Mallikarjun

Hi.

I am new to Autoit i have a problem in comparing the two screenshos

one original and another is taken sceenshot of emulator ...i have attached the screen shots to compare and find the differance in image........

Please help me to make it automate the image comparison...........

thanks

Share this post


Link to post
Share on other sites
Melba23

Mallikarjun,

Wrong part of the forum, no attachments to be seen, and asking for someone to write code for you. Pretty poor post! :graduated:

M23


Any of my own code posted anywhere on the forum is available for use by others without any restriction of any kind._______My UDFs:

Spoiler

ArrayMultiColSort ---- Sort arrays on multiple columns
ChooseFileFolder ---- Single and multiple selections from specified path treeview listing
Date_Time_Convert -- Easily convert date/time formats, including the language used
ExtMsgBox --------- A highly customisable replacement for MsgBox
GUIExtender -------- Extend and retract multiple sections within a GUI
GUIFrame ---------- Subdivide GUIs into many adjustable frames
GUIListViewEx ------- Insert, delete, move, drag, sort, edit and colour ListView items
GUITreeViewEx ------ Check/clear parent and child checkboxes in a TreeView
Marquee ----------- Scrolling tickertape GUIs
NoFocusLines ------- Remove the dotted focus lines from buttons, sliders, radios and checkboxes
Notify ------------- Small notifications on the edge of the display
Scrollbars ----------Automatically sized scrollbars with a single command
StringSize ---------- Automatically size controls to fit text
Toast -------------- Small GUIs which pop out of the notification area



Share this post


Link to post
Share on other sites
Mallikarjun

Thanks for reply, actuly i am using the code

$image1 = FileRead("C:\image\scree2.bmp")

$image2 = FileRead("C:\image\scree3.bmp")

If $image1==$image2 Then

MsgBox(0,"test","files match ")

Else

MsgBox(0,"test","files do not match")

EndIf

but i want to ignore the some portion in the image while comparing...

is it possible?

Share this post


Link to post
Share on other sites
monoscout999

Comparing the image file like a text is not correct, if the pic have a comment on the headder or something this will be different. if you want to compare the pixels of each you should use LockBits or something similar.

Edited by monoscout999

Share this post


Link to post
Share on other sites
Mallikarjun

thanks for replying ... but i am looking for fing the perticular area in the image like buttons and buttons tex is displating or not ....

is fixel find with color is helpull for me?


Share this post


Link to post
Share on other sites
Mallikarjun

Now i using $image1 = FileRead("C:\image\scree2.bmp")

$image2 = FileRead("C:\image\scree3.bmp")

If $image1==$image2 method to compare the images ... is it posible to compare the dowm portion and top portion of the image .....

2)And i have one more quetion i have used ....Func FileListToArray($Dir , $Dir2)

Dim $FilePath,$FilesList,$Files,$i

Dim $FilePath2,$FilesList2,$Files2,$j

$FilesList=_FileListToArray($Dir)

$FilesList2=_FileListToArray($Dir2)

If (Not IsArray($FilesList)) and (@Error=1) Then

MsgBox (0,"","No Files\Folders Found.")

Return

EndIf

$Files=_FileListToArray($Dir,"*",1)

$Files2=_FileListToArray($Dir2,"*",1)

If IsArray($Files ) Then

For $i=1 To $Files[0]

for $j=1 To $Files2[0]

$FilePath=$Dir&"\"&$Files[$i]

$FilePath2=$Dir&"\"&$Files2[$j]

If $FilePath==$FilePath2 Then

EndIf

Next

Next

EndIf

EndFunc

to get the image files from the directory ... But its no working properly,, Please check it what is the wrong?....Help is appreciated.

Share this post


Link to post
Share on other sites
numdig

If you want to check binary content, you'll be better off using something like that:

Func CompareFilesBinaryContent($file1, $file2)

$resTxt = ""

$handle = FileOpen(FileGetShortNameV2($file1), 16)
$content1 = FileRead($handle)
FileClose($handle)

$handle = FileOpen(FileGetShortNameV2($file2), 16)
$content2 = FileRead($handle)
FileClose($handle)

$str_diff = StringCompareExV1($content1, $content2)

If $str_diff Then
$resTxt = "Files have different binary content."
$resTxt &= @CRLF & "File1='" & $file1 & "'"
$resTxt &= @CRLF & "File2='" & $file2 & "'"
EndIf
Return $resTxt

EndFunc   ;==>CompareFilesBinaryContent

As for isolating part of image that are similar from the ones that are different, this is difficult problem. A lot of people are working on it ( inclusing in people in Universities - pattern recognition, image similarities, etc. ), but I haven't stumbled on an easy to use/implement solution yet. Academia is on it. Developers are on it ( eg. http://www.codeproject.com/KB/GDI-plus/comparingimages.aspx ). Let us know if you have more luck.

On a more personal note, I started writing a C# application a couple years ago that would group pixels and and search for similarities but interrupted this project because I found an easier way to achieve what I needed: 1/ I compare bare binary content and then 2/ I swap the 2 images every second at the same place and I visually check for differences (works great even for very tiny differences).

Take care.

-- Edited Tuesday, 4 October 2011, 6:23 PM

Note here is another similar work: if you can search for a pixel on the screen, then you can search for a given pixel in another image. The problems are somehow related.

Edited by Chess

Share this post


Link to post
Share on other sites
Mallikarjun

Thanks for all reply.. I have another problem is to run the multiple application scripts one by one ..The application list is in treeview list .....Is there any solution to run the scripts one by one ...reply is appreciated..

Share this post


Link to post
Share on other sites
Mallikarjun

Thanks for reply.. Ihave maked the scripts for application to execute...my problem is to find the application name in the list

and execute the perticular application one by one ..Plz reffer the attached file...

post-67312-0-95829200-1318705529_thumb.p

Share this post


Link to post
Share on other sites
Morthawt

If you need to check if an image is the same, why not render the image on a GUI and use PixelChecksum to calculate a checksum of a pre-defined area? If the images are the same size and the part on the image to check is in the same place, then doing this method will give you a clear yes or no to if its different. Even if the location is different you may be able to intuit the location to search using PixelSearch and PixelGetColor to define the coordinates of an area that could be quantified each time yet may be in a different location on the screen perhaps.

Share this post


Link to post
Share on other sites
Mallikarjun

Thanks for reply .... Please find the attached image for class and control information..

post-67312-0-18844300-1318746682_thumb.p

Share this post


Link to post
Share on other sites
Mallikarjun

I am finding the apllication in the list by copying the text and comparing that text to the given application name

;copying the application name

$data= ClipGet()

Local $file=FileOpen($Appname, 1)

FileWrite($file,$data)

_FileReadToArray($file, $fdata)

$CountLines = _FileCountLines($file)

For $x = 1 to $CountLines Step 1

$sourcePath = $fdata[$x]

Next

If StringRegExp ($sourcePath, "AnimationApp", 0) == 1 Then

MsgBox(0, "yes", "i am")

EndIf

problem is to run the scripts one by one ...after finding the application....

Share this post


Link to post
Share on other sites
Mallikarjun

Thanks to all.. i am running all my application in one script..... :D

Share this post


Link to post
Share on other sites
Mallikarjun

Hi All,

I have some problem in this code

to compare the 2 directory images plz see bellow script....

Func ImgComp2()

Global $file1=_FileListToArray("C:Sdk_AutomationDatabaseWQVGA" & $mytext2 & "", "*.bmp", 1)

Global $file2=_FileListToArray("C:Sdk_AutomationOutputImagesWQVGA"& $mytext2 & "","*.bmp",1)

For $i=1 To UBound($file1)-1

$ram1=FileRead($file1[$i])

$ram2=FileRead($file2[$i])

;MsgBox(0, "", $file1[$i])

;MsgBox(0, "", $file2[$i])

If $ram1==$ram2 Then

Imglog2("ok")

;MsgBox(0, "", "ok")

Else

Imglog2("NG")

;MsgBox(0, "", "NG")

EndIf

Next

I am comparing 2 directory images one for updating the outputs but its not working properly plz check it once help should be apreciated...

Thanks in advance

Edited by Mallikarjun

Share this post


Link to post
Share on other sites
Mallikarjun

Its comparing the images when i comparing the single images.

$ram1=FileRead("C:arjun1.bmp")

$ram2=FileRead("C:arjun2.bmp")

If $ram1==$ram2 Then

MsgBox(0, "", "good luck")

Else

MsgBox(0, "", "no")

EndIf

but the problem occurs to compare the multiple images.

help should be appreciated

thanks

Edited by Mallikarjun
