[Yashied]

expandcollapse popup

#Include <GDIPlus.au3>
#Include <GUIConstantsEx.au3>
#Include <WinAPIEx.au3>
#Include <WindowsConstants.au3>

_GDIPlus_Startup()

$hImage = _GDIPlus_ImageLoadFromFile(@ScriptDir & '\bg_440x440.png')
$hBitmap = _GDIPlus_BitmapCreateHBITMAPFromBitmap($hImage)
_GDIPlus_ImageDispose($hImage)

$hForm = GUICreate('', 440, 440, 200, 200, $WS_POPUPWINDOW, $WS_EX_LAYERED)
_WinAPI_UpdateLayeredWindowEx($hForm, $hBitmap, 127)
$hPopup = GUICreate('', 380, 380, 200 + 30, 200 + 30, $WS_POPUP, $WS_EX_LAYERED, $hForm)
GUISetBkColor(0xABABAB)
$Edit = GUICtrlCreateEdit('', 20, 20, 340, 250)
$Slider = GUICtrlCreateSlider(20, 286, 340, 32)
GUICtrlSetLimit(-1, 100, 0)
GUICtrlSetData(-1, 50)
$Button = GUICtrlCreateButton('OK', 155, 344, 70, 23)
_WinAPI_SetLayeredWindowAttributes($hPopup, 0xABABAB, 0, $LWA_COLORKEY)

GUIRegisterMsg($WM_MOVE, 'WM_MOVE')
GUIRegisterMsg($WM_NCHITTEST, 'WM_NCHITTEST')

GUISetState(@SW_SHOW, $hForm)
GUISetState(@SW_SHOW, $hPopup)

While 1
    $Msg = GUIGetMsg()
    Switch $Msg
        Case $GUI_EVENT_CLOSE, $Button
            ExitLoop
        Case $Slider
            _WinAPI_UpdateLayeredWindowEx($hForm, $hBitmap, 255 / 100 * GUICtrlRead($Slider))
    EndSwitch
WEnd

_GDIPlus_Shutdown()

Func WM_MOVE($hWnd, $iMsg, $wParam, $lParam)
    Switch $hWnd
        Case $hForm

            Local $X = BitAND($lParam, 0xFFFF), $Y = BitShift($lParam, 16)

            If $X > 0x7FFF Then
                $X -= 0x10000
            EndIf
            If $Y > 0x7FFF Then
                $Y -= 0x10000
            EndIf
            WinMove($hPopup, '', $X + 30, $Y + 30)
    EndSwitch
    Return $GUI_RUNDEFMSG
EndFunc   ;==>WM_MOVE

Func WM_NCHITTEST($hWnd, $iMsg, $iwParam, $ilParam)
    Switch $hWnd
        Case $hForm
            Switch $iMsg
                Case $WM_NCHITTEST
                    Return $HTCAPTION
            EndSwitch
    EndSwitch
    Return $GUI_RUNDEFMSG
EndFunc   ;==>WM_NCHITTEST

WinAPIEx.au3

Edited August 21, 2010 by Yashied

[playlet]

---

Edited August 18, 2016 by playlet

[UEZ]

Do you mean this:

expandcollapse popup

#include <ButtonConstants.au3>
#include <GUIConstantsEx.au3>
#include <StaticConstants.au3>
#include <WindowsConstants.au3>
#include <WinApi.au3>
#include <GDIPlus.au3>

$width = 200
$height = 200
$hwnd = GUICreate("Test", $width, $height, Default, Default, $WS_POPUP, $WS_EX_LAYERED + $WS_EX_TOPMOST)
GUISetState(@SW_SHOW)
$bsize_x = 50
$bsize_y = 30
$child = GUICreate("", $bsize_x, $bsize_y, $width * 0.5 - $bsize_x * 0.5, $height * 0.5 - $bsize_y * 0.5, $WS_POPUP, $WS_EX_MDICHILD + $WS_EX_LAYERED, $hwnd)
$button = GUICtrlCreateButton ("Test", 0, 0, $bsize_x, $bsize_y)
_WinAPI_SetLayeredWindowAttributes($child, 0xFFFFFF, 160)
GUISetState(@SW_SHOW)

;~ GUISetBkColor (0xFFFFFF)

_GDIPlus_Startup ()
$Graphics = _GDIPlus_GraphicsCreateFromHWND ($hwnd)
$bitmap = _GDIPlus_BitmapCreateFromGraphics($width, $height, $graphics)
$backbuffer = _GDIPlus_ImageGetGraphicsContext($bitmap)

$ScreenDc = _WinAPI_GetDC($hWnd)
$gdibitmap = _GDIPlus_BitmapCreateHBITMAPFromBitmap($bitmap)
$dc = _WinAPI_CreateCompatibleDC($ScreenDc)
_WinAPI_SelectObject($dc, $gdibitmap)
; _WinAPI_UpdateLayeredWindow parameters
$tSize = DllStructCreate($tagSIZE)
$pSize = DllStructGetPtr($tSize)
DllStructSetData($tSize, "X", $width)
DllStructSetData($tSize, "Y", $height)
$tSource = DllStructCreate($tagPOINT)
$pSource = DllStructGetPtr($tSource)
$tBlend = DllStructCreate($tagBLENDFUNCTION)
$pBlend = DllStructGetPtr($tBlend)
$alpha = 160
DllStructSetData($tBlend, "Alpha", $alpha)
DllStructSetData($tBlend, "Format", 0)
$tPoint = DllStructCreate($tagPOINT)
$pPoint = DllStructGetPtr($tPoint)
DllStructSetData($tPoint, "X", 0)
DllStructSetData($tPoint, "Y", 0)

$PenRect = _GDIPlus_PenCreate (0xFFFFAA00, 10)
_GDIPlus_GraphicsClear($backbuffer, 0x0)
_GDIPlus_GraphicsDrawRect($backbuffer, 0, 0, $width, $height, $PenRect)
$bild = _GDIPlus_ImageLoadFromFile("..\..\images\Bubbles_03.png") ;<=-- replace path with a transparency png
_GDIPlus_GraphicsDrawImageRect($backbuffer, $Bild, 50, 50, 100, 100)

$gdibitmap = _GDIPlus_BitmapCreateHBITMAPFromBitmap($bitmap)
_WinAPI_SelectObject($dc, $gdibitmap)
_WinAPI_UpdateLayeredWindow($hWnd, $ScreenDc, 0, $pSize, $dc, $pSource, 0, $pBlend, 2)
_WinAPI_DeleteObject($gdibitmap)

While 1
    $nMsg = GUIGetMsg()
    Switch $nMsg
        Case -3
            _GDIPlus_GraphicsDispose($backbuffer)
            _GDIPlus_BitmapDispose($bitmap)
            _WinAPI_DeleteDC($dc)
            _WinAPI_ReleaseDC($hWnd, $ScreenDc)
            _GDIPlus_GraphicsDispose($Graphics)
            _GDIPlus_Shutdown()
            $tSize = ""
            $tSource = ""
            $tBlend = ""
            $tPoint = ""
            GUIDelete($child)
            GUIDelete($hwnd)
    Exit
        Case $button
            WinSetOnTop($hwnd, "", False)
            MsgBox(0, "Transparenz", "von UEZ '2010")
            WinSetOnTop($hwnd, "", True)
    EndSwitch
WEnd

Br,

UEZ

[playlet]

---

Edited August 18, 2016 by playlet

[playlet]

---

Edited August 18, 2016 by playlet

[UEZ]

This is working for me with only 1 window:

#include <ButtonConstants.au3>
#include <WindowsConstants.au3>
#include <GDIPlus.au3>

$width = 200
$height = 200
$hwnd = GUICreate("Test", $width, $height, Default, Default, $WS_POPUP, $WS_EX_LAYERED + $WS_EX_TOPMOST)
GUISetBkColor(0x000001)
_WinAPI_SetLayeredWindowAttributes($hwnd, 0x00000001, 0x00, 1, 0)
GUISetState(@SW_SHOW)

_GDIPlus_Startup ()
$hGraphics = _GDIPlus_GraphicsCreateFromHWND ($hwnd)
$hImage = _GDIPlus_ImageLoadFromFile("..\images\Smiley.png") ;<=-- replace path with a transparency png
_GDIPlus_GraphicsDrawImageRect($hGraphics, $hImage, 0, 0, 200, 200)

$button = GUICtrlCreateButton ("Test", 75, 85, 50, 30)
GUISetState(@SW_SHOW)

While 1
    $nMsg = GUIGetMsg()
    Switch $nMsg
    Case -3
    _GDIPlus_GraphicsDispose($hGraphics)
    _GDIPlus_Shutdown()
    GUIDelete($hwnd)
    Exit
    Case $button
    WinSetOnTop($hwnd, "", False)
    MsgBox(0, "Transparency", "by UEZ '2010")
    WinSetOnTop($hwnd, "", True)
    EndSwitch
WEnd

Br,

UEZ

Edited September 1, 2010 by UEZ

[playlet]

---

Edited August 18, 2016 by playlet

[UEZ]

Nice. Any way to restore true transparency?

What do you mean exactly with restore true transparency?

Br,

UEZ

[playlet]

---

Edited August 18, 2016 by playlet

[UEZ]

With GDI+ it is, as far as I know, not possible to draw png's with full tranparency! Same issue with full transparent icons!

Sorry,

UEZ
