Shouldn't it be '..."MYDomain\' & $sADGroupName & '"...'

Hi There,
I'm currently rebinding some of my keys (multimedia ones) and I have two keys that handle the Zoom (+ & -)
 (just after the calc key)

I looked everywhere (in the help file and on Google) but I was not able to find the matching code.
Do some of you could have a little idea on how to get their "name" so I'll be able to remap them?
Thanks

I've never used that method, I've always used something like:
Func _Uninstall() Local $sUninstallString = _GUICtrlListView_GetItemText($idListView, _GUICtrlListView_GetSelectionMark($idListView), 4) If StringStripWS($sUninstallString, 8) = "" Then Return -1 Return $sUninstallString EndFunc

change your function that reads the reg. pass it the key once for 32 bit, once for 64 in main loop
Func _ComputerGetSoftware(ByRef $aSoftwareInfo, $UnInstKey)
then don;t do this, remark that out.
Local Const $UnInstKey = "HKEY_LOCAL_MACHINE\SOFTWARE\Microsoft\Windows\CurrentVersion\Uninstall" pass that key to your function 2 times, 32 and 64 values and add them to the one array.

look at subz example

"HKEY_LOCAL_MACHINE64\SOFTWARE\Microsoft\Windows\CurrentVersion\Uninstall"

AutoItScript List installed programs and system information:
#include <GuiListView.au3> Opt("TrayAutoPause", 0) Opt('GUIOnEventMode', 1) Opt('GUICloseOnEsc', 1) ;Opt("MustDeclareVars", 1) ; Global $SoftwList = 'ALL', $iAskSoftName = 0, $sSft[1][0] Global $sGui = GUICreate('Currently Installed Software', 810, 650, -1, -1) Global $sLvw = GUICtrlCreateListView('#|Installed Software|Display Version|Publisher|Uninstall String', 5, 5, 800, 600) _ComputerGetSoftware($sSft) For $i = 1 To UBound($sSft) - 1 GUICtrlCreateListViewItem($i & '|' & $sSft[$i][0] & '|' & $sSft[$i][1] & '|' & $sSft[$i][2] & '|' & $sSft[$i][3], $sLvw) Next GUICtrlSendMsg($sLvw, 0x101E, 1, 175) GUICtrlSendMsg($sLvw, 0x101E, 2, 65) GUICtrlSendMsg($sLvw, 0x101E, 3, 150) GUICtrlSendMsg($sLvw, 0x101E, 4, 350) Global $mMen = GUICtrlCreateContextMenu($sLvw) Global $CopI = GUICtrlCreateMenuItem('Uninstall Current Selection', $mMen) GUICtrlSetOnEvent($CopI, '_Uninstall') Global $exp = GUICtrlCreateButton(' Expand ', 720, 615) GUICtrlSetOnEvent($exp, '_Expand') GUISetOnEvent(-3, '_AllExit') GUISetState(@SW_SHOW, $sGui) ; While 1 Sleep(10) WEnd ; Func _AllExit() GUIDelete($sGui) Exit EndFunc ;==>_AllExit ; Func _Uninstall() Local $proc = StringSplit(GUICtrlRead(GUICtrlRead($sLvw)), '|', 1) If $proc[1] == 0 Then Return -1 If $proc[5] Then RunWait($proc[5]) Exit EndFunc ;==>_Uninstall ; Func _Copy2Clip() Local $proc = StringSplit(GUICtrlRead(GUICtrlRead($sLvw)), '|', 1) If $proc[1] == 0 Then Return -1 If $proc[5] Then ClipPut($proc[5]) EndFunc ;==>_Copy2Clip ; ; Author JSThePatriot - Modified June 20, 2010 by ripdad - Modified 2018/29/05 by Dao Van Trong - Trong.LIVE Func _ComputerGetSoftware(ByRef $aSoftwareInfo) Local Const $UnInstKey = "HKEY_LOCAL_MACHINE64\SOFTWARE\Microsoft\Windows\CurrentVersion\Uninstall" Local $i = 1, $Reg, $string, $AppKey ReDim $aSoftwareInfo[1][4] If ($iAskSoftName) Then $SoftwList = InputBox("Which Software", "You are running " & @OSVersion & " " & @OSArch & @CRLF & @CRLF & "Which Software would you like to view?", 'ALL') If @error = 1 Then Exit If $SoftwList = 'ALL' Then For $j = 1 To 500 $AppKey = RegEnumKey($UnInstKey, $j) If @error <> 0 Then ExitLoop If RegRead($UnInstKey & "\" & $AppKey, "DisplayName") = '' Then ContinueLoop ReDim $aSoftwareInfo[UBound($aSoftwareInfo) + 1][4] $aSoftwareInfo[$i][0] = StringStripWS(StringReplace(RegRead($UnInstKey & "\" & $AppKey, "DisplayName"), " (remove only)", ""), 3) $aSoftwareInfo[$i][1] = StringStripWS(RegRead($UnInstKey & "\" & $AppKey, "DisplayVersion"), 3) $aSoftwareInfo[$i][2] = StringStripWS(RegRead($UnInstKey & "\" & $AppKey, "Publisher"), 3) $aSoftwareInfo[$i][3] = StringStripWS(RegRead($UnInstKey & "\" & $AppKey, "UninstallString"), 3) $i = $i + 1 Next $aSoftwareInfo[0][0] = UBound($aSoftwareInfo, 1) - 1 If $aSoftwareInfo[0][0] < 1 Then SetError(1, 1, 0) Return _ArraySort($aSoftwareInfo, 0, 1) Else For $j = 1 To 500 $AppKey = RegEnumKey($UnInstKey, $j) If @error <> 0 Then ExitLoop Local $Reg = RegRead($UnInstKey & "\" & $AppKey, "DisplayName") $string = StringInStr($Reg, $SoftwList) If $string = 0 Then ContinueLoop ReDim $aSoftwareInfo[UBound($aSoftwareInfo) + 1][4] $aSoftwareInfo[$i][0] = StringStripWS(StringReplace(RegRead($UnInstKey & "\" & $AppKey, "DisplayName"), " (remove only)", ""), 3) $aSoftwareInfo[$i][1] = StringStripWS(RegRead($UnInstKey & "\" & $AppKey, "DisplayVersion"), 3) $aSoftwareInfo[$i][2] = StringStripWS(RegRead($UnInstKey & "\" & $AppKey, "Publisher"), 3) $aSoftwareInfo[$i][3] = StringStripWS(RegRead($UnInstKey & "\" & $AppKey, "UninstallString"), 3) $i = $i + 1 Next $aSoftwareInfo[0][0] = UBound($aSoftwareInfo, 1) - 1 If $aSoftwareInfo[0][0] < 1 Then SetError(1, 1, 0) Return _ArraySort($aSoftwareInfo, 0, 1) EndIf EndFunc ;==>_ComputerGetSoftware ; Func _Expand() _GUICtrlListView_SetColumnWidth($sLvw, 1, $LVSCW_AUTOSIZE) _GUICtrlListView_SetColumnWidth($sLvw, 2, $LVSCW_AUTOSIZE) _GUICtrlListView_SetColumnWidth($sLvw, 3, $LVSCW_AUTOSIZE) _GUICtrlListView_SetColumnWidth($sLvw, 4, $LVSCW_AUTOSIZE) EndFunc ;==>_Expand

Maybe something like:
#include <GuiListView.au3> Opt("TrayAutoPause", 0) Opt('GUIOnEventMode', 1) Opt('GUICloseOnEsc' , 1) Global $aSoftwareInfo[0][5] _SoftwareInfo("HKLM\SOFTWARE\Microsoft\Windows\CurrentVersion\Uninstall") _SoftwareInfo("HKLM64\SOFTWARE\Microsoft\Windows\CurrentVersion\Uninstall") Global $hGui = GUICreate('Currently Installed Software', 810, 650, -1, -1) Global $idListView = GUICtrlCreateListView('#|Installed Software|Display Version|Publisher|Uninstall String', 5, 5, 800, 600) _GUICtrlListView_AddArray($idListView, $aSoftwareInfo) GUICtrlSendMsg($idListView, 0x101E, 1, 175) GUICtrlSendMsg($idListView, 0x101E, 2, 65) GUICtrlSendMsg($idListView, 0x101E, 3, 150) GUICtrlSendMsg($idListView, 0x101E, 4, 350) Local $mMen = GUICtrlCreateContextMenu($idListView) Local $Uninstall = GUICtrlCreateMenuItem('Proceed to Software uninstallation', $mMen) GUICtrlSetOnEvent($Uninstall, '_Uninstall') Local $exp = GUICtrlCreateButton(' Expand ', 720, 615) GUICtrlSetOnEvent($exp, '_Expand') GUISetOnEvent(-3, '_AllExit') GUISetState(@SW_SHOW, $hGui) While 1 Sleep(10) WEnd ; Func _AllExit() GUIDelete($hGui) Exit EndFunc Func _Uninstall() Local $proc = StringSplit(GUICtrlRead(GUICtrlRead($idListView)), '|', 1) If $proc[1] == 0 Then Return -1 ShellExecuteWait ($proc[5]) EndFunc Func _SoftwareInfo($_sHKLMUninstall) Local $i = 1 While 1 $sRegKey = RegEnumKey($_sHKLMUninstall, $i) If @error Then Exitloop If RegRead($_sHKLMUninstall & "\" & $sRegKey, "DisplayName") = '' Then $i += 1 ContinueLoop EndIf $sDisplayName = StringStripWS(StringReplace(RegRead($_sHKLMUninstall & "\" & $sRegKey, "DisplayName"), " (remove only)", ""), 3) $sDisplayVersion = StringStripWS(RegRead($_sHKLMUninstall & "\" & $sRegKey, "DisplayVersion"), 3) $sPublisher = StringStripWS(RegRead($_sHKLMUninstall & "\" & $sRegKey, "Publisher"), 3) $sUninstallString = StringStripWS(RegRead($_sHKLMUninstall & "\" & $sRegKey, "UninstallString"), 3) _ArrayAdd($aSoftwareInfo, "|" & $sDisplayName & "|" & $sDisplayVersion & "|" & $sPublisher & "|" & $sUninstallString) $i += 1 WEnd _ArraySort($aSoftwareInfo,0,1) For $i = 0 To UBound($aSoftwareInfo) - 1 $aSoftwareInfo[$i][0] = $i Next EndFunc ; Func _Expand() _GUICtrlListView_SetColumnWidth($idListView, 1, $LVSCW_AUTOSIZE) _GUICtrlListView_SetColumnWidth($idListView, 2, $LVSCW_AUTOSIZE) _GUICtrlListView_SetColumnWidth($idListView, 3, $LVSCW_AUTOSIZE) _GUICtrlListView_SetColumnWidth($idListView, 4, $LVSCW_AUTOSIZE) EndFunc

Just test if the link ends with .exe or .txt

You should be able to do this with the standard IE UDF commands. Here's an example --
#include <ie.au3> Example() Func Example() Local $oIE = _IECreate("http://downloads.dell.com/published/pages/latitude-12-5280-laptop.html", 1) Local $oDiv = _IEGetObjById($oIE, "Drivers-Category.BI") Local $oTable = _IETagNameGetCollection($oDiv, "Table", 0) Local $oRow = _IETagNameGetCollection($oTable, "TR", 1) Local $oCell = _IETagNameGetCollection($oRow, "TD", 5) Local $oLinks = _IETagNameGetCollection($oCell, "A") ConsoleWrite("Found " & $oLinks.length & " links!" & @CRLF) For $oLink In $oLinks ConsoleWrite($oLink.href & @CRLF) Next EndFunc ;==>Example

@31290 Remove the quotes around '$oLink.href' and your InetGet should work.

#include <File.au3> #include <Array.au3> Global $csv_file = @DesktopDir & "\Book1.csv" Global $aRecords If Not _FileReadToArray($csv_file,$aRecords) Then ; MsgBox(4096,"Error", " Error reading log to Array error:" & @error) Exit EndIf For $x = 1 to UBound($aRecords) -1 ConsoleWrite("ROW "&$x &" "&$aRecords[$x]&@CRLF) ; Shows the line that was read from file $csv_line_values = StringSplit($aRecords[$x], ",",1) ; Splits the line into 2 or more variables and puts them in an array For $z = 1 to UBound($csv_line_values) -1 If $z = 1 Then ConsoleWrite(" A " &$csv_line_values[$z]&@CRLF) ElseIf $z = 2 Then ConsoleWrite(" B " &$csv_line_values[$z]&@CRLF) ElseIf $z = 3 Then ConsoleWrite(" C " &$csv_line_values[$z]&@CRLF) EndIf Next ; _ArrayDisplay($csv_line_values) ; Shows what's in the array you just created. ; $csv_line_values[0] holds the number of elements in array ; $csv_line_values[1] holds the value ; $csv_line_values[2] holds the value ; etc ; Msgbox(0, 0, $csv_line_values[1]) Next

Use StringInStr to get the position of the first "A" and then use this as starting position for your calculation.

Make it this way: SEE_Delete_Temp_Functions.au3 This isn't tested (i don't want to clean my caches yet).

And here my extended Example: ArrayOfCheckBoxesOE.au3 (only simulating)

GUICtrlSetPos
Also, it's bad practice to create global variables inside a function. Declare them outside f_MainGui and initialize them in your function.
#include <ButtonConstants.au3> #Include <Constants.au3> #include <Date.au3> #include <File.au3> #Include <FontConstants.au3> #include <GUIConstantsEx.au3> #include <GuiEdit.au3> #include <Misc.au3> #include <WindowsConstants.au3> #include <StringConstants.au3> Global $hGui Global $btnExample Global $chkExample Opt("GUIOnEventMode", 1) Example() While 1 Sleep (100) Wend Func Example() $hGUI = GUIcreate("Example", 120, 80) $btnExample = GUICtrlCreateButton("Hidden Button", 400, 0, 100, 30) $chkExample = GUICtrlCreateCheckbox("Click me!", 10, 10, 100, 30) GUICtrlSetOnEvent($btnExample, "ButtonExample") GUICtrlSetOnEvent($chkExample, "SetButton") GUISetOnEvent($GUI_EVENT_CLOSE, "Close") GUISetState(@SW_SHOW, $hGUI) EndFunc Func SetButton() If (GUICtrlRead($chkExample) = $GUI_CHECKED) Then GUICtrlSetPos($btnExample, 10, 40, 100, 30) Else GUICtrlSetPos($btnExample, 400, 0, 100, 30) EndIf EndFunc Func ButtonExample() MsgBox("", "", "Hidden button has been clicked!") EndFunc Func Close() GUIDelete($hGUI) Exit 0 EndFunc

and which of the checkBoxes is the one which should toggle buttonstate? And where are the func's for the events?
Here's a small script: ArrayOfCheckBoxesOE.au3, which shows the logic you need if any checkbox should enable Button.

Hmm this looks like a great confusion between declaring an array, walking through an array [$i] and selecting the first element of an array [0]
Please try this one and guess what
Edit
BTW be careful with the syntax, $a... is for arrays, $s... for strings, and $b... for booleans
#include <String.au3> f_e5440Drivers() Func f_e5440Drivers() Local $sRead = InetRead('http://downloads.dell.com/published/pages/latitude-e5450-laptop.html', 1) Local $aDataBIOS = _StringBetween(BinaryToString($sRead), 'Type: BIOS', 'Category: Communications') Local $aDataGraphics = _StringBetween(BinaryToString($sRead), 'Category: Video', 'Type: Firmware') Local $aDataNetwork = _StringBetween(BinaryToString($sRead), 'Category: Network', 'Type: Utility') TrayTip("", "Downloading latest drivers, please wait...", 10, 3) Local $aLinksBIOS = _StringBetween($aDataBIOS[0], '<TR><TD>', '</TD></TR>') Local $aLinksGraphics = _StringBetween($aDataGraphics[0], '<TR><TD>', '</TD></TR>') Local $aLinksNetwork = _StringBetween($aDataNetwork[0], '<TR><TD>', '</TD></TR>') Local $slinksBIOS = "" Local $sLinksGraphics = "" Local $sLinksNetwork = "" For $i = 0 To UBound($aLinksBIOS) - 1 ;~ $aLinksBIOS[$i] = 'http://downloads.dell.com/' & $aLinksBIOS[$i] If StringInStr($aLinksBIOS[$i], "E5450") Then Local $a2LinksBIOS = _StringBetween($aLinksBIOS[$i], '<A HREF="/', '"><IMG') $sLinksBIOS = 'http://downloads.dell.com/' & $a2LinksBIOS[0] ConsoleWrite($sLinksBIOS & @LF) ExitLoop EndIf Next For $i = 0 To UBound($aLinksGraphics) - 1 ;~ $aLinksGraphics[$i] = 'http://downloads.dell.com/' & $aLinksGraphics[$i] If (StringInStr($aLinksGraphics[$i], "Intel HD, HD 4000/4200/4400/4600/5000/5100/5200/5300/5500 Graphics Driver") AND StringInStr($aLinksGraphics[$i], "Windows 7, 8 and 8.1 32-bit OS")) Then Local $a2LinksGraphics = _StringBetween($aLinksGraphics[$i], '<A HREF="/', '"><IMG') $sLinksGraphics = 'http://downloads.dell.com/' & $a2LinksGraphics[0] ConsoleWrite($sLinksGraphics & @LF) ;~ $slink = $aLinks[$i] ExitLoop EndIf Next For $i = 0 To UBound($aLinksNetwork) - 1 ;~ $aLinksNetwork[$i] = 'http://downloads.dell.com/' & $aLinksNetwork[$i] If (StringInStr($aLinksNetwork[$i], "Intel 7265/3165/7260/3160 WiFi Driver") AND StringInStr($aLinksNetwork[$i], "Windows 7 32-bit")) Then Local $a2LinksNetwork = _StringBetween($aLinksNetwork[$i], '<A HREF="/', '"><IMG') $sLinksNetwork = 'http://downloads.dell.com/' & $a2LinksNetwork[0] ConsoleWrite($sLinksNetwork & @LF) ExitLoop EndIf Next EndFunc

#include <String.au3> #include <MsgBoxConstants.au3> #include <WinAPIFiles.au3> Local $sRead = InetRead('http://downloads.dell.com/published/pages/latitude-e5450-laptop.html', 1) ;(BinaryToString($sRead) & @CRLF) Local $aData = _StringBetween(BinaryToString($sRead), 'Type: BIOS', 'Category:') TrayTip("", "Downloading latest BIOS Version, please wait...", 10, 3) Local $aLinks = _StringBetween($aData[0], '<A HREF="/', '"><IMG') Local $slink = "" For $i = 0 To UBound($aLinks) - 1 $aLinks[$i] = 'http://downloads.dell.com/' & $aLinks[$i] If StringInStr($aLinks[$i], "E5450") Then $slink = $aLinks[$i] ExitLoop EndIf Next Exit Local $hDownload = InetGet($slink, @DesktopDir & "\BIOSE5450.exe", 1, 1) Do Sleep(250) Until InetGetInfo($hDownload, 2) Local $iBytesSize = InetGetInfo($hDownload, 0) Local $iFileSize = Round(FileGetSize(@DesktopDir & "\BIOSE5450.exe") / 1048576) InetClose($hDownload) MsgBox(0, "", "The latest E5450 BIOS (" & $iFileSize & " MB) have been downloaded")

You're Wellcome.

Saludos

Hi. You can do this.

#include <String.au3> #include <Array.au3> Local $sRead = InetRead('http://downloads.dell.com/published/pages/optiplex-7010.html', 1) ConsoleWrite(BinaryToString($sRead) & @CRLF) Local $aData = _StringBetween(BinaryToString($sRead), 'Type: BIOS', 'Category:') Local $aLinks = _StringBetween($aData[0], '<A HREF="/', '"><IMG') For $i = 0 To UBound($aLinks) - 1 $aLinks[$i] = 'http://downloads.dell.com' & $aLinks[$i] Next ;~ _ArrayDisplay($aLinks) MsgBox(0, "Lastest Version BIOS", $aLinks[0]) Saludos

31290,
Not very difficult - look for the <<<<<<<<<<<< lines:
#include <GUIConstantsEx.au3> #include <WindowsConstants.au3> #include <StringConstants.au3> #include <Array.au3> #include <GuiListView.au3> ; Read file into array $aLines = FileReadToArray("EPES18.txt") ; Deal with title line $aLines[0] = StringRegExpReplace($aLines[0], "(\x20+)", "|") ; Now the other lines For $i = 1 To UBound($aLines) - 1 ; Extract line $sLine = $aLines[$i] ; Replace tabs with spaces $sLine = StringReplace($sLine, @TAB, " ") ; Extract possible name field $sName = StringRegExpReplace($sLine, "(?U)^.*(\x20.*\x20)(connected|notconnect|err-disabled).*$", "$1") ; Convert multiple spaces to singles $sStrippedName = StringRegExpReplace($sName, "\x20+", " ") ; Set placeholder if no name field If $sStrippedName = " " Then $sStrippedName = " ~ " ; Replace original name string in line with stripped version - add spaces to ensure multiple spaces before and after $sLine = StringReplace($sLine, $sName, " " & $sStrippedName & " ") ; Set delimiters by replacing multiple spaces $sLine = StringRegExpReplace($sLine, "(\x20{2,19})", "|") ; Remove placeholders $sLine = StringReplace($sLine, "~", "") ; Replace existing line with delimited line $aLines[$i] = $sLine Next ; Read IP Phone ID file $sID = Fileread("id.txt") $hGUI = GUICreate("Test", 500, 500) ; Create ListView with first 4 headers plus "IP Phone" $cLV = GUICtrlCreateListView(StringRegExpReplace($aLines[0], "(?U)^(.*\|.*\|.*\|.*)\|.*$", "$1") & "|IP Phone", 10, 10, 480, 380) ; Set column widths For $i = 0 To 4 _GUICtrlListView_SetColumnWidth($cLV, $i, 90) Next ; Add content of first 4 fields in each line plus the IP Phone result For $i = 1 To UBound($aLines) - 1 ; Assume not IP Phone $sIPPhone = "|Not set" ; Look for the port ID in the file - it will be preceded by a space and followed by either a comma or an EOL If StringRegExp($sID, " " & StringRegExpReplace($aLines[$i], "(?U)^(.*)\|.*$", "$1") & "[,\x0D]") Then ; If found change the set value $sIPPhone = "|Set" EndIf ; Add fields and IP Phone to the ListView $cLVItem = GUICtrlCreateListViewItem(StringRegExpReplace($aLines[$i], "(?U)^(.*\|.*\|.*\|.*)\|.*$", "$1") & $sIPPhone, $cLV) Next $cDummyCheckRow = GUICtrlCreateDummy() ; Create dummy control <<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<< GUIRegisterMsg($WM_NOTIFY, "_WM_NOTIFY") GUISetState() ; Set sort state Local $aSortSense[_GUICtrlListView_GetColumnCount($cLV)] While 1 Switch GUIGetMsg() Case $GUI_EVENT_CLOSE Exit Case $cDummyCheckRow ; Fired by the handler, but only once the handler has exited <<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<< $iRow = GUICtrlRead($cDummyCheckRow) ; Read the row value <<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<< MsgBox($MB_SYSTEMMODAL, $iRow, StringReplace(_GUICtrlListView_GetItemTextString($cLV, $iRow), "|", @CRLF)) ; Display the row data <<<<<<<<<<<<<<<<< EndSwitch WEnd Func _WM_NOTIFY($hWnd, $imsg, $wParam, $lParam) ; Struct = $tagNMHDR and "int Item;int SubItem" from $tagNMLISTVIEW Local $tStruct = DllStructCreate("hwnd;uint_ptr;int_ptr;int;int", $lParam) If @error Then Return Local $iCode = BitAND(DllStructGetData($tStruct, 3), 0xFFFFFFFF) Switch $iCode Case $LVN_COLUMNCLICK ; Get column index Local $iCol = DllStructGetData($tStruct, 5) If $iCol <> 0 Then ; Sort column _GUICtrlListView_SimpleSort($cLV, $aSortSense, $iCol) EndIf Case $NM_DBLCLK $iRow = DllStructGetData($tStruct, 4) GUICtrlSendToDummy($cDummyCheckRow, $iRow) ; Send the row value to the dummy control and fire it once returned <<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<< Case $NM_CUSTOMDRAW Local $tNMLVCUSTOMDRAW = DllStructCreate($tagNMLVCUSTOMDRAW, $lParam) Local $dwDrawStage = DllStructGetData($tNMLVCUSTOMDRAW, "dwDrawStage") Switch $dwDrawStage ; Holds a value that specifies the drawing stage Case $CDDS_PREPAINT ; Before the paint cycle begins Return $CDRF_NOTIFYITEMDRAW ; Notify the parent window of any item-related drawing operations Case $CDDS_ITEMPREPAINT ; Before painting an item Return $CDRF_NOTIFYSUBITEMDRAW ; Notify the parent window of any subitem-related drawing operations Case BitOR($CDDS_ITEMPREPAINT, $CDDS_SUBITEM) ; Before painting a subitem Local $iItem = DllStructGetData($tNMLVCUSTOMDRAW, "dwItemSpec") ; Item index Local $iSubItem = DllStructGetData($tNMLVCUSTOMDRAW, "iSubItem") ; Subitem index ; Gte text of item $sText = _GUICtrlListView_GetItemText($cLV, $iItem, $iSubItem) ; Set default back colour $iBkColour = 0xC4C4C4 ; Now check for our spoecific items Switch $iSubItem Case 2 ; connection Switch $sText Case "connected" $iBkColour = 0x00FF00 Case "notconnect" $iBkColour = 0x0000FF Case "err-disabled" $iBkColour = 0xC4C4C4 EndSwitch Case 3 ; vlan Switch $sText Case "trunk" $iBkColour = 0x00FFFF Case "1" $iBkColour = 0xFFFF00 Case "10" $iBkColour = 0xC4FFC4 Case "13" $iBkColour = 0xFF00FF EndSwitch EndSwitch ; Set required back colour DllStructSetData($tNMLVCUSTOMDRAW, "ClrTextBk", $iBkColour) Return $CDRF_NEWFONT ; $CDRF_NEWFONT must be returned after changing font or colors EndSwitch EndSwitch EndFunc ;==>_WM_NOTIFY Now you can move the MsgBox around as much as you like.
M23

31290,
Glad I could help.
M23

31290,
Il n'y a pas de quoi.
M23

31290,
I have completely recoded the delimiter parsing section to deal with the annoying "Name" section - please test this and see if it works for you:
#include <GUIConstantsEx.au3> #include <WindowsConstants.au3> #include <StringConstants.au3> #include <Array.au3> #include <GuiListView.au3> ; Read file into array $aLines = FileReadToArray("EPES18.txt") ; Deal with title line $aLines[0] = StringRegExpReplace($aLines[0], "(\x20+)", "|") ; Now the other lines For $i = 1 To UBound($aLines) - 1 ; Extract line $sLine = $aLines[$i] ; Replace tabs with spaces $sLine = StringReplace($sLine, @TAB, " ") ; Extract possible name field $sName = StringRegExpReplace($sLine, "(?U)^.*(\x20.*\x20)(connected|notconnect|err-disabled).*$", "$1") ; Convert multiple spaces to singles $sStrippedName = StringRegExpReplace($sName, "\x20+", " ") ; Set placeholder if no name field If $sStrippedName = " " Then $sStrippedName = " ~ " ; Replace original name string in line with stripped version - add spaces to ensure multiple spaces before and after $sLine = StringReplace($sLine, $sName, " " & $sStrippedName & " ") ; Set delimiters by replacing multiple spaces $sLine = StringRegExpReplace($sLine, "(\x20{2,19})", "|") ; Remove placeholders $sLine = StringReplace($sLine, "~", "") ; Replace existing line with delimited line $aLines[$i] = $sLine Next $hGUI = GUICreate("Test", 500, 500) ; Create ListView with first 4 headers $cLV = GUICtrlCreateListView(StringRegExpReplace($aLines[0], "(?U)^(.*\|.*\|.*\|.*)\|.*$", "$1"), 10, 10, 480, 380) ; Set column widths For $i = 0 To 3 _GUICtrlListView_SetColumnWidth($cLV, $i, 110) Next ; Add content of first 4 fields in each line For $i = 1 To UBound($aLines) - 1 $cLVItem = GUICtrlCreateListViewItem(StringRegExpReplace($aLines[$i], "(?U)^(.*\|.*\|.*\|.*)\|.*$", "$1"), $cLV) Next GUIRegisterMsg($WM_NOTIFY, "_WM_NOTIFY") GUISetState() ; Set sort state Local $aSortSense[_GUICtrlListView_GetColumnCount($cLV)] While 1 Switch GUIGetMsg() Case $GUI_EVENT_CLOSE Exit EndSwitch WEnd Func _WM_NOTIFY($hWnd, $imsg, $wParam, $lParam) ; Struct = $tagNMHDR and "int Item;int SubItem" from $tagNMLISTVIEW Local $tStruct = DllStructCreate("hwnd;uint_ptr;int_ptr;int;int", $lParam) If @error Then Return Local $iCode = BitAND(DllStructGetData($tStruct, 3), 0xFFFFFFFF) Switch $iCode Case $LVN_COLUMNCLICK ; Get column index Local $iCol = DllStructGetData($tStruct, 5) If $iCol <> 0 Then ; Sort column _GUICtrlListView_SimpleSort($cLV, $aSortSense, $iCol) EndIf Case $NM_DBLCLK $iRow = DllStructGetData($tStruct, 4) ; Row 0 in ListView is row 2 in the array $sData = $aLines[$iRow + 2] ; Split $aData = StringSplit($sData, "|") ConsoleWrite("Row Data: " & $aData[1] & " - " & $aData[2] & " - " & $aData[3] & " - " & $aData[4] & @CRLF) Case $NM_CUSTOMDRAW Local $tNMLVCUSTOMDRAW = DllStructCreate($tagNMLVCUSTOMDRAW, $lParam) Local $dwDrawStage = DllStructGetData($tNMLVCUSTOMDRAW, "dwDrawStage") Switch $dwDrawStage ; Holds a value that specifies the drawing stage Case $CDDS_PREPAINT ; Before the paint cycle begins Return $CDRF_NOTIFYITEMDRAW ; Notify the parent window of any item-related drawing operations Case $CDDS_ITEMPREPAINT ; Before painting an item Return $CDRF_NOTIFYSUBITEMDRAW ; Notify the parent window of any subitem-related drawing operations Case BitOR($CDDS_ITEMPREPAINT, $CDDS_SUBITEM) ; Before painting a subitem Local $iItem = DllStructGetData($tNMLVCUSTOMDRAW, "dwItemSpec") ; Item index Local $iSubItem = DllStructGetData($tNMLVCUSTOMDRAW, "iSubItem") ; Subitem index ; Gte text of item $sText = _GUICtrlListView_GetItemText($cLV, $iItem, $iSubItem) ; Set default back colour $iBkColour = 0xC4C4C4 ; Now check for our spoecific items Switch $iSubItem Case 2 ; connection Switch $sText Case "connected" $iBkColour = 0x00FF00 Case "notconnect" $iBkColour = 0x0000FF Case "err-disabled" $iBkColour = 0xC4C4C4 EndSwitch Case 3 ; vlan Switch $sText Case "trunk" $iBkColour = 0x00FFFF Case "1" $iBkColour = 0xFFFF00 Case "10" $iBkColour = 0xC4FFC4 Case "13" $iBkColour = 0xFF00FF EndSwitch EndSwitch ; Set required back colour DllStructSetData($tNMLVCUSTOMDRAW, "ClrTextBk", $iBkColour) Return $CDRF_NEWFONT ; $CDRF_NEWFONT must be returned after changing font or colors EndSwitch EndSwitch EndFunc ;==>_WM_NOTIFY If you still have problems, then please let me see the file containing the lines causing difficulty so I can refine the process further.
M23

31290,
Here is LarsJ's code integrated into mine - I enjoyed doing that:
#include <GUIConstantsEx.au3> #include <WindowsConstants.au3> #include <StringConstants.au3> #include <Array.au3> #include <GuiListView.au3> ; Read file and replace tabs $sContent = StringReplace(FileRead("EPES18.txt"), @TAB, " ") ; Replace orphaned dashes $sNoDashes = StringReplace($sContent, " - ", "  ") ; Expand possible single space before connection status $sExpanded = StringRegExpReplace($sNoDashes, "(\x20(connected|notconnect|err-disabled))", " $1") ; Replace multiple spaces with | delimiter - max 19 to allow for empty fields $sDelimed = StringRegExpReplace($sExpanded, "(\x20{2,19})", "|") ; Split on @CRLF $aLines = StringSplit($sDelimed, @CRLF, $STR_ENTIRESPLIT) ;_ArrayDisplay($aLines, "", Default, 8) $hGUI = GUICreate("Test", 500, 500) ; Create ListView with first 4 headers $cLV = GUICtrlCreateListView(StringRegExpReplace($aLines[1], "(?U)^(.*\|.*\|.*\|.*)\|.*$", "$1"), 10, 10, 480, 380) ; Set column widths For $i = 0 To 3 _GUICtrlListView_SetColumnWidth($cLV, $i, 110) Next ; Add content of first 4 fields in each line For $i = 2 To $aLines[0] $cLVItem = GUICtrlCreateListViewItem(StringRegExpReplace($aLines[$i], "(?U)^(.*\|.*\|.*\|.*)\|.*$", "$1"), $cLV) Next GUIRegisterMsg($WM_NOTIFY, "_WM_NOTIFY") GUISetState() ; Set sort state Local $aSortSense[_GUICtrlListView_GetColumnCount($cLV)] While 1 Switch GUIGetMsg() Case $GUI_EVENT_CLOSE Exit EndSwitch WEnd Func _WM_NOTIFY($hWnd, $imsg, $wParam, $lParam) ; Struct = $tagNMHDR and "int Item;int SubItem" from $tagNMLISTVIEW Local $tStruct = DllStructCreate("hwnd;uint_ptr;int_ptr;int;int", $lParam) If @error Then Return Local $iCode = BitAND(DllStructGetData($tStruct, 3), 0xFFFFFFFF) Switch $iCode Case $LVN_COLUMNCLICK ; Get column index Local $iCol = DllStructGetData($tStruct, 5) If $iCol <> 0 Then ; Sort column _GUICtrlListView_SimpleSort($cLV, $aSortSense, $iCol) EndIf Case $NM_DBLCLK $iRow = DllStructGetData($tStruct, 4) ; Row 0 in ListView is row 2 in the array $sData = $aLines[$iRow + 2] ; Split $aData = StringSplit($sData, "|") ConsoleWrite("Row Data: " & $aData[1] & " - " & $aData[2] & " - " & $aData[3] & " - " & $aData[4] & @‌CRLF) Case $NM_CUSTOMDRAW Local $tNMLVCUSTOMDRAW = DllStructCreate($tagNMLVCUSTOMDRAW, $lParam) Local $dwDrawStage = DllStructGetData($tNMLVCUSTOMDRAW, "dwDrawStage") Switch $dwDrawStage ; Holds a value that specifies the drawing stage Case $CDDS_PREPAINT ; Before the paint cycle begins Return $CDRF_NOTIFYITEMDRAW ; Notify the parent window of any item-related drawing operations Case $CDDS_ITEMPREPAINT ; Before painting an item Return $CDRF_NOTIFYSUBITEMDRAW ; Notify the parent window of any subitem-related drawing operations Case BitOR($CDDS_ITEMPREPAINT, $CDDS_SUBITEM) ; Before painting a subitem Local $iItem = DllStructGetData($tNMLVCUSTOMDRAW, "dwItemSpec") ; Item index Local $iSubItem = DllStructGetData($tNMLVCUSTOMDRAW, "iSubItem") ; Subitem index ; Gte text of item $sText = _GUICtrlListView_GetItemText($cLV, $iItem, $iSubItem) ; Set default back colour $iBkColour = 0xC0B0B0 ; Now check for our spoecific items Switch $iSubItem Case 2 ; connection Switch $sText Case "connected" $iBkColour = 0x00FF00 Case "notconnect" $iBkColour = 0x0000FF Case "err-disabled" $iBkColour = 0xC4C4C4 EndSwitch Case 3 ; vlan Switch $sText Case "trunk" $iBkColour = 0x00FFFF Case "1" $iBkColour = 0xFFFF00 Case "10" $iBkColour = 0xC4FFC4 Case "13" $iBkColour = 0xFF00FF EndSwitch EndSwitch ; Set required back colour DllStructSetData($tNMLVCUSTOMDRAW, "ClrTextBk", $iBkColour) Return $CDRF_NEWFONT ; $CDRF_NEWFONT must be returned after changing font or colors EndSwitch EndSwitch EndFunc ;==>_WM_NOTIFY It looks as if the file parsing could do with a bit more work - there are a couple of lines where the delimiters are not correct. It does not help that the file uses a mixture of spaces and tabs to separate the items on each line - and on some lines there are items missing. Can you get the file in a more reasonable CSV format or are you stuck with what you have posted?
M23
Edit: Recoded the file parsing - it now works for the test file, but I would still recommend trying to get a better delimited file initially as the parsing requirements are a bit arbitrary at the moment.

31290,
If you want to prevent sorting certain columns, then just check which column was clicked inside the handler - this prevents the first column being sorted:
Case $LVN_COLUMNCLICK ; Get column index Local $iCol = DllStructGetData($tStruct, 5) If $iCol <> 0 Then ; Sort column _GUICtrlListView_SimpleSort($cLV, $aSortSense, $iCol) EndIfM23:
