DaRam

Help with Splash Screen, Adding Label on Layered Window

9 posts in this topic

Hi:

I need some help with Splash Screen when displayed as an About Screen.

When I add Labels on Layered Window, they never appear.

Think I have to create a Child Window and use the SetLayeredWindowAttributes API (?) - If so some help would be appreciated.

Also, Should I just include the functions/code in Splash.Au3 instead of include(ing) it? :D

SplashTest.Au3 is the Main GUI, Which calls the 2 Functions in (the attached) Splash.Au3

Splash.png is the Graphic File used by Splash.Au3.

SplashTest.Au3

#NoTrayIcon
#Include "Splash.Au3"

Local $SplashShown
$SplashShown = True
DisplaySplash()
If @error Then $SplashShown = False
Sleep(1000)

$guiMain = GUICreate("Main GUI", 300, 400, -1, -1)
$MenuFile = GUICtrlCreateMenu("&File")
$mnuFileExit     = GUICtrlCreateMenuItem("E&xit", $MenuFile)

$MenuHelp = GUICtrlCreateMenu("&Help")
$mnuHelp = GUICtrlCreateMenuItem("&Help", $MenuHelp)
$mnuAbout = GUICtrlCreateMenuItem("&About", $MenuHelp)
GUISetState()
Sleep(1000)

If $SplashShown Then DismissSplash()
While 1
    $msg = GUIGetMsg()
    Switch $msg
    Case $GUI_EVENT_CLOSE, $mnuFileExit
             ExitLoop
    Case $mnuAbout
         $NormalLabelTxt = "Some Caption"
         $HotLabelTxt = "Hot Caption"
             DisplaySplash()
             If @error Then $SplashShown = False
             If $SplashShown Then
                  While 1
                     If Check4KbdOrMousePress() Then ExitLoop
                  WEnd
                DismissSplash()
             EndIf
  EndSwitch
Wend

Func Check4KbdOrMousePress()
Local $Keycodes = StringSplit("01|02|04|05|06" & _
    "|08|09|0C|0D|10|11|12|13|14|1B|20|21|22" & _
    "|23|24|25|26|27|28|29|2A|2B|2C|2D|2E|30" & _
    "|31|32|33|34|35|36|37|38|39|41|42|43|44" & _
    "|45|46|47|48|49|4A|4B|4C|4D|4E|4F|50|51" & _
    "|52|53|54|55|56|57|58|59|5A|5B|5C|60|61" & _
    "|62|63|64|65|66|67|68|69|6A|6B|6C|6D|6E" & _
    "|6F|70|71|72|73|74|75|76|77|78|79|7A|7B" & _
    "|90|91|A0|A1|A2|A3|A4|A5", "|")
    For $i in $Keycodes
        If _IsPressed(String($i)) Then Return 1
    Next
    Return 0
EndFunc

Splash.Au3


Share this post


Link to post
Share on other sites



Bump

Share this post


Link to post
Share on other sites

#3 ·  Posted (edited)

Bump

Try replacing the exiting SetBitmap() function with this one.

;
Func SetBitmap($hGUI, $hImage, $iOpacity)
Const $AC_SRC_ALPHA = 1
Const $ULW_ALPHA = 2
Local $hScrDC, $hMemDC, $hBitmap, $hOld, $pSize, $tSize, $pSource, $tSource, $pBlend, $tBlend
local $hBrush, $hFormat, $hFamily, $hFont, $tLayout,$hGraphic
    $hScrDC = _WinAPI_GetDC(0)
    $hMemDC = _WinAPI_CreateCompatibleDC($hScrDC)
    $hBitmap = _GDIPlus_BitmapCreateHBITMAPFromBitmap($hImage)
    $hOld = _WinAPI_SelectObject($hMemDC, $hBitmap)
    $hGraphic = _GDIPlus_GraphicsCreateFromHDC ($hMemDC)

    $hBrush  = _GDIPlus_BrushCreateSolid (0xffFA0C0A)
    $hFormat = _GDIPlus_StringFormatCreate ()
    $hFamily = _GDIPlus_FontFamilyCreate ("Arial")
    $hFont   = _GDIPlus_FontCreate ($hFamily, 32, 1)
    $tLayout = _GDIPlus_RectFCreate ( 100, 200, 350, 50 )
    _GDIPlus_GraphicsDrawStringEx ($hGraphic, $HotLabelTxt, $hFont, $tLayout, $hFormat, $hBrush)

     $tSize = DllStructCreate($tagSIZE)
    $pSize = DllStructGetPtr($tSize)
    DllStructSetData($tSize, "X", _GDIPlus_ImageGetWidth($hImage))
    DllStructSetData($tSize, "Y", _GDIPlus_ImageGetHeight($hImage))
    $tSource = DllStructCreate($tagPOINT)
    $pSource = DllStructGetPtr($tSource)
    $tBlend = DllStructCreate($tagBLENDFUNCTION)
    $pBlend = DllStructGetPtr($tBlend)
    DllStructSetData($tBlend, "Alpha", $iOpacity)
    DllStructSetData($tBlend, "Format", $AC_SRC_ALPHA)
    _WinAPI_UpdateLayeredWindow($hGUI, $hScrDC, 0, $pSize, $hMemDC, $pSource, 0, $pBlend, $ULW_ALPHA)
    _WinAPI_ReleaseDC(0, $hScrDC)
    _WinAPI_SelectObject($hMemDC, $hOld)
    _WinAPI_DeleteObject($hBitmap)
    WinAPI_DeleteDC($hMemDC)
    _GDIPlus_FontDispose ($hFont)
    _GDIPlus_FontFamilyDispose ($hFamily)
   _GDIPlus_StringFormatDispose ($hFormat)
   _GDIPlus_BrushDispose ($hBrush)
EndFunc   ;==>SetBitmap
;

With this I did get Hot Caption in red across the image when the About button is pressed.

If it works, You have some unnecessary code you can delete.

Edited by Malkey

Share this post


Link to post
Share on other sites

Thanks Malkey, but I can't seem to make it work [i did have to change WinAPI_DeleteDC($hMemDC) to _WinAPI_DeleteDC($hMemDC)]

Here are the Modified Scripts...

SplashTest.Au3:

#NoTrayIcon
#Include "Splash.Au3"

Local $SplashShown
$SplashShown = True
DisplaySplash()
If @error Then $SplashShown = False
Sleep(1000)

$guiMain = GUICreate("Main GUI", 300, 400, -1, -1)
$MenuFile = GUICtrlCreateMenu("&File")
$mnuFileExit     = GUICtrlCreateMenuItem("E&xit", $MenuFile)

$MenuHelp = GUICtrlCreateMenu("&Help")
$mnuHelp = GUICtrlCreateMenuItem("&Help", $MenuHelp)
$mnuAbout = GUICtrlCreateMenuItem("&About", $MenuHelp)
GUISetState()
Sleep(1000)

If $SplashShown Then DismissSplash()
While 1
    $msg = GUIGetMsg()
    Switch $msg
    Case $GUI_EVENT_CLOSE, $mnuFileExit
             ExitLoop
    Case $mnuAbout
         $HotLabelTxt = "About Splash"
             DisplaySplash()
             If @error Then $SplashShown = False
             If $SplashShown Then
                  While 1
                     If Check4KbdOrMousePress() Then ExitLoop
                  WEnd
                DismissSplash()
             EndIf
  EndSwitch
Wend

Func Check4KbdOrMousePress()
Local $Keycodes = StringSplit("01|02|04|05|06" & _
    "|08|09|0C|0D|10|11|12|13|14|1B|20|21|22" & _
    "|23|24|25|26|27|28|29|2A|2B|2C|2D|2E|30" & _
    "|31|32|33|34|35|36|37|38|39|41|42|43|44" & _
    "|45|46|47|48|49|4A|4B|4C|4D|4E|4F|50|51" & _
    "|52|53|54|55|56|57|58|59|5A|5B|5C|60|61" & _
    "|62|63|64|65|66|67|68|69|6A|6B|6C|6D|6E" & _
    "|6F|70|71|72|73|74|75|76|77|78|79|7A|7B" & _
    "|90|91|A0|A1|A2|A3|A4|A5", "|")
    For $i in $Keycodes
        If _IsPressed(String($i)) Then Return 1
    Next
    Return 0
EndFunc

Splash.Au3:

#include <GUIConstants.au3>
#Include <GDIPlus.au3>
Global $SplashGUI, $hSplashImage
Global $HotLabelTxt

Func DisplaySplash()
Local $pngSrc, $width, $height, $i
; Load PNG file as GDI bitmap
    $pngSrc = @WorkingDir & "\Splash.png"
    If NOT FileExists($pngSrc) Then
       SetError(1)
       Return
    EndIf
    _GDIPlus_Startup()
    $hSplashImage = _GDIPlus_ImageLoadFromFile($pngSrc)
; Extract image width and height from PNG
    $width = _GDIPlus_ImageGetWidth($hSplashImage)
    $height = _GDIPlus_ImageGetHeight($hSplashImage)
; Create layered window
    $SplashGUI = GUICreate("", $width, $height, -1, -1, $WS_POPUP, $WS_EX_LAYERED, $DS_MODALFRAME)
    SetBitmap($SplashGUI, $hSplashImage, 0)
    GUISetState()
    WinSetOnTop($SplashGUI, "", 1)
;fade in png background
    For $i = 0 To 255 Step 5
        SetBitmap($SplashGUI, $hSplashImage, $i)
    Next
EndFunc;==>DisplaySplash

Func DismissSplash()
Local $i
    If Not IsHWnd($SplashGUI) Then
       SetError(1)
       Return
    EndIf
;fade out png background
    For $i = 255 To 0 Step - 5
      SetBitmap($SplashGUI, $hSplashImage, $i)
    Next
; Release resources
    _GDIPlus_ImageDispose($hSplashImage)
    _GDIPlus_Shutdown()
    GUIDelete($SplashGUI)
EndFunc;==>DismissSplash()

Func SetBitmap($hGUI, $hImage, $iOpacity)
Const $AC_SRC_ALPHA = 1
Const $ULW_ALPHA = 2
Local $hScrDC, $hMemDC, $hBitmap, $hOld, $pSize, $tSize, $pSource, $tSource, $pBlend, $tBlend
local $hBrush, $hFormat, $hFamily, $hFont, $tLayout,$hGraphic
    $hScrDC = _WinAPI_GetDC(0)
    $hMemDC = _WinAPI_CreateCompatibleDC($hScrDC)
    $hBitmap = _GDIPlus_BitmapCreateHBITMAPFromBitmap($hImage)
    $hOld = _WinAPI_SelectObject($hMemDC, $hBitmap)
    $hGraphic = _GDIPlus_GraphicsCreateFromHDC ($hMemDC)

    $hBrush  = _GDIPlus_BrushCreateSolid (0xffFA0C0A)
    $hFormat = _GDIPlus_StringFormatCreate ()
    $hFamily = _GDIPlus_FontFamilyCreate ("Arial")
    $hFont   = _GDIPlus_FontCreate ($hFamily, 32, 1)
    $tLayout = _GDIPlus_RectFCreate ( 100, 200, 350, 50 )
    _GDIPlus_GraphicsDrawStringEx ($hGraphic, $HotLabelTxt, $hFont, $tLayout, $hFormat, $hBrush)

    $tSize = DllStructCreate($tagSIZE)
    $pSize = DllStructGetPtr($tSize)
    DllStructSetData($tSize, "X", _GDIPlus_ImageGetWidth($hImage))
    DllStructSetData($tSize, "Y", _GDIPlus_ImageGetHeight($hImage))
    $tSource = DllStructCreate($tagPOINT)
    $pSource = DllStructGetPtr($tSource)
    $tBlend = DllStructCreate($tagBLENDFUNCTION)
    $pBlend = DllStructGetPtr($tBlend)
    DllStructSetData($tBlend, "Alpha", $iOpacity)
    DllStructSetData($tBlend, "Format", $AC_SRC_ALPHA)
    _WinAPI_UpdateLayeredWindow($hGUI, $hScrDC, 0, $pSize, $hMemDC, $pSource, 0, $pBlend, $ULW_ALPHA)
    _WinAPI_ReleaseDC(0, $hScrDC)
    _WinAPI_SelectObject($hMemDC, $hOld)
    _WinAPI_DeleteObject($hBitmap)
    _WinAPI_DeleteDC($hMemDC)
    _GDIPlus_FontDispose ($hFont)
    _GDIPlus_FontFamilyDispose ($hFamily)
   _GDIPlus_StringFormatDispose ($hFormat)
   _GDIPlus_BrushDispose ($hBrush)
EndFunc  ;==>SetBitmap

I do see the alternative you are suggesting (painting the image), which I don't see yet.

But, I want to go with a transparent label on top of the background image, so I can later on have events triggered on label click or hover.

Any further thoughts/suggestions?

Share this post


Link to post
Share on other sites

#5 ·  Posted (edited)

I do see the alternative you are suggesting (painting the image), which I don't see yet.

But, I want to go with a transparent label on top of the background image, so I can later on have events triggered on label click or hover.

Any further thoughts/suggestions?

I just grabbed the first png file I found in my picture directory which happened to be 660x540. I got the script working.

I have now gone to the other extreme and found a 50x50 png file.

Initially, I suggested these two lines in the SetBitmap() function as:-

$hFont = _GDIPlus_FontCreate ($hFamily, 32, 1)

$tLayout = _GDIPlus_RectFCreate ( 100, 200, 350, 50 )

Replace these two lines with:-

$hFont = _GDIPlus_FontCreate ($hFamily, 8, 1)

$tLayout = _GDIPlus_RectFCreate ( 5,5, 45, 45 )

You can adjust the parameters in these functions to suit yourself.

Hope this works.

Edit: Just found your image. It looks very good in the script. I am blind to the advertising people put at the bottom of their posts. Try

$hFont = _GDIPlus_FontCreate ($hFamily, 32, 1)

$tLayout = _GDIPlus_RectFCreate ( 120, 5, 300, 40 )

Edited by Malkey

Share this post


Link to post
Share on other sites

Thanks again Malkey. I will try this, but would prefer to finally use a label for the reasons I posted earlier. :D

I would have to make the same font (size) and layout (Rect) adjustments whether I use the graphic paint or label method, but the final purpose is different (click event and hover action).

Do appreciate your efforts to help. :D

Share this post


Link to post
Share on other sites

#7 ·  Posted (edited)

I would have to make the same font (size) and layout (Rect) adjustments whether I use the graphic paint or label method, but the final purpose is different (click event and hover action).

Do appreciate your efforts to help. :D

Some time ago I did this function

#include <GDIPlus.au3>
#include <GuiConstantsEx.au3>

;Run Beta Version Includes
#include <WindowsConstants.au3>
#include <Misc.au3>

Global Const $WM_LBUTTONDOWN = 0x0201  ; Drag Window 1 of 3 addin
Global $hGui

Local $nText, $init = 1, $angle = -5, $xpos = 0
Opt("MustDeclareVars", 1)
Opt("GUIOnEventMode", 1)

$nText = "AutoIt GDIPlus rotate text Example"  ;Enter text to be displayed here

;CreateFloatAngleText($nText,$Left=-1,$Top=-1,$nAngle=0,$nFontName="Arial",$nFontSize=12,$iARGB=0xFFFF00FF)
;  CreateFloatAngleText($nText,    -130,    -45,       38,                -1,           70 ) ; Large text 70

; $init = 1 allows initial flow through to display text.
; 2nd time through Do-Until loop, spaceBar or middle mouse button need to be pressed to display text.
Do
    If _IsPressed("20") Or _IsPressed("04") Or $init = 1 Then ; SpaceBar or middle mouse button key
        If $init <> 1 Then GUIDelete()
        $init  = 2
        $angle = Mod($angle + 5, 360)
        ;$xpos += 20
        CreateFloatAngleText($nText, -1, -1, $angle, -1, -1, 0) ;0 for random color; $xpos - increment X position.
    EndIf
    Sleep(250)
Until _IsPressed("1B")  ; ESC key

; #FUNCTION# ================================================================
; Name...........: CreateFloatAngleText
; Description ...: Puts text on screen at any angle.
; Syntax.........: CreateFloatAngleText($nText, $Left = -1, $Top = -1, $nAngle = 0, $nFontName = "Arial", _
;                                       $nFontSize = 12, $iARGB = 0xFFFF00FF)
; Parameters ....: $nText   - Text string to be displayed
;                  $Left    - Approximate Top left position of text from left of screen (default = -1 )
;                  $Top     - Approximate Top left position of text from top of screen  (default = -1 )
;                  $nAngle     - the angle which the text will be place.                 (default = 0 )
;                  $nFontName  - The name of the font to be used                   (default = "Arial" )
;                  $nFontSize  - The font size to be used                               (default = 12 )
;                  $iARGB      - Alpha, Red, Green and Blue color. (0=random color)(default=0xFFFF00FF)
; Return values .: 1
; Author ........: Malkey 31/03/08
; Modified.......:
; Remarks .......: Tested on xp 512mb mem. 1280x1024 resolution. Worked ok.
;                  Enter 0 for color, generates random color of text.
; Related .......:
; Link ..........;
; Example .......; Yes
; ========================================================================================
Func CreateFloatAngleText($nText, $Left = -1, $Top = -1, $nAngle = 0, $nFontName = "Arial", _
                          $nFontSize = 12, $iARGB = 0xFFFF00FF)

    Local $hWnd, $hDC, $hBitmap, $pSize, $tSize, $pSource, $tSource, $pBlend, $tBlend
    Local $iOpacity = 200
    Local $ULW_ALPHA = 2
    Local $nPI = 3.1415926535897932384626433832795
    Local $hGui, $hGraphic
    Local $GuiSize, $x, $y, $nX, $ny, $GuiWidth, $GuiHeight, $nWidth, $nHeight, $txtlen
    Local $hMatrix, $nXt, $nYt, $hBrush, $hFormat, $hFamily, $hFont, $tLayout

    ; Default values
    If $nAngle    = "" Or $nAngle    = -1 Then $nAngle    = 0
    If $nFontName = "" Or $nFontName = -1 Then $nFontName = "Arial" ; "Microsoft Sans Serif"
    If $nFontSize = "" Or $nFontSize = -1 Then $nFontSize = 12
    If $iARGB = 0 Then  ;Randomize ARGB color
        $iARGB = "0xff" & Hex(Random(0, 255, 1), 2) & Hex(Random(0, 255, 1), 2) & Hex(Random(0, 255, 1), 2)
    EndIf

    $txtlen    = StringLen($nText)
    $nWidth    = Int($nFontSize * $txtlen * 28/ 40)         ;Tweak here to de/increase text box width size
    $nHeight   = Int(($nFontSize * 37 / 30) * (1280 / 1024)) ;Tweak here to de/increase text box height size
    $GuiWidth  = $nWidth - Abs($nHeight * Sin($nAngle * $nPI / 180))
    $GuiHeight = $nHeight + Abs($nWidth * Sin($nAngle * $nPI / 180))

    $nX   = $GuiWidth  / 2
    $ny   = $GuiHeight / 2
    $hGui = GUICreate("Rotate Text", $GuiWidth, $GuiHeight, $Left, $Top, 0, BitOR($WS_EX_LAYERED, $WS_EX_TOPMOST))
    GUIRegisterMsg($WM_LBUTTONDOWN, "_WinMove")    ; Drag Window 2 of 3 addin
    GUISetState()

    _GDIPlus_Startup ()
    $hWnd = _WinAPI_GetDC (0)
    $hDC = _WinAPI_CreateCompatibleDC ($hWnd)
    $hBitmap = _WinAPI_CreateCompatibleBitmap ($hWnd, $GuiWidth, $GuiHeight) ; $iWidth, $iHeight)
    _WinAPI_SelectObject ($hDC, $hBitmap)
    $hGraphic = _GDIPlus_GraphicsCreateFromHDC ($hDC)

    ;Rotation Matrix
    $hMatrix = _GDIPlus_MatrixCreate ()
    _GDIPlus_MatrixRotate ($hMatrix, $nAngle, 1)
    _GDIPlus_GraphicsSetTransform ($hGraphic, $hMatrix)

    ;x, y are display coordinates of center of width and height of the rectanglular text box.
    ;x, y increment in a circular path with radius (width of text box)/2.
    ;Parametric equations for a circle
    ; and adjusts for center of text box
    $x = ($nWidth / 2) * Cos($nAngle * $nPI / 180) - ($nHeight / 2) * Sin($nAngle * $nPI / 180)
    $y = ($nWidth / 2) * Sin($nAngle * $nPI / 180) + ($nHeight / 2) * Cos($nAngle * $nPI / 180)

    ;Rotation of Coordinate Axes formulae
    ;Use $nXt, $nYt in  _GDIPlus_RectFCreate. These x, y values is the position of the rectangular
    ;text box point before rotation. (before translation of the matrix)
    $nXt =  ($nX - $x) * Cos($nAngle * $nPI / 180) + ($ny - $y) * Sin($nAngle * $nPI / 180)
    $nYt = -($nX - $x) * Sin($nAngle * $nPI / 180) + ($ny - $y) * Cos($nAngle * $nPI / 180)

    ; Parameters for GDIPlus_GraphicsDrawStringEx()
    $hBrush  = _GDIPlus_BrushCreateSolid   ($iARGB)
    $hFormat = _GDIPlus_StringFormatCreate ()
    $hFamily = _GDIPlus_FontFamilyCreate   ($nFontName)
    $hFont   = _GDIPlus_FontCreate         ($hFamily, $nFontSize, 1, 3)
    $tLayout = _GDIPlus_RectFCreate        ($nXt, $nYt, $nWidth, $nHeight)
    _GDIPlus_GraphicsDrawStringEx          ($hGraphic, $nText, $hFont, $tLayout, $hFormat, $hBrush)

    ; Parameters for _WinAPI_UpdateLayeredWindow
    $tSize   = DllStructCreate  ($tagSIZE)
    $pSize   = DllStructGetPtr  ($tSize)
    DllStructSetData            ($tSize, "X", $GuiWidth)
    DllStructSetData            ($tSize, "Y", $GuiHeight)
    $tSource = DllStructCreate  ($tagPOINT)
    $pSource = DllStructGetPtr  ($tSource)
    $tBlend  = DllStructCreate  ($tagBLENDFUNCTION)
    $pBlend  = DllStructGetPtr  ($tBlend)
    DllStructSetData            ($tBlend, "Alpha", $iOpacity)
    DllStructSetData            ($tBlend, "Format", 1)
    _WinAPI_UpdateLayeredWindow ($hGui, $hWnd, 0, $pSize, $hDC, $pSource, 0, $pBlend, $ULW_ALPHA)

    ; Clean up resources
    _GDIPlus_MatrixDispose       ($hMatrix)
    _GDIPlus_FontDispose         ($hFont)
    _GDIPlus_FontFamilyDispose   ($hFamily)
    _GDIPlus_StringFormatDispose ($hFormat)
    _GDIPlus_BrushDispose        ($hBrush)
    _GDIPlus_GraphicsDispose     ($hGraphic)
    _WinAPI_ReleaseDC            (0, $hWnd)
    _WinAPI_DeleteObject         ($hBitmap)
    _WinAPI_DeleteDC             ($hDC)
    _GDIPlus_Shutdown            ()
    return 1
EndFunc   ;==>CreateFloatTextAngle


; =================================================================
; Drag Window 3 of 3 addin
; =================================================================
Func _WinMove($hWnd, $Command, $wParam, $lParam)
    If BitAND(WinGetState($hWnd), 32) Then Return $GUI_RUNDEFMSG
    ;DllCall("user32.dll", "long", "SendMessage", "hwnd", $HWnd, "int", $WM_SYSCOMMAND, "int", 0xF009, "int", 0)
    DllCall("user32.dll", "int", "SendMessage", "hWnd", $hWnd, "int", $WM_NCLBUTTONDOWN, "int", $HTCAPTION, "int", 0)
EndFunc   ;==>_WinMove

If you delete all the stuff that supports the function, and just use the CreateFloatAngleText() function, this is probably what you want.

Edit: Using this script, the space bar rotates the text.

Edited by Malkey

Share this post


Link to post
Share on other sites

hi!

@ Malkey: nice script!! but what do i need, if i simply want to display a label "embedded in desktop"? (without rotating and random colors)

Share this post


Link to post
Share on other sites

hi!

@ Malkey: nice script!! but what do i need, if i simply want to display a label "embedded in desktop"? (without rotating and random colors)

Here is GDIPlus desktop text Function with less extras.

#include <GDIPlus.au3>
#include <GuiConstantsEx.au3>
#include <WindowsConstants.au3>

HotKeySet("{ESC}", "Quit")

Func Quit()
    Exit
EndFunc   ;==>Quit

CreateFloatText("All you need is _ _ _ _ _ _ _ _.")
;or
CreateFloatText("Where to go to from here.", 100, 10, "Arial" , 25, 0xFFFF00ff)

While 1
    Sleep(20)
WEnd

Func CreateFloatText($nText, $Left = -1, $Top = -1, $nFontName = "Arial", _
        $nFontSize = 12, $iARGB = 0xFFFF0000)

    Local $hWnd, $hDC, $hBitmap, $pSize, $tSize, $pSource, $tSource, $pBlend, $tBlend
    Local $iOpacity  = 255
    Local $ULW_ALPHA = 2
    Local $hGui, $hGraphic, $GuiWidth = 500, $GuiHeight = 100
    Local $hBrush, $hFormat, $hFamily, $hFont, $tLayout

    $txtlen    = StringLen($nText)
     $GuiWidth = Int($nFontSize * $txtlen * 37/ 40)       ;Tweak here to de/increase text box width size
    $GuiHeight = Int(($nFontSize * 37 / 30) * (17 / 9)) ;Tweak here to de/increase text box height size


    $hGui = GUICreate("Text", $GuiWidth, $GuiHeight, $Left, $Top, -1, BitOR($WS_EX_LAYERED, $WS_EX_TOPMOST))
    GUISetState()

    _GDIPlus_Startup ()
    $hWnd    = _WinAPI_GetDC (0)
    $hDC     = _WinAPI_CreateCompatibleDC ($hWnd)
    $hBitmap = _WinAPI_CreateCompatibleBitmap ($hWnd, $GuiWidth, $GuiHeight)
    _WinAPI_SelectObject ($hDC, $hBitmap)
    $hGraphic = _GDIPlus_GraphicsCreateFromHDC ($hDC)

    ; Parameters for GDIPlus_GraphicsDrawStringEx()
    $hBrush     = _GDIPlus_BrushCreateSolid ($iARGB)
    $hFormat    = _GDIPlus_StringFormatCreate ()
    $hFamily    = _GDIPlus_FontFamilyCreate ($nFontName)
    $hFont      = _GDIPlus_FontCreate ($hFamily, $nFontSize, 1, 3)
    $tLayout    = _GDIPlus_RectFCreate ($Left, $Top, $GuiWidth, $GuiHeight)
    $aInfo      = _GDIPlus_GraphicsMeasureString ($hGraphic, $nText, $hFont, $tLayout, $hFormat)
    $rectWidth  = DllStructGetData($aInfo[0], "Width")
    $rectHeight = DllStructGetData($aInfo[0], "Height")
    _GDIPlus_GraphicsDrawStringEx ($hGraphic, $nText, $hFont, $tLayout, $hFormat, $hBrush)

    ; Parameters for _WinAPI_UpdateLayeredWindow
    $tSize = DllStructCreate($tagSIZE)
    $pSize = DllStructGetPtr($tSize)
    DllStructSetData($tSize, "X", $GuiWidth)
    DllStructSetData($tSize, "Y", $GuiHeight)
    $tSource = DllStructCreate($tagPOINT)
    $pSource = DllStructGetPtr($tSource)
    $tBlend  = DllStructCreate($tagBLENDFUNCTION)
    $pBlend  = DllStructGetPtr($tBlend)
    DllStructSetData($tBlend, "Alpha", $iOpacity)
    DllStructSetData($tBlend, "Format", 1)
    _WinAPI_UpdateLayeredWindow ($hGui, $hWnd, 0, $pSize, $hDC, $pSource, 0, $pBlend, $ULW_ALPHA)

    ; Clean up resources
    _GDIPlus_FontDispose ($hFont)
    _GDIPlus_FontFamilyDispose ($hFamily)
    _GDIPlus_StringFormatDispose ($hFormat)
    _GDIPlus_BrushDispose ($hBrush)
    _GDIPlus_GraphicsDispose ($hGraphic)
    _WinAPI_ReleaseDC (0, $hWnd)
    _WinAPI_DeleteObject ($hBitmap)
    _WinAPI_DeleteDC ($hDC)
    _GDIPlus_Shutdown ()
    Return 1
EndFunc   ;==>CreateFloatText

Hope this helps.

Share this post


Link to post
Share on other sites

Create an account or sign in to comment

You need to be a member in order to leave a comment

Create an account

Sign up for a new account in our community. It's easy!


Register a new account

Sign in

Already have an account? Sign in here.


Sign In Now
Sign in to follow this
Followers 0
