Transparent label flickering

Recommended Posts

n1maS

hey all

is there any way to create such lable that does not flicker?

checkout the example below

#include
#include

HotKeySet("{ESC}", "_Exit")

; ===============
; Test #1
; ===============


$hGUI = GUICreate("Test", 300, 200)
$iPic = GUICtrlCreatePic(".\SS.jpg", 0, 0, 300, 200)
$iLable = GUICtrlCreateLabel("", 70, 50, 100, 20, $SS_CENTER)
GUICtrlSetFont($iLable, 10, 400, 0, "Segoe Script")
GUICtrlSetBkColor($iLable, $GUI_BKCOLOR_TRANSPARENT)

GUISetState()

While Sleep(20)
GUICtrlSetData($iLable, Random(0, 100000, 1))
WEnd

Func _Exit()
Exit
EndFunc ;==>_Exit

I need to change the data a lot thats why I made the example this way.

is there any other way exepet using $WS_EX_COMPOSITED ?

tnx

post-71718-0-70535100-1351873245_thumb.j

Share this post


Link to post
Share on other sites
Melba23

n1maS,

Do you really need to change the data that often? I cannot even read the value when it is changing every 20ms! :o

If I slow down the script to write every 250ms I get no flickering at all - and I can read the value displayed without problem. ;)

M23


Any of my own code posted anywhere on the forum is available for use by others without any restriction of any kind._______My UDFs:

Spoiler

ArrayMultiColSort ---- Sort arrays on multiple columns
ChooseFileFolder ---- Single and multiple selections from specified path treeview listing
Date_Time_Convert -- Easily convert date/time formats, including the language used
ExtMsgBox --------- A highly customisable replacement for MsgBox
GUIExtender -------- Extend and retract multiple sections within a GUI
GUIFrame ---------- Subdivide GUIs into many adjustable frames
GUIListViewEx ------- Insert, delete, move, drag, sort, edit and colour ListView items
GUITreeViewEx ------ Check/clear parent and child checkboxes in a TreeView
Marquee ----------- Scrolling tickertape GUIs
NoFocusLines ------- Remove the dotted focus lines from buttons, sliders, radios and checkboxes
Notify ------------- Small notifications on the edge of the display
Scrollbars ----------Automatically sized scrollbars with a single command
StringSize ---------- Automatically size controls to fit text
Toast -------------- Small GUIs which pop out of the notification area



Share this post


Link to post
Share on other sites
n1maS

Melba23, first of all thanks for your quick reply. (as always!)

Well, not that often! :idiot:

but I need to change it fast. even if I slow it down to 250ms, I get flickering. (Every 5-10 sec)

Is it possible to use double buffering?

Share this post


Link to post
Share on other sites
stormbreaker

For such purpose (to avoid flickring) you will need ControlSetText()

#include <WindowsConstants.au3>
#include <GuiConstantsEx.au3>


HotKeySet("{ESC}", "_Exit")

; ===============
; Test #1
; ===============


$hGUI = GUICreate("Test", 300, 200)
$iPic = GUICtrlCreatePic(".SS.jpg", 0, 0, 300, 200)
$iLable = GUICtrlCreateLabel("", 70, 50, 100, 20)
GUICtrlSetFont($iLable, 10, 400, 0, "Segoe Script")
GUICtrlSetBkColor($iLable, $GUI_BKCOLOR_TRANSPARENT)

GUISetState()

While Sleep(250)
ControlSetText($hGUI, "", $iLable, Random(0, 100000, 1), 1)
WEnd

Func _Exit()
Exit
EndFunc ;==>_Exit

----------------------------------------

:bye: Hey there, was I helpful?

----------------------------------------

My Current OS: Win8 PRO (64-bit); Current AutoIt Version: v3.3.8.1

Share this post


Link to post
Share on other sites
n1maS

In that case, the whole GUI flickers! try it yourself and see the result :mellow:

Share this post


Link to post
Share on other sites
UEZ

You can use a child GUI.

Example:

#include <WinAPI.au3>
#include <WindowsConstants.au3>
#include <StaticConstants.au3>
#include <GUIConstantsEx.au3>

HotKeySet("{ESC}", "_Exit")

; ===============
; Test #1
; ===============


$hGUI = GUICreate("Test", 300, 200)
$iPic = GUICtrlCreatePic(".SS.jpg", 0, 0, 300, 200)
GUICtrlSetState(-1, $GUI_DISABLE)
$hGUI_Child = GUICreate("", 100, 20, 70, 50, $WS_POPUP, $WS_EX_MDICHILD + $WS_EX_TOPMOST + $WS_EX_LAYERED + $WS_EX_TRANSPARENT + $WS_EX_COMPOSITED, $hGUI)
$iTransCol = 0x808080
GUISetBkColor($iTransCol, $hGUI_Child)
$iLable = GUICtrlCreateLabel("", 0, 0, 100, 20, $SS_CENTER)
GUICtrlSetFont($iLable, 10, 400, 0, "Segoe Script", 5)
GUICtrlSetBkColor($iLable, $GUI_BKCOLOR_TRANSPARENT)
_WinAPI_SetLayeredWindowAttributes($hGUI_Child, $iTransCol)
GUISetState(@SW_SHOW, $hGUI)
GUISetState(@SW_SHOWNA, $hGUI_Child)

While Sleep(20)
    GUICtrlSetData($iLable, Random(0, 100000, 1))
WEnd

Func _Exit()
    GUIDelete($hGUI_Child)
    GUIDelete($hGUI)
    Exit
EndFunc ;==>_Exit

Br,

UEZ

Edited by UEZ

Please don't send me any personal message and ask for support! I will not reply!

Selection of finest graphical examples at Codepen.io

The own fart smells best!
Her 'sikim hıyar' diyene bir avuç tuz alıp koşma!
¯\_(ツ)_/¯  ٩(●̮̮̃•̃)۶ ٩(-̮̮̃-̃)۶ૐ

Share this post


Link to post
Share on other sites
KaFu

Well, for me the child gui does not seem to be treated as a real child, as when the parent goes to the background the child still stays on top (at least on Win7, guess it has something to do with the style mix (layered?) ) ?!

#include <WinAPI.au3>
#include <WindowsConstants.au3>
#include <StaticConstants.au3>
#include <GUIConstantsEx.au3>

HotKeySet("{ESC}", "_Exit")

; ===============
; Test #1
; ===============


$hGUI = GUICreate("Test", 300, 200)
$iPic = GUICtrlCreatePic(".ss.jpg", 0, 0, 300, 200)
GUICtrlSetState(-1, $GUI_DISABLE)

$hGUI_Child = GUICreate("", 100, 20, 70, 50, $WS_POPUP, BitOR($WS_EX_MDICHILD,$WS_EX_TOPMOST, $WS_EX_LAYERED, $WS_EX_TRANSPARENT ,$WS_EX_COMPOSITED), $hGUI)
$iTransCol = 0x808080
GUISetBkColor($iTransCol, $hGUI_Child)
$iLable = GUICtrlCreateLabel("", 0, 0, 100, 20, $SS_CENTER)
GUICtrlSetFont($iLable, 10, 400, 0, "Segoe Script", 5)
GUICtrlSetColor($iLable,0xff0000)
GUICtrlSetBkColor($iLable, $GUI_BKCOLOR_TRANSPARENT)
_WinAPI_SetLayeredWindowAttributes($hGUI_Child, $iTransCol)

GUIRegisterMsg($WM_ACTIVATE, "WM_ACTIVATE")
GUISetState(@SW_SHOW, $hGUI)


While Sleep(20)
    GUICtrlSetData($iLable, Random(0, 100000, 1))
WEnd

Func _Exit()
    GUIDelete($hGUI_Child)
    GUIDelete($hGUI)
    Exit
EndFunc ;==>_Exit

Func WM_ACTIVATE($hWnd, $Msg, $wParam, $lParam)
    Switch $hWnd
        Case $hGUI
            If $wParam Then
                GUISetState(@SW_SHOWNA, $hGUI_Child)
            Else
                GUISetState(@SW_HIDE, $hGUI_Child)
            endif
    EndSwitch
    Return $GUI_RUNDEFMSG
EndFunc

Share this post


Link to post
Share on other sites
UEZ

@KaFu: for me when the GUI loses the focus the child window is hidden and is visible when window is active again.

I'm using Win7 x64 with Aero.

Edit: now I got you. Indeed when activating another window the child window is still on top! I wasn't aware of this... good catch! In this case don't use $WS_EX_TOPMOST because it is not needed or your workaround!

Br,

UEZ

Edited by UEZ

Please don't send me any personal message and ask for support! I will not reply!

Selection of finest graphical examples at Codepen.io

The own fart smells best!
Her 'sikim hıyar' diyene bir avuç tuz alıp koşma!
¯\_(ツ)_/¯  ٩(●̮̮̃•̃)۶ ٩(-̮̮̃-̃)۶ૐ

Share this post


Link to post
Share on other sites
n1maS

UEZ, it worked fine, thanks :thumbsup:

I agree with KaFu. I'm using Win7 x64 too.

well WM_ACTIVATE seems to be a good option.

thank you both.

Share this post


Link to post
Share on other sites
LeCarre

Tried to implement this into my flickering window, spent hours on it, but it fuzzes up my fonts pretty bad, when I change the Transparent color from 0x808080 to 0xFF0000 it shows that the transparent color appears like an aura around the font, it's just less obvious with the Grey 0x808080 and the more artistic font... Trying a thin font looks like pretty bad.

well, flickering is my friend :)

Edited by LeCarre

Share this post


Link to post
Share on other sites
topten

The method of adding Child_gui helps avoiding flickering, but how can I access control behind the child_gui ?

GUICtrlSetCursor(-1, 0)
GUICtrlSetOnEvent($iLable, "somefunc")



Share this post


Link to post
Share on other sites
AutoBert

GuiCtrlSetData works with control behind a child gui:

#Region ;**** Directives created by AutoIt3Wrapper_GUI ****
#AutoIt3Wrapper_Add_Constants=n
#EndRegion ;**** Directives created by AutoIt3Wrapper_GUI ****
#cs ----------------------------------------------------------------------------

    AutoIt Version: 3.3.6.1
    Author:                        AutoBert:    http://www.autoit.de/index.php?page=Thread&postID=164341#post164341

    Skriptbeispiel für den Umgang mit INI-Files und ComboBox
#ce ----------------------------------------------------------------------------

#include <WindowsConstants.au3>
#include <GUIConstantsEx.au3>
#include <EditConstants.au3>
#include <GUIConstantsEx.au3>
#include <GuiComboBox.au3>
#include <StaticConstants.au3>
#include <Array.au3>

Const $sElect = "bitte einen Download auswählen"
Global $sUrl ;ausgewählte DownloadUrl
Global $sIni = @AppDataDir & "\Download.INI" ;Pfad zur Inidatei
Global $sLocalFolder ;letztes Verzeichnis in das gespeichert wurde
Global $aData[3] ;Download-Infos
Global $iFileSize ;Grösse des DL-Files
Global $tStart ;Download gestartet
Global $nKBPerSec ;KB pro Sekunde
Global $iPercent ;aktuell heruntergeladenen Prozentanteil der Datei

;FileDelete($sIni)
If Not FileExists($sIni) Then
    $sData = "AutoIt 3.3.14.2=https://www.autoitscript.com/cgi-bin/getfile.pl?autoit3/autoit-v3-setup.exe"
    $sData &= "|This is actual stable version<CRLF>It's recommended to use it"& @LF
    $sData &= "AutoIt Beta=https://www.autoitscript.com/forum/files/file/351-learn-to-program-using-free-tools-with-autoit/?do=download&csrfKey=46ede52eb772decda8c95753f0fe98c4"
    $sData &= "|This is a beta version<CRLF>Only excperts should use it"& @LF
    IniWriteSection($sIni, "URLs", $sData)
EndIf

$hGui = GUICreate("mini-Downloader", 300, 125, 302, 218)
$idcboProg = GUICtrlCreateCombo("", 8, 8, 200, 25)
$idbtnAdd = GUICtrlCreateButton("&Hinzufügen", 213, 8, 80)
$idbtnDel = GUICtrlCreateButton("&Löschen", 213, 35, 80)
$idprgInfo = GUICtrlCreateProgress(8, 70, 285, 30)
$idbtnDL = GUICtrlCreateButton("&Downloaden", 8, 35, 200)
$idMultiLine=GUICtrlCreateEdit("",8,65,285,50,$ES_ReadOnly)
$hGUI_c = GUICreate("", 184, 30, 8, 73, $WS_POPUP, BitOR($WS_EX_LAYERED, $WS_EX_TRANSPARENT, $WS_EX_MDICHILD), $hGUI)
GUISetBkColor(0x989898, $hGUI_c)
$idlblInfo = GUICtrlCreateLabel("0", 0, 0, 184, 25, $ES_CENTER)
GUICtrlSetFont(-1, 12, 1000)
GUICtrlSetBkColor(-1, $GUI_BKCOLOR_TRANSPARENT)
_WinAPI_SetLayeredWindowAttributes($hGUI_c, 0x989898)
GUICtrlSetState($idlblInfo, $GUI_HIDE)
GUICtrlSetState($idprgInfo, $GUI_HIDE)
read_INI()
GUISetState(@SW_SHOW, $hGUI)
GUISetState(@SW_SHOWNA, $hGUI_c)
HttpSetUserAgent("Mozilla/5.0 (Windows; U; Windows NT 5.1; de; rv:1.9.2.7) Gecko/20100713 Firefox/3.6.16") ;sonst streiken manche Freehoster wenn der AutoItUseragent gesetzt ist

While 1
    $nMsg = GUIGetMsg()
    Switch $nMsg
        Case $GUI_EVENT_CLOSE
            IniWrite($sIni, "Path", "Local", $sLocalFolder)
            Exit
        #cs
        Case $idbtnAdd
            $write1 = InputBox("Downloadadresse", "Bitte eine gültige Download-Adresse eingeben")
            If $write1 <> "" Then
                $write2 = InputBox("Download verwalten  unter", "Bitte Kurzbegriff eingeben")
                If $write2 <> "" Then IniWrite($sIni, "URLs", $write2, $write1)
                GUICtrlSetData($idcboProg, $write2, $write2)
            EndIf
            get_Selection()
        Case $idbtnDel
            $sDel = GUICtrlRead($idcboProg)
            IniDelete($sIni, "URLs", $sDel)
            GUICtrlSetData($idcboProg, "")
            read_INI()
        #ce
        Case $idcboProg
            get_Selection()
        Case $idbtnDL
            ;get_Selection()
            $bCanceld = False
            GUICtrlSetState($idMultiLine, $GUI_HIDE)
            GUICtrlSetData($idbtnDL, "Download &abbrechen")
            $aDatei = StringSplit($sUrl, "/")
            $sDatei = $aDatei[$aDatei[0]]
            $sLocal = FileSaveDialog($sDatei & "Speichern unter", $sLocalFolder, "Alle (*.*)", 18, $sDatei, $hGui)
            If Not @error Then
                GUICtrlSetState($idprgInfo, $GUI_SHOW)
                GUICtrlSetState($idlblInfo, $GUI_SHOW)
                GUICtrlSetData($idlblInfo, "Download startet")
                $aTmp = StringSplit($sLocal, "\")
                $sLocalFolder = $aTmp[$aTmp[1]]
                $iFileSize = InetGetSize($sUrl)
                $hDL = InetGet($sUrl, $sLocal, 1, 1)
                $tStart = TimerInit()
                $aData[0] = 0
                Do
                    $bCanceld = _MySleep(500)
                    If $bCanceld Then ExitLoop
                    $aData = InetGetInfo($hDL, -1)
                    If $aData[0] > 0 Then
                        $tDiff = TimerDiff($tStart)
                        $nKBPerSec = Round($aData[0] / $tDiff * 1000 / 1024, 2)
                        $iPercent = Round($aData[0] / $iFileSize * 100, 2)
                        If GUICtrlRead($idlblInfo) <> $iPercent Then
                            GUICtrlSetData($idprgInfo, $iPercent)
                            GUICtrlSetData($idlblInfo, $iPercent & " %  " & $nKBPerSec & " KB/sec")
                            WinSetTitle($hGui, "", "DL: " & $sDatei & " " & $iPercent & "%")
                        EndIf
                    EndIf
                Until $aData[2]
                InetClose($hDL)
                ;_ArrayDisplay($aData)
                If $aData[0] < $aData[1] Then $aData[3] = False ;dummerweise werden nur DL-Fehler auf meiner Seite erkannt es kommt aber vo das der DL aus anderen Gründen nicht erfolgreich war
                If $aData[0] < $iFileSize Then $aData[3] = False ;dummerweise werden nur DL-Fehler auf meiner Seite erkannt es kommt aber vo das der DL aus anderen Gründen nicht erfolgreich war
                If Not $aData[3] Then
                    If $bCanceld Then
                        $sMsg = "Download wurde durch Benutzer abgebrochen"
                    Else
                        $sMsg = "Download hat abgebrochen," & @CRLF & "überprüfen sie Ihre Internetverbindung." & @CRLF & @CRLF & "Probieren Sie danach noch einmal!"
                    EndIf
                    MsgBox(48, "Fehler:", $sMsg)
                    FileDelete($sLocal)
                Else
                    GUICtrlSetState($idbtnDL, $GUI_DISABLE)
                    GUICtrlSetData($idcboProg,$sElect,$sElect)
                    MsgBox(64, $sLocal, "erfolgreich heruntergeladen")
                EndIf
                GUICtrlSetState($idMultiLine, $GUI_SHOW)
            Else
                MsgBox(48, "Fehler:", "keinen Namen zum Speichern ausgeählt")
            EndIf
            GUICtrlSetData($idprgInfo, 0)
            GUICtrlSetData($idlblInfo, 0)
            GUICtrlSetState($idlblInfo, $GUI_HIDE)
            GUICtrlSetState($idprgInfo, $GUI_HIDE)
            GUICtrlSetData($idbtnDL, "&Downloaden")
            WinSetTitle($hGui, "", "mini-Downloader")
    EndSwitch
WEnd

Func _MySleep($iMSec)
    Local $nMsg, $dt = TimerInit()
    Do
        $nMsg = GUIGetMsg()
        Switch $nMsg
            Case $GUI_EVENT_CLOSE
                Exit
            Case $idbtnDL
                Return 1; DL Abbrechen wurde gedrückt
        EndSwitch
        Sleep(10)
    Until TimerDiff($dt) > $iMSec
EndFunc   ;==>_MySleep

Func read_INI()
    $list1 = IniReadSection($sIni, "URLs")
    ;ConsoleWrite($list1 & @CRLF)
    If IsArray($list1) Then
        For $i = 1 To $list1[0][0]
            GUICtrlSetData($idcboProg, $list1[$i][0])
        Next
    EndIf
    _GUICtrlComboBox_InsertString($idcboProg, $sElect, 0)
    _GUICtrlComboBox_SetCurSel($idcboProg, 0)
    $sLocalFolder = IniRead($sIni, "Path", "Local", @ScriptDir)
EndFunc   ;==>read_INI

Func get_Selection()
    If GUICtrlRead($idcboProg) = $sElect Then
        GUICtrlSetState($idbtnDL, $GUI_DISABLE)
        GUICtrlSetData($idlblInfo, "")
        GUICtrlSetData($idMultiLine, "")
    Else
        GUICtrlSetState($idbtnDL, $GUI_ENABLE)
        $Prog = GUICtrlRead($idcboProg)
        ;ConsoleWrite("ausgewählt: " & $Prog & @CRLF)
        $sTmp = IniRead($sIni, "URLs", $Prog, "")
        $aTmp=StringSplit($sTmp,"|")
        ;_ArrayDisplay($aTmp)
        $sUrl=$aTmp[1]
        GUICtrlSetData($idMultiLine,StringReplace($aTmp[2],"<CRLF>",@CRLF))
    EndIf
EndFunc   ;==>get_Selection

what you would ask with your snipet, i don't understand.

Share this post


Link to post
Share on other sites

Create an account or sign in to comment

You need to be a member in order to leave a comment

Create an account

Sign up for a new account in our community. It's easy!

Register a new account

Sign in

Already have an account? Sign in here.

Sign In Now

×
