ioa747 Posted 8 hours ago Posted 8 hours ago (edited) _StringToTable() – Convert Text to a Formatted Table The _StringToTable() function allows you to convert structured text (like tab-separated data) into a formatted, aligned table using Unicode box-drawing characters. Ideal for displaying readable output in console-based tools or logs. Local $sData = _ "Company" & @TAB & "Contact" & @TAB & "Revenue" & @CRLF & _ "Alfreds Futterkiste" & @TAB & "Maria Anders" & @TAB & "1200" & @CRLF & _ "Centro Moctezuma" & @TAB & "Francisco Chang" & @TAB & "950" & @CRLF & _ "Island Trading" & @TAB & "Helen Bennett" & @TAB & "15800" ConsoleWrite(_StringToTable($sData, 3, @TAB, "L,C,R") & @CRLF) ┌──────────────────────┬───────────────────┬──────────┐ │ Company │ Contact │ Revenue │ ├──────────────────────┼───────────────────┼──────────┤ │ Alfreds Futterkiste │ Maria Anders │ 1200 │ │ Centro Moctezuma │ Francisco Chang │ 950 │ │ Island Trading │ Helen Bennett │ 15800 │ └──────────────────────┴───────────────────┴──────────┘ Made with ❤️ for readable and elegant output. expandcollapse popup; https://www.autoitscript.com/forum/topic/212876-_stringtotable/ ;---------------------------------------------------------------------------------------- ; Title...........: _StringToTable.au3 ; Description.....: Converts a string to a formatted table with alignment and frame options. ; AutoIt Version..: 3.3.16.1 Author: ioa747 Script Version: 0.2 ; Note............: Testet in Win10 22H2 ;---------------------------------------------------------------------------------------- ;~ #AutoIt3Wrapper_Au3Check_Parameters=-d -w 1 -w 2 -w 3 -w 4 -w 5 -w 6 -w 7 #include <String.au3> Example() ;--------------------------------------------------------------------------------------- Func Example() Local $sTxt, $sOut Local $sData = _ "Company" & @TAB & "Contact" & @TAB & "Revenue" & @CRLF & _ "Alfreds Futterkiste" & @TAB & "Maria Anders" & @TAB & "1200" & @CRLF & _ "Centro Moctezuma" & @TAB & "Francisco Chang" & @TAB & "950" & @CRLF & _ "Island Trading" & @TAB & "Helen Bennett" & @TAB & "15800" $sOut = _StringToTable($sData, 3, @TAB, "L,C,R") ConsoleWrite($sOut & @CRLF & @CRLF) $sTxt &= $sOut & @CRLF & @CRLF $sOut = _StringToTable($sData, 0, @TAB, "L,C,R") ConsoleWrite($sOut & @CRLF & @CRLF) $sTxt &= $sOut & @CRLF & @CRLF $sOut = " https://www.autoitscript.com/forum/topic/212833-json-udf-using-json-c/#findComment-1542670" ConsoleWrite($sOut & @CRLF) $sTxt &= $sOut & @CRLF $sData = "" ; from https://www.autoitscript.com/forum/topic/212833-json-udf-using-json-c/#findComment-1542670 $sData &= " name | time[ms] | factor | Std. Dev | Std. Err. | min | max | range |" & @CRLF $sData &= " StringRegExp only | 1.691 | 1 | 0.351 | 0.035 | 1.304 | 3.167 | 1.863 |" & @CRLF $sData &= " jq UDF | 32.933 | 19.48 | 2.929 | 0.293 | 29.308 | 43.169 | 13.861 |" & @CRLF $sData &= " JsonC-UDF | 51.086 | 30.21 | 3.205 | 0.321 | 45.625 | 63.46 | 17.835 |" & @CRLF $sData &= " pure AutoIt JSON-UDF | 97.916 | 57.9 | 5.685 | 0.569 | 86.362 | 113.467 | 27.105 |" & @CRLF $sData &= " JSMN-based JSON-UDF | 108.248 | 64.01 | 5.512 | 0.551 | 99.029 | 130.864 | 31.835 |" & @CRLF $sOut = _StringToTable($sData, 3, "|", "L,R,R,R,R,R,R,R") ConsoleWrite($sOut & @CRLF & @CRLF) $sTxt &= $sOut & @CRLF & @CRLF ClipPut($sTxt) Run("notepad.exe") WinWaitActive("[CLASS:Notepad]", "", 5) Sleep(100) Send("^v") EndFunc ;==>Example ; #FUNCTION# -------------------------------------------------------------------------------------------------------------------- ; Name...........: _StringToTable ; Description....: Converts a string to a formatted table with alignment and frame options. ; Syntax.........: _StringToTable( $sString [, $iFrame = 3 [, $sSeparator = @TAB [, $sAlign = ""]]] ) ; Parameters.....: $sString - The input string containing data values. ; $iFrame - [optional] Frame type (0=NoFrame, 1=FrameNoHeader, 2=HeaderNoFrame, 3=FrameAndHeader) (Default is 3) ; $sSeparator - [optional] Separator used in the input string. (Default is @TAB) ; $sAlign - [optional] Alignment options for each column (e.g., "L,R,C"). (Default is "" (left-aligned)) ; Return values..: The formatted table as a string. ; Author ........: ioa747 ; Notes .........: This function processes an input string, splits it into rows and columns, ; and formats them into a visually table with optional frames and alignment. ; Link ..........: https://www.autoitscript.com/forum/topic/212876-_stringtotable/ ; Dependencies...: __FormatCell() ;-------------------------------------------------------------------------------------------------------------------------------- Func _StringToTable($sString, $iFrame = 3, $sSeparator = @TAB, $sAlign = "") If $iFrame < 0 Or $iFrame > 3 Then $iFrame = 3 If $sSeparator = Default Or $sSeparator = -1 Then $sSeparator = @TAB ;Prepare string $sString = StringRegExpReplace($sString, "(\r\n|\n)", @CRLF) $sString = StringReplace($sString, $sSeparator & @CRLF, @CRLF) $sString = StringReplace($sString, @CRLF & $sSeparator, @CRLF) $sString = StringStripCR(StringRegExpReplace($sString, "(\r\n)$", "")) ;ConsoleWrite($sString & @CRLF) Local $aRows = StringSplit($sString, @LF, 1) If $aRows[0] = 0 Then Return SetError(1, 0, "") Local $aTable[UBound($aRows)][0] Local $iCols = 0 For $i = 1 To $aRows[0] Local $aCols = StringSplit($aRows[$i], $sSeparator, 1) If $i = 1 Then $iCols = $aCols[0] ReDim $aTable[$aRows[0]][$iCols] Else If $aCols[0] < $iCols Then ReDim $aCols[$iCols + 1] For $k = $aCols[0] + 1 To $iCols $aCols[$k] = "" Next EndIf EndIf For $j = 0 To $iCols - 1 $aTable[$i - 1][$j] = StringStripWS($aCols[$j + 1], 3) Next Next Local $aColWidths[$iCols] For $j = 0 To $iCols - 1 $aColWidths[$j] = 0 For $i = 0 To UBound($aTable) - 1 $aColWidths[$j] = $aColWidths[$j] > StringLen($aTable[$i][$j]) ? $aColWidths[$j] : StringLen($aTable[$i][$j]) Next Next ; Alignment Local $aAlign[$iCols] If $sAlign <> "" Then Local $aRawAlign = StringSplit($sAlign, ",", 2) For $j = 0 To $iCols - 1 Local $iIndex = $j If $iIndex >= UBound($aRawAlign) Then $iIndex = UBound($aRawAlign) - 1 $aAlign[$j] = StringStripWS(StringUpper($aRawAlign[$iIndex]), 3) If Not StringRegExp($aAlign[$j], "^[LRC]$") Then $aAlign[$j] = "L" Next Else For $j = 0 To $iCols - 1 $aAlign[$j] = "L" Next EndIf ; label Meaning ; $TL ┌ Top Left ; $TR ┐ Top Right ; $BL └ Bottom Left ; $BR ┘ Bottom Right ; $H ─ Horizontal ; $V │ Vertical ; $TH ┬ Top Head ; $CH ┴ Column Head ; $LH ├ Left Head ; $RH ┤ Right Head ; $C ┼ Center Local Const $TL = "┌", $TR = "┐", $BL = "└", $BR = "┘" Local Const $H = "─", $V = "│", $C = "┼" Local Const $TH = "┬", $CH = "┴", $LH = "├", $RH = "┤" Local $sResult = "" Local $bHeader = ($iFrame = 2 Or $iFrame = 3) Local $bBorder = ($iFrame = 1 Or $iFrame = 3) Local $sPre = ($iFrame = 0 ? "" : " ") ; Top border If $bBorder Then $sResult &= $TL For $j = 0 To $iCols - 1 $sResult &= _StringRepeat($H, $aColWidths[$j] + 2) $sResult &= ($j < $iCols - 1) ? $TH : $TR Next $sResult &= @LF EndIf ; Header row If $bHeader Then If $bBorder Or $iFrame = 2 Then $sResult &= $V For $j = 0 To $iCols - 1 $sResult &= $sPre & __FormatCell($aTable[0][$j], $aColWidths[$j], $aAlign[$j]) & " " If $j < $iCols - 1 Then $sResult &= ($bBorder Or $iFrame = 2) ? $V : "" Next If $bBorder Or $iFrame = 2 Then $sResult &= $V $sResult &= @LF ; Header separator If $bBorder Then $sResult &= $LH ElseIf $iFrame = 2 Then $sResult &= $V EndIf For $j = 0 To $iCols - 1 $sResult &= _StringRepeat($H, $aColWidths[$j] + 2) If $j < $iCols - 1 Then $sResult &= ($bBorder ? $C : ($iFrame = 2 ? $C : "")) Else If $bBorder Then $sResult &= $RH EndIf Next If $iFrame = 2 Then $sResult &= $V $sResult &= @LF EndIf ; Data rows For $i = ($bHeader ? 1 : 0) To UBound($aTable) - 1 If $bBorder Or $iFrame = 2 Then $sResult &= $V For $j = 0 To $iCols - 1 $sResult &= $sPre & __FormatCell($aTable[$i][$j], $aColWidths[$j], $aAlign[$j]) & " " If $j < $iCols - 1 Then $sResult &= ($bBorder Or $iFrame = 2) ? $V : "" Next If $bBorder Or $iFrame = 2 Then $sResult &= $V $sResult &= @LF Next ; Bottom border If $bBorder Then $sResult &= $BL For $j = 0 To $iCols - 1 $sResult &= _StringRepeat($H, $aColWidths[$j] + 2) $sResult &= ($j < $iCols - 1) ? $CH : $BR Next EndIf Return $sResult EndFunc ;==>_StringToTable ;--------------------------------------------------------------------------------------- Func __FormatCell($text, $width, $align) ; internal Switch $align Case "R" Return StringFormat("%" & $width & "s", $text) Case "C" Local $pad = $width - StringLen($text) Local $left = Floor($pad / 2) Local $right = $pad - $left Return _StringRepeat(" ", $left) & $text & _StringRepeat(" ", $right) Case Else ; "L" Return StringFormat("%-" & $width & "s", $text) EndSwitch EndFunc ;==>__FormatCell ;--------------------------------------------------------------------------------------- Please, every comment is appreciated! leave your comments and experiences here! Thank you very much Relative: https://www.autoitscript.com/forum/topic/211237-treestructuredir/ Edited 7 hours ago by ioa747 update to Version: 0.2 Andreik, WildByDesign, SOLVE-SMART and 1 other 4 I know that I know nothing
WildByDesign Posted 7 hours ago Posted 7 hours ago This is really nice. I can think of many times where this would have come in handy. It's neat that you have alignment feature too. Thanks for sharing. ioa747 1
SOLVE-SMART Posted 7 hours ago Posted 7 hours ago Thanks @ioa747, I like the implementation too 👍 . One little thing: In frame type/mode 0 ($iFrame = 0), the table will be generated without any frame (border). But there is a leading whitespace for each table row which is unnecessary in my opionion. Do you mind to change the code to get rid of that? Of course I could do it on my own, but maybe it's also good for all others here. What do you think? Best regards Sven ioa747 1 ==> AutoIt related: 🔗 GitHub, 🔗 Discord Server, 🔗 Cheat Sheet Spoiler 🌍 Au3Forums 🎲 AutoIt (en) Cheat Sheet 📊 AutoIt limits/defaults 💎 Code Katas: [...] (comming soon) 🎭 Collection of GitHub users with AutoIt projects 🐞 False-Positives 🔮 Me on GitHub 💬 Opinion about new forum sub category 📑 UDF wiki list ✂ VSCode-AutoItSnippets 📑 WebDriver FAQs 👨🏫 WebDriver Tutorial (coming soon)
SOLVE-SMART Posted 7 hours ago Posted 7 hours ago Is it okay when I use your function to add two more modes? I would add a markdown table format and a gherkin feature table format. If I would use your code in any of my open source project, I would refer to you (naming and link). 👉 Markdown table format: Spoiler | Item | In Stock | Price | | :---------------- | :------: | ----: | | Python Hat | True | 23.99 | | SQL Hat | True | 23.99 | | Codecademy Tee | False | 19.99 | | Codecademy Hoodie | False | 42.99 | 👉 Gherkin feature table format: Spoiler Given the following users exist: | name | email | twitter | | Aslak | aslak@cucumber.io | @aslak_hellesoy | | Julien | julien@cucumber.io | @jbpros | | Matt | matt@cucumber.io | @mattwynne | Best regards Sven ==> AutoIt related: 🔗 GitHub, 🔗 Discord Server, 🔗 Cheat Sheet Spoiler 🌍 Au3Forums 🎲 AutoIt (en) Cheat Sheet 📊 AutoIt limits/defaults 💎 Code Katas: [...] (comming soon) 🎭 Collection of GitHub users with AutoIt projects 🐞 False-Positives 🔮 Me on GitHub 💬 Opinion about new forum sub category 📑 UDF wiki list ✂ VSCode-AutoItSnippets 📑 WebDriver FAQs 👨🏫 WebDriver Tutorial (coming soon)
ioa747 Posted 6 hours ago Author Posted 6 hours ago @SOLVE-SMART update to Version: 0.2 without leading whitespace in $iFrame = 0 16 minutes ago, SOLVE-SMART said: Is it okay when I use your function to add two more modes? Of course, feel free to use it Adding these features sounds really cool. I can't wait to see the result. SOLVE-SMART 1 I know that I know nothing
SOLVE-SMART Posted 6 hours ago Posted 6 hours ago 48 minutes ago, ioa747 said: Of course, feel free to use it Nice, thanks. 44 minutes ago, ioa747 said: Adding these features sounds really cool. I can't wait to see the result. I will share the code, but I won't add the features to your function(s). I would use my own code style and my own use cases. Therefore not all of your frame types will be applied in my version - just to mention it 😆 . In other words, it would not be that dynamic and UDF-like, because I focus on specific use cases not on plenty of variants. Best regards Sven ioa747 1 ==> AutoIt related: 🔗 GitHub, 🔗 Discord Server, 🔗 Cheat Sheet Spoiler 🌍 Au3Forums 🎲 AutoIt (en) Cheat Sheet 📊 AutoIt limits/defaults 💎 Code Katas: [...] (comming soon) 🎭 Collection of GitHub users with AutoIt projects 🐞 False-Positives 🔮 Me on GitHub 💬 Opinion about new forum sub category 📑 UDF wiki list ✂ VSCode-AutoItSnippets 📑 WebDriver FAQs 👨🏫 WebDriver Tutorial (coming soon)
