Absolute coordinates for image movements?

4 posts in this topic

#1 ·  Posted (edited)

Greetings,

  I'm having a difficult time with this.  The attached working code creates 2 GUI windows, the 'second' is labeled as "Map Selector" and within that I have a 2048x2048 pixel image with a bunch of hexagons.  On this large image I am creating small ("plus sign") images inside each of the hexagons using an external ".txt" file that contains the x, y coordinates that each "plus sign" is to be placed at.  Following this I create a single square image that I call "unit1"...This all works correctly.

  My problem is that I want to 'click' the "plus-sign" images and then have the "unit" image move to that 'clicked' location...that works fine IF the window is NOT SCROLLED...however when I do move the GUI window using the scrollbars the image placement no longer works correctly...I am at a loss to explain why.  I simply want to be able to move the "unit1" image (either by clicking a location or by other code-controlled means) to an absolute screen position...even if that position is not within view as it lies in an area of the main image beyond the viewable area of the window...for example move "unit1" from x = 10, y = 30 to x = 977, y = 1589...

  There must be a way to move images in absolute terms to any area on the 2048x2048 image...??

  Thanks in advance for any help on what I am missing here.

  NOTE:  when the code begins running you will need to wait maybe 10 seconds until the images are all drawn...there will be a progressbar to indicate when the "Map Selector" is completely drawn...Thanks again.



#include <EditConstants.au3>
#include <WindowsConstants.au3>
#include <GUIConstantsEx.au3>
#include <StaticConstants.au3>
#include <GuiComboBoxEx.au3>
#include <GUIConstantsEx.au3>
#include <File.au3>
#include <GDIPlus.au3>
#include <GUIScrollBars_Size.au3>
#include <Misc.au3>

 Opt("PixelCoordMode", 0)

 Global $aSB_Size_MapBack, $aSB_Size_MiniBack

 Global $BEACON_X = 0
 Global $BEACON_Y = 1
 Global $BEACON[2586]
 Global $BEACON_TRAITS[2586][18]  ;hold the 'traits' for each BEACON on the map...
 Global $MapFile = "C:\My Documents\HEXES-2048.bmp"  ;get the file for the map...


 Global $MainGUI = GUICreate("SAMPLE", 425, 540, 450, 250)
 GUISetState(@SW_SHOW)

 GUIRegisterMsg($WM_HSCROLL, "WM_HSCROLL")
 GUIRegisterMsg($WM_VSCROLL, "WM_VSCROLL")

 $font = "Arial"

 $_Reference = FileOpen("C:\My Documents\BEACONS_55-47.txt", 0)  ;open for READING...
  if $_Reference == -1 Then MsgBox(64, "Error: File Open", "Unable to open 'BEACONS'...")

 $PROGRESS_TXT = GUICtrlCreateLabel("Processing Map Data...", 10, 286, 175, 20, BitOr($GUI_SS_DEFAULT_LABEL, $SS_LEFT), -1)
 GUICtrlSetState($PROGRESS_TXT, $GUI_SHOW)
 GUICtrlSetBkColor($PROGRESS_TXT, $GUI_BKCOLOR_TRANSPARENT)
 GUICtrlSetFont($PROGRESS_TXT, 8.5, 400, 4, $font)

 $progressbar1 = GUICtrlCreateProgress(10, 300, 195, 20)
 GUICtrlSetState($progressbar1, $GUI_SHOW)
 GUICtrlSetState($PROGRESS_TXT, $GUI_SHOW)
 $s = 0  ;ProgressBar-saveposition

 Map_Window()

 if $s >= 100 Then
 GUICtrlSetState($progressbar1, $GUI_HIDE)  ;hide 'ProgressBar' when 'completed'...
 $s = 0  ;reset ProgressBar-saveposition
 GUICtrlSetData($PROGRESS_TXT, "Thank you for waiting...")
 EndIf  ;$s >= 100...'ProgressBar' has been 'completed'


 GUISetState(@SW_ENABLE, $MapBack)
 $_UNIT1 = GUICtrlCreatePic("C:\My Documents\unit1.gif", 10, 10, 0, 0, $SS_NOTIFY)
 GuiCtrlSetState($_UNIT1, $GUI_DISABLE)

 WinActivate("SAMPLE")


While 1

    $nMsg = GUIGetMsg(1)  ;use advanced mode when using multiple GUIs
    Switch $nMsg[1]  ;Switch on the GUI sending the message

        Case $MapBack
            Switch $nMsg[0]

                Case $BEACON[0] To $BEACON[2585]

                 For $i = 1 To UBound($BEACON) - 1
                  if $nMsg[0] = $BEACON[$i] Then

                  $MARK_X_PLOT = $BEACON_TRAITS[$i][$BEACON_X]  ;store the 'clicked' X position...
                  $MARK_Y_PLOT = $BEACON_TRAITS[$i][$BEACON_Y]  ;store the 'clicked' Y position...
                  GUISwitch($MapBack)
                  GuiCtrlSetState($_UNIT1, $GUI_ENABLE)

                  Local $size = WinGetPos("Map Selector")
                  ; Create a point structure
                  Local $tPoint = DllStructCreate("int X;int Y")
                  ; Insert the coords
                  DllStructSetData($tPoint, "X", $MARK_X_PLOT)
                  DllStructSetData($tPoint, "Y", $MARK_Y_PLOT)
                  ; Convert the coords
                  _WinAPI_ScreenToClient($MapBack, $tPoint)
                 GUICtrlSetPos($_UNIT1, DllStructGetData($tPoint, "X") + $size[0], DllStructGetData($tPoint, "Y") + $size[1])

                  ExitLoop
                  EndIf
                 Next

                 GUISwitch($MainGUI)  ;set the focus back to the Main Interface...

            EndSwitch

        Case $MainGUI
            Switch $nMsg[0] ; switch on the control from the GUI sending the message.
                Case $GUI_EVENT_CLOSE
                  Exit

            EndSwitch

    EndSwitch

Wend


Func Map_Window()

    ; get parameters for this GUI
    $aSB_Size_MapBack = _GUIScrollbars_Size(2048, 2048, 768, 576)

    Global $MapBack = GUICreate("Map Selector", 768, 576, 485, 250, BitOR($WS_MINIMIZE, $WS_DISABLED, $WS_CAPTION, $WS_EX_LAYERED), -1)

    ; background picture
    Global $TheMap = GUICtrlCreatePic($MapFile, 9, 0, 2048, 2048, -1, -1)
    GUICtrlSetState($TheMap, $GUI_DISABLE) ; you have to disable the graphic or it overlaps all controls on it


    _GUIScrollBars_Init($MapBack)
    _GUIScrollBars_SetScrollInfoMax($MapBack, $SB_HORZ, $aSB_Size_MapBack[1])
    _GUIScrollBars_SetScrollInfoPage($MapBack, $SB_HORZ, $aSB_Size_MapBack[0])
    _GUIScrollBars_SetScrollInfoMax($MapBack, $SB_VERT, $aSB_Size_MapBack[3])
    _GUIScrollBars_SetScrollInfoPage($MapBack, $SB_VERT, $aSB_Size_MapBack[2])

    GUISetState(@SW_SHOW)


   For $x = 1 To UBound($BEACON) - 1

   $LOOK = FileReadLine($_Reference, $x)  ;read the line # in the 'BEACONS' file for the associated HEX...
   $result = StringInStr($LOOK, ",", 0, 1)  ; find the "1st" instance of a "," in the read line...(follows '$BEACON_X' file info, precedes '$BEACON_Y')
   $result2 = StringInStr($LOOK, ",", 0, 2)  ; find the "2nd" instance of a "," in the read line...(follows '$BEACON_Y' file info)

   $MARK_X_PLOT = Number(StringLeft($LOOK, $result - 1))
   $MARK_Y_PLOT = Number(StringMid($LOOK, $result + 1, ($result2 - $result) - 1))

   $BEACON[$x] = GUICtrlCreatePic("C:\My documents\Cross.gif", $MARK_X_PLOT, $MARK_Y_PLOT, 11, 11, $SS_NOTIFY)
   GUICtrlSetState($BEACON[$x], $GUI_ENABLE)
   GUICtrlSetState($BEACON[$x], $GUI_SHOW)

   ;**set the NEEDED "BEACON_TRAITS" INTO ARRAY POSITIONS...
   $BEACON_TRAITS[$x][$BEACON_X] = $MARK_X_PLOT
   $BEACON_TRAITS[$x][$BEACON_Y] = $MARK_Y_PLOT

   GUICtrlSetData($progressbar1, $s)  ;update the 'ProgressBar'...
   $s += .039  ;2583 * .039 = 100 (about)...

   Next

 $s += 1  ;set to indicate 'completion' of 'ProgressBar'...

EndFunc   ;==>Map_Window


;/////////////////

Func WM_HSCROLL($hWnd, $Msg, $wParam, $lParam)

    #forceref $Msg, $lParam
    Local $nScrollCode = BitAND($wParam, 0x0000FFFF)
    Local $iIndex = -1, $xChar, $xPos
    Local $Page, $Pos, $TrackPos
    For $x = 0 To UBound($aSB_WindowInfo) - 1
        If $aSB_WindowInfo[$x][0] = $hWnd Then
            $iIndex = $x
            $xChar = $aSB_WindowInfo[$iIndex][2]
            ExitLoop
        EndIf
    Next
    If $iIndex = -1 Then Return 0
    Local $tSCROLLINFO = _GUIScrollBars_GetScrollInfoEx($hWnd, $SB_HORZ)
    $Page = DllStructGetData($tSCROLLINFO, "nPage")
    $xPos = DllStructGetData($tSCROLLINFO, "nPos")
    $Pos = $xPos
    $TrackPos = DllStructGetData($tSCROLLINFO, "nTrackPos")
    Switch $nScrollCode
        Case $SB_LINELEFT
            DllStructSetData($tSCROLLINFO, "nPos", $Pos - 1)
        Case $SB_LINERIGHT
            DllStructSetData($tSCROLLINFO, "nPos", $Pos + 1)
        Case $SB_PAGELEFT
            DllStructSetData($tSCROLLINFO, "nPos", $Pos - $Page)
        Case $SB_PAGERIGHT
            DllStructSetData($tSCROLLINFO, "nPos", $Pos + $Page)
        Case $SB_THUMBTRACK
            DllStructSetData($tSCROLLINFO, "nPos", $TrackPos)
    EndSwitch
    DllStructSetData($tSCROLLINFO, "fMask", $SIF_POS)
    _GUIScrollBars_SetScrollInfo($hWnd, $SB_HORZ, $tSCROLLINFO)
    _GUIScrollBars_GetScrollInfo($hWnd, $SB_HORZ, $tSCROLLINFO)

    ; Move the scrollbar
    $Pos = DllStructGetData($tSCROLLINFO, "nPos")
    If ($Pos <> $xPos) Then _GUIScrollBars_ScrollWindow($hWnd, $xChar * ($xPos - $Pos), 0)

    ; Now move other scrollbar
    Switch $hWnd
        Case $MapBack
            ; get fractional position of scrollbar in moved GUI
            $nPos_HORZ = _GUIScrollBars_GetScrollInfoPos($MapBack, $SB_HORZ)
            $nFraction_HORZ = $nPos_HORZ / ($aSB_Size_MapBack[1] - $aSB_Size_MapBack[0])
            ; And set other scrollbar to same fraction
            ;_GUIScrollBars_SetScrollInfoPos($MiniBack, $SB_HORZ, ($aSB_Size_MiniBack[1] - $aSB_Size_MiniBack[0]) * $nFraction_HORZ)
    EndSwitch

    Return $GUI_RUNDEFMSG

EndFunc   ;==>WM_HSCROLL

Func WM_VSCROLL($hWnd, $Msg, $wParam, $lParam)

    #forceref $Msg, $lParam
    Local $nScrollCode = BitAND($wParam, 0x0000FFFF)
    Local $iIndex = -1, $yChar, $yPos
    Local $Page, $Pos, $TrackPos
    For $x = 0 To UBound($aSB_WindowInfo) - 1
        If $aSB_WindowInfo[$x][0] = $hWnd Then
            $iIndex = $x
            $yChar = $aSB_WindowInfo[$iIndex][3]
            ExitLoop
        EndIf
    Next
    If $iIndex = -1 Then Return 0
    Local $tSCROLLINFO = _GUIScrollBars_GetScrollInfoEx($hWnd, $SB_VERT)
    $Page = DllStructGetData($tSCROLLINFO, "nPage")
    $yPos = DllStructGetData($tSCROLLINFO, "nPos")
    $Pos = $yPos
    $TrackPos = DllStructGetData($tSCROLLINFO, "nTrackPos")
    Switch $nScrollCode
        Case $SB_LINEUP
            DllStructSetData($tSCROLLINFO, "nPos", $Pos - 1)
        Case $SB_LINEDOWN
            DllStructSetData($tSCROLLINFO, "nPos", $Pos + 1)
        Case $SB_PAGEUP
            DllStructSetData($tSCROLLINFO, "nPos", $Pos - $Page)
        Case $SB_PAGEDOWN
            DllStructSetData($tSCROLLINFO, "nPos", $Pos + $Page)
        Case $SB_THUMBTRACK
            DllStructSetData($tSCROLLINFO, "nPos", $TrackPos)
    EndSwitch
    DllStructSetData($tSCROLLINFO, "fMask", $SIF_POS)
    _GUIScrollBars_SetScrollInfo($hWnd, $SB_VERT, $tSCROLLINFO)
    _GUIScrollBars_GetScrollInfo($hWnd, $SB_VERT, $tSCROLLINFO)

    ; Move the scrollbar
    $Pos = DllStructGetData($tSCROLLINFO, "nPos")
    If ($Pos <> $yPos) Then _GUIScrollBars_ScrollWindow($hWnd, 0, $yChar * ($yPos - $Pos))
    ; Now move other scrollbar
    Switch $hWnd
        Case $MapBack
            ; get fractional position of scrollbar in moved GUI
            $nPos_VERT = _GUIScrollBars_GetScrollInfoPos($MapBack, $SB_VERT)
            $nFraction_VERT = $nPos_VERT / ($aSB_Size_MapBack[1] - $aSB_Size_MapBack[0])
            ; And set other scrollbar to same fraction
            ;_GUIScrollBars_SetScrollInfoPos($MiniBack, $SB_VERT, ($aSB_Size_MiniBack[1] - $aSB_Size_MiniBack[0]) * $nFraction_VERT)
    EndSwitch
    Return $GUI_RUNDEFMSG

EndFunc   ;==>WM_VSCROLL

post-35979-0-38786700-1368971523_thumb.g

BEACONS_55-47.txt

post-35979-0-08385500-1368972033_thumb.j

Edited by Burgs

Share this post


Link to post
Share on other sites



#2 ·  Posted (edited)

Change to this the main loop

While 1

    $nMsg = GUIGetMsg(1) ;use advanced mode when using multiple GUIs
    Switch $nMsg[1] ;Switch on the GUI sending the message

        Case $MapBack
            Switch $nMsg[0]

                Case $BEACON[0] To $BEACON[2585]

                    For $i = 1 To UBound($BEACON) - 1
                        If $nMsg[0] = $BEACON[$i] Then

                            $MARK_X_PLOT = $BEACON_TRAITS[$i][$BEACON_X] ;store the 'clicked' X position...
                            $MARK_Y_PLOT = $BEACON_TRAITS[$i][$BEACON_Y] ;store the 'clicked' Y position...
                            GUISwitch($MapBack)
                            GUICtrlSetState($_UNIT1, $GUI_ENABLE)

                            Local $aPos = ControlGetPos($MapBack, "", $nMsg[0])
                            GUICtrlSetPos($_UNIT1, $aPos[0], $aPos[1])

                            ExitLoop
                        EndIf
                    Next

                    GUISwitch($MainGUI) ;set the focus back to the Main Interface...

            EndSwitch

        Case $MainGUI
            Switch $nMsg[0] ; switch on the control from the GUI sending the message.
                Case $GUI_EVENT_CLOSE
                    Exit

            EndSwitch

    EndSwitch

WEnd
Edited by PhoenixXL

My code:

PredictText: Predict Text of an Edit Control Like Scite. Remote Gmail: Execute your Scripts through Gmail. StringRegExp:Share and learn RegExp.

Run As System: A command line wrapper around PSEXEC.exe to execute your apps scripts as System (LSA). Database: An easier approach for _SQ_LITE beginners.

MathsEx: A UDF for Fractions and LCM, GCF/HCF. FloatingText: An UDF for make your text floating. Clipboard Extendor: A clipboard monitoring tool.

Custom ScrollBar: Scroll Bar made with GDI+, user can use bitmaps instead. RestrictEdit_SRE: Restrict text in an Edit Control through a Regular Expression.

Share this post


Link to post
Share on other sites

Oh sorry I forgot the other 'plus sign' image...

post-35979-0-92229400-1368979158_thumb.g

Share this post


Link to post
Share on other sites

Thank you for that post, PhoenixXL...that seems to have fixed the problem.  That is a great command to know, I didn't realize it returned a control's position relative to its window...that would be very handy to move controls around the 'grid' system I have setup.  Thanks again, I really appreciate that!
