How to set network state private or public using AutoIt ?

Recommended Posts

Hi to all, I was wondering how to do something like this powershell command:

Get-NetConnectionProfile -InterfaceAlias "Ethernet" | Set-NetConnectionProfile -NetworkCategory Private -Confirm:$false -PassThru

natively, or bypassing powershell, in AutoIt.

My goal is to change the state of the current network connection from public to private and viceversa.

And looking beyond, to enable/disable network discovery, network crypt properties, sharing options etc....


Edited by t0nZ
Link to post
Share on other sites

You could set the registry values directly at

HKEY_LOCAL_MACHINE\SOFTWARE\Microsoft\Windows NT\CurrentVersion\NetworkList\Profiles\<guid>

Category will be a DWORD with one of the following values:

0 for Public network

1 for Private network

2 for Domain network

Link to post
Share on other sites

Thank you @rsn.

I am exploring also the registry way, it's seems interesting, and maybe easier.

My final goal is to have a solution to execute a script on a "random" machine and have:

  1. current connected network to private
  2. allow sharing without password
  3. set up a folder shared to everyone R/W
  4. transfer some data
  5. revert all this.

I have already solutions for points 3 and 4.. working on 1 and 2.

Returning to powershell way, I come up with this :

Func _Set_Network_Private() ;
    ShellExecuteWait("powershell.exe", "start-process -verb runas 'powershell.exe' " & _
            "-argumentlist @('-executionpolicy unrestricted',' -command Get-NetConnectionProfile -InterfaceAlias Ethernet | Set-NetConnectionProfile -NetworkCategory Private -Confirm:$false -PassThru')", '', '', @SW_SHOW)

This can be run inside a non admin script, and it asks for elevation. Moreover, if you want to set private/public the current active connection, you can change this

-InterfaceAlias Ethernet

with this:

-IPv4Connectivity Internet

...quick and dirty.... keeping in mind this command output in powershell :


PS C:\Windows\system32> powershell.exe -executionpolicy unrestricted -command 'Get-NetConnectionProfile -IPv4Connectivity Internet| Set-NetConnectionProfile -NetworkCategory Private -Confirm:$false -PassThru'

Name             : guest
InterfaceAlias   : Wi-Fi
InterfaceIndex   : 6
NetworkCategory  : Private
IPv4Connectivity : Internet
IPv6Connectivity : NoTraffic


Link to post
Share on other sites

If you're an admin on the remote PC, you don't have to set up sharing. The admin share will be accessible by either IP or hostname:

\\<hostname>\c$\path\to\whatever or \\<IPAddress>\c$\path\to\whatever

If you aren't an admin, you probably shouldn't be doing  this kind of stuff... :think:

Link to post
Share on other sites

If you aren't an admin, you probably shouldn't be doing  this kind of stuff... :think:

@rsn I am improving 2 existing scripts of mine capable of moving data between two PCs, and these scripts are working one on the source and one on the destination, and they use a shared folder to pass files.

In my typical scenario, I have to move data between heterogeneous machines (one in domain one not, or different domains, or no domain at all, user already admin or not, or admin disabled) so c$ it's not an option, and for years I went through shared folders...

But 🤔 ... I should  create two identical hidden admin users on both machines, to work like you suggest...

Link to post
Share on other sites

Here is a way to do it without using any external command (just use COM objects)

#RequireAdmin ; Needed

_NetSetCategory("LAN", 1) ; Sets the Private category to the network connection called "LAN"

; #FUNCTION# ====================================================================================================================
; Name...........: _NetSetCategory
; Description....: Sets the category of a network. Changes made take effect immediately
; Syntax.........: _NetSetCategory($sNetworkId, $iNetCategory)
; Parameters.....: $sNetworkId     - Name of the network connection
;                  $iNetCategory   - New category of the network. Can be one of :
;                   0 : Public
;                   1 : Private
;                   2 : Domain
; Return values..: Success  - 1
;                  Failure  - 0 and sets the @error flag to non-zero
; Remarks........: The function requires administrator privileges
; ===============================================================================================================================
Func _NetSetCategory($sNetworkId, $iNetCategory)
    Local $iRet = 1, $iNetFound = 0, $oNetwork, $oNetConnection
    If Not IsAdmin() Then Return SetError(4, 0, 0)
    If Not IsInt($iNetCategory) Or $iNetCategory < 0 Or $iNetCategory > 2 Then Return SetError(5, 0, 0)
    Local $INetListManager = ObjCreate("{DCB00C01-570F-4A9B-8D69-199FDBA5723B}")
    If Not IsObj($INetListManager) Then Return SetError($iRet, 0, 0)
    Local $oNetConnections = $INetListManager.GetNetworkConnections()
    If IsObj($oNetConnections) Then
        For $oNetConnection In $oNetConnections
            $oNetwork = $oNetConnection.GetNetwork
            If $oNetwork.GetName = $sNetworkId Then
                $iNetFound = 1
                $iRet = (@error ? 2 : 0)
        If Not $iNetFound Then $iRet = 3
    $INetListManager = 0
    If $iRet Then Return SetError($iRet, 0, 0)
    Return 1
EndFunc ; ===> _NetSetCategory

Inspired from @Danyfirex code (thanks)

Link to post
Share on other sites



As you write, that you have a mixture of stand alone PCs and Domain PCs I'd like to mention, that there is another registry value that can be a bad constraint:


Windows Registry Editor Version 5.00


If the destination computer providing the share has this value set to 5, and a computer from a different domain or a stand alone PC is set to 0, 1 or 2 trying to use this share, then this will only work, if specifying a AD-user account with access rights from the domain, the sharing computer is a member of.

Using a local user account of the PC/Win-Server presenting the share will not work. The error message will give you an "invalid username or password" error. Any AD account will work smoothly (but that was not possible for my scenario)



Seting both sides to "2" solves this issue immediately, a reboot is not required.


If this should switch back to 5 check for the GPO pushing the value and exclude the sharing server from receiving that particular GPO.


Regards, Rudi.
