UEZ

Stretched Image on GDI+ _GDIPlus_GraphicsDrawImage() Function

4 posts in this topic

#1 ·  Posted (edited)

When I want to use _GDIPlus_GraphicsDrawImage() for displaying images then some images will be displayed in window stretched!

#include <GuiConstantsEx.au3>
#include <GDIPlus.au3>
Opt('MustDeclareVars', 1)
Opt("GUIOnEventMode", 1)
Global $hWnd1, $hWnd2, $hGraphic, $file, $hImage, $hMatrix
Global $iX, $iY

$file = FileOpenDialog("Select image to load", @ScriptDir, "Images (*.jpg;*.bmp)")

_GDIPlus_Startup()

$hImage = _GDIPlus_ImageLoadFromFile($file)

$iX = _GDIPlus_ImageGetWidth($hImage)
$iY = _GDIPlus_ImageGetHeight($hImage)

$hWnd1 = GUICreate("_GDIPlus_GraphicsDrawImage", $iX, $iY, @DesktopWidth / 2 - $iX - 10)
GUISetState()

$hGraphic = _GDIPlus_GraphicsCreateFromHWND($hWnd1)
_GDIPlus_GraphicsDrawImage($hGraphic, $hImage, 0, 0) ;is not working properly with some images
;_GDIPlus_GraphicsDrawImageRect($hGraphic, $hImage, 0, 0, $iX, $iY) ;is working
_GDIPlus_ImageDispose($hImage)

$hWnd2 = GUICreate("GUICtrlCreatePic", $iX, $iY, @DesktopWidth / 2 + 10)
GUISetBkColor(0)
GUICtrlCreatePic($file, 0, 0, $iX, $iY)
GUISetState()

GUISetOnEvent($GUI_EVENT_CLOSE, "_Exit")

Do
Until Not Sleep(10000000)

Func _Exit()
    _GDIPlus_GraphicsDispose($hGraphic)
    _GDIPlus_Shutdown()
    Exit
EndFunc

I attached 2 images, both images will be displayed stretched (zoomed) with _GDIPlus_GraphicsDrawImage($hGraphic, $hImage, 0, 0) function but not with GUICtrlCreatePic($file, 0, 0, $iX, $iY)!

Why?

I tried to re-save the images but no success! I couldn't see the difference between the jpg files (formats)

Thanks and merry x-mas!

UEZ



Edited by UEZ

Please don't send me any personal message and ask for support! I will not reply!

Selection of finest graphical examples at Codepen.io

The own fart smells best!
Her 'sikim hıyar' diyene bir avuç tuz alıp koşma!
¯\_(ツ)_/¯  ٩(●̮̮̃•̃)۶ ٩(-̮̮̃-̃)۶ૐ

Share this post


Link to post
Share on other sites



#3 ·  Posted (edited)

I think the problem is in the picture. Try to resave Eye.jpg and everything will be OK.

Intel.jpg was originally in BMP format which will be displayed stretched (zoomed)!

Thanks,

UEZ

Edited by UEZ

Please don't send me any personal message and ask for support! I will not reply!

Selection of finest graphical examples at Codepen.io

The own fart smells best!
Her 'sikim hıyar' diyene bir avuç tuz alıp koşma!
¯\_(ツ)_/¯  ٩(●̮̮̃•̃)۶ ٩(-̮̮̃-̃)۶ૐ

Share this post


Link to post
Share on other sites

#4 ·  Posted (edited)

Solution is to use _GDIPlus_GraphicsDrawImageRect($hGraphic, $hImage, 0, 0, $iX, $iY) instead! I don't know why it is not working on some images with _GDIPlus_GraphicsDrawImage() but anyway...

UEZ

Edited by UEZ

Please don't send me any personal message and ask for support! I will not reply!

Selection of finest graphical examples at Codepen.io

The own fart smells best!
Her 'sikim hıyar' diyene bir avuç tuz alıp koşma!
¯\_(ツ)_/¯  ٩(●̮̮̃•̃)۶ ٩(-̮̮̃-̃)۶ૐ

Share this post


Link to post
Share on other sites
