Slider background?

13 posts in this topic

Hi guys,

I'm wondering how can we set the background of the slider transparent? Because I put the slider on an image, so the background of slider make the GUI look really bad! "GUICtrlSetBkColor(-1, $GUI_BKCOLOR_TRANSPARENT)" does not work for slider!

I would thank for anyone who either read or reply ^^!


http://www.facebook.com/xx3004?sk=info

Share this post


Link to post
Share on other sites



#3 ·  Posted (edited)

DllCall("UxTheme.dll", "int", "SetWindowTheme", "hwnd", GUICtrlGetHandle($hButton), "wstr", 0, "wstr", 0)

Hi AmiraAlkex,

I've try your code, it does not work, here is the whole code:

$opa = GUICtrlCreateSlider(312, 120, 102, 45, $TBS_NOTICKS, $WS_EX_TRANSPARENT);
GUICtrlSetLimit(-1, 150, 0);
GUICtrlSetData(-1, 150);
$iLastSlider=150;
DllCall("UxTheme.dll", "int", "SetWindowTheme", "hwnd", GUICtrlGetHandle($opa), "wstr", 0, "wstr", 0)

Thanks for your help, do you come up with any other idea :graduated:

Edited by Truong

http://www.facebook.com/xx3004?sk=info

Share this post


Link to post
Share on other sites

How about creating a 2nd Gui and put the slider in there?

You can then set that gui with:

WinSetTrans($Gui2, "", 150)

The slider wil then fade with it.


Share this post


Link to post
Share on other sites

#include <GUIConstantsEx.au3>
#include <WindowsConstants.au3>
#include <WINAPI.au3>

$bkwin=GUICreate("bkcontrols", 250, 200, -1, -1)
GUISetBkColor(0x000000)
GUISetState()
$hGUI = GUICreate("controls", 250, 200, -1, -1, $WS_POPUP, BitOR($WS_EX_LAYERED, $WS_EX_MDICHILD), $bkwin)
GUISetBkColor(0xABCDEF)
    $slider1 = GUICtrlCreateSlider(10, 10, 200, 20)
    GUICtrlSetBkColor(-1,0xABCDEF)
    GUICtrlSetLimit(-1, 200, 0)     ; change min/max value
    $button = GUICtrlCreateButton("Value?", 75, 70, 70, 20)
    GUISetState()
    GUICtrlSetData($slider1, 45)    ; set cursor
_WinAPI_SetLayeredWindowAttributes($hGUI, 0xABCDEF, 250)

While 1
    Switch GUIGetMsg()
        Case $GUI_EVENT_CLOSE
            Exit
     EndSwitch
WEnd

Share this post


Link to post
Share on other sites

#include <GUIConstantsEx.au3>
#include <WindowsConstants.au3>
#include <WINAPI.au3>

$bkwin=GUICreate("bkcontrols", 250, 200, -1, -1)
GUISetBkColor(0x000000)
GUISetState()
$hGUI = GUICreate("controls", 250, 200, -1, -1, $WS_POPUP, BitOR($WS_EX_LAYERED, $WS_EX_MDICHILD), $bkwin)
GUISetBkColor(0xABCDEF)
    $slider1 = GUICtrlCreateSlider(10, 10, 200, 20)
    GUICtrlSetBkColor(-1,0xABCDEF)
    GUICtrlSetLimit(-1, 200, 0)     ; change min/max value
    $button = GUICtrlCreateButton("Value?", 75, 70, 70, 20)
    GUISetState()
    GUICtrlSetData($slider1, 45)    ; set cursor
_WinAPI_SetLayeredWindowAttributes($hGUI, 0xABCDEF, 250)

While 1
    Switch GUIGetMsg()
        Case $GUI_EVENT_CLOSE
            Exit
     EndSwitch
WEnd

Hi, thanks for your help.

The problem here is I've already used 2 layers to change the windows skin already :graduated::

I have attached the file so that it will be easier for you guys to help me make the slider background transparent.

Look at this picture, the slider make my GUI look terrible!

Posted Image

post-60590-0-39640100-1290788573_thumb.j

Test.au3

post-60590-0-66366100-1290788587_thumb.g


http://www.facebook.com/xx3004?sk=info

Share this post


Link to post
Share on other sites

Hi.

Yeah it can be tough merging different scripts together. Here is the solution...I hope. Your attached picture is way to small though.

#include <GDIPlus.au3>
#include <WindowsConstants.au3>
#include <GuiConstantsEx.au3>
#include <StaticConstants.au3>
#include <ButtonConstants.au3>
#include <SliderConstants.au3>
Global Const $AC_SRC_ALPHA = 1

_GDIPlus_Startup()
$aOT=true
$pngSrc = @ScriptDir & "\bg.jpg"
;This allows the png to be dragged by clicking anywhere on the main image.
GUIRegisterMsg($WM_NCHITTEST, "WM_NCHITTEST")
$GUI = _GUICreate_Alpha("Primary", $pngSrc) ; create primary gui
$myGuiHandle = WinGetHandle("Primary")
GUISetState()
$butGui = GUICreate("ControlGUI", 400, 400, 0, 0, $WS_POPUP, BitOR($WS_EX_LAYERED, $WS_EX_MDICHILD), $myGuiHandle)

GUISetBkColor(0xABCDEF)
GUICtrlSetState(-1, $GUI_DISABLE);

$proDef = GUICtrlCreateInput("/d", 10, 40, 49, 21);
$query = GUICtrlCreateInput("", 66, 40, 289, 21);

$submit = GUICtrlCreateButton("Go !", 364, 38, 43, 25, $BS_DEFPUSHBUTTON);

$ESF = GUICtrlCreateCheckbox("", 10, 70, 13, 13);
GUICtrlSetState(-1, $GUI_CHECKED);

$l1 = GUICtrlCreateLabel("Enable Smart Filter (Automatically defines application to lauch)", 27, 70, 378, 17);
GUICtrlSetColor(-1, 0xFFFFFF);
GUICtrlSetBkColor(-1, $GUI_BKCOLOR_TRANSPARENT);
;GUICtrlSetColor(-1, 0x000000);
;GUICtrlSetBkColor(-1, 0xFFFFFF);

$headerTitle = GUICtrlCreateLabel("Multiple Tasks Laucher", 12, 10, 180, 23);
GUICtrlSetFont(-1, 12, 800, 0, "Arial");
GUICtrlSetColor(-1, 0xFFFFFF);
GUICtrlSetBkColor(-1, $GUI_BKCOLOR_TRANSPARENT);
$config = GUICtrlCreateButton("Configure", 48, 90, 75, 25);
$extend = GUICtrlCreateButton("Extend", 136, 90, 75, 25);
$about = GUICtrlCreateButton("Help / About", 224, 90, 75, 25);
$exit = GUICtrlCreateButton("Exit", 308, 90, 75, 25);
$pBar = GUICtrlCreateProgress(5, 142, 418, 20);
$stt = GUICtrlCreateLabel("Welcome to Multi Tasks Launcher", 14, 122, 315, 17);
GUICtrlSetColor(-1, 0xFFFFFF);
GUICtrlSetBkColor(-1, $GUI_BKCOLOR_TRANSPARENT);
$opa = GUICtrlCreateSlider(312, 120, 102, 45, $TBS_NOTICKS, $WS_EX_TRANSPARENT);
GUICtrlSetBkColor(-1,0xABCDEF)
GUICtrlSetLimit(-1, 150, 0);
GUICtrlSetData(-1, 150);
$iLastSlider=150;

$alwaysTop = GUICtrlCreateCheckbox("", 312, 13, 13, 13);
If $aOT=True Then
    GUICtrlSetState(-1, $GUI_CHECKED);
EndIf
$lb2 = GUICtrlCreateLabel("Always on top", 336, 13, 70, 17);
GUICtrlSetColor(-1, 0xFFFFFF);
GUICtrlSetBkColor(-1, $GUI_BKCOLOR_TRANSPARENT);

_WinAPI_SetLayeredWindowAttributes($butGui, 0xABCDEF, 255)

GUISetState()



GUISetState()
$i = 0

While 1
$i = $i + 1
If $i = 255 Then $i = 0
    $msg = GUIGetMsg()
    $advMsg = GUIGetMsg(1)
    Select
        Case $msg = $GUI_EVENT_CLOSE
            ExitLoop

    EndSelect

WEnd


_GDIPlus_Shutdown()

Func WM_NCHITTEST($hWnd, $iMsg, $iwParam, $ilParam)
    If ($hwnd = WinGetHandle("Look at the shiny")) And ($iMsg = $WM_NCHITTEST) Then
    Return $HTCAPTION
    EndIf
EndFunc

Func _GUICreate_Alpha($sTitle, $sPath, $iX=-1, $iY=-1, $iOpacity=255)
    Local $hGUI, $hImage, $hScrDC, $hMemDC, $hBitmap, $hOld, $pSize, $tSize, $pSource, $tSource, $pBlend, $tBlend
    $hImage = _GDIPlus_ImageLoadFromFile($sPath)
    $width = _GDIPlus_ImageGetWidth($hImage)
    $height = _GDIPlus_ImageGetHeight($hImage)
    $hGUI = GUICreate($sTitle, $width, $height, $iX, $iY, $WS_POPUP, $WS_EX_LAYERED)

    $hScrDC = _WinAPI_GetDC(0)
    $hMemDC = _WinAPI_CreateCompatibleDC($hScrDC)
    $hBitmap = _GDIPlus_BitmapCreateHBITMAPFromBitmap($hImage)
    $hOld = _WinAPI_SelectObject($hMemDC, $hBitmap)
    $tSize = DllStructCreate($tagSIZE)
    $pSize = DllStructGetPtr($tSize)
    DllStructSetData($tSize, "X", $width)
    DllStructSetData($tSize, "Y", $height)
    $tSource = DllStructCreate($tagPOINT)
    $pSource = DllStructGetPtr($tSource)
    $tBlend = DllStructCreate($tagBLENDFUNCTION)
    $pBlend = DllStructGetPtr($tBlend)
    DllStructSetData($tBlend, "Alpha", $iOpacity)
    DllStructSetData($tBlend, "Format", 1)
    _WinAPI_UpdateLayeredWindow($hGUI, $hScrDC, 0, $pSize, $hMemDC, $pSource, 0, $pBlend, 2)
    _WinAPI_ReleaseDC(0, $hScrDC)
    _WinAPI_SelectObject($hMemDC, $hOld)
    _WinAPI_DeleteObject($hBitmap)
    _WinAPI_DeleteObject($hImage)
    _WinAPI_DeleteDC($hMemDC)
EndFunc ;==>_GUICreate_Alpha

Func SetBitmap($hGUI, $hImage, $iOpacity)
    Local $hScrDC, $hMemDC, $hBitmap, $hOld, $pSize, $tSize, $pSource, $tSource, $pBlend, $tBlend
    $hScrDC = _WinAPI_GetDC(0)
    $hMemDC = _WinAPI_CreateCompatibleDC($hScrDC)
    $hBitmap = _GDIPlus_BitmapCreateHBITMAPFromBitmap($hImage)
    $hOld = _WinAPI_SelectObject($hMemDC, $hBitmap)
    $tSize = DllStructCreate($tagSIZE)
    $pSize = DllStructGetPtr($tSize)
    DllStructSetData($tSize, "X", _GDIPlus_ImageGetWidth($hImage))
    DllStructSetData($tSize, "Y", _GDIPlus_ImageGetHeight($hImage))
    $tSource = DllStructCreate($tagPOINT)
    $pSource = DllStructGetPtr($tSource)
    $tBlend = DllStructCreate($tagBLENDFUNCTION)
    $pBlend = DllStructGetPtr($tBlend)
    DllStructSetData($tBlend, "Alpha", $iOpacity)
    DllStructSetData($tBlend, "Format", $AC_SRC_ALPHA)
    _WinAPI_UpdateLayeredWindow($hGUI, $hScrDC, 0, $pSize, $hMemDC, $pSource, 0, $pBlend, $ULW_ALPHA)
    _WinAPI_ReleaseDC(0, $hScrDC)
    _WinAPI_SelectObject($hMemDC, $hOld)
    _WinAPI_DeleteObject($hBitmap)
    _WinAPI_DeleteDC($hMemDC)
EndFunc   ;==>SetBitmap

Share this post


Link to post
Share on other sites

Hi.

Yeah it can be tough merging different scripts together. Here is the solution...I hope. Your attached picture is way to small though

....

Thanks for your help Picea, combination of different scripts make something impossible (i think), you script make the background black, not transparent :graduated:. I think I should try the other way instead of slider, updown control for instance.

I'm still expecting for help :(,and thank you again.

PS: About the attached pictures, I thought you would download it for easier test :D


http://www.facebook.com/xx3004?sk=info

Share this post


Link to post
Share on other sites

#9 ·  Posted (edited)

#Include <Constants.au3>
#Include <GUIConstantsEx.au3>
#Include <SliderConstants.au3>
#Include <StaticConstants.au3>
#Include <WinAPI.au3>
#Include <WindowsConstants.au3>

Global Const $tagNMCUSTOMDRAW = 'hwnd hWndFrom;uint_ptr IDFrom;int Code;dword DrawStage;hwnd hDC;' & $tagRECT & ';dword_ptr ItemSpec;uint ItemState;lparam ItemlParam'
Global Const $STM_GETIMAGE = 0x0173

Global $hTemp = 0

GUICreate('MyGUI', 413, 161)
GUICtrlCreatePic(@ScriptDir & '\bg.jpg', 0, 0, 413, 161)
GUICtrlSetState(-1, $GUI_DISABLE)
$hPic = GUICtrlGetHandle(-1)
GUICtrlCreateSlider(200, 100, 200, 23, $TBS_NOTICKS)
$hSlider = GUICtrlGetHandle(-1)
GUIRegisterMsg($WM_NOTIFY, 'WM_NOTIFY')
GUISetState()

Do
Until GUIGetMsg() = $GUI_EVENT_CLOSE

Func WM_NOTIFY($hWnd, $iMsg, $wParam, $lParam)

    Local $tNMCD = DllStructCreate($tagNMCUSTOMDRAW, $lParam)
    Local $hWndFrom = DllStructGetData($tNMCD, 'hWndFrom')
    Local $Code = DllStructGetData($tNMCD, 'Code')
    Local $DrawStage = DllStructGetData($tNMCD, 'DrawStage')
    Local $ItemSpec = DllStructGetData($tNMCD, 'ItemSpec')
    Local $hDC = DllStructGetData($tNMCD, 'hDC')
    Local $hMemDC, $hBitmap, $hPrev
    Local $aPos

    Switch $hWndFrom
        Case $hSlider
            Switch $Code
                Case $NM_CUSTOMDRAW
                    Switch $DrawStage
                        Case $CDDS_PREPAINT, $CDDS_POSTPAINT
                            $aPos = ControlGetPos($hSlider, '', '')
                            Switch $DrawStage
                                Case $CDDS_PREPAINT
                                    $hMemDC = _WinAPI_CreateCompatibleDC($hDC)
                                    $hBitmap = _SendMessage($hPic, $STM_GETIMAGE, $IMAGE_BITMAP, 0)
                                    $hPrev = _WinAPI_SelectObject($hMemDC, $hBitmap)
                                    _WinAPI_BitBlt($hDC, 0, 0, $aPos[2], $aPos[3], $hMemDC, $aPos[0], $aPos[1], $SRCCOPY)
                                    _WinAPI_SelectObject($hMemDC, $hPrev)
                                    _WinAPI_DeleteDC($hMemDC)
                                    Return BitOR($CDRF_NOTIFYITEMDRAW, $CDRF_NOTIFYPOSTPAINT)
                                Case $CDDS_POSTPAINT
                                    $hMemDC = _WinAPI_CreateCompatibleDC($hDC)
                                    If Not $hTemp Then
                                        $hTemp = _WinAPI_CreateCompatibleBitmap($hDC, $aPos[2], $aPos[3])
                                        $hPrev = _WinAPI_SelectObject($hMemDC, $hTemp)
                                        _WinAPI_BitBlt($hMemDC, 0, 0, $aPos[2], $aPos[3], $hDC, 0, 0, $MERGECOPY)
                                    Else
                                        $hMemDC = _WinAPI_CreateCompatibleDC($hDC)
                                        $hPrev = _WinAPI_SelectObject($hMemDC, $hTemp)
                                        _WinAPI_BitBlt($hDC, 0, 0, $aPos[2], $aPos[3], $hMemDC, 0, 0, $SRCCOPY)
                                    EndIf
                                    _WinAPI_SelectObject($hMemDC, $hPrev)
                                    _WinAPI_DeleteDC($hMemDC)
                                    Return $CDRF_DODEFAULT
                            EndSwitch
                        Case $CDDS_ITEMPREPAINT
                            If $hTemp Then
                                _WinAPI_DeleteObject($hTemp)
                                $hTemp = 0
                            EndIf
                            Switch $ItemSpec
                                Case $TBCD_TICS
                                    Return $CDRF_SKIPDEFAULT
                                Case $TBCD_THUMB, $TBCD_CHANNEL
                                    Return $CDRF_DODEFAULT
                            EndSwitch
                    EndSwitch
            EndSwitch
    EndSwitch
    Return $GUI_RUNDEFMSG
EndFunc   ;==>WM_NOTIFY

Posted Image

Edited by Yashied

Share this post


Link to post
Share on other sites

Thank you Yashied it works perfectly!


http://www.facebook.com/xx3004?sk=info

Share this post


Link to post
Share on other sites

Greetings Yashied  :graduated:

you can eliminate the focus rectangle on the slider

with this line after CDS_PREPAINT

DllStructSetData($tNMCD, 'ItemState', BitXOR(DllStructGetData($tNMCD, 'ItemState'), $CDIS_FOCUS))

this never worked for buttons so I disregarded it until I looked at the great example you posted above

I never tried it for sliders before

Case $CDDS_PREPAINT
                                    $hMemDC = _WinAPI_CreateCompatibleDC($hDC)
                                    $hBitmap = _SendMessage($hPic, $STM_GETIMAGE, $IMAGE_BITMAP, 0)
                                    $hPrev = _WinAPI_SelectObject($hMemDC, $hBitmap)
                                    _WinAPI_BitBlt($hDC, 0, 0, $aPos[2], $aPos[3], $hMemDC, $aPos[0], $aPos[1], $SRCCOPY)
                                    _WinAPI_SelectObject($hMemDC, $hPrev)
                                    _WinAPI_DeleteDC($hMemDC)
                                    DllStructSetData($tNMCD, 'ItemState', BitXOR(DllStructGetData($tNMCD, 'ItemState'), $CDIS_FOCUS))
                                    Return BitOR($CDRF_NOTIFYITEMDRAW, $CDRF_NOTIFYPOSTPAINT)

I see fascists...

Share this post


Link to post
Share on other sites

Create an account or sign in to comment

You need to be a member in order to leave a comment

Create an account

Sign up for a new account in our community. It's easy!


Register a new account

Sign in

Already have an account? Sign in here.


Sign In Now
Sign in to follow this
Followers 0
