jerwin

Loading Progress

11 posts in this topic

can anyone can give me Loading Progress script for GUI that when i click start it the progress will load up to 100% then the script for start will execute...

thanx in advance...


[font="Arial Black"]Looking for a partner in making Perfect Bot for DEKARONPm me if you wanna join.....[/font]

Share this post


Link to post
Share on other sites



Well depends on what your script is doing in the background. If you want to make just a loading bar, then really, I see no point in it, and really 30seconds in the helpfile for ProgressOn is all you need. :P

Also, you signature is way too long. Makes me have to scroll more than i want too :P Please shorten it.

Share this post


Link to post
Share on other sites

Well depends on what your script is doing in the background. If you want to make just a loading bar, then really, I see no point in it, and really 30seconds in the helpfile for ProgressOn is all you need. :P

Also, you signature is way too long. Makes me have to scroll more than i want too :P Please shorten it.

sorry about my signature....

heres my progress bar....

ProgressOn("Progress Meter", "Increments every second", "0 percent")
For $i = 10 to 100 step 10
    sleep(1000)
    ProgressSet( $i, $i & " percent")
Next
ProgressSet(100 , "Done", "Complete")
sleep(500)
ProgressOff()

but i want it to be like this.........

Posted Image

after loading the real gui will show have an idea how to do it???


[font="Arial Black"]Looking for a partner in making Perfect Bot for DEKARONPm me if you wanna join.....[/font]

Share this post


Link to post
Share on other sites

#include <GUIConstantsEx.au3>
#include <StaticConstants.au3>
#include <WindowsConstants.au3>
$pic = @ScriptDir & "\Screenie.jpg"
$i = 1
$timestamp = TimerInit()
#Region ### START Koda GUI section ### Form=
$Form1 = GUICreate("AForm1", 460, 326, 193, 115)
$Pic1 = GUICtrlCreatePic($pic, 0, 0, 460, 300, BitOR($SS_NOTIFY, $WS_GROUP))
$Progress1 = GUICtrlCreateProgress(2, 304, 456, 17)
GUICtrlSetData(-1, $i)
GUISetState(@SW_SHOW)
#EndRegion ### END Koda GUI section ###

While 1
    $nMsg = GUIGetMsg()
    Switch $nMsg
        Case $GUI_EVENT_CLOSE
            Exit
        Case TimerDiff($timestamp) < 20
            $timestamp = TimerInit()
            $i += 1
            If $i > 100 Then $i = 0
            GUICtrlSetData($Progress1, $i)
    EndSwitch
WEnd

You will need the picture:


Share this post


Link to post
Share on other sites

Sorry For Triple Post-

ahmm sir.. the loading dont have end... :P

i wait for 5 mins but still the gui is loading...


[font="Arial Black"]Looking for a partner in making Perfect Bot for DEKARONPm me if you wanna join.....[/font]

Share this post


Link to post
Share on other sites

Course it doesn't end.... I did that on purpose. You need to study the code, work out how it works (It's a just a Basic GUI...)

Depending on what you are loading, you can set the progress... GUICtrlSetData ($Progress1, ammount...)

I must add, I will not give it to you on a silver platter. I was hoping you would take the time to work out what I did, but obviously I was wrong....

Share this post


Link to post
Share on other sites

oh sure thanx :P

ur nise teacher......

thanx for the info i apreaciate it so much.... :P


[font="Arial Black"]Looking for a partner in making Perfect Bot for DEKARONPm me if you wanna join.....[/font]

Share this post


Link to post
Share on other sites

This is what I've been looking for but I still don't know enough about it to use it in a program. I don't know where to put my variables to make the progress change or how to use it in my programs.


The SuperFlyChetGuy

Share this post


Link to post
Share on other sites

Allright, I'll comment the script, and tell you exactly what we're doing... :P

#include <GUIConstantsEx.au3>
#include <StaticConstants.au3>
#include <WindowsConstants.au3>

$pic = @ScriptDir & "\Screenie.jpg"; This is the path to the image.
$i = 1; initial value for the progress
$timestamp = TimerInit(); start the timer- ONLY NEEDED FOR THIS EXAMPLE
#Region ### START Koda GUI section ### Form=
$Form1 = GUICreate("AForm1", 460, 326, 193, 115); Create The GUI
$Pic1 = GUICtrlCreatePic($pic, 0, 0, 460, 300, BitOR($SS_NOTIFY, $WS_GROUP)); Create the picture control, and set the pic to what we told it to have earlier.
$Progress1 = GUICtrlCreateProgress(2, 304, 456, 17); Create the progress control
GUICtrlSetData(-1, $i);Set the progress to the inital value we set earlier
GUISetState(@SW_SHOW);Show the GUI
#EndRegion ### END Koda GUI section ###

While 1;Start loop
    $nMsg = GUIGetMsg();Get the messages from the gui (Events- like button clicks etc.)
    Switch $nMsg;Switch $nMsg.  A switch conditionally runs statements.
        Case $GUI_EVENT_CLOSE; If the Big Red X is pressed....
            Exit            ; ... Then Exit
        Case TimerDiff($timestamp) < 20; If the timer is more than 20ms, change the progress.  This is only for out example
            $timestamp = TimerInit(); Reset the timer
            $i += 1; Increase the value of what we're setting the progress to
            If $i > 100 Then $i = 0; If it is more than 100, then set it to be 0 again.
            GUICtrlSetData($Progress1, $i); Set the progress
    EndSwitch
WEnd

And here is a different example of setting the progress bar.

#include <GUIConstantsEx.au3>
#include <StaticConstants.au3>
#include <WindowsConstants.au3>
#Include <Misc.au3>
$i = 1; Set the initial value of the progress

$Form1 = GUICreate("AForm1", 460, 326, 193, 115); Create The GUI
$Progress1 = GUICtrlCreateProgress(2, 304, 456, 17); Create the progress control
GUICtrlSetData(-1, $i);Set the progress to the inital value we set earlier
GUISetState(@SW_SHOW);Show the GUI
#EndRegion ### END Koda GUI section ###

While 1;Start loop
    $nMsg = GUIGetMsg();Get the messages from the gui (Events- like button clicks etc.)
    Select
        Case $nMsg = $GUI_EVENT_CLOSE; If the Big Red X is pressed....
            Exit ; ... Then Exit
        Case _IsPressed("26") = 1; If Up Arrow is pressed
            Do; Do The following until we release the key
                Sleep(50); Sleep so we don't increment the slider too fast
                $i += 1; Increase the value by 1
                If $i > 100 Then $i = 100; If it = 100 then keep it at 100
                GUICtrlSetData($Progress1, $i);Set the progress
            Until _IsPressed("26") = 0; Testing if the key is released
        Case _IsPressed("28") = 1; If Down Arrow is pressed
            Do; Do The following until we release the key
                Sleep(50); Sleep so we don't increment the slider too fast
                $i -= 1; Decrease the value by 1
                If $i < 0 Then $i = 0; If it is less than 0, then keep it at 0
                GUICtrlSetData($Progress1, $i); Set the Progress
            Until _IsPressed("28") = 0; Testing if the key is released
    EndSelect
WEnd

Cheers,

Brett
