY, 300)
$hExportDestBrowse = GUICtrlCreateButton("Browse", $CurX + 450, $CurY - 2)

$CurY = $CurY + 27
GUICtrlCreateLabel("Exported image name", $CurX + 20, $CurY + 3)
$hExportNameEdit = GUICtrlCreateInput("My Vista Image", $CurX + 140, $CurY, 300)

$CurY = $CurY + 27
GUICtrlCreateLabel("Compression", $CurX + 20, $CurY + 3)
$hExportCompression = GUICtrlCreateCombo("Maximum", $CurX + 85, $CurY, 100, 500, $CBS_DROPDOWNLIST)
GUICtrlSetData(-1, "Fast")

; Options Group
$CurY = $CurY + 40
GUICtrlCreateGroup("Options", $CurX + 10, $CurY, 580, 100)
$CurY = $CurY + 18

$CurY = $CurY + 27
GUICtrlCreateLabel("/flags", $CurX + 20, $CurY + 3)
$hExportFlagsEdit = GUICtrlCreateInput("", $CurX + 140, $CurY, 300)

$CurY = $CurY + 27
$hExportBootCheck = GUICtrlCreateCheckbox("/boot (WinPE Images Only) ", $CurX + 20, $CurY)
$hExportCheckCheck = GUICtrlCreateCheckbox("/check", $CurX + 190, $CurY)

$hExportButtonGo = GUICtrlCreateButton("&Export!", $BaseX + 500, $BaseY + 290, 100)

; Delete Tab
;
$hTab_2 = GUICtrlCreateTabItem("  Delete  ")

$CurX = $BaseX
$CurY = $BaseY

; File Group
$CurY = $CurY + 10
GUICtrlCreateGroup("WIM Image", $CurX + 10, $CurY, 580, 205)
$CurY = $CurY + 18
GUICtrlCreateLabel("1. Select image", $CurX + 20, $CurY + 3)
$hDeleteSourceEdit = GUICtrlCreateInput("MyWim.wim", $CurX + 100, $CurY, 300)
$hDeleteSourceBrowse = GUICtrlCreateButton("Browse", $CurX + 410, $CurY - 2)

$CurY = $CurY + 27
GUICtrlCreateLabel("Input Image Number", $CurX + 15, $CurY + 30, 70, 30)
$hDeleteName = GUICtrlCreateInput("1", $CurX + 85, $CurY + 30, 40, 20)
$hDeleteNameBrowse = GUICtrlCreateButton("2. Poll Image Number", $CurX + 15, $CurY + 1)
$treeviewd = GUICtrlCreateTreeView(150, 90, 450, 120, BitOR($TVS_HASBUTTONS, $TVS_HASLINES, $TVS_LINESATROOT, $TVS_DISABLEDRAGDROP, $TVS_SHOWSELALWAYS), $WS_EX_CLIENTEDGE)
$CurY = $CurY + 27

; Options Group
$CurY = $CurY + 40
GUICtrlCreateGroup("Options", $CurX + 10, $CurY + 100, 580, 50)
$CurY = $CurY + 18
$hDelCheck = GUICtrlCreateCheckbox("/Check", $CurX + 20, $CurY + 100, 130, 15)
$hDeleteButtonGo = GUICtrlCreateButton("&Delete!", $BaseX + 500, $BaseY + 290, 100)

; Split Tab
;
$hTab_1 = GUICtrlCreateTabItem("  Split  ")

$CurX = $BaseX
$CurY = $BaseY

; File Group
$CurY = $CurY + 10
GUICtrlCreateGroup("WIM Image", $CurX + 10, $CurY, 580, 155)
$CurY = $CurY + 18
GUICtrlCreateLabel("Source image", $CurX + 20, $CurY + 3)
$hSplitSourceEdit = GUICtrlCreateInput("MyWim.wim", $CurX + 140, $CurY, 300)
$hSplitSourceBrowse = GUICtrlCreateButton("Browse", $CurX + 450, $CurY - 2)

$CurY = $CurY + 27
GUICtrlCreateLabel("Exported image", $CurX + 20, $CurY + 3)
$hSplitDestEdit = GUICtrlCreateInput("MyWim.wim", $CurX + 140, $CurY, 300)
$hSplitDestBrowse = GUICtrlCreateButton("Browse", $CurX + 450, $CurY - 2)

$CurY = $CurY + 27
GUICtrlCreateLabel("Split image size in MB", $CurX + 20, $CurY + 3)
$hSplitNumber = GUICtrlCreateInput("650", $CurX + 140, $CurY, 40, 20)

; Options Group
$CurY = $CurY + 90
GUICtrlCreateGroup("Options", $CurX + 10, $CurY, 580, 100)
$CurY = $CurY + 18

$CurY = $CurY + 27
GUICtrlCreateLabel("/flags", $CurX + 20, $CurY + 3)
$hSplitFlagsEdit = GUICtrlCreateInput("", $CurX + 140, $CurY, 300)

$CurY = $CurY + 27
$hSplitCheckCheck = GUICtrlCreateCheckbox("/check", $CurX + 190, $CurY)

$hSplitButtonGo = GUICtrlCreateButton("&Split!", $BaseX + 500, $BaseY + 290, 100)

; Info Tab
;
$hTab_1 = GUICtrlCreateTabItem("  Info  ")

$CurX = $BaseX
$CurY = $BaseY

; File Group
$CurY = $CurY + 10
GUICtrlCreateGroup("WIM Image", $CurX + 10, $CurY, 580, 155)
$CurY = $CurY + 18
GUICtrlCreateLabel("Source image", $CurX + 20, $CurY + 3)
$hInfoSourceEdit = GUICtrlCreateInput("MyWim.wim", $CurX + 140, $CurY, 300)
$hInfoSourceBrowse = GUICtrlCreateButton("Browse", $CurX + 450, $CurY - 2)

$CurY = $CurY + 27
GUICtrlCreateLabel("Source image number", $CurX + 20, $CurY + 3)
$hInfoNumber = GUICtrlCreateInput("1", $CurX + 140, $CurY, 40, 20)

$CurY = $CurY + 27
GUICtrlCreateLabel("New image name", $CurX + 20, $CurY + 3)
$hInfoNewName = GUICtrlCreateInput("My Vista Image", $CurX + 140, $CurY, 300)

$CurY = $CurY + 27
GUICtrlCreateLabel("New image description", $CurX + 20, $CurY + 3)
$hInfoNewDesc = GUICtrlCreateInput("My Vista Image", $CurX + 140, $CurY, 300)

; Options Group
$CurY = $CurY + 65
GUICtrlCreateGroup("Options", $CurX + 10, $CurY, 580, 100)
$CurY = $CurY + 18

$CurY = $CurY + 27
GUICtrlCreateLabel("/flags", $CurX + 20, $CurY + 3)
$hInfoFlagsEdit = GUICtrlCreateInput("", $CurX + 140, $CurY, 300)

$CurY = $CurY + 27
$hInfoBootCheck = GUICtrlCreateCheckbox("/boot (WinPE Images Only) ", $CurX + 20, $CurY)
$hInfoCheckCheck = GUICtrlCreateCheckbox("/check", $CurX + 190, $CurY)

$hInfoButtonGo = GUICtrlCreateButton("&Info!", $BaseX + 500, $BaseY + 290, 100)

; Credits Tab
;
$hTab_1 = GUICtrlCreateTabItem("  Credits  ")

GUICtrlCreateLabel("Original Script by joshiieeii...", $CurX + 20, $CurY + 3)
$CurY = $CurY + 27
GUICtrlCreateLabel("DiskPartitoner and progress bar plus other functionalities by ImageXGUI...", $CurX + 20, $CurY + 3)
$CurY = $CurY + 27
GUICtrlCreateLabel("Mount/Unmount, Append, Export, Delete, Split, Info and automatically saving settings by Hosam M. Ahmed... ", $CurX + 20, $CurY + 3)

;
; Set Default Options
;
LoadSettings()
SettingsToGUI()
;
; The GUI message loop
;
GUISetState()
While 1
    $msg = GUIGetMsg()
    Select
    ; General Messages
        Case $msg = $GUI_EVENT_CLOSE
            ExitLoop

        ; Capture Messages
        Case $msg = $hCaptureButtonGo
            SaveSettings()
            DoCapture()
        Case $msg = $hCaptureSourceBrowse
            $sDir = BrowseForDirectory()
            If $sDir Then GUICtrlSetData($hCaptureSourceEdit, $sDir)
        Case $msg = $hCaptureDestBrowse
            $sFile = BrowseForWimToSave()
            If $sFile Then GUICtrlSetData($hCaptureDestEdit, $sFile)
        Case $msg = $hCaptureConfigBrowse
            $sFile = BrowseForConfig()
            If $sFile Then GUICtrlSetData($hCaptureConfigEdit, $sFile)

        ; Info Messages
        Case $msg = $hInfoButtonGo
            SaveSettings()
            DoInfo()
        Case $msg = $hInfoSourceBrowse
            $sDir = BrowseForWimToLoad()
            If $sDir Then GUICtrlSetData($hInfoSourceEdit, $sDir)

        ; Split Messages
        Case $msg = $hSplitButtonGo
            SaveSettings()
            DoSplit()
        Case $msg = $hSplitSourceBrowse
            $sDir = BrowseForWimToLoad()
            If $sDir Then GUICtrlSetData($hSplitSourceEdit, $sDir)
        Case $msg = $hSplitDestBrowse
            $sFile = BrowseForWimToSave()
            If $sFile Then GUICtrlSetData($hSplitDestEdit, $sFile)

        ; Export Messages
        Case $msg = $hExportButtonGo
            SaveSettings()
            DoExport()
        Case $msg = $hExportSourceBrowse
            $sDir = BrowseForWimToLoad()
            If $sDir Then GUICtrlSetData($hExportSourceEdit, $sDir)
        Case $msg = $hExportDestBrowse
            $sFile = BrowseForWimToSave()
            If $sFile Then GUICtrlSetData($hExportDestEdit, $sFile)

        ; Append Messages
        Case $msg = $hAppendButtonGo
            SaveSettings()
            DoAppend()
        Case $msg = $hAppendSourceBrowse
            $sDir = BrowseForWimToLoad()
            If $sDir Then GUICtrlSetData($hAppendSourceEdit, $sDir)
        Case $msg = $hAppendDestBrowse
            $sFile = BrowseForDirectory()
            If $sFile Then GUICtrlSetData($hAppendDestEdit, $sFile)
        Case $msg = $hAppendConfigBrowse
            $sFile = BrowseForConfig()
            If $sFile Then GUICtrlSetData($hAppendConfigEdit, $sFile)

        ; Delete Messages
        Case $msg = $hDeleteNameBrowse
            PollImageDelete()
        Case $msg = $hDeleteButtonGo
            SaveSettings()
            DoDelete()
        Case $msg = $hDeleteSourceBrowse
            $sDir = BrowseForWimToLoad()
            If $sDir Then GUICtrlSetData($hDeleteSourceEdit, $sDir)

        ; Mount Messages
        Case $msg = $hMountNameBrowse
            PollImageMount()
        Case $msg = $hMountButtonGo
            SaveSettings()
            DoMount()
        Case $msg = $hUnmountButtonGo
            DoUnmount()
        Case $msg = $hMountSourceBrowse
            $sDir = BrowseForWimToLoad()
            If $sDir Then GUICtrlSetData($hMountSourceEdit, $sDir)
        Case $msg = $hMountDestBrowse
            $sFile = BrowseForDirectory()
            If $sFile Then GUICtrlSetData($hMountDestEdit, $sFile)

        ; Apply Messages
        Case $msg = $hDPart
            MsgBox(4144, "DiskPart GUI", "*** USE AT YOUR OWN RISK *** | *** USE AT YOUR OWN RISK ***" & @CRLF & @CRLF & _
                    "      *You may need to reboot for the changes to take effect.*" & @CRLF & @CRLF & _
                    "     If you just format a partition you do not need to reboot.")
            FileInstall("DiskPartitioner.exe", @ScriptDir & "\DiskPartitioner.exe")
            RunWait(@ScriptDir & '\DiskPartitioner.exe')
            FileDelete(@ScriptDir & "\Diskpartitioner.exe")
        Case $msg = $hApplyNameBrowse
            PollImage()
        Case $msg = $hApplyButtonGo
            SaveSettings()
            DoApply()
        Case $msg = $hApplyDestBrowse
            $sDir = BrowseForDirectory()
            If $sDir Then GUICtrlSetData($hApplyDestEdit, $sDir)
        Case $msg = $hApplySourceBrowse
            $sFile = BrowseForWimToLoad()
            If $sFile Then GUICtrlSetData($hApplySourceEdit, $sFile)

        ; Drive Map Messages
        Case $msg = $hMapButtonGo
            SaveSettings()
            DoMapping()

        Case Else
        ;;;
    EndSelect
WEnd

Exit


;
; FUNCTIONS
;

Func BrowseForDirectory()
    $sDir = FileSelectFolder("Select source folder", "")
    If StringRight($sDir, 1) = "\" Then $sDir = StringTrimRight($sDir, 1)
    Return $sDir
EndFunc  ;==>BrowseForDirectory


Func BrowseForWimToSave()
    $sFile = FileSaveDialog("Select destination file", "", "WIM Files (*.wim)", 3)
    If @error Then Return ""

    If StringRight($sFile, 4) <> ".wIM" Then $sFile = $sFile & ".wim"

    Return $sFile
EndFunc  ;==>BrowseForWimToSave


Func BrowseForWimToLoad()
    $sFile = FileOpenDialog("Select source file", "", "WIM Files (*.wim)", 3)
    If @error Then Return ""

    Return $sFile
EndFunc  ;==>BrowseForWimToLoad


Func BrowseForConfig()
    $sFile = FileOpenDialog("Select config file", @ScriptDir, "INI files (*.ini)", 1)
    If @error Or StringRight($sFile, 4) <> ".ini" Then Return ""

    Return $sFile
EndFunc  ;==>BrowseForConfig


Func DoCapture()
    $gCaptureSource = GUICtrlRead($hCaptureSourceEdit)
    $gCaptureDestination = GUICtrlRead($hCaptureDestEdit)
    $gCaptureCompression = GUICtrlRead($hCaptureCompression)
    $gCaptureFlags = GUICtrlRead($hCaptureFlagsEdit)
    $gCaptureConfig = GUICtrlRead($hCaptureConfigEdit)
    $gCaptureBoot = GUICtrlRead($hCaptureBootCheck)
    $gCaptureCheck = GUICtrlRead($hCaptureCheckCheck)
    $gCaptureName = GUICtrlRead($hCaptureNameEdit)
    $gCaptureDescription = GUICtrlRead($hCaptureDescEdit)

    $sCmd = '"' & @ScriptDir & '\imagex.exe"'

    If $gCaptureConfig <> "" Then $sCmd = $sCmd & ' /config "' & $gCaptureConfig & '"'

    If $gCaptureCompression = "fast" Then
        $sCmd = $sCmd & " /compress fast"
    Else
        $sCmd = $sCmd & " /compress maximum"
    EndIf

    If $gCaptureCheck = 1 Then $sCmd = $sCmd & " /check"
    If $gCaptureBoot = 1 Then $sCmd = $sCmd & " /boot"
    If $gCaptureFlags <> "" Then $sCmd = $sCmd & ' ' & $gCaptureFlags

;   $sCmd = $sCmd & ' /capture /scroll "' & $sDir & '" "' & $sFile & '"'
    $sCmd = $sCmd & ' /capture /scroll "' & GUICtrlRead($hCaptureSourceEdit) & '" "' & GUICtrlRead($hCaptureDestEdit) & '"'
    $sCmd = $sCmd & ' "' & GUICtrlRead($hCaptureNameEdit) & '" "' & GUICtrlRead($hCaptureDescEdit) & '"'
    If GUICtrlRead($hCaptureDiagCheck) = '1' Then
        $ret = RunWait($sCmd, @WorkingDir, @SW_SHOW)
    Else
        $ret = ShowProgress($sCmd, 'Capturing...')
    EndIf
;$ret = RunWait($sCmd, @WorkingDir, @SW_SHOW)
    If $ret = '0' Then
        SplashTextOn('ImageX Status', 'Image Successfully Created!', 400, 50, -1, -1, 32, "Tahoma", 14, 500)
        Sleep(3000)
        SplashOff()
    Else
        SplashTextOn('ImageX Status', 'ImageX.exe ERROR : ' & $ret, 400, 50, -1, -1, 32, "Tahoma", 14, 500)
        Sleep(5000)
        SplashOff()
    EndIf

EndFunc  ;==>DoCapture

Func DoExport()
    $gExportSource = GUICtrlRead($hExportSourceEdit)
    $gExportDestination = GUICtrlRead($hExportDestEdit)
    $gExportCompression = GUICtrlRead($hExportCompression)
    $gExportFlags = GUICtrlRead($hExportFlagsEdit)
    $gExportBoot = GUICtrlRead($hExportBootCheck)
    $gExportCheck = GUICtrlRead($hExportCheckCheck)
    $gExportName = GUICtrlRead($hExportNameEdit)
    $gExportNumber = GUICtrlRead($hExportNumber)

    $sCmd = '"' & @ScriptDir & '\imagex.exe"'

    If $gExportCompression = "fast" Then
        $sCmd = $sCmd & " /compress fast"
    Else
        $sCmd = $sCmd & " /compress maximum"
    EndIf

    If $gExportCheck = 1 Then $sCmd = $sCmd & " /check"
    If $gExportBoot = 1 Then $sCmd = $sCmd & " /boot"
    If $gExportFlags <> "" Then $sCmd = $sCmd & ' /flags "' & $gExportFlags & '"'

    $sCmd = $sCmd & ' /Export "' & $gExportSource & '" "' & $gExportNumber & '" "' & $gExportDestination & '" "' & $gExportName & '"'

    $ret = RunWait($sCmd, @WorkingDir, @SW_SHOW)
    SplashTextOn("Return Code", "Imagex.exe returned with code = " & $ret, 400, 200, -1, -1, 32, "Tahoma", 16, 500)
    Sleep(3000)
    SplashOff()

EndFunc  ;==>DoExport

Func DoSplit()
    $gSplitSource = GUICtrlRead($hSplitSourceEdit)
    $gSplitDestination = GUICtrlRead($hSplitDestEdit)
    $gSplitFlags = GUICtrlRead($hSplitFlagsEdit)
    $gSplitCheck = GUICtrlRead($hSplitCheckCheck)
    $gSplitNumber = GUICtrlRead($hSplitNumber)

    $sCmd = '"' & @ScriptDir & '\imagex.exe"'

    If $gSplitCheck = 1 Then $sCmd = $sCmd & " /check"
    If $gSplitFlags <> "" Then $sCmd = $sCmd & ' /flags "' & $gSplitFlags & '"'

    $sCmd = $sCmd & ' /Split "' & $gSplitSource & '" "' & $gSplitDestination & '" "' & $gSplitNumber & '"'

    $ret = RunWait($sCmd, @WorkingDir, @SW_SHOW)
    SplashTextOn("Return Code", "Imagex.exe returned with code = " & $ret, 400, 200, -1, -1, 32, "Tahoma", 16, 500)
    Sleep(3000)
    SplashOff()

EndFunc  ;==>DoSplit

Func DoInfo()
    $gInfoSource = GUICtrlRead($hInfoSourceEdit)
    $gInfoDescription = GUICtrlRead($hInfoNewDesc)
    $gInfoFlags = GUICtrlRead($hInfoFlagsEdit)
    $gInfoBoot = GUICtrlRead($hInfoBootCheck)
    $gInfoCheck = GUICtrlRead($hInfoCheckCheck)
    $gInfoName = GUICtrlRead($hInfoNewName)
    $gInfoNumber = GUICtrlRead($hInfoNumber)

    $sCmd = '"' & @ScriptDir & '\imagex.exe"'

    If $gInfoCheck = 1 Then $sCmd = $sCmd & " /check"
    If $gInfoBoot = 1 Then $sCmd = $sCmd & " /boot"
    If $gInfoFlags <> "" Then $sCmd = $sCmd & ' /flags "' & $gInfoFlags & '"'

    $sCmd = $sCmd & ' /Info "' & $gInfoSource & '" "' & $gInfoNumber & '" "' & $gInfoName & '" "' & $gInfoDescription & '"'

    $ret = RunWait($sCmd, @WorkingDir, @SW_SHOW)
    SplashTextOn("Return Code", "Imagex.exe returned with code = " & $ret, 400, 200, -1, -1, 32, "Tahoma", 16, 500)
    Sleep(3000)
    SplashOff()

EndFunc  ;==>DoInfo

Func DoAppend()

    $gAppendSource = GUICtrlRead($hAppendSourceEdit)
    $gAppendDestination = GUICtrlRead($hAppendDestEdit)
    $gAppendFlags = GUICtrlRead($hAppendFlagsEdit)
    $gAppendConfig = GUICtrlRead($hAppendConfigEdit)
    $gAppendBoot = GUICtrlRead($hAppendBootCheck)
    $gAppendCheck = GUICtrlRead($hAppendCheckCheck)
    $gAppendName = GUICtrlRead($hAppendNameEdit)
    $gAppendDescription = GUICtrlRead($hAppendDescEdit)

    $sCmd = '"' & @ScriptDir & '\imagex.exe"'

    If $gAppendConfig <> "" Then $sCmd = $sCmd & ' /config "' & $gAppendConfig & '"'
    If $gAppendCheck = 1 Then $sCmd = $sCmd & " /check"
    If $gAppendBoot = 1 Then $sCmd = $sCmd & " /boot"
    If $gAppendFlags <> "" Then $sCmd = $sCmd & ' /flags "' & $gAppendFlags & '"'

    $sCmd = $sCmd & ' /Append "' & $gAppendDestination & '" "' & $gAppendSource & '"'
    $sCmd = $sCmd & ' "' & $gAppendName & '" "' & $gAppendDescription & '"'

    $ret = RunWait($sCmd, @WorkingDir, @SW_SHOW)
    SplashTextOn("Return Code", "Imagex.exe returned with code = " & $ret, 400, 200, -1, -1, 32, "Tahoma", 16, 500)
    Sleep(3000)
    SplashOff()

EndFunc  ;==>DoAppend

Func DoDelete()
    $gDeleteSource = GUICtrlRead($hDeleteSourceEdit)
    $gDeleteName = GUICtrlRead($hDeleteName)
    $gDelCheck = GUICtrlRead($hDelCheck)
    If StringInStr(GUICtrlRead(122, 1), 'Image: #') > 0 Then
        Dim $arINum = StringSplit(GUICtrlRead(122, 1), '#')
        GUICtrlSetData($hDeleteName, StringLeft($arINum[2], 1))
    Else
        MsgBox(4096, "Apply", "You must select the image to apply." & @CRLF & "Example: Image: #1")
        Return
    EndIf
    $sCmd = '"' & @ScriptDir & '\imagex.exe"'
    If $gDelCheck = 1 Then $sCmd = $sCmd & " /check"

    $sCmd = $sCmd & " /Delete"

    $sCmd = $sCmd & '" "' & $gDeleteSource & '" "' & $gDeleteName & '"'

    $ret = RunWait($sCmd, @WorkingDir, @SW_SHOW)
    SplashTextOn("Return Code", "Imagex.exe returned with code = " & $ret, 400, 200, -1, -1, 32, "Tahoma", 16, 500)
    Sleep(3000)
    SplashOff()

EndFunc  ;==>DoDelete

Func DoMount()
    $gMountSource = GUICtrlRead($hMountSourceEdit)
    $gMountName = GUICtrlRead($hMountName)
    $gMountDestination = GUICtrlRead($hMountDestEdit)
    $gRWCheck = GUICtrlRead($hRWCheck)
    If StringInStr(GUICtrlRead(23, 1), 'Image: #') > 0 Then
        Dim $arINum = StringSplit(GUICtrlRead(23, 1), '#')
        GUICtrlSetData($hMountName, StringLeft($arINum[2], 1))
    Else
        MsgBox(4096, "Apply", "You must select the image to apply." & @CRLF & "Example: Image: #1")
        Return
    EndIf
    $sCmd = '"' & @ScriptDir & '\imagex.exe"'
    If $gRWCheck = 1 Then
        $sCmd = $sCmd & " /mountrw"
    Else
        $sCmd = $sCmd & " /mount"
    EndIf

    $sCmd = $sCmd & '" "' & $gMountSource & '" "' & $gMountName & '" "' & $gMountDestination & '"'

    $ret = RunWait($sCmd, @WorkingDir, @SW_SHOW)
    SplashTextOn("Return Code", "Imagex.exe returned with code = " & $ret, 400, 200, -1, -1, 32, "Tahoma", 16, 500)
    Sleep(3000)
    SplashOff()

EndFunc  ;==>DoMount

Func DoUnmount()
    $gMountDestination = GUICtrlRead($hMountDestEdit)
    $gRWCheck = GUICtrlRead($hRWCheck)

    $sCmd = '"' & @ScriptDir & '\imagex.exe"'
    If $gRWCheck = 1 Then
        $sCmd = $sCmd & " /unmount /commit"
    Else
        $sCmd = $sCmd & " /unmount"
    EndIf

    $sCmd = $sCmd & '" "' & $gMountDestination & '"'

    $ret = RunWait($sCmd, @WorkingDir, @SW_SHOW)
    SplashTextOn("Return Code", "Imagex.exe returned with code = " & $ret, 400, 200, -1, -1, 32, "Tahoma", 16, 500)
    Sleep(3000)
    SplashOff()

EndFunc  ;==>DoUnmount

Func PollImage()
    Dim $nitem
    Dim $imageinfo = " "
    $read = GUICtrlRead($hApplySourceEdit)
    $sCmd = "imagex.exe"
    If $read = "" Then
        MsgBox(48, "Input required", "Please select the source")
    Else
        $sCmd = $sCmd & ' /info "' & $read & '"'
    EndIf
;MsgBox(0, "scmd", $sCmd)
    Dim $ret = Run(@ComSpec & " /c " & $sCmd & '"', @ScriptDir, @SW_HIDE, $STDERR_CHILD + $STDOUT_CHILD)
    While 1
        $line = StdoutRead($ret)
        If $line = "" Then ExitLoop
        $imageinfo = $imageinfo & $line
    ;   MsgBox(0, "RunDOS", $line)
        If @error Then ExitLoop
    WEnd
    _GUICtrlTreeViewDeleteAllItems($treeview)
    $aImageInfo = _StringBetween($imageinfo, "<NAME>", "</NAME>")
    If @error Then $aImageInfo = _ArrayCreate("<Empty>")
    $aImageDesc = _StringBetween($imageinfo, "<Description>", "</Description>")
    If @error Then $aImageDesc = _ArrayCreate("<Empty>")
    $aImageFileCount = _StringBetween($imageinfo, "<Filecount>", "</Filecount>")
    If @error Then $aImageFileCount = _ArrayCreate("<Empty>")
;$aImageBuild = _StringBetween ( $imageinfo, "<Build>", "</Build>" )
;   If @error Then $aImageBuild = _ArrayCreate("<Empty>")
    $imagenumber = UBound($aImageInfo, 1)
    If @error Then $imagenumber = _ArrayCreate("<Empty>")
    $x = 0
    Dim $nitem[$imagenumber]
    Do
        $nitem[$x] = GUICtrlCreateTreeViewItem("Image: #" & $x + 1 & ": " & $aImageInfo[$x], $treeview)
        GUICtrlCreateTreeViewItem("Description: " & $aImageDesc [$x], $nitem[$x])
        GUICtrlCreateTreeViewItem("File Count: " & $aImageFileCount [$x], $nitem[$x])
    ;GUICtrlCreateTreeViewItem ( "Build Version: " & $aImageBuild [$x], $nitem[$x] )
        GUICtrlSetState($nitem[$x], $GUI_DEFBUTTON)
        $x = $x + 1
    Until $x = $imagenumber
EndFunc  ;==>PollImage

Func PollImageMount()
    Dim $nitem
    Dim $imageinfo = " "
    $read = GUICtrlRead($hMountSourceEdit)
    $sCmd = "imagex.exe"
    If $read = "" Then
        MsgBox(48, "Input required", "Please select the source")
    Else
        $sCmd = $sCmd & ' /info "' & $read & '"'
    EndIf
;MsgBox(0, "scmd", $sCmd)
    Dim $ret = Run(@ComSpec & " /c " & $sCmd & '"', @ScriptDir, @SW_HIDE, $STDERR_CHILD + $STDOUT_CHILD)
    While 1
        $line = StdoutRead($ret)
        If $line = "" Then ExitLoop
        $imageinfo = $imageinfo & $line
    ;   MsgBox(0, "RunDOS", $line)
        If @error Then ExitLoop
    WEnd
    _GUICtrlTreeViewDeleteAllItems($treeviewm)
    $aImageInfo = _StringBetween($imageinfo, "<NAME>", "</NAME>")
    If @error Then $aImageInfo = _ArrayCreate("<Empty>")
    $aImageDesc = _StringBetween($imageinfo, "<Description>", "</Description>")
    If @error Then $aImageDesc = _ArrayCreate("<Empty>")
    $aImageFileCount = _StringBetween($imageinfo, "<Filecount>", "</Filecount>")
    If @error Then $aImageFileCount = _ArrayCreate("<Empty>")
;$aImageBuild = _StringBetween ( $imageinfo, "<Build>", "</Build>" )
;   If @error Then $aImageBuild = _ArrayCreate("<Empty>")
    $imagenumber = UBound($aImageInfo, 1)
    If @error Then $imagenumber = _ArrayCreate("<Empty>")
    $x = 0
    Dim $nitem[$imagenumber]
    Do
        $nitem[$x] = GUICtrlCreateTreeViewItem("Image: #" & $x + 1 & ": " & $aImageInfo[$x], $treeviewm)
        GUICtrlCreateTreeViewItem("Description: " & $aImageDesc [$x], $nitem[$x])
        GUICtrlCreateTreeViewItem("File Count: " & $aImageFileCount [$x], $nitem[$x])
    ;GUICtrlCreateTreeViewItem ( "Build Version: " & $aImageBuild [$x], $nitem[$x] )
        GUICtrlSetState($nitem[$x], $GUI_DEFBUTTON)
        $x = $x + 1
    Until $x = $imagenumber
EndFunc  ;==>PollImageMount

Func PollImageDelete()
    Dim $nitem
    Dim $imageinfo = " "
    $read = GUICtrlRead($hDeleteSourceEdit)
    $sCmd = "imagex.exe"
    If $read = "" Then
        MsgBox(48, "Input required", "Please select the source")
    Else
        $sCmd = $sCmd & ' /info "' & $read & '"'
    EndIf
;MsgBox(0, "scmd", $sCmd)
    Dim $ret = Run(@ComSpec & " /c " & $sCmd & '"', @ScriptDir, @SW_HIDE, $STDERR_CHILD + $STDOUT_CHILD)
    While 1
        $line = StdoutRead($ret)
        If $line = "" Then ExitLoop
        $imageinfo = $imageinfo & $line
    ;   MsgBox(0, "RunDOS", $line)
        If @error Then ExitLoop
    WEnd
    _GUICtrlTreeViewDeleteAllItems($treeviewd)
    $aImageInfo = _StringBetween($imageinfo, "<NAME>", "</NAME>")
    If @error Then $aImageInfo = _ArrayCreate("<Empty>")
    $aImageDesc = _StringBetween($imageinfo, "<Description>", "</Description>")
    If @error Then $aImageDesc = _ArrayCreate("<Empty>")
    $aImageFileCount = _StringBetween($imageinfo, "<Filecount>", "</Filecount>")
    If @error Then $aImageFileCount = _ArrayCreate("<Empty>")
;$aImageBuild = _StringBetween ( $imageinfo, "<Build>", "</Build>" )
;   If @error Then $aImageBuild = _ArrayCreate("<Empty>")
    $imagenumber = UBound($aImageInfo, 1)
    If @error Then $imagenumber = _ArrayCreate("<Empty>")
    $x = 0
    Dim $nitem[$imagenumber]
    Do
        $nitem[$x] = GUICtrlCreateTreeViewItem("Image: #" & $x + 1 & ": " & $aImageInfo[$x], $treeviewd)
        GUICtrlCreateTreeViewItem("Description: " & $aImageDesc [$x], $nitem[$x])
        GUICtrlCreateTreeViewItem("File Count: " & $aImageFileCount [$x], $nitem[$x])
    ;GUICtrlCreateTreeViewItem ( "Build Version: " & $aImageBuild [$x], $nitem[$x] )
        GUICtrlSetState($nitem[$x], $GUI_DEFBUTTON)
        $x = $x + 1
    Until $x = $imagenumber
EndFunc  ;==>PollImageDelete

Func DoApply()
    $gApplySource = GUICtrlRead($hApplySourceEdit)
    $gApplyDestination = GUICtrlRead($hApplyDestEdit)
    $gApplyVerify = GUICtrlRead($hApplyVerifyCheck)
    $gApplyName = GUICtrlRead($hApplyName)
    If StringInStr(GUICtrlRead(84, 1), 'Image: #') > 0 Then
        Dim $arINum = StringSplit(GUICtrlRead(84, 1), '#')
        GUICtrlSetData($hApplyName, StringLeft($arINum[2], 1))
    Else
        MsgBox(4096, "Apply", "You must select the image to apply." & @CRLF & "Example: Image: #1")
        Return
    EndIf
    $sCmd = '"' & @ScriptDir & '\imagex.exe"'

    If $gApplyVerify = 1 Then $sCmd = $sCmd & " /verify"
    $sCmd = $sCmd & ' /apply /scroll "' & GUICtrlRead($hApplySourceEdit) & '" "' & GUICtrlRead($hApplyName) & '" "' & GUICtrlRead($hApplyDestEdit) & '"'

    If GUICtrlRead($hApplyDiagCheck) = '1' Then
        $ret = RunWait($sCmd, @WorkingDir, @SW_SHOW)
    Else
        $ret = ShowProgress($sCmd, 'Applying...')
    EndIf
    If $ret = '0' Then
        SplashTextOn('ImageX Status', 'Image Successfully Applied!', 400, 50, -1, -1, 32, "Tahoma", 14, 500)
        Sleep(3000)
        SplashOff()
    Else
        SplashTextOn('ImageX Status', 'ImageX.exe ERROR : ' & $ret, 400, 50, -1, -1, 32, "Tahoma", 14, 500)
        Sleep(5000)
        SplashOff()
    EndIf
    $Rebootstate = GUICtrlRead($hReboot)
    If $Rebootstate = 1 Then
        _RunDOS("Start wpeutil reboot")
    EndIf
EndFunc  ;==>DoApply


Func DoMapping()
;$gMapLetter = GUICtrlRead($hMapLetter
;$gMapUser = GUICtrlRead($hMapUserEdit
;$gMapPassword = GUICtrlRead($hMapPasswordEdit
;$gMapShare = GUICtrlRead($hMapShareEdit
    $gMapLetter = IniRead($sIni, "MAP", "Letter", "V:")
    DriveMapDel($gMapLetter)
    $gMapShare = IniRead($sIni, "Map", "Share", "")
    $VistaAccount = GUICtrlRead($hMapUserEdit)
    $VistaPwd = GUICtrlRead($hMapPasswordEdit)
    $res = DriveMapAdd($gMapLetter, $gMapShare, 0, $VistaAccount, $VistaPwd)

    If $res Then
        ControlSetText("Mapping Drive", "", "Static1", "Drive successfully mapped!")
        Sleep(2000)
    ;MsgBox(64, "Drive Mapping", "Drive successfully mapped!")
    Else
        SplashOff()
        MsgBox(16, "Drive Mapping", "Error mapping drive! Code: " & $avDriveMapAdd[@error])

    EndIf
EndFunc  ;==>DoMapping

Func LoadSettings()
    $sIni = @ScriptDir & "\gimagex.ini"

;Capture
    $gCaptureSource = IniRead($sIni, "CAPTURE", "Source", "")
    $gCaptureDestination = IniRead($sIni, "CAPTURE", "Destination", "MyWim.wim")
    $gCaptureCompression = IniRead($sIni, "CAPTURE", "Compression", "Maximum")
    $gCaptureFlags = IniRead($sIni, "CAPTURE", "Flags", "")
    $gCaptureConfig = IniRead($sIni, "CAPTURE", "Config", "")
    $gCaptureBoot = IniRead($sIni, "CAPTURE", "Boot", "0")
    $gCaptureCheck = IniRead($sIni, "CAPTURE", "Check", "1")
    $gCaptureName = IniRead($sIni, "CAPTURE", "Name", "My Build Name")
    $gCaptureDescription = IniRead($sIni, "CAPTURE", "Description", "My Vista Build Description")
    $gCaptureDiag = IniRead($sIni, "CAPTURE", "Diag", "0")

;Append
    $gAppendSource = IniRead($sIni, "Append", "Source", "")
    $gAppendDestination = IniRead($sIni, "Append", "Destination", "MyWim.wim")
    $gAppendFlags = IniRead($sIni, "Append", "Flags", "")
    $gAppendConfig = IniRead($sIni, "Append", "Config", "")
    $gAppendBoot = IniRead($sIni, "Append", "Boot", "0")
    $gAppendCheck = IniRead($sIni, "Append", "Check", "1")
    $gAppendName = IniRead($sIni, "Append", "Name", "My Build Name")
    $gAppendDescription = IniRead($sIni, "Append", "Description", "My Vista Build Description")

;Export
    $gExportSource = IniRead($sIni, "Export", "Source", "")
    $gExportDestination = IniRead($sIni, "Export", "Destination", "MyWim.wim")
    $gExportCompression = IniRead($sIni, "Export", "Compression", "Maximum")
    $gExportFlags = IniRead($sIni, "Export", "Flags", "")
    $gExportBoot = IniRead($sIni, "Export", "Boot", "0")
    $gExportCheck = IniRead($sIni, "Export", "Check", "1")
    $gExportName = IniRead($sIni, "Export", "Name", "My Build Name")
    $gExportNumber = IniRead($sIni, "Export", "Number", "1")

;Info
    $gInfoSource = IniRead($sIni, "Info", "Source", "")
    $gInfoFlags = IniRead($sIni, "Info", "Flags", "")
    $gInfoBoot = IniRead($sIni, "Info", "Boot", "0")
    $gInfoCheck = IniRead($sIni, "Info", "Check", "1")
    $gInfoNumber = IniRead($sIni, "Info", "Number", "1")

;Delete
    $gDeleteSource = IniRead($sIni, "Delete", "Source", "d:\install.wim")
    $gDeleteName = IniRead($sIni, "Delete", "Name", "1")
    $gDeleteCheck = IniRead($sIni, "Delete", "Check", "1")

;Split
    $gSplitSource = IniRead($sIni, "Split", "Source", "d:\install.wim")
    $gSplitFlags = IniRead($sIni, "Split", "Flags", "")
    $gSplitCheck = IniRead($sIni, "Split", "Check", "1")
    $gSplitDestination = IniRead($sIni, "Split", "Destination", "d:\Split")
    $gSplitNumber = IniRead($sIni, "Split", "Number", "1")

;Apply
    $gApplySource = IniRead($sIni, "APPLY", "Source", "")
    $gApplyDestination = IniRead($sIni, "APPLY", "Destination", "MyWim.wim")
    $gApplyVerify = IniRead($sIni, "APPLY", "Verify", "0")
    $gApplyName = IniRead($sIni, "APPLY", "Name", "")
    $gApplyDiag = IniRead($sIni, "APPLY", "Diag", "0")

;Mount
    $gMountSource = IniRead($sIni, "MOUNT", "Source", "d:\install.wim")
    $gMountDestination = IniRead($sIni, "MOUNT", "Destination", "d:\mount")
    $gMountName = IniRead($sIni, "MOUNT", "Name", "1")
    $gRWCheck = IniRead($sIni, "MOUNT", "RWCheck", "1")

;Map
    $gMapLetter = IniRead($sIni, "MAP", "Letter", "M:")
    $gMapShare = IniRead($sIni, "MAP", "Share", "\\Server\Share")
    $gMapUser = IniRead($sIni, "MAP", "User", "User")

EndFunc  ;==>LoadSettings

Func SaveSettings()
    $sIni = @ScriptDir & "\gimagex.ini"
;Capture
    IniWrite($sIni, "CAPTURE", "Source", GUICtrlRead($hCaptureSourceEdit))
    IniWrite($sIni, "CAPTURE", "Destination", GUICtrlRead($hCaptureDestEdit))
    IniWrite($sIni, "CAPTURE", "Compression", GUICtrlRead($hCaptureCompression))
    IniWrite($sIni, "CAPTURE", "Flags", GUICtrlRead($hCaptureFlagsEdit))
    IniWrite($sIni, "CAPTURE", "Config", GUICtrlRead($hCaptureConfigEdit))
    IniWrite($sIni, "CAPTURE", "Name", GUICtrlRead($hCaptureNameEdit))
    IniWrite($sIni, "CAPTURE", "Description", GUICtrlRead($hCaptureDescEdit))
    IniWrite($sIni, "CAPTURE", "Boot", GUICtrlRead($hCaptureBootCheck))
    IniWrite($sIni, "CAPTURE", "Check", GUICtrlRead($hCaptureCheckCheck))
    IniWrite($sIni, "CAPTURE", "Diag", GUICtrlRead($hCaptureDiagCheck))

;Append
    IniWrite($sIni, "Append", "Source", GUICtrlRead($hAppendSourceEdit))
    IniWrite($sIni, "Append", "Destination", GUICtrlRead($hAppendDestEdit))
    IniWrite($sIni, "Append", "Flags", GUICtrlRead($hAppendFlagsEdit))
    IniWrite($sIni, "Append", "Config", GUICtrlRead($hAppendConfigEdit))
    IniWrite($sIni, "Append", "Name", GUICtrlRead($hAppendNameEdit))
    IniWrite($sIni, "Append", "Description", GUICtrlRead($hAppendDescEdit))
    IniWrite($sIni, "Append", "Boot", GUICtrlRead($hAppendBootCheck))
    IniWrite($sIni, "Append", "Check", GUICtrlRead($hAppendCheckCheck))

;Export
    IniWrite($sIni, "Export", "Source", GUICtrlRead($hExportSourceEdit))
    IniWrite($sIni, "Export", "Destination", GUICtrlRead($hExportDestEdit))
    IniWrite($sIni, "Export", "Compression", GUICtrlRead($hExportCompression))
    IniWrite($sIni, "Export", "Flags", GUICtrlRead($hExportFlagsEdit))
    IniWrite($sIni, "Export", "Name", GUICtrlRead($hExportNameEdit))
    IniWrite($sIni, "Export", "Boot", GUICtrlRead($hExportBootCheck))
    IniWrite($sIni, "Export", "Check", GUICtrlRead($hExportCheckCheck))
    IniWrite($sIni, "Export", "Number", GUICtrlRead($hExportNumber))

;Info
    IniWrite($sIni, "Info", "Source", GUICtrlRead($hInfoSourceEdit))
    IniWrite($sIni, "Info", "Flags", GUICtrlRead($hInfoFlagsEdit))
    IniWrite($sIni, "Info", "Boot", GUICtrlRead($hInfoBootCheck))
    IniWrite($sIni, "Info", "Check", GUICtrlRead($hInfoCheckCheck))
    IniWrite($sIni, "Info", "Number", GUICtrlRead($hInfoNumber))

;Delete
    IniWrite($sIni, "Delete", "Source", GUICtrlRead($hDeleteSourceEdit))
    IniWrite($sIni, "Delete", "Name", GUICtrlRead($hDeleteName))
    IniWrite($sIni, "Delete", "Check", GUICtrlRead($hDelCheck))


;Split
    IniWrite($sIni, "Split", "Source", GUICtrlRead($hSplitSourceEdit))
    IniWrite($sIni, "Split", "Destination", GUICtrlRead($hSplitDestEdit))
    IniWrite($sIni, "Split", "Flags", GUICtrlRead($hSplitFlagsEdit))
    IniWrite($sIni, "Split", "Check", GUICtrlRead($hSplitCheckCheck))
    IniWrite($sIni, "Split", "Number", GUICtrlRead($hSplitNumber))

;Apply
    IniWrite($sIni, "APPLY", "Source", GUICtrlRead($hApplySourceEdit))
    IniWrite($sIni, "APPLY", "Destination", GUICtrlRead($hApplyDestEdit))
    IniWrite($sIni, "APPLY", "Name", GUICtrlRead($hApplyName))
    IniWrite($sIni, "Apply", "Diag", GUICtrlRead($hApplyDiagCheck))
    IniWrite($sIni, "Apply", "Verify", GUICtrlRead($hApplyVerifyCheck))

;Mount
    IniWrite($sIni, "MOUNT", "Source", GUICtrlRead($hMountSourceEdit))
    IniWrite($sIni, "MOUNT", "Destination", GUICtrlRead($hMountDestEdit))
    IniWrite($sIni, "MOUNT", "Name", GUICtrlRead($hMountName))
    IniWrite($sIni, "MOUNT", "RWCheck", GUICtrlRead($hRWCheck))
;Map
    IniWrite($sIni, "MAP", "Letter", GUICtrlRead($hMapLetter))
    IniWrite($sIni, "MAP", "Share", GUICtrlRead($hMapShareEdit))
    IniWrite($sIni, "MAP", "User", GUICtrlRead($hMapUserEdit))

EndFunc  ;==>SaveSettings


Func SettingsToGUI()

; MOUNT
    GUICtrlSetData($hMountSourceEdit, $gMountSource)
    GUICtrlSetData($hMountDestEdit, $gMountDestination)
    GUICtrlSetData($hMountName, $gMountName)
; CAPTURE
    GUICtrlSetData($hCaptureSourceEdit, $gCaptureSource)
    GUICtrlSetData($hCaptureDestEdit, $gCaptureDestination)
    GUICtrlSetData($hCaptureCompression, $gCaptureCompression)
    GUICtrlSetData($hCaptureFlagsEdit, $gCaptureFlags)
    GUICtrlSetData($hCaptureConfigEdit, $gCaptureConfig)
    If $gCaptureBoot = 1 Then
        GUICtrlSetState($hCaptureBootCheck, $GUI_CHECKED)
    Else
        GUICtrlSetState($hCaptureBootCheck, $GUI_UNCHECKED)
    EndIf
    If $gCaptureCheck = 1 Then
        GUICtrlSetState($hCaptureCheckCheck, $GUI_CHECKED)
    Else
        GUICtrlSetState($hCaptureCheckCheck, $GUI_UNCHECKED)
    EndIf
    If $gCaptureDiag = 1 Then
        GUICtrlSetState($hCaptureDiagCheck, $GUI_CHECKED)
    Else
        GUICtrlSetState($hCaptureDiagCheck, $GUI_UNCHECKED)
    EndIf
    GUICtrlSetData($hCaptureNameEdit, $gCaptureName)
    GUICtrlSetData($hCaptureDescEdit, $gCaptureDescription)

; APPLY
    GUICtrlSetData($hApplySourceEdit, $gApplySource)
    GUICtrlSetData($hApplyDestEdit, $gApplyDestination)
    If $gApplyVerify = 1 Then
        GUICtrlSetState($hApplyVerifyCheck, $GUI_CHECKED)
    Else
        GUICtrlSetState($hApplyVerifyCheck, $GUI_UNCHECKED)
    EndIf
    If $gApplyDiag = 1 Then
        GUICtrlSetState($hApplyDiagCheck, $GUI_CHECKED)
    Else
        GUICtrlSetState($hApplyDiagCheck, $GUI_UNCHECKED)
    EndIf
    GUICtrlSetData($hApplyName, $gApplyName)

; MAP
    GUICtrlSetData($hMapLetter, $gMapLetter)
    GUICtrlSetData($hMapShareEdit, $gMapShare)
    GUICtrlSetData($hMapUserEdit, $gMapUser)
    GUICtrlSetData($hMapPasswordEdit, $gMapPassword)

EndFunc  ;==>SettingsToGUI

Func ShowProgress($sCmd, $ImageType)
;Include rtconsole.exe for progress bar.
;
    FileInstall("rtconsole.exe", @ScriptDir & "\rtconsole.exe")

;Msgbox(0,"RUN",'"' & @ScriptDir & '\rtconsole.exe" ' & $sCmd)
    $foo = Run('"' & @ScriptDir & '\rtconsole.exe" ' & $sCmd, '', '', 2 + 4)
    $line1 = '0'
    ProgressOn('Imagex', 'ImageX', $line1)

    While 1
        $line = StdoutRead($foo)
        If StringInStr($line, 'ImageX Tool for Windows') <> 0 Then $line = 0
        If StringInStr($line, 'Progress: 100%') <> 0 Then ExitLoop
        If StringInStr($line, 'Error') <> 0 Then ExitLoop
        $line = StringStripWS($line, 7)
        If StringInStr($line, ',') <> 0 Then
        ;   $line2 = StringSplit($line, ',')
        ;   $line3 = StringRight($line2[2], StringLen($line2[2])-1)
        EndIf
        $line3 = StringSplit($line, @CRLF)
        $line1 = StringSplit($line, '%')
        $line = StringRight($line1[1], 2)
        If @error Then ExitLoop
        If $line <> "" Then
            ProgressSet($line, $line3[1], $ImageType)
        EndIf
    WEnd

    ProgressOff()
    FileDelete(@ScriptDir & "\rtconsole.exe")
EndFunc  ;==>ShowProgress

and here is all the bundle to try with imagex, rtlconsol, DiskPartioner and the wrapper ...

http://rapidshare.com/files/39398886/_Imagex_GUI.rar.html

i will be waiting for your replies ....

Share this post


Link to post
Share on other sites

Have tried to run it on WinPE 2.0 ? I'm writing small script for automatic deployment of machines (ie check for machine type and modify sysprep/drivers/post install scripts etc.) and I have encountered problem with FileSelectFolder function. Under WinPE 2.0 if root folder/drive is not specified FileSelectFolder I just get empty dialog.

FileSelectFolder("Choose your destiny","X:\") ---> works
FileSelectFolder("Choose your destiny","") -----> empty dialog

See attached picture for outcome of FileSelectFolder - post-24780-1183887355_thumb.png

I don't have Windows Vista but I assume that under Vista it works OK right ? Maybe there is only some dll or app missing in WinPE2 :whistle:

Share this post


Link to post
Share on other sites

#12 ·  Posted (edited)

Moin, moin... :)

ImageX is a really good tool, which I use daily at my work. I already had the same suggestion, too, but I

never had time for realise it. Now I found your posted script and I tried to use it. But I've got any

problems. Even it doesn't work in WinPE enironment.

So I started to modify the script and added some functions, too, to get a satisfying result.

Also I created a DiskPart-GUI because DiskPartitioner in no case was finding a hard disk. I know, that

there are already other GUIs like that exist, but I had the ambition to realise it successful with

AutoIt :).

Thank you guys, for the fantastic preparatory work. I think it would be to much, to post the whole script

once more again, therefor I post the needed files here as a ZIP-file (GImageX-Code.zip) to download.

Greets Rudika

GImageX_Code.zip

Edited by rudika

[font="Comic Sans Ms"][center]Powered by AutoIt3http://www.wik-eric.de/zips/Synchro2.2.2-4free.zip[/center][/font]

Share this post


Link to post
Share on other sites

Create an account or sign in to comment

You need to be a member in order to leave a comment

Create an account

Sign up for a new account in our community. It's easy!


Register a new account

Sign in

Already have an account? Sign in here.


Sign In Now
Sign in to follow this
Followers 0
