#1 akurakkauaaa

akurakkauaaa

    Seeker

  • Active Members
  • 25 posts

Posted 31 October 2011 - 08:14 PM

description: search image in desktop / picture.
not require dll. :D


include: myImageSearch.au3

AutoIt
#include-once #include <ScreenCapture.au3>   ; #INDEX# ======================================================================================================================= ; Title .........: myImageSearch ; AutoIt Version: 3.3.6.1 ; Script Version: 1.0 (31.10.2011) ; Language: English, Polski. ; Description: Search image. ; ===============================================================================================================================     ; #CURRENT# ===================================================================================================================== ; myImageSearch_Desktop ; myImageSearch_Picture ; ===============================================================================================================================     ; #FUNCTION# ==================================================================================================================== ; Name...........: myImageSearch_Desktop ; Description ...: Znajdz obrazek na pulpicie. ; Syntax.........: myImageSearch_Desktop($Image, $x = 0, $y = 0, $iIW = @DesktopWidth, $iIH = @DesktopHeight, $TransColorRGB = '', $OnlyFirst = True) ; Parameters ....: $Image - znajdz obrazek: adres do szuaknego obrazka, lub bitmapa (format .bmp 24-bit) ; $x - lewe koordynaty [Default is 0 (pierwszy pixel).] ; $y - gorne koordynaty. [Default is 0 (pierwszy pixel).] ; $iIW - prawe koordynaty. [Default is @DesktopWidth.] ; $iIH - dolne koordynaty. [Default is @DesktopHeight.] ; $TransColorRGB - Kolor przezroczystosci / Ignorowany kolor. Musi byc string i format RGB. a.g: "0xFFFFFF".[Default is "".] ; $OnlyFirst - [Default is True.] ; |True = Success: Zwraca tablice 2-elementowa z koordynatami. ; $array[0] = x koordynaty ; $array[1] = y koordynaty ; |False = Success: Zwraca 2D tablice z koordynatami. ; $array[0][0] = 1st x coordinate ; $array[0][1] = 1st y coordinate ; $array[1][0] = 2nd x coordinate ; $array[1][1] = 2nd y coordinate ; $array[3][0] = 3rd x coordinate ; $array[3][1] = 3rd y coordinate ; $array[n][0] = nth x coordinate ; $array[n][1] = nth y coordinate ; ; UWAGA: Jesli uzyjesz "False" to max obszar przeszukiwania moze wynosic 800x600 pixeli, lub ekwiwalent max 480.000 pixeli!!! ; Nie wiecej. ; ; Return values . : On Success - Zwrot tablica 2-elementowa z koordynatami lub 2D tablica z koordynatami. ; On Failure - @Error = 1 - Sciezka do pliku jest bledna, lub bitmapa/obrazek jest bledna. ; @Error = 2 - Obrazka nie znaleziono (na pulpicie). ; ===============================================================================================================================     ; #FUNCTION# ==================================================================================================================== ; Name...........: myImageSearch_Desktop ; Description ...: Image search in desktop. ; Syntax.........: myImageSearch_Desktop($Image, $x = 0, $y = 0, $iIW = @DesktopWidth, $iIH = @DesktopHeight, $TransColorRGB = '', $OnlyFirst = True) ; Parameters ....: $Image - search image: string adress for file, or bitmat (format .bmp 24-bit) ; $x - left coordinate. [Default is 0 (first pixel).] ; $y - top coordinate. [Default is 0 (first pixel).] ; $iIW - right coordinate. [Default is @DesktopWidth.] ; $iIH - bottom coordinate. [Default is @DesktopHeight.] ; $TransColorRGB - Color transparancy / Ignore color. Must be string and format RGB. a.g: "0xFFFFFF".[Default is "".] ; $OnlyFirst - [Default is True.] ; |True = Success: Returns a two-element array coordinates. ; $array[0] = x coordinate ; $array[1] = y coordinate ; |False = Success: Returns a 2D array coordinates. ; $array[0][0] = 1st x coordinate ; $array[0][1] = 1st y coordinate ; $array[1][0] = 2nd x coordinate ; $array[1][1] = 2nd y coordinate ; $array[3][0] = 3rd x coordinate ; $array[3][1] = 3rd y coordinate ; $array[n][0] = nth x coordinate ; $array[n][1] = nth y coordinate ; ; ATTENTION: If u use "False" max area for search must be 800x600 pixels, or equivalent maximal 480.000 pixels!!! ; No more. ; ; Return values . : On Success - Returns two-element array coordinates, or 2D array coordinates. ; On Failure - @Error = 1 - Path not found or invalid image/bitmap. ; @Error = 2 - Image not exist (in desktop). ; ===============================================================================================================================     Func myImageSearch_Desktop($Image, $x = 0, $y = 0, $iIW = @DesktopWidth, $iIH = @DesktopHeight, $TransColorRGB = '', $OnlyFirst = True) Local $hBMP, $hImage1, $aReturn, $error, $i _GDIPlus_Startup() $hBMP = _ScreenCapture_Capture("", $x, $y, $iIW + $x, $iIH + $y, False) $hImage1 = _GDIPlus_BitmapCreateFromHBITMAP($hBMP) $aReturn = myImageSearch_Picture($hImage1, $Image, 0, 0, $iIW, $iIH, $TransColorRGB, $OnlyFirst) $error = @error _GDIPlus_ImageDispose($hImage1) _WinAPI_DeleteObject($hBMP) _GDIPlus_Shutdown()   Switch $error Case 0 If $OnlyFirst Then $aReturn[0] += $x $aReturn[1] += $y Else For $i = 0 To UBound($aReturn, 1) - 1 $aReturn[$i][0] += $x $aReturn[$i][1] += $y Next EndIf Return $aReturn Case 2 Return SetError(1, 1, '') Case Else Return SetError(2, 2, '') EndSwitch   EndFunc ;==>myImageSearch_Desktop     ; #FUNCTION# ==================================================================================================================== ; Name...........: myImageSearch_Picture ; Description ...: Znajdz obrazek na obrazku. ; Syntax.........: myImageSearch_Picture($hImage1, $hImage2, $x = 0, $y = 0, $iIW = 0, $iIH = 0, $TransColorRGB = '', $OnlyFirst = True) ; Parameters ....: $hImage1 - bazowy obrazek: adres do szuaknego obrazka, lub bitmapa (format .bmp 24-bit) ; $hImage2 - znajdz obrazek: adres do szuaknego obrazka, lub bitmapa (format .bmp 24-bit) ; $x - lewe koordynaty [Default is 0 (pierwszy pixel).] ; $y - gorne koordynaty. [Default is 0 (pierwszy pixel).] ; $iIW - prawe koordynaty. [Default is 0 (0 to ostani pixel (caly obrazek).] ; $iIH - dolne koordynaty. [Default is 0 (0 to ostani pixel (caly obrazek).] ; $TransColorRGB - Kolor przezroczystosci / Ignorowany kolor. Musi byc string i format RGB. a.g: "0xFFFFFF".[Default is "".] ; $OnlyFirst - [Default is True.] ; |True = Success: Zwraca tablice 2-elementowa z koordynatami. ; $array[0] = x koordynaty ; $array[1] = y koordynaty ; |False = Success: Zwraca 2D tablice z koordynatami. ; $array[0][0] = 1st x coordinate ; $array[0][1] = 1st y coordinate ; $array[1][0] = 2nd x coordinate ; $array[1][1] = 2nd y coordinate ; $array[3][0] = 3rd x coordinate ; $array[3][1] = 3rd y coordinate ; $array[n][0] = nth x coordinate ; $array[n][1] = nth y coordinate ; ; UWAGA: Jesli uzyjesz "False" to max obszar przeszukiwania moze wynosic 800x600 pixeli, lub ekwiwalent max 480.000 pixeli!!! ; Nie wiecej. ; ; Return values . : On Success - Zwrot tablica 2-elementowa z koordynatami lub 2D tablica z koordynatami. ; On Failure - @Error = 1 - 1 sciezka do pliku jest bledna, lub bitmapa/obrazek jest bledna. ; @Error = 2 - 2 sciezka do pliku jest bledna, lub bitmapa/obrazek jest bledna. ; @Error = 3 - Obrazka nie znaleziono (na obrazku). ; ===============================================================================================================================     ; #FUNCTION# ==================================================================================================================== ; Name...........: myImageSearch_Picture ; Description ...: Image search in picture. ; Syntax.........: myImageSearch_Picture($hImage1, $hImage2, $x = 0, $y = 0, $iIW = 0, $iIH = 0, $TransColorRGB = '', $OnlyFirst = True) ; Parameters ....: $hImage1 - base image: string adress for file, or bitmat (format .bmp 24-bit) ; $hImage2 - search image: string adress for file, or bitmat (format .bmp 24-bit) ; $x - left coordinate. [Default is 0 (first pixel).] ; $y - top coordinate. [Default is 0 (first pixel).] ; $iIW - right coordinate. [Default is 0 (0 is last pixel (full imege).] ; $iIH - bottom coordinate. [Default is 0 (0 is last pixel (full imege).] ; $TransColorRGB - Color transparancy / Ignore color. Must be string and format RGB. a.g: "0xFFFFFF".[Default is "".] ; $OnlyFirst - [Default is True.] ; |True = Success: Returns a two-element array coordinates. ; $array[0] = x coordinate ; $array[1] = y coordinate ; |False = Success: Returns a 2D array coordinates. ; $array[0][0] = 1st x coordinate ; $array[0][1] = 1st y coordinate ; $array[1][0] = 2nd x coordinate ; $array[1][1] = 2nd y coordinate ; $array[3][0] = 3rd x coordinate ; $array[3][1] = 3rd y coordinate ; $array[n][0] = nth x coordinate ; $array[n][1] = nth y coordinate ; ; ATTENTION: If u use "False" max area for search must be 800x600 pixels, or equivalent maximal 480.000 pixels!!! ; No more. ; ; Return values . : On Success - Returns two-element array coordinates, or 2D array coordinates. ; On Failure - @Error = 1 - 1st path not found or invalid image/bitmap. ; @Error = 2 - 2nd path not found or invalid image/bitmap. ; @Error = 3 - Image not exist (in picture). ; ===============================================================================================================================     Func myImageSearch_Picture($hImage1, $hImage2, $x = 0, $y = 0, $iIW = 0, $iIH = 0, $TransColorRGB = '', $OnlyFirst = True) Local $testiIW, $testiIH Local $hBitmap1, $Reslt, $width, $height, $stride, $format, $Scan0 Local $iIW_2, $iIH_2, $hBitmap2, $Reslt2, $width2, $height2, $stride2, $format2, $Scan02 Local $sREResult1, $sREResult2, $sREResult3   _GDIPlus_Startup()   If IsString($hImage1) Then $hImage1 = _GDIPlus_ImageLoadFromFile($hImage1) EndIf   $testiIW = _GDIPlus_ImageGetWidth($hImage1) $testiIH = _GDIPlus_ImageGetHeight($hImage1)   If $hImage2 = "" Or $testiIW = 0 Or $testiIH = 0 Then Return SetError(1, 1, '') EndIf   If $iIW = 0 Or $testiIW < $iIW Then $iIW = $testiIW If $iIH = 0 Or $testiIH < $iIH Then $iIH = $testiIH   $hBitmap1 = _GDIPlus_BitmapCloneArea($hImage1, 0, 0, $iIW, $iIH, $GDIP_PXF32ARGB) $Reslt = _GDIPlus_BitmapLockBits($hBitmap1, $x, $y, $iIW - $x, $iIH - $y, BitOR($GDIP_ILMREAD, $GDIP_ILMWRITE), $GDIP_PXF32ARGB) $width = DllStructGetData($Reslt, "width") $height = DllStructGetData($Reslt, "height") $stride = DllStructGetData($Reslt, "stride") $format = DllStructGetData($Reslt, "format") $Scan0 = DllStructGetData($Reslt, "Scan0") $sREResult1 = DllStructCreate("byte[" & $height * $width * 4 & "]", $Scan0); Create DLL structure for all pixels $sREResult1 = DllStructGetData($sREResult1, 1) _GDIPlus_BitmapUnlockBits($hBitmap1, $Reslt); releases the locked region _GDIPlus_ImageDispose($hImage1) _GDIPlus_ImageDispose($hBitmap1)   If IsString($hImage2) Then $hImage2 = _GDIPlus_ImageLoadFromFile($hImage2) EndIf   $iIW_2 = _GDIPlus_ImageGetWidth($hImage2) $iIH_2 = _GDIPlus_ImageGetHeight($hImage2)   If $hImage2 = "" Or $iIW_2 = 0 Or $iIH_2 = 0 Then Return SetError(2, 2, '') EndIf   $hBitmap2 = _GDIPlus_BitmapCloneArea($hImage2, 0, 0, $iIW_2, $iIH_2, $GDIP_PXF32ARGB) $Reslt2 = _GDIPlus_BitmapLockBits($hBitmap2, 0, 0, $iIW_2, $iIH_2, BitOR($GDIP_ILMREAD, $GDIP_ILMWRITE), $GDIP_PXF32ARGB) $width2 = DllStructGetData($Reslt2, "width") $height2 = DllStructGetData($Reslt2, "height") $stride2 = DllStructGetData($Reslt2, "stride") $format2 = DllStructGetData($Reslt2, "format") $Scan02 = DllStructGetData($Reslt2, "Scan0") $sREResult2 = DllStructCreate("byte[" & $height2 * $width2 * 4 & "]", $Scan02); Create DLL structure for all pixels $sREResult2 = DllStructGetData($sREResult2, 1) _GDIPlus_BitmapUnlockBits($hBitmap2, $Reslt2); releases the locked region _GDIPlus_ImageDispose($hImage2) _GDIPlus_ImageDispose($hBitmap2)   _GDIPlus_Shutdown()   $sREResult1 = StringTrimLeft($sREResult1, 2) $sREResult2 = StringTrimLeft($sREResult2, 2)   If IsString($TransColorRGB) Then ; ignore color $TransColorRGB = StringRegExpReplace($TransColorRGB, "0x(.{2})(.{2})(.{2})", "\3\2\1FF") If $TransColorRGB Then $sREResult2 = StringRegExpReplace($sREResult2, "(.{8})", "\1 ") $sREResult2 = StringReplace($sREResult2, $TransColorRGB, "........") $sREResult2 = StringReplace($sREResult2, " ", "") EndIf EndIf ;ConsoleWrite($sREResult2 & @CRLF)   $sREResult2 = StringRegExpReplace($sREResult2, "(.{" & $iIW_2 * 8 & "})", "\\Q\1\\E.\{" & ($iIW - $iIW_2) * 8 & "\}") $sREResult2 = StringTrimRight($sREResult2, StringLen(($iIW - $iIW_2) * 8) + 3) ;ConsoleWrite($sREResult2 & @CRLF)   If $TransColorRGB Then $sREResult2 = StringReplace($sREResult2, "........", "\E........\Q") $sREResult2 = StringReplace($sREResult2, "\Q\E", "") $sREResult2 = StringRegExpReplace($sREResult2, "([.}{\w]*)([\\].*[E])([.}{\w]*)", "\2") ; obcina kropki EndIf ;ConsoleWrite($sREResult2 & @CRLF)   If $OnlyFirst Then $sREResult2 = '(?i)(.*?)' & $sREResult2 & ".*" ;ConsoleWrite($sREResult2 & @CRLF)   $sREResult3 = StringRegExpReplace($sREResult1, $sREResult2, "\1") ; test pathern ("first")   If Not @extended Then Return SetError(3, 3, '') ; extendet zero to nie znaleziono nic   $sREResult3 = StringLen($sREResult3) / 8 Local $pozycja_Y = Int($sREResult3 / $iIW) + $y Local $pozycja_X = Int($sREResult3 - $pozycja_Y * $iIW) + ($y * $iIW) Local $aReturn[2] = [$pozycja_X, $pozycja_Y]   Else   $sREResult2 = '(?i)(.*?)(' & $sREResult2 & ".*?)" ; wersja dla wielu winikow ;ConsoleWrite($sREResult2 & @CRLF)   $sREResult3 = StringRegExp($sREResult1, $sREResult2, 3) ; test pathern ("mulit")   If @error Or Not IsArray($sREResult3) Then Return SetError(3, 3, '')   Local $ile = UBound($sREResult3) Local $i Local $aReturn[$ile / 2][2] Local $sREResult4 = 0 Local $pozycja_Y Local $pozycja_X   For $i = 0 To $ile - 1 Step 2 $sREResult4 += StringLen($sREResult3[$i]) / 8 If $i > 0 Then $sREResult4 += StringLen($sREResult3[$i + 1]) / 8   $pozycja_Y = Int($sREResult4 / $iIW) + $y $pozycja_X = Int($sREResult4 - $pozycja_Y * $iIW) + ($y * $iIW) $aReturn[$i / 2][0] = $pozycja_X $aReturn[$i / 2][1] = $pozycja_Y Next   EndIf Return $aReturn EndFunc ;==>myImageSearch_Picture


example:

AutoIt
#include <array.au3> #include <myImageSearch.au3>   ;Opt('MustDeclareVars', 1)   ;########## test 1 Desktop ##########   Global $pozycja1 Global $time1   Global $ImageSearch = @ScriptDir & "\recycle.bmp" Global $x = 0 Global $y = 0 Global $w = @DesktopWidth Global $h = @DesktopHeight Global $ColorTrans = '' Global $mOnlyFirst = True   Sleep(10) $time1 = TimerInit()   $pozycja1 = myImageSearch_Desktop($ImageSearch, $x, $y, $w, $h, $ColorTrans, $mOnlyFirst) If @error Then ConsoleWrite("sorry image not exist" & @CRLF)   ConsoleWrite("time 1: " & TimerDiff($time1) / 1000 & ' sek.' & @CRLF)   If IsArray($pozycja1) Then _ArrayDisplay($pozycja1) EndIf   ;##################################   ;########## test 2 Scren ##########   Global $pozycja2 Global $time2   Global $ImageBazowe = @ScriptDir & "\where is wally.bmp" Global $ImageSearch = @ScriptDir & "\wanted wally.bmp" Global $x = 0 Global $y = 0 Global $w = 0 Global $h = 0 Global $ColorTrans = "0x00ffff" Global $mOnlyFirst = False ;False = search more image, but not all.., ; ;If u use "False" max area for search must be 800x600 pixels, ; ;or equivalent maximal 480.000 pixels!!! ; ;No more. ; ;Recommended is "True" Sleep(10) $time2 = TimerInit()   $pozycja2 = myImageSearch_Picture($ImageBazowe, $ImageSearch, $x, $y, $w, $h, $ColorTrans, $mOnlyFirst) If @error Then ConsoleWrite("sorry image not exist" & @CRLF)   ConsoleWrite("time 2: " & TimerDiff($time2) / 1000 & ' sek.' & @CRLF)   If IsArray($pozycja2) Then _ArrayDisplay($pozycja2) EndIf   ;##################################

Attached Files


  • tbodine88 and XabiK like this







#2 vfear

vfear

    Seeker

  • Active Members
  • 16 posts

Posted 31 October 2011 - 08:16 PM

I wonder about the speed with the script vs. dll.

#3 akurakkauaaa

akurakkauaaa

    Seeker

  • Active Members
  • 25 posts

Posted 31 October 2011 - 08:35 PM

of course my is slow. but has more option.

#4 LoWang

LoWang

    Polymath

  • Active Members
  • PipPipPipPip
  • 206 posts

Posted 01 January 2012 - 05:45 PM

nice work. Finally something which seems to be able to find more pictures then just one, do I understand it right? You just could try to write comments in english man :)

#5 chrisad

chrisad

    Seeker

  • Active Members
  • 9 posts

Posted 11 March 2012 - 03:52 PM

hello pal, i am try to make a loop of your way, but no luck, could you please take a look and tell me whats happening...

Plain Text
#include <array.au3> #include <myImageSearch.au3> func exittheprog ()    Exit EndFunc HotKeySet( "{F10}", "exittheprog" ) while 1    sleep(1000)     MouseMove(969,844) MouseClick("left") ;########## Number0 ########## Global $Number0 Global $time1 Global $ImageSearch = @ScriptDir & "images0.bmp" Global $x = 0 Global $y = 0 Global $w = @DesktopWidth Global $h = @DesktopHeight Global $ColorTrans = '' Global $mOnlyFirst = True Sleep(10) $time1 = TimerInit() $Number0 = myImageSearch_Desktop($ImageSearch, $x, $y, $w, $h, $ColorTrans, $mOnlyFirst) If @error Then ConsoleWrite("sorry image not exist" & @CRLF) ConsoleWrite("time 1: " & TimerDiff($time1) / 1000 & ' sek.' & @CRLF) If IsArray($Number0) Then     MouseMove(1443,457) MouseClick("left") send ("0") Send ("{ENTER}")   Else     MouseMove(969,844) MouseClick("left") EndIf sleep(1000)   MouseMove(969,844) MouseClick("left") ;################################## WEnd


#6 akurakkauaaa

akurakkauaaa

    Seeker

  • Active Members
  • 25 posts

Posted 11 March 2012 - 05:21 PM

hello pal, i am try to make a loop of your way, but no luck, could you please take a look and tell me whats happening...

maybe u have wrong format.

create picture:
#include <ScreenCapture.au3> _ScreenCapture_Capture(@ScriptDir & "testscren.bmp", 100, 100, 120 , 120)

find:
#include <myImageSearch.au3> HotKeySet("{F10}", "exittheprog") Global $Number0 Global $Error Global $ImageSearch = @ScriptDir & "testscren.bmp" While 1 $Number0 = myImageSearch_Desktop($ImageSearch) $Error = @error If $Error Then ConsoleWrite("sorry image not exist. Error nr:" & $Error & @CRLF) If IsArray($Number0) Then   ConsoleWrite("Pos: " & $Number0[0] & " : " & $Number0[1] & @CRLF)   MouseMove($Number0[0], $Number0[1]) EndIf Sleep(1000) WEnd Func exittheprog() Exit EndFunc   ;==>exittheprog

Edited by akurakkauaaa, 11 March 2012 - 05:22 PM.


#7 anh7codon

anh7codon

    Seeker

  • Normal Members
  • 3 posts

Posted 11 April 2012 - 12:55 PM

How about game screen (scaled)?

#8 sktan7

sktan7

    Seeker

  • Active Members
  • 12 posts

Posted 21 August 2012 - 02:48 PM

Hi,
What about can this work with IE? like for example capture an flash object, which could be a upload buttons. If it does not work with IE, any thought about integrate with it IE?

This will be greatly useful.

#9 Matthy

Matthy

    Adventurer

  • Active Members
  • PipPip
  • 109 posts

Posted 28 December 2012 - 01:03 AM

Works great THX!

nice that you also posted a good example

#10 Amiekbir

Amiekbir

    Seeker

  • Active Members
  • 27 posts

Posted 20 March 2013 - 08:29 PM

anything to do with 32/64 bit?

#11 XabiK

XabiK

    Seeker

  • Normal Members
  • 4 posts

Posted 04 July 2013 - 06:17 PM

of course my is slow. but has more option.





Probably it's slow... but it works quite well, but I found a strange behavior: when I look for an image (actually, an icon) at the desktop, using '_ImageSearch_Desktop' function, it doesn't find it, but when I look for the same icon in a specific area of the desktop, using following code (yeah, it's derived from yours!):

AutoIt
; #FUNCTION# ==================================================================================================================== ; Name...........: _ImageSearch_Position ; Description ...: Image search in a position of the desktop, according to provided width and height ; Syntax.........: _ImageSearch_Position($Image, $Position, $Width, $Height, $TransColorRGB = '') ; Parameters ....: $Image - search image: string address for file, or bitmap (format .bmp 24-bit) ;                  $Position - topleft, topcenter, topright, middleleft, center (default), middleright, bottomleft, bottomcenter, bottomright ;                  $Width - width of searching area [Default is @DesktopWidth.] ;                  $Height - height of searching area [Default is @DesktopHeight.] ;                  $TransColorRGB - Color transparency / Ignore color. Must be string and format RGB. a.g: "0xFFFFFF".[Default is "".] ; ; Return values . : On Success - Returns two-element array coordinates, or 2D array coordinates. CENTER of search image. ;                   On Failure - @Error = 1 - Path not found or invalid image/bitmap. ;                                @Error = 2 - Image not exist (in searching area). ; =============================================================================================================================== Func _ImageSearch_Position($Image, $Position = "center", $width = @DesktopWidth, $height = @DesktopHeight, $TransColorRGB = '')     Local $aCoords[4], $aReturn, $error     ;Some initial checks     $width = Int($width)     $height = Int($height)     If $width = 0 Or $width > @DesktopWidth Then         $width = @DesktopWidth     EndIf     If $height = 0 Or $height > @DesktopHeight Then         $height = @DesktopHeight     EndIf     ;Coordinates calculation     Switch $Position         Case "topleft"             $aCoords[0] = 0             $aCoords[1] = 0         Case "topcenter"             $aCoords[0] = Int((@DesktopWidth - $width) / 2)             $aCoords[1] = 0         Case "topright"             $aCoords[0] = @DesktopWidth - $width             $aCoords[1] = 0         Case "middleleft"             $aCoords[0] = 0             $aCoords[1] = Int((@DesktopHeight - $height) / 2)         Case "middleright"             $aCoords[0] = @DesktopWidth - $width             $aCoords[1] = Int((@DesktopHeight - $height) / 2)         Case "bottomleft"             $aCoords[0] = 0             $aCoords[1] = @DesktopHeight - $height         Case "bottomcenter"             $aCoords[0] = Int((@DesktopWidth - $width) / 2)             $aCoords[1] = @DesktopHeight - $height         Case "bottomright"             $aCoords[0] = @DesktopWidth - $width             $aCoords[1] = @DesktopHeight - $height         Case Else ;"center"             $aCoords[0] = Int((@DesktopWidth - $width) / 2)             $aCoords[1] = Int((@DesktopHeight - $height) / 2)     EndSwitch     $aCoords[2] = $aCoords[0] + $width     $aCoords[3] = $aCoords[1] + $height     $aReturn = _ImageSearch_Desktop($Image, $aCoords[0], $aCoords[1], $aCoords[2], $aCoords[3], $TransColorRGB)     $error = @error     Switch $error         Case 0             Return $aReturn         Case 1             Return SetError(1, 1, '')         Case 2             Return SetError(2, 2, '')     EndSwitch EndFunc   ;==>_ImageSearch_Position

It finds it!



I think the reason is that my desktop is quite big (1920x1200), and the original code 'get lost'. As I know that the icon is located in a specific area of the desktop, I can search in a smaller area.



Anyway, thanks a lot for your code!
