Add image to GUI and tell me what kind of an animal.


Recommended Posts

My image has a lot of small pictures with different kinds of animals.

My idea is, when you press each pictures a messagebox should apear with the word of what kind of animal.

How do I add an image to a GUI and how do I control the mouse to tell me what kind of picture I pressed?

Yours sincerely

Kenneth.

Link to post
Share on other sites

Hmmm need more information, what have you tried? Is it one image file with different animals in it?

If it's one image you can use GUICtrlCreatePic and load your image, define the areas of each animal yourself (x, y, width, height of the animal, I'd suggest an array), and when the user clicks the picture, grab the x, y coordinates of the click. Go through the array and use _WinApi_PtinRectEx to test if the click was in the area for each animal. Alternatively you can just create labels where each animal are and set an OnEvent for each label (Or a case for each label, depending on if you use GUIOnEvent mode or not). Whenever the user clicks the picture they'll click the underlying label and activate what you want to do.

Link to post
Share on other sites

I'd use the images as if they were buttons, and do something like this.

#include <GUIConstantsEx.au3>
#include <MsgBoxConstants.au3>
#include <StaticConstants.au3>

Example()

Func Example()
    GUICreate("My Draw")
    Local $idTech = GUICtrlCreatePic("\AutoIt3\Examples\Helpfile\Extras\Tech.bmp", 10, 10, 100, 100) ; <<<<<<<<<<<<<  Change this to the path that your AutoIt installation is in.
    Local $idAutoIt = GUICtrlCreatePic("\AutoIt3\Examples\Helpfile\Extras\AutoIt.bmp", 120, 10, 100, 100) ; <<<<<<<<<<<<<  Change this to the path that your AutoIt installation is in.
    GUISetState(@SW_SHOW)

    Do
        $idMsg = GUIGetMsg()
        Switch $idMsg
            Case $idTech
                MsgBox($mb_systemmodal, "Clicked", "Tech clicked")
            Case $idAutoIt
                MsgBox($mb_systemmodal, "Clicked", "AutoIt clicked")
        EndSwitch
    Until $idMsg = $GUI_EVENT_CLOSE
EndFunc   ;==>Example



If I posted any code, assume that code was written using the latest release version unless stated otherwise. Also, if it doesn't work on XP I can't help with that because I don't have access to XP, and I'm not going to.
Give a programmer the correct code and he can do his work for a day. Teach a programmer to debug and he can do his work for a lifetime - by Chirag Gude
How to ask questions the smart way!

I hereby grant any person the right to use any code I post, that I am the original author of, on the autoitscript.com forums, unless I've specifically stated otherwise in the code or the thread post. If you do use my code all I ask, as a courtesy, is to make note of where you got it from.

Back up and restore Windows user files _Array.au3 - Modified array functions that include support for 2D arrays.  -  ColorChooser - An add-on for SciTE that pops up a color dialog so you can select and paste a color code into a script.  -  Customizable Splashscreen GUI w/Progress Bar - Create a custom "splash screen" GUI with a progress bar and custom label.  -  _FileGetProperty - Retrieve the properties of a file  -  SciTE Toolbar - A toolbar demo for use with the SciTE editor  -  GUIRegisterMsg demo - Demo script to show how to use the Windows messages to interact with controls and your GUI.  -   Latin Square password generator

Link to post
Share on other sites

I was bored.... This would be one way to do it, you probably don't have to get as detailed as I did to outline the animals with labels (take out the for $i = $lblPikachu loop to see where all the labels are).  This won't work on all computers, my desktop resolution is 1920x1080, some may have larger or smaller resolutions.

#include <WindowsConstants.au3>
#include <GUIConstantsEx.au3>

Global $hWndGui = GUICreate("Example", @DesktopWidth, @DesktopHeight, 0, 0, $WS_POPUP)
Global $picImage = GUICtrlCreatePic(@ScriptDir & "\Image.jpg", 0, 0, @DesktopWidth, @DesktopHeight)
Global $lblPikachu1 = GUICtrlCreateLabel("", 115, 700, 95, 50)
Global $lblPikachu2 = GUICtrlCreateLabel("", 180, 675, 50, 30)
Global $lblSquirtle1 = GUICtrlCreateLabel("", 315, 678, 70, 90)
Global $lblSquirtle2 = GUICtrlCreateLabel("", 385, 735, 28, 25)
GLobal $lblLugia1 = GUICtrlCreateLabel("", 1245, 205, 50, 50)
GLobal $lblLugia2 = GUICtrlCreateLabel("", 1295, 225, 30, 20)
GLobal $lblLugia3 = GUICtrlCreateLabel("", 1325, 210, 20, 20)
GLobal $lblLugia4 = GUICtrlCreateLabel("", 1285, 160, 40, 35)
GLobal $lblLugia5 = GUICtrlCreateLabel("", 1325, 185, 20, 20)
GLobal $lblLugia6 = GUICtrlCreateLabel("", 1345, 190, 70, 95)
GLobal $lblLugia7 = GUICtrlCreateLabel("", 1400, 135, 50, 70)
GLobal $lblLugia8 = GUICtrlCreateLabel("", 1410, 255, 50, 22)
Global $lblEevee1 = GUICtrlCreateLabel("", 605, 735, 165, 120)
Global $lblEevee2 = GUICtrlCreateLabel("", 750, 720, 35, 30)
Global $lblEevee3 = GUICtrlCreateLabel("", 775, 700, 30, 30)
Global $lblCharizard1 = GUICtrlCreateLabel("", 1290, 650, 100, 40)
Global $lblCharizard2 = GUICtrlCreateLabel("", 1315, 630, 50, 20)
Global $lblCharizard3 = GUICtrlCreateLabel("", 1340, 620, 25, 10)
Global $lblCharizard4 = GUICtrlCreateLabel("", 1380, 607, 50, 30)
Global $lblCharizard5 = GUICtrlCreateLabel("", 1410, 635, 20, 40)
Global $lblCharizard6 = GUICtrlCreateLabel("", 1430, 645, 5, 30)
Global $lblCharizard7 = GUICtrlCreateLabel("", 1355, 685, 100, 75)
Global $lblCharizard8 = GUICtrlCreateLabel("", 1390, 665, 150, 50)
Global $lblCharizard9 = GUICtrlCreateLabel("", 1475, 625, 50, 40)
Global $lblCharizard10 = GUICtrlCreateLabel("", 1320, 720, 60, 55)
Global $lblCharizard11 = GUICtrlCreateLabel("", 1455, 725, 25, 55)
Global $lblCharizard12 = GUICtrlCreateLabel("", 1480, 745, 20, 15)
Global $lblCharizard12 = GUICtrlCreateLabel("", 1500, 715, 25, 25)
Global $lblBulbasaur1 = GUICtrlCreateLabel("", 1700, 815, 150, 100)
Global $lblBulbasaur2 = GUICtrlCreateLabel("", 1760, 800, 75, 15)

For $i = $lblPikachu1 To $lblBulbasaur2
    GUICtrlSetBkColor($i, $GUI_BKCOLOR_TRANSPARENT)
Next

GUICtrlSetState($picImage, $GUI_DISABLE)

GUISetState(@SW_SHOW, $hWndGui)

While (True)
    Switch (GUIGetMsg())
        Case $GUI_EVENT_CLOSE
            ExitLoop
        Case $lblPikachu1 to $lblPikachu2
            MsgBox("", "", "You clicked Pikachu!")
        Case $lblSquirtle1 to $lblSquirtle2
            MsgBox("", "", "You clicked Squirtle!")
        Case $lblLugia1 to $lblLugia8
            MsgBox("", "", "You clicked Lugia!")
        Case $lblEevee1 to $lblEevee3
            MsgBox("", "", "You clicked Eevee!")
        Case $lblCharizard1 to $lblCharizard12
            MsgBox("", "", "You clicked Charizard!")
        Case $lblBulbasaur1 to $lblBulbasaur2
            MsgBox("", "", "You clicked Bulbasaur!")
    EndSwitch
WEnd

GUIDelete($hWndGui)




Link to post
Share on other sites
