AD - Active Directory UDF

   (2 reviews)

1 Screenshot

About This File

Extensive library to control and manipulate Microsoft Active Directory.

Threads: Development - General Help & Support - Example Scripts - Wiki

Previous downloads: 30467


Known Bugs: (last changed: 2018-06-01)

  • None


Things to come: (last changed: 2018-06-01)

  • None

BTW: If you like this UDF please click the "I like this" button. This tells me where to next put my development effort :)

What's New in Version



  • UDF WinAPIConv.au3 is now included. Is needed for AutoIt >= as some WinAPI functions have moved to this UDF


  • _AD_GetObjectProperties: Correctly calculates property MSDS-UserPasswordExpiryTimeComputed


  • _AD_GetObjectProperties: Now handles up to 10000 properties. 1000 wasn't enough ;)
  • _AD_GetPasswordInfo: Returns the calculated password expiration date/time. Identical with element 9 of this array.
    Returns a value even when fine grained password policy is in use; which means that most of the other elements of this array are blank or 0.


  • _AD_DeleteSubTree: Deletes the specified object including all child objects of this object.
    Be careful when using this function - use in test environment to verify it works as expected!!


  • Fixed some documentation bugs
  • Enhanced documentation
  • Like 40

User Feedback

You may only provide a review once you have downloaded the file.


   2 of 2 members found this review helpful 2 / 2 members

Extremely useful for Sys admins or even just an engineer to manipulate AD data or Data Collections.

Tests are simple and code is simple to read and modify. If you work with anyone who doesn't know much about AD building a GUI with this UDF is very helpful.

Great Job @water

  • Like 2

Share this review

Link to review

   1 of 1 member found this review helpful 1 / 1 member

This is one of my three top used UDFs at the office, and has GREATLY simplified data gathering for some very complex reports, as well as automating several tasks.  I have even been able to free up one admin completely from our annual security audit process (for which he is also very grateful) thanks to the use of your UDF!

  • Like 1

Share this review

Link to review
