spudw2k

Retrieve SysListView32 Contents

8 posts in this topic

#1 ·  Posted (edited)

I couldn't find such a function (could be I'm not looking in the right place), but I thought this was useful.

#include <GUIListView.au3>
#include <Array.au3>   ;For demo purposes only

$hWnd = ControlGetHandle("My Computer","","SysListView321")
$arr = _GUICtrlListView_GetContents($hWnd)
_ArrayDisplay($arr)

;===============================================================================
;
; Function Name:   _GUICtrlListView_GetContents
; Description::    Captures Contents of a SysListView32 Contrl Into an Array
; Parameter(s):    $hWnd - Handle to the control
; Requirement(s):  #include <GUIListView.au3>
; Return Value(s): Success - Array with ListView Contents
;                  Failure - 0
; Author(s):       Paul Wilson (spudw2k)
;
;===============================================================================
Func _GUICtrlListView_GetContents($hWnd)
    $iCol = _GUICtrlListView_GetColumnCount($hWnd)
    If $iCol = 0 Then Return 0
    Dim $arrListView[1][$iCol]
    For $i = 0 to $iCol-1
        Local $Col=_GUICtrlListView_GetColumn($hWnd,$i)
        $arrListView[0][$i]=$Col[5]
    Next
    $Col = 0
    $iRows = _GUICtrlListView_GetItemCount($hWnd)
    For $i = 0 to $iRows-1
        Redim $arrListView[UBound($arrListView)+1][$iCol]
        $arrListView[UBound($arrListView)-1][0]=_GUICtrlListView_GetItemText($hWnd,$i)
        For $j = 1 To $iCol-1
            $arrListView[UBound($arrListView)-1][$j]=_GUICtrlListView_GetItemText($hWnd,$i,$j)
        Next
    Next
    Return $arrListView
EndFunc   ;==>_GUICtrlListView_GetContents
Edited by spudw2k
1 person likes this

Share this post


Link to post
Share on other sites



Very nice!! I like it.


Programming today is a race between software engineers striving to
build bigger and better idiot-proof programs, and the Universe
trying to produce bigger and better idiots.
So far, the Universe is winning.

Share this post


Link to post
Share on other sites

There is a one problem

if I try to

Retrieve SysListView32 Contents from ListView with 1000 elements

then

I Retrive only that part which is visible on the screen at the moment, all others are not retrived


Signature beginning:   Wondering who uses AutoIT and what it can be used for ?
* GHAPI UDF - modest begining - comunication with GitHub REST API *
ADO.au3 UDF     POP3.au3 UDF     XML.au3 UDF    How to use IE.au3  UDF with  AutoIt v3.3.14.x  for other useful stuff click the following button

Spoiler

Any of my own code posted anywhere on the forum is available for use by others without any restriction of any kind.

My contribution (my own projects): * Debenu Quick PDF Library - UDF * Debenu PDF Viewer SDK - UDF * Acrobat Reader - ActiveX Viewer * UDF for PDFCreator v1.x.x * XZip - UDF * AppCompatFlags UDF * CrowdinAPI UDF * _WinMergeCompare2Files() * _JavaExceptionAdd() * _IsBeta() * Writing DPI Awareness App - workaround * _AutoIt_RequiredVersion() * Chilkatsoft.au3 UDF * TeamViewer.au3 UDF * JavaManagement UDF * VIES over SOAP * WinSCP UDF * GHAPI UDF - modest begining - comunication with GitHub REST API *

My contribution to others projects or UDF based on  others projects: * _sql.au3 UDF  * POP3.au3 UDF *  RTF Printer - UDF * XML.au3 - BETA * ADO.au3 UDF SMTP Mailer UDF *

Useful links: * Forum Rules * Forum etiquette *  Forum Information and FAQs * How to post code on the forum * AutoIt Online Documentation * AutoIt Online Beta Documentation * SciTE4AutoIt3 getting started * Convert text blocks to AutoIt code * Games made in Autoit * Programming related sites * Polish AutoIt Tutorial * DllCall Code Generator *

Wiki: Expand your knowledge - AutoIt Wiki * Collection of User Defined Functions * How to use HelpFile * Best coding practices *

IE Related:  * How to use IE.au3  UDF with  AutoIt v3.3.14.x * Why isn't Autoit able to click a Javascript Dialog? * Clicking javascript button with no ID * IE document >> save as MHT file * IETab Switcher (by LarsJ ) * HTML Entities * _IEquerySelectorAll() (by uncommon) *

I encourage you to read: * Global Vars * Best Coding Practices * Please explain code used in Help file for several File functions * OOP-like approach in AutoIt * UDF-Spec Questions *  EXAMPLE: How To Catch ConsoleWrite() output to a file or to CMD *

"Homo sum; humani nil a me alienum puto" - Publius Terentius Afer
"Program are meant to be read by humans and only incidentally for computers and execute" - Donald Knuth, "The Art of Computer Programming"
:naughty:  :ranting:, be  :) and       \\//_.

Anticipating Errors :  "Any program that accepts data from a user must include code to validate that data before sending it to the data store. You cannot rely on the data store, ...., or even your programming language to notify you of problems. You must check every byte entered by your users, making sure that data is the correct type for its field and that required fields are not empty."

Signature last update: 2017-06-04

Share this post


Link to post
Share on other sites

That might be a side effect/limitation of the ArrayDisplay func. Just a guess, I'll test it later. Interesting observation.

Share this post


Link to post
Share on other sites

I check it problem again now on some different machine

hmm..... now I can't repeat that situation.

but now I try on different system, programs..... even AUTOIT version

I think

check this problem again on this same machine ..... environment

but this need time .. to next visit my client

I think it is posible situation in which I change something in program on which was source ListView


Signature beginning:   Wondering who uses AutoIT and what it can be used for ?
* GHAPI UDF - modest begining - comunication with GitHub REST API *
ADO.au3 UDF     POP3.au3 UDF     XML.au3 UDF    How to use IE.au3  UDF with  AutoIt v3.3.14.x  for other useful stuff click the following button

Spoiler

Any of my own code posted anywhere on the forum is available for use by others without any restriction of any kind.

My contribution (my own projects): * Debenu Quick PDF Library - UDF * Debenu PDF Viewer SDK - UDF * Acrobat Reader - ActiveX Viewer * UDF for PDFCreator v1.x.x * XZip - UDF * AppCompatFlags UDF * CrowdinAPI UDF * _WinMergeCompare2Files() * _JavaExceptionAdd() * _IsBeta() * Writing DPI Awareness App - workaround * _AutoIt_RequiredVersion() * Chilkatsoft.au3 UDF * TeamViewer.au3 UDF * JavaManagement UDF * VIES over SOAP * WinSCP UDF * GHAPI UDF - modest begining - comunication with GitHub REST API *

My contribution to others projects or UDF based on  others projects: * _sql.au3 UDF  * POP3.au3 UDF *  RTF Printer - UDF * XML.au3 - BETA * ADO.au3 UDF SMTP Mailer UDF *

Useful links: * Forum Rules * Forum etiquette *  Forum Information and FAQs * How to post code on the forum * AutoIt Online Documentation * AutoIt Online Beta Documentation * SciTE4AutoIt3 getting started * Convert text blocks to AutoIt code * Games made in Autoit * Programming related sites * Polish AutoIt Tutorial * DllCall Code Generator *

Wiki: Expand your knowledge - AutoIt Wiki * Collection of User Defined Functions * How to use HelpFile * Best coding practices *

IE Related:  * How to use IE.au3  UDF with  AutoIt v3.3.14.x * Why isn't Autoit able to click a Javascript Dialog? * Clicking javascript button with no ID * IE document >> save as MHT file * IETab Switcher (by LarsJ ) * HTML Entities * _IEquerySelectorAll() (by uncommon) *

I encourage you to read: * Global Vars * Best Coding Practices * Please explain code used in Help file for several File functions * OOP-like approach in AutoIt * UDF-Spec Questions *  EXAMPLE: How To Catch ConsoleWrite() output to a file or to CMD *

"Homo sum; humani nil a me alienum puto" - Publius Terentius Afer
"Program are meant to be read by humans and only incidentally for computers and execute" - Donald Knuth, "The Art of Computer Programming"
:naughty:  :ranting:, be  :) and       \\//_.

Anticipating Errors :  "Any program that accepts data from a user must include code to validate that data before sending it to the data store. You cannot rely on the data store, ...., or even your programming language to notify you of problems. You must check every byte entered by your users, making sure that data is the correct type for its field and that required fields are not empty."

Signature last update: 2017-06-04

Share this post


Link to post
Share on other sites

#6 ·  Posted (edited)

I modify your Function and create another usefull functions

Func _GUICtrlListView_GetSelectedContents($hWnd)
    $iCol = _GUICtrlListView_GetColumnCount($hWnd)
    If $iCol = 0 Then Return 0
    Dim $arrListView[1][$iCol]
    For $i = 0 To $iCol - 1
        Local $Col = _GUICtrlListView_GetColumn($hWnd, $i)
        $arrListView[0][$i] = $Col[5]
    Next
    $Col = 0
    $iRows = _GUICtrlListView_GetSelectedIndices($hWnd)
    $arr_iRows = StringSplit($iRows, "|")
    For $i = 1 To $arr_iRows[0]
        ReDim $arrListView[UBound($arrListView) + 1][$iCol]
        $arrListView[UBound($arrListView) - 1][0] = _GUICtrlListView_GetItemText($hWnd, $arr_iRows[$i])
        For $j = 1 To $iCol - 1
            $arrListView[UBound($arrListView) - 1][$j] = _GUICtrlListView_GetItemText($hWnd, $arr_iRows[$i], $j)
        Next
    Next
    Return $arrListView
EndFunc   ;==>_GUICtrlListView_GetSelectedContents
Func _GUICtrlListView_GetSelectedContentsFromSomeColumns($hWnd, $sColumnToCheck = "")
    Local $var_to_return = "null"
    $arrToCheck = _GUICtrlListView_GetSelectedContents($hWnd)
    $rows = UBound($arrToCheck)
    $cols = UBound($arrToCheck, 2)
    $aColumnToCheck = StringSplit($sColumnToCheck, "|")
    For $x = 1 To $aColumnToCheck[0]
        For $y = 0 To $cols - 1
            If $aColumnToCheck[$x] = $arrToCheck[0][$y] Then
                If $var_to_return = "null" Then
                    $var_to_return = String($y)
                Else
                    $var_to_return &= "|" & String($y)
                EndIf
            EndIf
        Next
    Next
    If $var_to_return = "" Then
        Return 1 ;do not found anything
    Else
        $aFoundColumns = StringSplit($var_to_return, "|")
        Dim $aToReturn[$rows][$aFoundColumns[0]]
        For $a = 1 To $aFoundColumns[0]
            For $b = 0 To $rows - 1
                $aToReturn[$b][$a - 1] = $arrToCheck[$b][$aFoundColumns[$a]]
            Next
        Next
        Return $aToReturn
    EndIf
EndFunc   ;==>_GUICtrlListView_GetSelectedContentsFromSomeColumns

usage:

_GUICtrlListView_GetSelectedContentsFromSomeColumns($hWnd, "ColName3|ColName1|ColName5")

Returned array has a new column order

first is ColName3 next ColName1 and Last ColName5

Edited by mlipok

Signature beginning:   Wondering who uses AutoIT and what it can be used for ?
* GHAPI UDF - modest begining - comunication with GitHub REST API *
ADO.au3 UDF     POP3.au3 UDF     XML.au3 UDF    How to use IE.au3  UDF with  AutoIt v3.3.14.x  for other useful stuff click the following button

Spoiler

Any of my own code posted anywhere on the forum is available for use by others without any restriction of any kind.

My contribution (my own projects): * Debenu Quick PDF Library - UDF * Debenu PDF Viewer SDK - UDF * Acrobat Reader - ActiveX Viewer * UDF for PDFCreator v1.x.x * XZip - UDF * AppCompatFlags UDF * CrowdinAPI UDF * _WinMergeCompare2Files() * _JavaExceptionAdd() * _IsBeta() * Writing DPI Awareness App - workaround * _AutoIt_RequiredVersion() * Chilkatsoft.au3 UDF * TeamViewer.au3 UDF * JavaManagement UDF * VIES over SOAP * WinSCP UDF * GHAPI UDF - modest begining - comunication with GitHub REST API *

My contribution to others projects or UDF based on  others projects: * _sql.au3 UDF  * POP3.au3 UDF *  RTF Printer - UDF * XML.au3 - BETA * ADO.au3 UDF SMTP Mailer UDF *

Useful links: * Forum Rules * Forum etiquette *  Forum Information and FAQs * How to post code on the forum * AutoIt Online Documentation * AutoIt Online Beta Documentation * SciTE4AutoIt3 getting started * Convert text blocks to AutoIt code * Games made in Autoit * Programming related sites * Polish AutoIt Tutorial * DllCall Code Generator *

Wiki: Expand your knowledge - AutoIt Wiki * Collection of User Defined Functions * How to use HelpFile * Best coding practices *

IE Related:  * How to use IE.au3  UDF with  AutoIt v3.3.14.x * Why isn't Autoit able to click a Javascript Dialog? * Clicking javascript button with no ID * IE document >> save as MHT file * IETab Switcher (by LarsJ ) * HTML Entities * _IEquerySelectorAll() (by uncommon) *

I encourage you to read: * Global Vars * Best Coding Practices * Please explain code used in Help file for several File functions * OOP-like approach in AutoIt * UDF-Spec Questions *  EXAMPLE: How To Catch ConsoleWrite() output to a file or to CMD *

"Homo sum; humani nil a me alienum puto" - Publius Terentius Afer
"Program are meant to be read by humans and only incidentally for computers and execute" - Donald Knuth, "The Art of Computer Programming"
:naughty:  :ranting:, be  :) and       \\//_.

Anticipating Errors :  "Any program that accepts data from a user must include code to validate that data before sending it to the data store. You cannot rely on the data store, ...., or even your programming language to notify you of problems. You must check every byte entered by your users, making sure that data is the correct type for its field and that required fields are not empty."

Signature last update: 2017-06-04

Share this post


Link to post
Share on other sites

I a discover another problem

In Scite

when I GO SCRIPT then no one items are retrived

but

when I COMPILE SCRIPT then all works fine

It's possible I have wrong version or config.

Can anybody help me ?


Signature beginning:   Wondering who uses AutoIT and what it can be used for ?
* GHAPI UDF - modest begining - comunication with GitHub REST API *
ADO.au3 UDF     POP3.au3 UDF     XML.au3 UDF    How to use IE.au3  UDF with  AutoIt v3.3.14.x  for other useful stuff click the following button

Spoiler

Any of my own code posted anywhere on the forum is available for use by others without any restriction of any kind.

My contribution (my own projects): * Debenu Quick PDF Library - UDF * Debenu PDF Viewer SDK - UDF * Acrobat Reader - ActiveX Viewer * UDF for PDFCreator v1.x.x * XZip - UDF * AppCompatFlags UDF * CrowdinAPI UDF * _WinMergeCompare2Files() * _JavaExceptionAdd() * _IsBeta() * Writing DPI Awareness App - workaround * _AutoIt_RequiredVersion() * Chilkatsoft.au3 UDF * TeamViewer.au3 UDF * JavaManagement UDF * VIES over SOAP * WinSCP UDF * GHAPI UDF - modest begining - comunication with GitHub REST API *

My contribution to others projects or UDF based on  others projects: * _sql.au3 UDF  * POP3.au3 UDF *  RTF Printer - UDF * XML.au3 - BETA * ADO.au3 UDF SMTP Mailer UDF *

Useful links: * Forum Rules * Forum etiquette *  Forum Information and FAQs * How to post code on the forum * AutoIt Online Documentation * AutoIt Online Beta Documentation * SciTE4AutoIt3 getting started * Convert text blocks to AutoIt code * Games made in Autoit * Programming related sites * Polish AutoIt Tutorial * DllCall Code Generator *

Wiki: Expand your knowledge - AutoIt Wiki * Collection of User Defined Functions * How to use HelpFile * Best coding practices *

IE Related:  * How to use IE.au3  UDF with  AutoIt v3.3.14.x * Why isn't Autoit able to click a Javascript Dialog? * Clicking javascript button with no ID * IE document >> save as MHT file * IETab Switcher (by LarsJ ) * HTML Entities * _IEquerySelectorAll() (by uncommon) *

I encourage you to read: * Global Vars * Best Coding Practices * Please explain code used in Help file for several File functions * OOP-like approach in AutoIt * UDF-Spec Questions *  EXAMPLE: How To Catch ConsoleWrite() output to a file or to CMD *

"Homo sum; humani nil a me alienum puto" - Publius Terentius Afer
"Program are meant to be read by humans and only incidentally for computers and execute" - Donald Knuth, "The Art of Computer Programming"
:naughty:  :ranting:, be  :) and       \\//_.

Anticipating Errors :  "Any program that accepts data from a user must include code to validate that data before sending it to the data store. You cannot rely on the data store, ...., or even your programming language to notify you of problems. You must check every byte entered by your users, making sure that data is the correct type for its field and that required fields are not empty."

Signature last update: 2017-06-04

Share this post


Link to post
Share on other sites

From the help-file for ControlListView():

"Some commands may fail when using a 32-bit AutoIt process to read from a 64-bit process. Likewise commands may fail when using a 64-bit AutoIt process to read from a 32-bit process."

So accessing ListViews (and TreeViews too) the scripts needs to run / be compiled for the right @OSArch. See ICU in my signature how melba23 and I enforced the usage of the right architecture there.

Share this post
